English
Supplied Accessories:
1 x headphones HE250
1 x remote control, AY3802
1 x AA battery door
1 x AC/DC adapter, AY3162 (for some versions only)
1 x charge cradle, AY4105 (for some versions only)
2 x rechargeable batteries AY3363 (for some
1
Controls ( see figure
)
1 4.5V DC ............... jack for AC/DC adapter power supply
2 ESP ..................... selects between the battery powersave mode and
Electronic Skip Protection (ESP). ESP prevents playback
interruptions caused by shocks.
3 DBB .................... switches the bass enhancement on/off. When pressed for
more than 2 seconds, the button switches audible
feedback (beep) on/off.
+
-
4 VOLUME
,
...... adjusts the volume
5 ............................. typeplate
6 Docking jack.....
connects to the docking pins on your AY4105 charge
cradle
(for some versions only)
7 9.......................... stops playback/ clears programmed tracks
/ switches off the set.
8 SEARCH ∞ / §...skips and searches backward/ forward tracks.
9 ALBUM +/ -..........MP3/WMA- CD only: selects the next/previous
album or skips forward/backward tracks.
0 2;........................ switches the player on, starts or pauses CD playback.
! ç........................ opens the CD lid
@ OFF .......................switches RESUME and HOLD off (on the set only)
RESUME .............saves the last position played
HOLD ...................locks all buttons (on the set only)
# p ......................... connect the remote control here and your headphones to
the remote control
$ ............................. battery door
REMOTE CONTROL AY3802 / HEADPHONE HE 250
Using the remote control
The remote control allows you to command all the
functions on the player.
1
Firmly connect the remote control to
LINE OUT p on the set.
2
Firmly connect the headphones to the jack p
on the remote control.
On the remote control, press 2; to start playback.
3
4
Adjust the volume and sound on your remote control.
To stop playback, press 9.
5
To switch off the CD player, press 9 again.
6
Headphones HE250, LINE OUT
• Connect the remote control to LINE OUT p jack of
the player and your headphones to the remote control.
• p can also be used for connecting the player to your
HiFi system.
IMPORTANT!
Hearing safety: listen at a moderate volume. using head-
phones at high volume can impair your hearing.
Traffic safety: do not use headphones while driving or cycling as you may cause an
accident.
This set complies with the radio interference requirements of the
European Union.
CONTROLS
Remote control AY3802 ( see figure
1 p ........................3.5 mm headphone jack
2 VOL
3 MODE ................selects playback options. To select and enter the display
4 PROG .................programs tracks and reviews the program
versions
only)
5 DBB ...................switches the bass enhancement on and off. When pressed
6 ESP ............. ......selects between the battery powersave mode and
7 .. .........................clip
8 2; ......................switches the player on, starts or pauses CD playback.
9 OFF ....................switches HOLD off (on the remote control only)
0 ALBUM
! SEARCH ∞ / §..skips and searches backward/ forward tracks
@ ...........................display
Charge cradle
1 Docking pins ..... connects to the docking jacks on your CDplayer
2
3 4.5V DC ..................
• Do not touch the lens A of the CD player.
• Do not expose the unit, batteries or CDs to humidity,
• You can clean the CD player with a soft, slightly
• To clean the CD, wipe it in a straight line from the center toward the edge
• The lens may cloud over when the unit is moved suddenly from cold to warm
• Active mobile phones in the vicinity of the CD player may cause malfunctions.
• Avoid dropping the unit as this may cause damage.
CONTROLS
2
+
-
/
............adjusts the volume
function, press and hold MODE for 3 seconds.
for more than 2 seconds, the button switches audible
feedback (beep) on/off.
Electronic Skip Protection (ESP). ESP prevents playback
interruptions caused by shocks.
9 ........................stops CD playback, clears a program or
switches the player off.
HOLD ................locks all buttons (on the remote control only)
+
-
/
.....MP3/WMA-CD only: selects the previous or next album
3
AY4105 ( see figure
, for some versions only)
Charging indicator
.....
lights up red/green for charging on/standby
jack for AC/DC adapter power supply
CD PLAYER AND CD HANDLING
rain, sand or excessive heat (caused by heating
equipment or direct sunlight).
dampened, lint-free cloth. Do not use any cleaning agents as they may have a
corrosive effect.
using a soft, lint-free cloth. A cleaning agent may damage the disc! Never
write on a CD or attach a sticker to it.
surroundings. Playing a CD is not possible then. Leave the CD player in a
warm environment until the moisture has evaporated.
CAUTION
Use of controls or adjustments or performance of procedures
other than herein may result in hazardous radiation exposure
or other unsafe operation.
)
