Philips AZ3020 User Manual

CD Soundmachine
Audio
Audio
AZ3020 AZ3021 AZ3022
• •
Need help? Call us!
Return
Philips representatives are ready to help you with
your Warranty
any questions about your new product. We can guide you
Registration Card
through Connections, First-time Setup, or any of the Features. within 10 days
We want you to start enjoying your new product right away!
CALL US BEFORE YOU CONSIDER
RETURNING THE PRODUCT!
1-800-531-0039
or
Visit us on the web at www.philips.com
PHILIPS CONSUMER ELECTRONICS NORTH AMERICA
Knoxville, Tennessee 37914-1810, U.S.A.
Meet Philips at the Internet
http://www.philips.com
W
AZ 3020
AZ 3021
AZ 3022
CLASS 1
LASER PRODUCT
Printed in China YM-039-17-1
English CONTROLS POWER SUPPLY
Top and front panels (See 1 ) Power Supply
1VOLUME Whenever convenient, use the power supply if you
– adjusts volume level want to conserve battery life. Make sure you remove
2DBB (Dynamic Bass Boost) the plug from the set and wall outlet before inserting
– enhances bass response batteries.
3Source selector
Batteries (not included)
– selects source of sound CD or TUNER. Also the
power off switch Open the battery compartment and insert six
4Display
batteries, type R-14, UM-2 or C-cells, (preferably
– shows the CD and tuner functions
alkaline) with the correct polarity as indicated by the
5FM•AM
"+" and "–" symbols inside the compartment.
– selects FM/ AM waveband
6LIFT TO OPEN
Batteries contain chemical substances, so they
– opens/ closes the CD door
should be disposed of properly.
7PRESS TO PLAY 2;
– starts or pauses CD play
Incorrect use of batteries can cause electrolyte
8STOP 9
leakage and will corrode the compartment or cause
– stops CD playback; erases a CD program
the batteries to burst. Therefore:
9SEARCH ∞ , §
• Do not mix battery types: e.g. alkaline with carbon
CD: skips or searches a passage/track
zinc. Only use batteries of the same type for the
backwards or forward
set.
Tuner: tunes to a station (up, down)
• When inserting new batteries, do not try to mix old
0PRESET +, –
batteries with the new ones.
– selects a preset station (up, down)
• Remove the batteries if the set is not to be used
!PROG MODE
for a long time.
CD: – programs and reviews programmed
track numbers; Using AC Power
– plays tracks CD/ program in random
1 Check if the power voltage, as shown on the type
order;
plate located on the bottom of the set, corresponds
– repeats a track/CD/ program
to your local AC power supply. If it does not,
Tuner: – programs preset stations
consult your dealer or service center.
2 Connect the power cord to the AC MAINS inlet and
Back Panel (See 1 )
the wall outlet. The power supply is now
@Telescopic antenna
connected and ready for use.
– to improve FM reception
3 To switch off completely, unplug the power cord
#Battery door from the wall outlet.
– to open battery compartment
• Unplug the power cord from the wall outlet to
$AC MAINS
protect your set during heavy thunderstorms.
– inlet for power cord
The typeplate is located on the bottom of the set
CD PLAYER MAINTENANCE & SAFETY
Programming track numbers
Precautions & General Maintenance (See $)
You may store up to 20 tracks in the desired
sequence. If you like, store any track more than once.
• Don't expose the set, batteries, CDs to humidity,
1 In the STOP mode, press ∞ or § for your desired
rain, sand or excessive heat.
track.
• Clean the set with a dry cloth. Don't use any
2 When your chosen track number appears, press
cleaning agents containing alcohol, ammonia,
PROG MODE once to store the track.
benzene or abrasives as these may harm the set.
™ The display shows prog and prog briefly
• Place the set on a hard and flat surface so that the
followed by your selected track number. (See 9)
system does not tilt. Make sure there is good
™ If you attempt to program without first selecting
ventilation to prevent the set overheating.
a track number, no sel is shown.
• Apparatus shall not be exposed to dripping or
(See 0)
splashing.
3 Repeat steps 1 to 2 to select and store all desired
• Do not place any sources of danger on the
tracks in this way.
apparatus (e.g. liquid filled objects, lighted
™ full is displayed if you attempt to program more
candles).
than 20 tracks.(See !)
• The mechanical parts of the set contain
4 To play your program, press 2;.
self-lubricating bearings and must not be oiled or
lubricated.
Reviewing your set program
• In the STOP mode, press and hold down
CD player and CD handling (See %)
PROG MODE for more than one second.
• The lens of the CD player should never be touched!
™ The display shows all your stored track numbers
• Sudden changes in the surrounding temperature
in sequence.
can cause condensation to form and the lens of
your CD player to cloud over. Playing a CD is then
Erasing a program
not possible. Do not attempt to clean the lens but
You can erase the contents of the memory by:
leave the set in a warm environment until the
– opening the CD door;
moisture evaporates.
– selecting TUNER source;
• Always close the CD door to keep the CD
– pressing 9 (twice during playback or in the stop
compartment dust-free. To clean, dust the
position
compartment with a soft dry cloth.
™ Display: shows no prog briefly when the
• To clean the CD, wipe in a straight line from the
program is cancelled.(See @)
center towards the edge using a soft, lint-free
cloth. Do not use cleaning agents as they may
damage the disc.
• Never write on a CD or attach any stickers to it.
BASIC FUNCTIONS
Switching power on/off: Save energy – For FM, pull out the telescopic antenna. Incline and
turn the antenna. Reduce its length if the signal is
Whether you are using mains or battery supply, to
too strong (very close to a transmitter).
avoid unnecessary energy consumption always adjust
– For AM the set is provided with a built-in antenna
the source selector to off.
so the telescopic antenna is not needed. Direct the
antenna by turning the whole set.
General operation
1 To select your sound source adjust the source
Programming radio stations
selector to CD/TUNER/OFF.
You can store up to a total of 32 radio stations in the
2 Adjust the sound with the VOLUME and DBB
memory: 20 FM and 12 AM.
(Dynamic Bass Boost) controls.
1 Tune to your desired station (see Radio Reception).
3 To switch off the set, adjust the source selector to
2 Press PROG MODE to activate programming.
off position.
™ Display: prog flashes. (See 5)
3 Press PRESET + or – once or more to allocate a
Note: When the set is switched off the tuner presets
number from 1 to 20 for FM or 1 to 12 for AM.
will be retained in the set's memory.
4 Press PROG MODE again to confirm the setting.
™ Display: prog disappears, the preset number
Tuner
and the frequency of the preset station are
Radio reception
shown. (See 3)
1 Adjust the source selector to TUNER.
5 Repeat steps 1-4 to store other stations.
™ Display: shows tu briefly (See 2).
• You can erase a preset station by storing another
2 Press FM•AM once or more to select the desired
frequency in its place.
waveband.
™ Display: shows your waveband and the preset
number and the frequency of a preset station if
already programmed (See 3)
3 Press and hold down ∞ or § briefly to tune to a
radio station. Release when the frequency in the
display starts to change.
™ The radio automatically tunes to a radio station
of sufficient reception. Display shows Srch
during automatic tuning. (See 4)
TROUBLESHOOTING
Troubleshooting
If a fault occurs, first check the points listed below before taking the set for repair.
Do not open the set as there is a risk of electric shock.
If you are unable to remedy a problem by following these hints, consult your dealer or service center.
WARNING:
Under no circumstances should you try to repair the set yourself, as this will invalidate the
warranty.
– Problem
• Solution
No sound /power no disc indication
– Volume not adjusted – CD-RW inserted /No CD inserted
• Adjust the VOLUME • Insert a CD or a CD-R
– power cord not securely connected – CD badly scratched or dirty
• Connect the AC power cord properly • Replace/ clean CD, see Maintenance
– Batteries dead/ incorrectly inserted – Laser lens steamed up
• Insert (fresh) batteries correctly • Wait until lens has cleared
– CD-R is blank or the disc is not finalized
Display does not function does not function
• Use a finalized CD-R
properly/ No reaction to operation of any of
the controls
CD playback does not work
– Electrostatic discharge
– CD badly scratched/ dirty
• Switch off and unplug the set. Reconnect after a
• Replace/ clean CD (see maintenance)
few seconds
– Laser lens steamed up
• Wait until lens has adjusted to room temperature
The CD skips tracks
– CD damaged or dirty
• Replace or clean CD
– SHUFFLE or a program is active
• Quit SHUFFLE/ program mode(s)
Environmental information
We have done our best to reduce the packaging and make it easy to separate into 3 materials: cardboard,
paper pulp and expandable polyethylene.
Your set consists of materials which can be recycled if disassembled by a specialized company. Please observe
the local regulations regarding the disposal of packaging, dead batteries and old equipment..
TUNER CD PLAYER
Selecting a different track
CD Player
During playback you can use ∞ or § to select a
Display indication for CD functions
particular track.
– CD open: CD door open (See 6)
• If you have selected a track number in the stop or
– disc: CD inserted (See 7)
pause position, press 2; to start playback.
– In stop mode: total track number and total
• Press § once briefly for the next track, or press
playback time
repeatedly until the desired track number appears
– During CD playback: elapsed playback time of
in the display.
current track and current track number
• Press ∞ once briefly to return to the beginning of
– Pause: elapsed playback time freezes and flashes
a current track.
(See 8)
• Press ∞ more than once briefly for a previous
– shuffle/ repeat modes: when the respective mode
track.
is activated
– prog: when CD program active); prog also appears
Finding a passage within a track
briefly when you store a track (See 9)
1 Press and hold down ∞ or §.
– no sel: program activated but no tracks selected
• The CD is played at high speed and low volume.
(See 0)
2 When you recognize the passage you want release
– full: program memory full (See !)
∞ or §.
– no prog: program cancelled (See @)
™ Normal playback resumes.
– no disc: no disc/ error in CD operation /CD-R(W) is
blank or the disc is not finalized (See # +
Different play modes: Shuffle and Repeat
Troubleshooting)
PROG MODE allows you to select various play
Playing a CD
modes. The modes can be selected or changed during
playback of an entire CD/ CD program in the following
This CD-player can play Audio Discs and CD-
sequence:
Recordables. Do not try to play CD-Rewritables,
shuffle – all tracks are played in random order
a CD-ROM, CDi, VCD, DVD or computer CD.
shuffle repeat all –
1 Adjust the source selector to CD.
™ Display: shows Cd briefly. repeats the entire CD in random order
repeat – plays the current track continuously
2 To open the CD door, lift the CD door at the edge
repeat all – plays the entire CD continuously
marked LIFT TO OPEN.
1 During playback, select your play mode by pressing
3 Insert a CD or CD-R with the printed side facing up
PROG MODE once or more until the desired play
and press the CD door gently close.
4 Press 2; on the set to start playback. mode is shown.
5 To pause playback press 2;. To resume, press 2; ™ Display: your selected mode flashes 2 seconds
before playback
again.
• You can use ∞ or § to skip tracks during the
6 To stop CD playback, press STOP 9.
shuffle/ repeat modes.
• The shuffle/ repeat play options can be combined
Note: CD play will also stop when:
and used with a program: e.g. shuffle/ repeat all
– you open the CD compartment;
repeats the entire CD program in random order.
– you select TUNER sound source;
2 To return to normal playback press PROG MODE
– the CD has reached to the end.
until the shuffle/ repeat modes are no longer
shown.
• You can also press 9 to quit the play mode.
Return your Warranty Registration card today to
ensure you receive all the benefits you're entitled to.
• Once your Philips purchase is • So complete and return the Warranty
registered, you're eligible to receive all Registration Card enclosed with your
the privileges of owning a Philips purchase at once. And take advantage
product. of these important benefits.
Warranty Owner
Verification Confirmation
Registering your product Your completed Warranty
within 10 days confirms Registration Card serves
your right to maximum as verification of
protection under the ownership in the event of
terms and conditions of product theft or loss.
your Philips warranty.
Know these
s s a a f f e e t t y y
For Customer Use
symbols
Enter below the Serial No. which is located
on the bottom of the cabinet. Retain this
information for future reference.
CAUTION
RISK OF ELECTRIC SHOCK
Model No. ________________________
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT
Serial No. _________________________
REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS
INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
This "bolt of lightning"
WARNING:
indicates uninsulated
FIRE OR SHOCK HAZARD, DO
material within your unit
NOT EXPOSE THIS EQUIPMENT TO
which may cause an electrical shock.
RAIN OR MOISTURE.
For the safety of everyone in your
household, please do not remove
product covering.
The "exclamation point"
CAUTION:
calls attention to features
electric shock, match wide blade of
for which you should read
plug to wide slot, and fully insert.
the enclosed literature closely to
prevent operating and maintenance
problems.
Model
Registration
Returning your Warranty
Registration Card right
away guarantees you'll
receive all the information
and special offers which
you qualify for as the
owner of your model.
TO PREVENT
To prevent
