Page 1: Table Of Contents
Part I: Introduction, Installation, Operation Introduction Self-Contained Spot Description Merchandiser Receipt, Preparation, Unpacking, and Installation Operation Technical Data Dixell XR75CX Digital Controller Parts List Standard Warranty - Rev. January 2013 Appendices Part II: Specification Sheets Models: LD1C1A Applications: KW-IOM-2150 | Version 06...
Page 2: Manual Structure
Part I. Introduction, Installation, and Operation This is the I&O manual for the LD1C1A spot merchandiser and is part of the family of Kysor/Warren (KW) merchandisers. Its purpose is to assist the user in the installation and operation of these merchandisers.
Page 3 NOTE: Installation and service instructions for the condensing unit are not part of this manual. The LD1C1A-5 and LD1C1A-10 are installed individually in an area approximately 3-1/2 feet x 6 feet or 3-1/2 feet x 11 feet respectively. Adjustable glide feet are provided on each merchandiser for leveling the merchandiser. Swivel plate mount casters with brakes are optional in lieu of glide feet.
Page 4 Installation and Operation Manual 2.1. Components Electrical All field installed wiring must comply with the NATIONAL ELECTRICAL CODE AND LOCAL ELECTRICAL CODES. The merchandiser is provided with power cord(s) that have a male plug that is shipped loose for installation in the store. There is/are also matching female receptacle(s) that are shipped loose. To gain access to the inside of the electrical control panel, remove the control panel cover.
Page 5 Self-Contained Spot Merchandiser that stops the refrigeration cycle and energizes the defrost circuit to energize the defrost heater. The defrost cycle is terminated either by a temperature sensor connected to the electronic controller or failsafe time returning the merchandiser into refrigeration mode. A defrost heater safety limit thermostat (Klixon) is wired in series with the defrost heater that opens if the temperature exceeds 70°F.
Page 6: Receipt, Preparation, Unpacking And Installation
Installation and Operation Manual 3. Receipt, Preparation, Unpacking and Installation This section covers the receipt, preparation, unpacking and installation of the merchandiser. NOTE: Read all instructions carefully before beginning installation. 3.1. Receipt All equipment should be examined for shipping damage before and during unloading. If there is any damage: •...
Page 7 Self-Contained Spot Merchandiser 5 foot section). The discharge air sensor is located inside the rear discharge air duct. The settings for low temperature and medium temperature are preset in the electronic controller and no adjustment is required after connecting power to the merchandiser.
Page 8: Electrical Connections
Installation and Operation Manual CAUTIONS: DO NOT FLUSH THE MERCHANDISER WITH WATER. This merchandiser is not connected to a drain system and has a defrost water evaporating pan with only a limited volume capacity. The merchandiser should have at least 18” clearance from any wall or other obstruction in order to operate properly. NOTE: Do not stack anything in front of the intake or exhaust louvers that may block airflow on the merchandiser.
Page 9 Self-Contained Spot Merchandiser Installation of Power Cord to Exit the Base-End Panel of the Merchandiser Install the cordgrip into the hole in the base end panel of the merchandiser. Route the power cord through the cordgrip installed in the base end panel and into the control panel through the hole located in the bottom right hand side of the control panel. Do not tighten the cordgrip until the power cord wire conductors have been connected into the circuit breaker and terminal board.
Page 10: Technical Data
Figure 4-2. Power Cord Installation Exiting the Bottom of Merchandiser Base 5. Technical Data This I&O manual is in two parts: Technical data listed in the LD1C1A specification sheet The technical data for the LD1C1A merchandiser is located on the unit’s specification sheet titled: LD1C1A –...
Page 11: Dixell Xr75Cx Digital Controller
Self-Contained Spot Merchandiser 5.2. Data Plate Figure 5-1 shows a sample data plate for an LD1C1A-5 Spot Merchandiser. Data on the plate includes: • Model • Serial number • Circuit number • Refrigerant • Charge • Minimum Circuit Ampacity (MIN CKT) •...
Page 12 Installation and Operation Manual There are 6 keys on the control front panel display. Table 6-1 explains their meaning. Function Function Press the UP-arrow key to see the MAX stored temperature, to browse the Switches the light ON and OFF, if oA1 = Lig parameter codes in programming mode, or to increase the displayed temperature value.
Page 13 Self-Contained Spot Merchandiser • Alarms • Silencing an alarm • Alarm recovery Changing a Setpoint Value Use the following steps to change a setpoint value. See Appendix A for the list of default settings and Appendix C for the factory settings. Changing a Setpoint Value Press and hold the SET button for more than 2 seconds to change the setpoint value.
Page 14 Installation and Operation Manual Table 6-3 displays the alarm message, cause, and outputs. Message Cause Outputs Room probe failure Compressor output acc. to par. Con and CoF Evaporator probe failure Defrost end is timed Third probe failure Outputs unchanged Fourth probe failure Outputs unchanged Maximum temperature alarm Outputs unchanged.
Page 15: Control Settings
Self-Contained Spot Merchandiser To restore the normal display, press the DOWN button again or wait five seconds. View Maximum Temperature Press and release the UP button. The Hi message will be displayed followed by the maximum temperature recorded. To restore the normal display, press the UP button again or wait five seconds. Reset the Maximum and Minimum Temperatures Press and hold the SET button for more than 3 seconds while the maximum or minimum temperature is dis- played (rSt message will be displayed).
Page 16 Installation and Operation Manual 6.4. Wiring Diagram Figure 6-2 shows the wiring diagram for the LD1C1A-5 Spot Merchandiser. Figure 6-2. Wiring Diagram for the LD1C1A-5 Spot Merchandiser...
Page 17: Parts List
Self-Contained Spot Merchandiser 7. Parts List Figure 7-1 shows the major components of the five foot LD1C1A spot merchandiser and Table 7-1 is the parts list. Figure 7-1. Isometric View of LD1C1A–5 Spot Merchandiser Table 7-1 provides a list of parts for the LD1C1A merchandisers.
Page 18 Condensing Unit (208 VAC) (EJAL-A102-CAV-021) (208 VAC) 01F10015 Table 7-1. LD1C1A Parts List NOTE: Standard parts are provided in the parts lists. Merchandisers may be equipped with specialty parts that were incorporated into the merchandiser(s) at the time it was manufactured. It is important to have the merchandiser serial...
Page 19: Standard Warranty - Rev. January 2013
Self-Contained Spot Merchandiser 8. Standard Warranty - Rev. January 2013 Seller warrants to its direct purchasers that Products, including Service Parts, shall be of a merchantable quality, free of defects in material or workmanship, under normal use and service for a period of one (1) year from date of original equipment start-up, or eighteen (18) months from date of shipment by Seller, whichever first occurs.
Page 20 Installation and Operation Manual Unit Cooler EC Fan Motors Seller warrants EC Motors (made by McMillan) for a period of two (2) years from date of original installation, or thirty (30) months from date of shipment by Seller, whichever first occurs. Beacon II™ CONTROL SYSTEMS Seller warrants the Beacon II™ Control System for a period of three (3) years from the date of original installation, or forty-two (42) months from the date of shipment by Seller, whichever first occurs.
Page 21 Self-Contained Spot Merchandiser 9. To equipment with final destinations unknown to seller as indicated on the original sales order. 10. To labor cost for repair or replacement of parts. 11. To special or expedited freight or shipping charges or to customs duties to any country. 12. If the Warranty holder fails to comply with all the provisions, terms and conditions of this Warranty. Parts replaced under this Warranty are warranted only through the remainder of the original Warranty.
Page 22: Appendices
Installation and Operation Manual Appendices There are three appendices related to the Dixell XR75CX Digital Controller. They are: • Appendix A: Default Setting Values • Appendix B: Parameters • Appendix C: Factory Settings Appendix A: Default Setting Values Label Name Range Value Level Setpoint LS to US [-5.0°C] [23°F] - - - [0.1 to 25.5°C] Differential [2.0°C] [2°F] [1 to 255°F]...
Page 23 Self-Contained Spot Merchandiser Appendix B: Parameters Code Parameter Function REGULATION (0.1 to 25.5°C; 1 to 45°F) Intervention differential for setpoint. Compressor Cut IN is Set Point + differential (HY). Differential Compressor Cut OUT is when the temperature reaches the setpoint. (-50°C to SET; -58°F to SET) Sets the minimum value for the Minimum setpoint setpoint. (SET to 110°C; SET to 230°F) Sets the maximum value for Maximum setpoint setpoint. (-12.0 to 12.0°C; -21 to 21°F) Allows to adjust possible offset Thermostat probe calibration of the thermostat probe. (n; Y) n = not present, the defrost stops by time; Y = present, Evaporator probe presence the defrost stops by temperature.
Page 24 Installation and Operation Manual (P1; P2, P3, P4, SET, dtr) Selects which probe is displayed by the instrument. P1 = Thermostat probe; P2 = Evaporator Instrument display probe; P3 = Third probe (only for model with this option enabled); P4= Fourth probe, SET = setpoint; dtr = percentage of visualization.
Page 25 Self-Contained Spot Merchandiser (-50 to 50°C; -58 to 122°F) Setting of temperature, detected Fans stop temperature by evaporator probe, above which fans are always OFF. (0 to 15min) With FnC=C_n or C_Y, (fan activated in parallel with compressor) it sets the evaporator fan ON cycling time Fan ON time when the compressor is OFF. With Fon=0 and FoF≠0 the fan is always OFF, with Fon=0 and FoF=0 the fan is always OFF.
Page 26 Installation and Operation Manual (-50 to 110°C; -58 to 230°F) When this temperature is Low temperature alarm of condenser reached the LA2 alarm is signalled, possibly after the Ad2 delay. (-50 to 110°C; -58 to 230°F) When this temperature is High temperature alarm of condenser reached the HA2 alarm is signalled, possibly after the Ad2 delay. Differential for temperature condenser alarm recovery (0.1 to 25.5°C; 1 to 45°F) (0 to 255 min) Time interval between the detection of the con- Condenser temperature alarm delay denser alarm condition and alarm signaling.
Page 27 Self-Contained Spot Merchandiser (n; Y) n = outputs not affected by the doA alarm; Y = outputs Outputs restart after doA alarm restart with the doA alarm (-30.0 to 30.0°C; -54 to 54°F) Sets the increasing value of the Delta temperature during an Energy Saving cycle setpoint [SET+HES] during the Energy Saving cycle. OTHER (1 to 247) Identifies the instrument address when connected Serial address to a MODBUS compatible monitoring system.
Page 28 Installation and Operation Manual Probe displayed P1; P2 X-REP display P1 - P2 - P3 - P4 - Set - dtr Display temperature delay 0 to 20.0 min (10 sec) P1-P2 percentage for display 1 to 99 EdF* Kind of interval for defrost rtC to in Defrost type EL = electric heater;...
Page 29 Self-Contained Spot Merchandiser Condenser for low temperature -67 to 302°F alarm Condenser for high temperature -67 to 302°F alarm Differential for condenser tempera- 1°F to 45°F ture alarm recovery Condenser temperature alarm 0 to 254 min, 255 = not used delay Delay of condenser temperature 0.0 to 23 hr and 50' alarm at start up Compressor OFF for condenser n(0) - Y(1)
Page 30 Installation and Operation Manual ISE* Energy Saving cycle start on 0 to 23hr 50 min holidays dSE* Energy Saving cycle length on 0 to 24hr 00 min holidays Ld1* 1st workdays defrost start 0 to 23hr 50 min - not used not used Ld2* 2nd workdays defrost start...
Page 31: Part Ii: Specification Sheets
Self-Contained Spot Merchandiser Part II: Specification Sheets Specification sheets contain technical data specific to the unit and include: • Case Data • Capacities • Drawings Specification sheets can be downloaded at www.kysorwarren.com Or contact Technical Sales Support Kysor//Warren 5201 Transport Blvd Columbus, GA 31907 800-866-5596 phone 706-568-8990 fax...
Page 32 Installation and Operation Manual...
Page 33 Self-Contained Spot Merchandiser...
Page 34 The company behind the brands you trust. ™ CLIMATE CONTROL Commercial Refrigeration Parts...
