- Page 1 IT IS POSSIBLE. LINX AUDIO ™ Sound Clarity With LINX AUDIO ™ ™ Wireless Infrared Stereo Headphones...
- Page 3 Soft ear cushions and lightweight design provide superior comfort for hours of listening pleasure. LINX AUDIO™ provides optimal sound quality and clarity creating a “Live Experience” with full rich sound and clear speech even at lower volumes enabling you to “Turn it Down™”...
-
Page 4: Special Features
SPECIAL FEATURES • Patent Pending LINX AUDIO™ for Superior Sound Quality and speech clarity • State of the Art Wireless Infrared Technology • Lightweight Adjustable Headband with Full Size Ear Cup and Soft Cushions for Maximum Comfort • Automatic Level Control prevents input signal over loading •... - Page 5 EXPLANATION OF CONTROLS (Fig. 1) TRANSMITTER 1) Power On/Off switch turns on transmitter. 2) 8 high-power INFRARED LEDs transmits signal to headphones for optimum room coverage. 3) DC INPUT JACK inputs DC power to transmitter. 4) RCA JACK input audio signal for channel A. 5) MINI PLUG JACK input audio signal for channel B.
- Page 6 TRANSMITTER TRANSMITTER RECEIVER Fig.1 Fig.1 Three position tilt base. Transmitter easlly snaps in and out of base. RIGHT LEFT RIGHT RECEIVER Fig.1 RIGHT DUAL RCA PLUGS LEFT RIGHT...
- Page 7 EXPLANATION OF CONTROLS (Fig. 1) HEADPHONE RECEIVER 1. Switch the Transmitter “ON” and place in a position that is slightly lower or approximate in height to your listening level when wearing the HEADPHONES. 2. Face the TRANAMITTER LED towards your listening area with no obstructions between you and the device.
-
Page 8: Installation
INSTALLATION 1. Connect the stereo signal to the Transmitter with the adapter cord (fig. 2) Fig.2 LEFT RIGHT Note: When batteries are low the LED will not go “ON” and the MUTE FUNCTION becomes inoperable. Please replace the batteries to restore quality of sound. MINI PLUG DUAL RCA PLUGS 2. -
Page 9: Installing/Changing The Batteries
Installing/Changing the Batteries Two AAA batteries power the Sound Clarity Wireless Infrared Headphones. Batteries are located behind the battery cap on the front of the left ear cup. Identify the battery comparment (picture) before attempting to open battery cap. Do not attempt to open the right-side ear cup. - Page 10 Adjusting Your Headphone for a Comfortable Fit Identify the left (L) and Right (R) designations located on each side of the headband. The headband adjusts for a comfortable fit by sliding the top and side of the headband apart as seen in Illustration B. Place one hand on the top of the headband and the other hand on the side of the headband and pull in opposite directions to adjust the size of the headband, and then, place them on your head.
- Page 11 Illustration B...
-
Page 12: Operation
OPERATION 1. Switch the Transmitter “ON” and place in a position that is slightly lower or approximate in height to your listening level when wearing the HEADPHONES. 2. Face the TRANSMITTER LED towards your listening area with no obstructions between you and the device. -
Page 13: Specifications
SPECIFICATIONS SYSTEM: INFRARED CARRIER FREQENCY: LEFT CHANNEL 2.3mHz RIGHT CHANNEL 2.8mHz MODULATION Frequency Modulation INPUT LEVEL 300mV RMS POWER SUPPLY TRANSMITTER: 12Vdc, 200mA(AC ADAPTER) RECEIVER: 2x 1. 5 V UM-4”AAA” Batteries OUTPUT IMPEDANCE: 40 Ohms FREQUENCY RESPONSE: 35-18,000Hz S/N RATIO: 60db DISTORTION: 0.5% THD... -
Page 14: Troubleshooting
Troubleshooting No Sound • Make sure the headphones and the transmitter are turned on. Headphones have a red indicator light when on and red infrared transmitter lights can be seen when an audio signal has been detected. • Check the connections of the AV equipment to the transmitter •... - Page 15 CAUTIONS Long-term exposure to loud audio volume levels may cause hearing damage. All Able Planet products include a volume control to enable you to “Turn it Down™”. Remember to adjust the sound volume to a safe listening level. This device complies with part 15 of the FCC Rules. Operation is subject to the following...
- Page 16 : Reorient or relocate the receiving antenna Increase the separation between the equipment and receiver Connect the separation into an outlet on a circuit different from that to which the receiver is needed. Contact Able Planet technical support...
- Page 17 Folding the Headphones for Storage The headphones fold flat inside its hard shell protective carrying case, making them ideal for travel around the corner, or around the world. To store, identify the left (L) and Right (R) designations located on each side of the headband. Holding the headphones with two hands with the right ear cup in your right hand, you should be able to see the CH.B / CH.
