  • Page 3 Preface Notebook Computer D400P/D410P Service Manual...
  • Page 4 Preface Notice The company reserves the right to revise this publication or to change its contents without notice. Information contained herein is for reference only and does not constitute a commitment on the part of the manufacturer or any subsequent ven- dor.

  • Page 5: About This Manual

    This manual is intended for service personnel who have completed sufficient training to undertake the maintenance and inspection of personal computers. It is organized to allow you to look up basic information for servicing and/or upgrading components of the D400P/D410P series notebook PC.

  • Page 6: Related Documents

    Preface Related Documents You may also need to consult the following manual for additional information: User’s Manual on CD This describes the notebook PC’s features and the procedures for operating the computer and its ROM-based setup pro- gram. It also describes the installation and operation of the utility programs provided with the notebook PC.

  • Page 7: Table Of Contents

    Preface Contents Introduction ..........1-1 Mainboard Overview - Top (Key Parts) ........1-10 Mainboard Overview - Bottom (Key Parts) ......... 1-11 Overview ..................1-1 Mainboard Overview - Top (Connectors) ........1-12 System Specifications ..............1-2 Mainboard Overview - Bottom (Connectors) ....... 1-13 Processor ..................1-2 Disassembly ..........2-1 Core Logic ..................1-2 Structure ..................1-2...
  • Page 8 Preface Removing the PC Card Assembly ..........2-29 Clock Generator ................B-5 Removing the LCD Front Panel Module ........2-30 M650 (Host/AGP) 1 of 4 ..............B-6 Removing the Inverter ..............2-31 M650 (Memory for DDR) 2 of 4 ............B-7 Removing the PC Video Camera Module ........2-32 M650 (&...

  • Page 9: Introduction

    1: Introduction Overview This manual covers the information you need to service or upgrade the D400P/D410P series notebook computer. Infor- mation about operating the computer (e.g. getting started, and the Setup utility) is in the User’s Manual. Information about drivers (e.g. VGA & audio) is also found in User’s Manual. That manual is shipped with the computer.

  • Page 10: System Specifications

    Introduction System Specifications Processor Security • Intel Pentium 4 Processor - (478-pin) FC-PGA2 package • Security (Kensington® Type) Lock µ • BIOS Password 0.13) 0.13 Micron Process Technology, 512KB L2 Cache & 400MHz FSB - 2.0/ 2.2/ 2.4/ 2.5/ 2.6 GHz µ...

  • Page 11: Storage Devices

    Introduction Storage Devices Interface • 3.5" 3-mode Floppy Disk Drive • Three USB 2.0/ 1.1 ports • One Mini-IEEE 1394 port • Easy changeable 2.5" 9.5 mm (h) Hard Disk Drive • One S-Video Out port for TV output Supporting Master mode IDE •...

  • Page 12: Power Management

    Introduction Power Management Physical Dimensions • Supports ACPI v1.0b • 329 (w) x 275 (d) x 36.5 (h) mm • Supports suspend to RAM (S3) • Supports suspend to disk (S4) Weight • Supports Battery low suspend • Around 2.8 kg (depend on optional modules included) •...

  • Page 13: Design Differences

    Introduction Design Differences This manual refers to the two notebook designs pictured below. The designs vary slightly in external design. Photographs used throughout this manual are of Design I. Figure 1 Design Differences Design I Design II System Specifications 1 - 5...

  • Page 14: External Locator - Top View

    Introduction External Locator - Top View Figure 2 Top View 1. Optional Built-in USB Camera 2. LCD 3. Built-In Microphone 4. LED Power & Communication Indicators 5. LED Status Indicators 6. Hot-Key buttons 7. Close Cover Switch 8. Power Button 9.

  • Page 15: External Locator - Front & Left Side Views

    Introduction External Locator - Front & Left Side Views Figure 3 Front View 1. LCD Latches 2. Mini IEEE 1394 Port 3. S/PDIF Out Port 4. Microphone Jack 5. Headphone Jack 6. Infrared Transceiver 7. Wireless Module ON/OFF Switch 8. Built-In Speakers Figure 4 Left Side View 1.

  • Page 16: External Locator - Right Side & Rear Views

    Introduction External Locator - Right Side & Rear Views Figure 5 Right Side View 1. Security Lock Slot Figure 6 Rear View 9 10 1. Vent 2. DC-In Jack 3. 2 * USB Ports 4. External Monitor (CRT) Port 5. Parallel Port 6.

  • Page 17: External Locator - Bottom View

    Introduction External Locator - Bottom View Figure 7 Bottom View 1. Vent/Fan Intake 2. Battery Cover 3. Hard Disk Cover 4. Bluetooth Module Cover 5. CPU Heatsink Cover Note : The RAM and optional Wireless LAN module are lo- cated under the CPU Heatsink Cover External Locator - Bottom View 1 - 9...

  • Page 18: Mainboard Overview - Top (Key Parts)

    Introduction Mainboard Overview - Top (Key Parts) Figure 8 Mainboard Top Key Parts 1. PC Card Assembly 2. Northbridge - SiS M650 3. Southbridge - SiS 4. Flash ROM BIOS 1 - 10 Mainboard Overview - Top (Key Parts)

  • Page 19: Mainboard Overview - Bottom (Key Parts)

    Introduction Mainboard Overview - Bottom (Key Parts) Figure 9 Mainboard Bottom Key Parts 1. CPU Socket (no CPU installed) 2. Memory Sockets (no memory installed) 3. SiS 302LV TV- Out Controller 4. LAN Controller RTL8100BL 5. CardBus ENE CB1410 6. ALC202 - Audio Codec 7.

  • Page 20: Mainboard Overview - Top (Connectors)

    Introduction Mainboard Overview - Top (Connectors) Figure 10 Mainboard Top Connectors 1. Modem Cable Connector (CN1) 2. LCD and Inverter Cable Connector (JLCD1) 3. Video Camera Module Connector (JCCD1) 4. Switch Board Cable Connector (JSW1) 5. Fan Cable Connector (JFAN1) 6.

  • Page 21: Mainboard Overview - Bottom (Connectors)

    Introduction Mainboard Overview - Bottom (Connectors) Figure 11 Mainboard Bottom Connectors 1. Wireless LAN Cable Connector (JWL1) 2. Fan Cable Connector (JFAN2) 3. CD Device Connector (JCDROM1) 4. Hard Disk Cable Connector (JHDD1) 5. Bluetooth Module Connector (JBT1) 6. CMOS Battery Cable Connector (JBAT1) 7.
  • Page 22 Introduction 1 - 14...

  • Page 23: Disassembly

    2: Disassembly Overview This chapter provides step-by-step instructions for disassembling the D400P/D410P series notebook’s parts and sub- systems. When it comes to reassembly, reverse the procedures (unless otherwise indicated). We suggest you completely review any procedure before you take the computer apart.

  • Page 24: Maintenance Tools

    Disassembly NOTE : All disassembly procedures assume that the system is turned OFF , and disconnected from any power supply (the battery is removed too). Maintenance Tools The following tools are recommended when working on the notebook PC: • M3 Philips-head screwdriver •...

  • Page 25: Maintenance Precautions

    Disassembly Maintenance Precautions The following precautions are a reminder. To avoid personal injury or damage to the computer while performing a re- moval and/or replacement job, take the following precautions: Power Safety Warning 1. Don't drop it. Perform your repairs and/or upgrades on a stable surface. If the computer falls, the case and other Before you undertake components could be damaged.

  • Page 26: Disassembly Steps

    Disassembly Disassembly Steps The following table lists the disassembly steps, and on which page to find the related information. PLEASE PERFORM THE DISASSEMBLY STEPS IN THE ORDER INDICATED. To remove the Battery: To remove the Processor: 1. Remove the battery page 2 - 8 1.
  • Page 27 Disassembly To remove the TouchPad and Click Board: To remove the Modem: 1. Remove the battery page 2 - 8 1. Remove the battery page 2 - 8 2. Remove the HDD page 2 - 9 2. Remove the HDD page 2 - 9 3.
  • Page 28 Disassembly To remove the Mainboard: To remove the Floppy Disk Drive Assembly: 1. Remove the battery page 2 - 8 1. Remove the battery page 2 - 8 2. Remove the HDD page 2 - 9 2. Remove the HDD page 2 - 9 3.
  • Page 29 Disassembly To remove the LCD Front Panel Module: To remove the PC Video Camera Module: 1. Remove the battery page 2 - 8 1. Remove the battery page 2 - 8 2. Remove the HDD page 2 - 9 2. Remove the HDD page 2 - 9 3.

  • Page 30: Removing The Battery

    Disassembly Removing the Battery 1. Turn the computer off, and turn it over. 2. Remove screws & (Figure 1a) from the battery cover , and remove the cover. 3. Carefully (use a small screwdriver) disconnect the battery cable at point (Figure 1b) 4.

  • Page 31: Removing The Hard Disk Drive

    Disassembly Removing the Hard Disk Drive The hard disk drive is mounted in a removable case and can be taken out to accommodate other 2.5" IDE hard disk drives with a height of 9.5mm (h). Follow your operating system’s installation instructions, and install all necessary drivers and utilities (as outlined in Chapter 4 of the User’s Manual ) when setting up a new hard disk.

  • Page 32: Removing The System Memory (Ram)

    Disassembly Removing the System Memory (RAM) The computer has two memory sockets for 200 pin Small Outline Dual In-line Memory Modules (SO-DIMM) supporting DDR 200/266 MHz. The main memory can be expanded up to 1024MB. The SO-DIMM modules supported are 128Mb, 256Mb, and 512Mb.
  • Page 33 Disassembly 5. Gently pull the two release latches ( & on the sides of the memory socket toward the sides of the computer. Figure 4 Removing/ Installing a RAM Module a. Pull release latches. b.Remove the module. 6. The module (Figure 4b) will pop-up, and you can remove it.

  • Page 34: Removing The Cd Device

    Disassembly Removing the CD Device The easy changeable CD device may be upgraded or changed. 1. Turn off the computer, remove the battery ( page 2 - 8 ) and turn it over. 2. Remove screws (Figure 5a) from the memory socket cover 3.
  • Page 35 Disassembly 4. Use a screwdriver to carefully push the CD device assembly out of the computer at point Figure 6 CD Device Removal Push the CD device out off the computer at point 5. Insert the new device and carefully slide it into the computer (the device only fits one way. DO NOT FORCE IT; The screw holes should line up.

  • Page 36: Removing The Bluetooth Module

    Disassembly Removing the Bluetooth Module page 2 - 8 1. Turn off the computer, remove the battery ( ) and turn it over. 2. Remove screws (Figure 7a) from the Bluetooth module cover 3. Carefully lift up the Bluetooth module cover off the computer.

  • Page 37: Removing The Wireless Lan Module

    Disassembly Removing the Wireless LAN Module page 2 - 8 1. Turn off the computer, remove the battery ( ) and turn it over. 2. Remove screws from the memory socket cover 3. Carefully lift up the memory socket cover (a fan cable is still attached to the mainboard and you can discon- nect it).

  • Page 38: Removing The Processor

    Disassembly Removing the Processor page 2 - 8 1. Turn off the computer, remove the battery ( ) and turn it over. 2. Remove screws from the memory socket cover 3. Carefully lift up the memory socket cover (a fan cable is still attached to the mainboard and you can discon- Figure 9 nect it).
  • Page 39 Disassembly 6. Unlock the processor by raising lever (Figure 10a). 7. Lift the CPU (Figure 10b) off the computer. Figure 10 Processor Removal (cont’d) a. Raise the lever to unlock the CPU. b. Lift the CPU off the sock- Caution The heat sink, and CPU area in general, contains parts which...

  • Page 40: Removing The Keyboard

    Disassembly Removing the Keyboard page 2 - 8 1. Turn off the computer, remove the battery ( 2. Press the three keyboard latches at the top of the keyboard to elevate the keyboard from its normal position (you may need to use a small screwdriver to do this). 3.

  • Page 41: Removing The Keyboard Shielding Plate

    Disassembly Removing the Keyboard Shielding Plate page 2 - 8 page 2 - 18 1. Turn off the computer, remove the battery ( ) and keyboard ( 2. Remove screws (Figure 12a) from the keyboard shielding plate and lift the plate off the computer.

  • Page 42: Removing The Lcd And Top Case

    Disassembly Removing the LCD and Top Case page 2 - 8 page 2 - 9 page 2 - 10 page 1. Turn off the computer, remove the battery ( ), hard disk ( ), RAM ( ), CD Device ( 2 - 12 ), Bluetooth module ( page 2 - 14...
  • Page 43 Disassembly & 5. Slide the LCD hinge covers (Figure 14a) out of the computer. 6. Remove screws & (Figure 14b) then carefully (pay careful attention to the antenna cables) lift the LCD assembly (Figure 14c) off the computer. & & 7.

  • Page 44: Removing The Touchpad And Click Board

    Disassembly Removing the TouchPad and Click Board page 2 - 8 page 2 - 9 page 2 - 10 page 1. Turn off the computer, remove the battery ( ), hard disk ( ), RAM ( ), CD Device ( 2 - 12 ), Bluetooth module ( page 2 - 14...

  • Page 45: Removing The Switch Board

    Disassembly Removing the Switch Board page 2 - 8 page 2 - 9 page 2 - 10 page 1. Turn off the computer, remove the battery ( ), hard disk ( ), RAM ( ), CD Device ( 2 - 12 ), Bluetooth module ( page 2 - 14 ), Wireless LAN module (...

  • Page 46: Removing The Modem

    Disassembly Removing the Modem page 2 - 8 page 2 - 9 page 2 - 10 page 1. Turn off the computer, remove the battery ( ), hard disk ( ), RAM ( ), CD Device ( 2 - 12 ), Bluetooth module ( page 2 - 14 ), Wireless LAN module (...

  • Page 47: Removing The Speakers

    Disassembly Removing the Speakers page 2 - 8 page 2 - 9 page 2 - 10 page 1. Turn off the computer, remove the battery ( ), hard disk ( ), RAM ( ), CD Device ( 2 - 12 ), Bluetooth module ( page 2 - 14 ), Wireless LAN module (...

  • Page 48: Removing The Mainboard

    Disassembly Removing the Mainboard page 2 - 8 page 2 - 9 page 2 - 10 page 1. Turn off the computer, remove the battery ( ), hard disk ( ), RAM ( ), CD Device ( 2 - 12 ), Bluetooth module ( page 2 - 14 ), Wireless LAN module (...

  • Page 49: Removing The Fan Unit

    Disassembly Removing the Fan Unit page 2 - 8 page 2 - 9 page 2 - 10 page 1. Turn off the computer, remove the battery ( ), hard disk ( ), RAM ( ), CD Device ( 2 - 12 ), Bluetooth module ( page 2 - 14 ), Wireless LAN module (...

  • Page 50: Removing The Floppy Disk Drive Assembly

    Disassembly Removing the Floppy Disk Drive Assembly page 2 - 8 page 2 - 9 page 2 - 10 page 1. Turn off the computer, remove the battery ( ), hard disk ( ), RAM ( ), CD Device ( 2 - 12 ), Bluetooth module ( page 2 - 14...

  • Page 51: Removing The Pc Card Assembly

    Disassembly Removing the PC Card Assembly page 2 - 8 page 2 - 9 page 2 - 10 page 1. Turn off the computer, remove the battery ( ), hard disk ( ), RAM ( ), CD Device ( 2 - 12 ), Bluetooth module ( page 2 - 14 ), Wireless LAN module (...

  • Page 52: Removing The Lcd Front Panel Module

    Disassembly Removing the LCD Front Panel Module page 2 - 8 page 2 - 9 page 2 - 10 page 1. Turn off the computer, remove the battery ( ), hard disk ( ), RAM ( ), CD Device ( 2 - 12 ), Bluetooth module ( page 2 - 14...

  • Page 53: Removing The Inverter

    Disassembly Removing the Inverter page 2 - 8 page 2 - 9 page 2 - 10 page 1. Turn off the computer, remove the battery ( ), hard disk ( ), RAM ( ), CD Device ( 2 - 12 ), Bluetooth module ( page 2 - 14 ), Wireless LAN module (...

  • Page 54: Removing The Pc Video Camera Module

    Disassembly Removing the PC Video Camera Module page 2 - 8 page 2 - 9 page 2 - 10 page 1. Turn off the computer, remove the battery ( ), hard disk ( ), RAM ( ), CD Device ( 2 - 12 ), Bluetooth module ( page 2 - 14...

  • Page 55: Removing The Lcd Module

    Disassembly Removing the LCD Module page 2 - 8 page 2 - 9 page 2 - 10 page 1. Turn off the computer, remove the battery ( ), hard disk ( ), RAM ( ), CD Device ( 2 - 12 ), Bluetooth module ( page 2 - 14 ), Wireless LAN module (...
  • Page 56 Disassembly 2 - 34...

  • Page 57: Part Lists

    Part Lists Appendix A:Part Lists This appendix breaks down the D400P/D410P series notebook’s construction into a series of illustrations. The compo- nent part numbers are indicated in the tables opposite the drawings. Note: This section indicates the manufacturer’s part numbers. Your organization may use a different system, so be sure to cross-check any relevant documentation.

  • Page 58: Part List Illustration Location

    Part Lists Part List Illustration Location The following table indicates where to find the appropriate part list illustration. Table 1 - 1 Part List Illustration Part 400P 410P Location page A - 3 page A - 13 page A - 4 page A - 14 Bottom page A - 5...

  • Page 59: Top (400P

    Part Lists Top (400P) Figure 1 Top (400P) Top (400P) A - 3...

  • Page 60: Bottom (400P

    Part Lists Bottom (400P) Figure 2 Bottom (400P) A - 4 Bottom (400P)

  • Page 61: Lcd 14" (400P

    Part Lists LCD 14" (400P) Figure 3 LCD 14" (400P) LCD 14" (400P) A - 5...

  • Page 62: Lcd 15" (400P

    Part Lists LCD 15" (400P) Figure 4 LCD 15" (400P) A - 6 LCD 15" (400P)

  • Page 63: Cd-Rom Drive (400P

    Part Lists CD-ROM Drive (400P) Figure 5 CD-ROM Drive (400P) CD-ROM Drive (400P) A - 7...

  • Page 64: Cd-Rw Drive (400P

    Part Lists CD-RW Drive (400P) Figure 6 CD-RW Drive (400P) A - 8 CD-RW Drive (400P)

  • Page 65: Combo Drive (400P

    Part Lists Combo Drive (400P) Figure 7 Combo Drive (400P) Combo Drive (400P) A - 9...

  • Page 66: Dvd-Rom Drive (400P

    Part Lists DVD-ROM Drive (400P) Figure 8 DVD-ROM Drive (400P) A - 10 DVD-ROM Drive (400P)

  • Page 67: Floppy Disk Drive (400P

    Part Lists Floppy Disk Drive (400P) Figure 9 Floppy Disk Drive (400P) Floppy Disk Drive (400P) A - 11...

  • Page 68: Hard Disk Drive (400P

    Part Lists Hard Disk Drive (400P) Figure 10 HDD Drive (400P) A - 12 Hard Disk Drive (400P)

  • Page 69: Top (410P

    Part Lists Top (410P) Figure 11 Top (410P) Top (410P) A - 13...

  • Page 70: Bottom (410P

    Part Lists Bottom (410P) Figure 12 Bottom (410P) A - 14 Bottom (410P)

  • Page 71: Lcd 14" (410P

    Part Lists LCD 14" (410P) Figure 13 LCD 14" (410P) LCD 14" (410P) A - 15...

  • Page 72: Lcd 15" (410P

    Part Lists LCD 15" (410P) Figure 14 LCD 15" (410P) A - 16 LCD 15" (410P)

  • Page 73: Cd-Rom Drive (410P

    Part Lists CD-ROM Drive (410P) Figure 15 CD-ROM Drive (410P) CD-ROM Drive (410P) A - 17...

  • Page 74: Cd-Rw Drive (410P

    Part Lists CD-RW Drive (410P) Figure 16 CD-RW Drive (410P) A - 18 CD-RW Drive (410P)

  • Page 75: Combo Drive (410P

    Part Lists Combo Drive (410P) Figure 17 Combo Drive (410P) Combo Drive (410P) A - 19...

  • Page 76: Dvd-Rom Drive (410P

    Part Lists DVD-ROM Drive (410P) Figure 18 DVD-ROM Drive (410P) A - 20 DVD-ROM Drive (410P)

  • Page 77: Floppy Disk Drive (410P

    Part Lists Floppy Disk Drive (410P) Figure 19 Floppy Disk Drive (410P) Floppy Disk Drive (410P) A - 21...

  • Page 78: Hard Disk Drive (410P

    Part Lists Hard Disk Drive (410P) Figure 20 HDD Drive (410P) A - 22 Hard Disk Drive (410P)
  • Page 79 Schematic Diagrams Appendix B:Schematic Diagrams This appendix has circuit diagrams of the D400P/D410P notebook’s PCB’s. The following table indicates where to find the appropriate schematic diagram. Table 1 Diagram - Page Diagram - Page Diagram - Page Schematic System Block Diagram - Page B - 2...

  • Page 80: Schematic Diagrams

    Schematic Diagrams System Block Diagram D400 System Block Diagram NORTHWOOD CLOCK GENERATOR SOCKET - 478 Host Bus GTL+ & AGTL DDR INTERFACE Sheet 1 of 41 TV-OUT SiS 302LV SiS M650 System Block VB-LINK Diagram 702 mBGA PANEL CRT PORT Ultra 66/100/133 M I I I/F HDD/CD-ROM CON...
  • Page 81 Schematic Diagrams Socket 478 1 of 2 HD#[0..63] HD#[0..63] [5] VCC_CORE JCPU1A HA#[3..31] HD#0 HA#[3..31] [3,5] HD#1 HD#2 HD#3 HA#31 HD#4 HA#30 HD#5 HA#29 HD#6 HA#28 HD#7 HA#27 HD#8 HA#26 HD#9 HA#25 HD#10 HA#24 HD#11 HA#23 HD#12 HA#22 HD#13 HA#21 HD#14 HA#20 HD#15...

  • Page 82: Socket 478 & Itp 2

    Schematic Diagrams Socket 478 & ITP 2 of 2 VCC_CORE 49.9_1% CPUGTLVREFA R275 CPUGTLVREFB 49.9_1% C316 C313 C330 R276 C346 C349 C112 220P 220P 100_1% 220P 220P 100_1% CPU SIGNAL TERMINALION VCC_CORE VCC_CORE CLOSE TO CPU JCPU1B FERR# R274 4.7uH_SMD_30% 62_1% IERR AE23...

  • Page 83: Clock Generator

    Schematic Diagrams Clock Generator Main Clock Generator Damping Resistors Place near to the +3VS Clock Outputs By-Pass Capacitors Place near to the Clock FCM2012V121 CLOCK GEN (650) Outputs CLK_VCC3 VDDREF CPU-1 RP44 HCLK-CPU HCLK-CPU 49.9_1% HCLK-CPU [3] C401 VDDZ CPUCLK0 CPU-2 C102 C103...

  • Page 84: M650 (Host/Agp) 1

    Schematic Diagrams M650 (Host/AGP) 1 of 4 AAD18/AHSYNC AAD30/BHSYNC 22(R) 22(R) VAHSYNC [10] VBHSYNC [10] [30] AAD18/AHSYNC [30] AAD30/BHSYNC AAD17/AVSYNC 22(R) AAD31/BVSYNC 22(R) AAD16/VADE VAVSYNC [10] VBVSYNC [10] [30] AAD17/AVSYNC [30] AAD31/BVSYNC AAD16 [10,30] AAD27/VBDE AAD27 [10,30] R264 HNCOMP AAD28/VBCTL0 22(R) VBCLK [10] AAD28 [10,30]...

  • Page 85: M650 (Memory For Ddr) 2

    Schematic Diagrams M650 (Memory for DDR) 2 of 4 /RMD[0..63] /RMD[0..63] [7,8] /RDQM[0..7] /RDQM[0..7] [7,8] /RDQS[0..7] /RDQS[0..7] [7,8] /RMA[0..14] /RMA[0..14] [7,8] /RCS#[0..5] /RCS#[0..5] [7,8] CKE[0..5] CKE[0..5] [7] Rs place close to DIMM1 BGA1B +2.5V /RMD4 RP46 AJ23 /RMD5 AG22 DQM0 /RDQM0 AH21 /RMD6...

  • Page 86: M650 (& Crt Out) 3

    Schematic Diagrams M650 (& CRT Out) 3 of 4 BGA1C SIS M650 NOTE: This page is for universal PCB design( suitable for both 645 or 650) ZCLK0 ZCLK0 ZCLK REFCLK0 NB Hardware Trap Table VOSCI REFCLK0 [4] ZUREQ [13] ZUREQ ZUREQ ZDREQ embedded pull-low...

  • Page 87: M650 (Power) 4

    Schematic Diagrams M650 (Power) 4 of 4 +3VS +3VS +1.8VS +3VS C360 +1.8V 10UF/10V 0.1UF C412 C410 C374 BGA1D 10U(0805) 10UF/10V 0.1UF C427 C423 C381 +1.8V AUX1.8 AUX3.3 0.1UF C426 C395 C367 0.1UF 0.1UF 0.1UF +1.8VS C382 C681 0.1UF +3VS +1.8VS C363 0.1UF...

  • Page 88: Ddr Memory Dimm

    Schematic Diagrams DDR Memory DIMM +2.5V /RMA0 /RMD0 /RMA0 +2.5V /RMA1 /RMD1 /RMA1 /RMA2 /RMD2 /RMA2 RP20 /RMA3 /RMD3 /RMA3 CKE4 /RMA4 /RMD4 /RMA4 CKE2 /RMA5 /RMD5 /RMA5 CKE3 /RMA6 /RMD6 /RMA6 CKE5 /RMA7 /RMD7 /RMA7 /RMA8 /RMD8 /RMA8 8P4R-470 /RMA9 /RMD9 /RMA9...

  • Page 89: Ddr Sstl-2 Termination

    Schematic Diagrams DDR SSTL-2 Termination SSTL-2 Termination Resistors MD/DQM(/DQS) SSTL-2 MA/Control SSTL-2 SSTL-2 OD 2.5V /RMD[0..63] /RMD[0..63][6,7] /RDQM[0..7] /RDQM[0..7][6,7] +1.25VS +1.25VS /RDQS[0..7] /RDQS[0..7][6,7] /RMA[0..14] /RMA[0..14] [6,7] /RCS#[0..5] /RCS#[0..5] [6,7] /RMA2 /RMD0 /RMD1 /RMA0 /RMA12 /RDQS0 /RSRAS# /RMD2 [6,7] /RSRAS# RP63 8P4R-33 RP34 8P4R-33...

  • Page 90: Lvds Interface (Sis302Lv

    Schematic Diagrams LVDS Interface (SiS302LV) C248 33PF(R) +3VS COMPOSITE Z1301 R211 0(R) [30] COMPOSITE LVDD1 FCM1608K121(R) R212 [30] FCM1608K-121T07 JTV1 10U/10V(R) 0.1UF 0.1UF LGND [30] 2.7UH DA204U(R) DA204U(R) R213 C250 33PF(R) R202 C261 C249 C262 C251 330PF 330PF +3VS 330PF 330PF LVDD2 SVIDEO CON...

  • Page 91: Panel Con & Led Indicator

    Schematic Diagrams Panel Con & LED Indicator LCDVCC LCDVCC FCM2012V-121 FCM2012V-121 +3VS C322 C284 LCDVCC 4800 JLCD1 0.1UF 0.1UF +3VS TXOUT-LN0 TXOUT-UN0 C337 C338 TXOUT-LP0 TXOUT-UP0 R278 4.7U(0805) 0.1UF TXOUT-LN1 TXOUT-UN1 C285 C286 TXOUT-LP1 TXOUT-UP1 R301 0.1UF 4.7U(0805) Z245 TXOUT-LN2 TXOUT-UN2 TXOUT-LP2 TXOUT-UP2...

  • Page 92: Pci/Ide/Hyperzip) 1

    Schematic Diagrams 962 (PCI/IDE/HyperZip) 1 of 4 AD[0..31] IDESAA[0..2] [19,20,25] AD[0..31] IDESAA[0..2] [14] IDECS#A[0..1] IDECS#A[0..1] [14] IDESAB[0..2] IDESAB[0..2] [14] +1.8VS IDECS#B[0..1] IDECS#B[0..1] [14] R118 BGA2A C151 C150 +3VS 0.01UF 0.1UF IDEAVDD REQ4# PREQ#4 IDEAVSS REQ3# RP32 REQ2# PREQ#3 ICHRDYA [25] REQ2# ICHRDYA [14] FRAME#...

  • Page 93: Misc Signals) 2

    Schematic Diagrams 962 (Misc Signals) 2 of 4 BGA2B Programable on-die pull-high strength for CPU_S: ( Infinite, 150, 110, 56 Ohm) R102 4.7K NEED NOT to place OSC25MHI INIT# close to 96X +3VS INIT# INIT# OSC25MHO A20M# A20M# A20M# RN11 SMI# SMI# SMI#...

  • Page 94: Usb I

    Schematic Diagrams 962 (USB I/F) 3 of 4 BGA2C 1394_MA2/EESK UCLK48M UCLK48M[4] EESK(GPI21) USBCLK48M 1394_MA1/EEDI EEDI(GPI22) 1394_MA0/EEDO UV3- -DATA3 -DATA3 [17] EEDO(GPI23) 1394_EECS UV0+ EECS(GPI24) UV0+ UV0+ [17] UV0- UV3+ +DATA3 UV0- [17] +DATA3 [17] UV0- UV1+ UV1+ [17] UV1+ UV1- UV1- [17] UV1-...

  • Page 95: Power & Rtc) 4

    Schematic Diagrams 962 (Power & RTC) 4 of 4 +1.8VS +1.8V +3VS C512 C511 C351 C406 C526 C489 C490 C505 C508 C469 C147 C482 C476 C501 C477 C127 0.1UF 0.1UF 10UF/10V 10UF/10V 0.1UF 0.1UF 0.1UF 0.1UF 0.1UF 0.1UF 0.1UF 10UF/10V BGA2D +1.8VS VDDZ...

  • Page 96: Hdd/Combo Connector

    Schematic Diagrams HDD/Combo Connector RP41 IDEDB7 /2IDB7 [13] IDEDB7 IDEDB6 /2IDB6 /2IDB8 IDEDB8 [13] IDEDB6 IDEDB8[13] IDEDB5 /2IDB5 /2IDB9 IDEDB9 [13] IDEDB5 IDEDB9[13] +3VS IDEDB4 /2IDB4 /2IDB10 IDEDB10 [13] IDEDB4 IDEDB10[13] /2IDB11 IDEDB11 JCDROM1 IDEDB11[13] MICHRDYB CD-L CD-R R277 4.7K 8P4R-10 [26] CD-L...

  • Page 97: Usb Port

    Schematic Diagrams USB Port 560K 470K OC0# OC0# USBVCC0 +5VS C309 C308 FCM2012V121 1.1A F1AJ3 0.1UF L101 10UF/10V JCCD1 -DATA3 0.1UF -DATA3 FCM1608K121 L102 +DATA3 +DATA3 UV0- -DATA0 FCM1608K121 UV0- CCD CON NEAR CCD CON. C848 UV0+ +DATA0 UV0+ C847 47P(R) 47P(R) C101...

  • Page 98: Pcmcia Ene1410

    Schematic Diagrams PCMCIA ENE1410 B_VCC C627 C619 C608 C602 C601 C644 C617 C632 C595 C646 0.1UF 0.1UF 0.1UF 0.1UF 0.1UF 0.1UF 0.1UF 0.1UF 10UF/10V 10UF/10V C618 C645 0.1UF 0.1UF JPCM1 B_VCC VPPD0 B_CD0 [20] VPPD0 VPPD1 B_CD1 [20] VPPD1 VCCD0# B_CD2 [20] VCCD0#...

  • Page 99: Pcmcia Power

    Schematic Diagrams PCMCIA Power +5VS C563 0.1UF JMDC1 +12V +3VS MONO_OUT AUDIO_PD PHONE MONO_PHONE PHONE [26] R431 AUXR B_VCC BVCC AUXL C588 10K(R) BVCC CDGND C590 C591 R423 BVCC CD_R 0.1UF CD_L 0.1UF 4.7U(0805) 8.2K(R) P_DN VDD3 3.3V AC_SYNC AC_SYNC [15,26] 3.3V SYNC AC_SDOUT...

  • Page 100: 1394 Phy Tsb41Lv01

    Schematic Diagrams 1394 PHY TSB41LV01 +3VS PHY3V BLM21P221SGPTM00-03 C573 C582 C583 C581 C586 C580 C585 C572 0.01UF 0.01UF 0.01UF 0.1UF 0.1UF 0.1UF 0.1UF 4.7U(0805) Sheet 21 of 41 R170 6.34K_1% R176 1394 PHY PHY3V Z216 Z240 TSB41LV01 R422 1K(R) VDD5 PHYISO# R439 4.7K...

  • Page 101: Lpc Super I/O

    Schematic Diagrams LPC Super I/O +3VS C530 C539 C529 0.1UF 0.1UF 0.1UF +3VS SA10 SA11 SA12 PD[0..7] PD[0..7] [23] R228 +5VS SA13 +5VS LPC_AD[0..3] [15,24] LPC_AD[0..3] SA14 SA15 LPC_AD0 LAD0 PD0/INDEX# SA16 LPC_AD1 FLASH# LPC_AD2 LAD1 PD1/TRK0# R227 BIOSCS# SA17 LPC_AD3 LAD2 PD2/WP#...

  • Page 102: Lpt/Com Port

    Schematic Diagrams LPT/COM Port VDD5 VDD3 C260 0.1UF R223 100K PME# C247 PME# [19,22,24,25] 0.1UF(K%) C246 C268 COM1RI 2N7002 C267 0.1UF(K%) 0.1UF(K%) JCOM1 1SS355 0.1UF(K%) R224 RN10 100K SOUTA [22] SOUTA T1IN T1OUT RTSA# [22] RTSA# T2IN T2OUT DTRA [22] DTRA T3IN T3OUT...
  • Page 103 Schematic Diagrams LPC H8 VDD5 R508 0(0805)(R) 3VH8 3VH8 L135 R509 0(0805) VDD3 3VH8 C212 4.7U(0805) C255 0.1UF +5VS C575 1.1A FH50ACB321611T 3VH8 F1AJ3 C570 C571 0.1UF 0.1UF 0.1UF 0.1UF C569 C562 C561 C202 RP39 KB-SI3 0.1UF 0.1UF 0.1UF 10UF/10V JPS1 KB-SI2 KB-SI4...

  • Page 104: Lan Rtl8100Bl

    Schematic Diagrams LAN RTL8100BL VCTRL LANVDD3 LANVCC25 LANVDD3 2SB1198K C431 C432 C404 C384 C403 0.1UF 0.1UF 0.1UF 0.1UF 0.1UF 10UF/10V 0.1UF 10UF/10V DE-COUPLE CAPS PLEASE CLOSE CHIP POWER PIN *For RTL8100C application, all bead must be rated 300mA/100ohm@100Mhz The maximum voltage drop when on should be less than 0.3V LANVDD3 FCM2012V121 C362...

  • Page 105: Audio Codec Alc201A

    Schematic Diagrams Audio Codec ALC201A For some crystal, FCM1608K-121 VDDA +3VS U18 78L05(SO8)(R) the bias resistor is needed VDDA R486 C613 C616 C637 C638 1M(R) C672 R482 10UF/10V 0.1UF 0.1UF 10UF/10V 0(R) C665 C664 0.1UF(R) 0.1UF 4.7U(0805) AGND LOUT-L C642 LOUT-R 24.576MHz C615...

  • Page 106: Audio Out & Off Board Connectors

    Schematic Diagrams Audio Out & Off Board Connectors VDDA JAUDIO1 SPDIF OUT R192 INTMIC AUDIO_JACK INTMIC [11] 2.2K C225 SPDIF FCM1608K-121 [26] SPDIF 0.1UF C234 C226 680P R191 10UF/10V 2.2K JAUDIO2 BK1608HS330 AUDIO_JACK AGND Vrefout R190 2.2K(R) MIC IN [26] Vrefout MIC1 R196...

  • Page 107: System Power Control

    Schematic Diagrams System Power Control U14B R462 U15B +12VS U14C S3AUXSW# SUSB# 74LVC14 SUSB# [13,24] PSON# [15,29] PSON# U14D R197 74(A)HC08 100K SI2301 SLP S3 74LVC14 C235 4.7UF/25V PSON 74LVC14 R654 PSON [39] 100K U14E PSON U15C 2N7002 U14F 74LVC14 [6,13] S3AUXSW# SUSC# [24]...

  • Page 108: Fan Control And Speedstep

    Schematic Diagrams Fan Control and SpeedStep FAN_VCC FCM2012V121 MAIN FAN C833 100U/16V DIP R410 H_DPSLP# JFAN1 24.9K H_DPSLP# [2,36] R409 F01J2E 4.7K FAN_SEN [24] FAN_SEN R517 FI-S03P-HF 3904 +3VS CPUSTP# CPUSTP# [4,15] C522 FAN1-ON R367 1SS355 [24] FAN1-ON 0.1UF 2SD1834 C515 0.1UF(R) R182...

  • Page 109: Vcore

    Schematic Diagrams VCORE PR131 PR63 FCM1608K121 INTVCC SYS5V PC84 PR151 PR152 PR20 PR21 PC76 PC82 PC78 PC77 PC80 PC79 PC81 10U/25V 10U/25V 10U/25V 0.1U 0.1U 0.1U 10U/25V 100K 100K [29] VR_PWRGD VID0 [2,15] VID1 SENSE1- SENSE1+ PC18 1000PF RB751V RB751V RB751V PC85 VID1...

  • Page 110: Ddr Power

    Schematic Diagrams DDR Power VDDP SYS5V PR96 PR95 PC113 PC52 PD16 RB751V PD17 PC106 RB751V PC34 0.1uF/25V 10U_1210 PC132 1000P PGOOD1 PGOOD2 PC133 1000P VCCA1 PQ70 VDDP1 VCCA2 2.5V Si4800 PC49 PC107 PR93 PC33 0.1uF/25V ILIM1 TON1 PR103 20K 1% 10U_1210 PR105 750K...

  • Page 111: System

    Schematic Diagrams System PR108 VIN1 PC57 PC56 0.1A 12VR 0.1U 10U/25V PC62 PC58 PC123 PC55 0.1U 10U/25V 0.1U PD18 PC54 PC119 10U/16V PD22 PC63 RB751V 0.1U 1U/50V_0805 11FS2 10U_1210 PC53 PD19 PQ43A 0.1U RB751V AO4900 PC122 BST3 0.1U VDD3 SYS3V PR86 PR109 PQ44A...

  • Page 112: Charger

    Schematic Diagrams Charger F1J3FTP PQ40 2.5A Si4435 2.5A PC25 PC89 PC24 PR72 PD30 0.1U 10U_1210 0.1U PQ15 Si4435 PQ18 CDRH-1205-470 100m(2512) 03A04 DTA114EUA PC94 PC96 PR24 PD28 PC99 PC95 PC32 PC97 1N4148 10U/25V_DIP F1J3FTP 0.1U(0805) 0.1U(1206) 100K 100U/25V_DIP 100U/25V_DIP 0.1U(1206) PR75 PR73 PQ17...

  • Page 113: Sw Board And Hotkey

    Schematic Diagrams SW Board and HotKey VSW2 LID_SW#_10 VCN1 VIN_10 VIN_10 MPU-101-81 PWRS_10 PWRS_10 LID_SW#_10 LID_SW#_10 WEB0#_10 WEB0#_10 0.1U WEB1#_10 WEB1#_10 WEB2#_10 WEB2#_10 Sheet 34 of 41 GND_L GND_L CON8 SW Board and HotKey GND_L Hot keys,Power switch,key,Lid VIN_10 VSW1 PWRS_10 HCH STS-05-A 0.1U...

  • Page 114: Touchpad And Switch Board

    Schematic Diagrams TouchPad and Switch Board VCC5_T 10MIL VCN3 VCC5_T 10MIL VCN2 TPADDATA TPADCLK TPADDATA TPADCLK 10MIL SW_UP TP_FFC4-R SW_DOWN SW_L 0.1U SW_R Sheet 35 of 41 120P 120P 120P 0(R) TouchPad and plan GND_A GND_A Switch Board C178D83N C178D83N GND_A GND_A GND_A...

This manual is also suitable for:

D410p

Table of Contents
