User Manual
Quick Use
Quick Use
Guide
Guide
AZ1836
1
Choosing Power Supply
a
Connect the AC power cord to the
AC~ Mains inlet and the wall socket.
-OR-
b Open the battery door and insert 6 x C
batteries (not included).
2
Listening to the Radio
a
Push the source selector to FM or AM.
b Turn TUNING to tune to a station.
3
Playing a disc
This player plays Audio Discs including
CD-R/CD-RW, MP3-CD. and WMA.
a
Adjust the source selector to CD/USB.
b Press CD/USB to enter CD mode if
"USB" is displayed.
c
Open the disc door.
d Insert a disc with the printed side facing up
and close the door.
e Press 38 to start playback.
To stop disc playback, press 9.
f
4
Playing a USB device
a
Push the source selector to CD/USB.
b Press CD/USB to enter USB mode if
"USB" is NOT displayed.
c
Plug a compatible USB mass storage
device to AZ1836's USB port marked
d Press 2; on your AZ1836 to start play.
6 x R14 • UM-2 • C-CELLS
1b
R-14, UM-2 or C-cells
(not included)
2a
3c
3a
4a
3e
5c
4d
3f
3e
3b
4b
4d
4c
5b
5
CD ripping
a
Follow steps a-d from "3 Playing a disc".
b Plug a USB mass storage device.
To record one
c1 Select the track you want to record.
c2 Press once or repeatedly USB REC (or REC
on the remote) until ONE appears, flashing.
To record all
c1 Press repeatedly USB REC (or REC on the
.
remote) until ALL appears, flashing.
d Disc playback will start automactically.
Source selector
Slide to select
function: CD/MP3
(or USB mode), FM or AM
∞
§
,
Briefly press to skip to
the beginning of the
current/previous/
later disc track;
During disc playback,
1a
press and hold to find a
particular passage
backward/forward
38
Press to start or pause
disc/USB playback
PROG
Use to program disc
tracks and review a disc
program
2b
9
Press to stop disc/USB
playback, or erase a disc
program
USB REC
Copy one file or all files of a
disc to an external portable
USB storage device/MP3 player
CD/USB
Press to enter disc or
USB mode
Telescopic antenna
Improves FM reception
Display
Shows disc/USB functions
OPEN•CLOSE
Push to open the disc
door
TUNING
Turn to tune to a
station
VOLUME
Turn to adjust volume
level
ALBUM +/-
For MP3-CD/USB/WMA
play: Press to select
albums
MODE
Press to select different
play modes, such as
REPEAT or SHUFFLE
(random order)
USB Port
Connects an external
USB mass storage device
Removing the insulation plastic tab
