Service Guide
Specifications
Power Source:
220-240V AC, 50/60 Hz
Power Consumption:
Normal use: 380W
Stand-by condition: 1.7W
Power off condition: 0.7W
Plasma Display panel:
Drive method AC type
42-inch, 16:9 aspect ratio
Screen size:
42" (106cm) diagonal
920mm(W) x 518mm(H) x 1056mm(diagonal)
No. of pixels
408,960(852 (W) x 480 (H)) [2,556 x 480 dots]
Operating conditions:
Temperature:0°-40°C
Humidity: 20%-80%
Applicable signals
Colour System: NTSC, PAL, PAL-60, SECAM (Modified NTSC
signals cannot be displayed.)
Scanning fomrat: 525i, 525p, 625i, 625p, 1080i, 1080p
PC signals: VGA, S-VGA (compressed), Horizontal scanning fre-
quency 15.6-50 kHz
Connection terminals:
AV
VIDEO IN (BNC)
S-VIDEO IN
(Mini DIN 4-pin)
AUDIO IN L-R
(RCA pin jack x 2)
VIDEO OUT (BNC) 1.0V p-p (75Ω)
COMPONENT Y/G
/RGB
P
/B
B
P
/R
R
HD
VD
AUDIO IN L-R
(RCA pin jack x 2)
1.0V p-p (75Ω)
(with 75Ω or high-impedan-
ce auto select)
Y: 1V p-p (75Ω),
C: 0.286V p-p (75Ω)
0.5Vrms
(bridge output)
1.0V p-p
(including synchronization)
±0.35V p-p
±0.35V p-p
±1.0-5.0V p-p
±1.0-5.0V p-p
0.5Vrms
Wide Plasma Display
TC-42PD1F
GP2D Chassis
PC
VIDEO (High-density D-sub 15pin)
AUDIO
SPEAKERS
For TY-SP42PD1E only.
(8Ω)
SERIAL
External control terminal
TUNER
REMOTE
Accessories Supplied:
Remote control Transmitter
Battery (2 x R6 (UM3) Size)
RCA-BNC adaptor plug
Cleaning cloth
Ferrite sleeve
Guarantee Card
Optional Accessories:
Pedestal
Wall stand
Mobile stand
Wall-hanging bracket (vertical)
Wall-hanging bracket(angled)
Ceiling unit
RS-232C Conversion cable
Dimensions(W x D x H):
1030mm x 633.5mm x 89mm
Weight (Mass):
Note:
Disign and Specifications are subject to change without notice.
Weight and Dimensions shown are approximate.
1999 Matsushita Electric Industrial Co.,Ltd.
All right reserved. Unauthorized copying and
distribution is a violation of law.
ORDER NO.ITD9906022C2
0.5Vrms (3mm mini jack)
TNQE178
TJS1A4270
TPEX006
TSK1027
TY-ST42PT1E
TY-ST42PW1E
TY-ST42PF1E
TY-WK42PV1E
TY-WK42PR1E
TY-CE42PS1E
TY-SCP02RS1E
33.0kg net (main unit only)
36.4kg (with speakers)
