- Page 1 1 5 ” F L A T P A N E L D I S P L A Y REFERENCE MANUAL...
- Page 2 © 2002 Sylvania Computer Products. All rights reserved. This manual may not be copied in whole or in part without the written consent of Sylvania Computer Products. Sylvania Computer Products is not responsible for printing or clerical errors. Product specifications are subject to change without notice. Windows® is a registered trademark of Microsoft Corporation.
-
Page 3: Table Of Contents
Table of Contents FCC Compliance Statement Safety Instructions Installation Removing Base Controls & Functions Specifications Display Mode Troubleshooting... -
Page 4: Fcc Compliance Statement
FCC Compliance Statement This equipment has been tested and found to comply with the limits for a Class B digital device, Pursuant to part 15 of the Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. -
Page 5: Safety Instructions
Safety Instructions Power • Use the type of power indicated on the marking label. Plugs • Do not remove any parts of the Display’s three-pronged power plug. • Disconnect the power plug from the AC outlet when the Display will not be used for an indefinite period of time. -
Page 6: Installation
Installation The SF150 display incorporates a 15” color active matrix thin-film-transistor (TFT) liquid crystal display to provide superior display performance. A maximum resolution of XGA 1024x768 is ideal for displaying graphics and images. Other outstanding features that enhance this LCD Display’s performance are Plug &... -
Page 7: Power Button
Installation Taking a closer look 1. Function “1” Pressing this button will activate the On-Screen Display and cancel sub-menus. 2. Up Pressing this will move your selection up or increase the adjustment values. 3. Down Pressing this will move your selection down or decrease the adjustment values. - Page 8 Installation Display Angle FULL 90° For viewing clarity, you can tilt the LCD to full 90 degrees. CAUTION: In order to protect the LCD, be sure to hold the base when you adjust the LCD. Do not touch the screen.
- Page 9 Installation Connecting the SF150 to your computer 1. Connect the video input into the video outlets on your computer.
- Page 10 Installation Connecting the LCD15S to your computer 2. Plug the power cord monitor and onto the power outlet. 3. Press the power buttons on both your computer and the monitor.
-
Page 11: Removing Base
Installation Removing the base for wall or arm mounting Remove all 6 screws to remove base. -
Page 12: Controls & Functions
Controls & Functions 48.3KHz/60.0Hz 1024 768 Contrast / Brightness Auto Adjust Phase / Clock H. Position / V. Position Sharpness Color Adjustment Language OSD Function Text Mode Memory Recall :EXIT SELECT Press the Up or Down buttons to activate these menus. The next few pages will describe each controls and functions. - Page 13 Controls & Functions Contrast/Brightness Language Selecting the Contrast function allows you to make Selecting this function allows you to change a different adjustments to the luminosity level of display. Selecting language for your On-Screen Display. the Brightness function allows you to make adjustments to (English, French, German, Italian, and Spanish) the black level of the display.
- Page 14 Controls & Functions Power LED Display and Power Saving General Power Saving Mode When the SF150 is on, the LED lights green. When the SF150 is in Power Saving, the LED lights orange. (see below) Mode Power LED Color Power...
-
Page 15: Specifications
Specifications Model SF150 LCD Display 15” TFT Active Matrix Panel, Anti-Glare, Hard Coated Display Size 304mm (H) x 228mm (V) Pixel Pitch 0.297mm (H) x 0.297mm (V) Max. Resolution XGA 1280 x 1024 Contrast Ratio 350:1 (Typical) Brightness 200 cd/m²... -
Page 16: Display Mode
Display Modes Resolution Type H.Scan V.Scan Polarity (KHz) (Hz) 720x350 31.469 70.087 720x400 31.469 70.087 640x480 31.469 59.940 640x480 35.000 66.700 640x480 VESA72 37.861 72.809 640x480 VESA75 37.500 75.000 800x600 SVGA 35.156 56.250 800x600 SVGA 37.879 60.317 800x600 VESA72 48.077 72.200 800x600 VESA75... -
Page 17: Troubleshooting
Troubleshooting The SF150 does not respond after I turn on the system. • Check if the Power Switch of the Display is turned on. • Turn off the power and check the Display’s power cord and signal cable for proper connection. - Page 18 Access Sylvania Computer Products website to download the latest drivers*, get latest news, view new and upcoming products. You can even register your product online! This monitor does not require any device driver to function. * You may purchase a driver CD by calling (714) 751-8405 Extension 4024 for Parts Department.
