Page 2: Subwoofer Parameters
1 Ohm at the amplifier, (See Fig. 1) if your amplifier is rated to drive 1 Ohm in bridged or one-channel operation. If each of two dual-voice coil 2-Ohm woofers are connected in parallel and then wired to each PSPL-10 PSPL-12 300 Watts... - Page 3 other in parallel, a 0.5-Ohm monaural output would result (See Fig. 2). On the other hand, if your amplifier is rated for 2-Ohm operation in bridged or one-channel operation, series-connect the woofer voice coils (See Fig. 3). If the amplifier is rated for 4 Ohms, interconnect the voice coils of the woofer in series as shown to obtain an 4-Ohm mon- aural output (See Fig.
-
Page 4: Installation Recommendations
ENCLOSURE CONSTRUCTION RECOMMENDATIONS To enhance subwoofer performance, the following general recommendations should be addressed when constructing the speaker enclosure: Use 3/4" MDF for your construction material Glue all joint seams Screw all joints tight... - Page 5 PSPL-10 Parameters Series 38.88 Hz 3.97 Ohms 31.88 Ohms 3.89 0.48 0.43 8.69 Ohms Vas (Sd) 29.44 Ltrs Mms (Sd) 68.43Gms Cms (Sd) 245 M/Ntn Bl (Sd) 11.31 Tesla-M SPLref (Sd) 87.4 dB PSPL-12 Parallel Series 38.40 Hz 32.44 Hz 0.95 Ohms...
- Page 6 10" W (inside) x 16.125" H (inside) x 6.125" D (inside) (sealed side) x 6" D (inside) (vented side) © 2000 Audiovox Corporation, Hauppauge, NY 11788 (Vb) Box Volume = 0.77 Cu. Ft. F3: 64 Hz Dimensions: 13.5" W x 17.75" H x 5.5" D (Vb) Box Volume = 1.68 Cu.
