Summary of Contents for Citizen H504
-
Page 2: Table Of Contents
CONTENTS 1. Features 1. Features ..................... 3 This watch is a solar-powered watch that contains a solar cell in its face that 2. Before Using ....................4 drives the watch by converting light energy into electrical energy. It is equipped 3. -
Page 3: Before Using
2. Before Using 3. Displays and Buttons This watch is a solar-powered watch. Please fully charge the watch before Hour hand using by exposing it to light. Chronograph second hand A secondary battery is used in this watch to store electrical energy. This secondary battery is a clean energy battery that does not contain mercury or Button (A) Chronograph minute... -
Page 4: Functions Unique To Solar-Powered Watches
4. Functions Unique to Solar-Powered [Insufficient Charging Warning Feature] [Stopped] Watches The second hand switches from 1-second All hands stop moving interval movement to 2-second interval [Normal Time Display] movement When the watch becomes insufficiently charged, the following warning features If insufficiently If watch is continued to be charged... -
Page 5: Quick Start Feature
[Insufficient Charging Warning Feature] [Quick Start Feature] When the capacity of the secondary battery decreases as a result of light not If the watch has stopped as a result of being insufficiently charged, the second shining on the solar cell, the second hand switches from 1-second interval hand will begin 2-second interval movement and the watch will begin to run movement to 2-second interval movement (insufficient charging warning about 10 seconds after the watch is exposed to light (approx. -
Page 6: When The Watch Has Stopped Due To Insufficient Charging
[When the Watch has Stopped due to Insufficient Charging] 5. General Reference for Charging Times When the capacity of the secondary battery decreases as a result of the solar cell not being exposed to light, the watch will stop due to being insufficiently Recharging time varies according to the watch model (such as the color of the dial). -
Page 7: Handling Precautions
6. Handling Precautions • When charging using the light from an incandescent lamp, charge while being careful that the watch does not become excessively hot by placing at a distance of at least 50 cm (20in) from the lamp. <Try to Keep the Watch Charged at All Times> Please note that if you wear long sleeves, the watch can easily become Handling of Secondary Battery insufficiently charged as a result of the watch being covered and not being... -
Page 8: Replacing The Secondary Battery
7. Replacing the Secondary Battery 8. Setting the Time and Date Unlike ordinary silver-based batteries, the secondary battery used in this watch In the case the crown is of the screw-lock type, loosen the screw by turning the does not have to be periodically replaced since it is able to be charged and crown to the left before operating the crown, and after having returned the discharged repeatedly. -
Page 9: Setting The Date
[Hint for Accurately Setting the Time] • The date is based on a 31-day calendar. The date must be changed from After stopping the second hand at the 0 seconds position, turn the minute hand the last day of the month to the first day of the following month for those 4-5 minutes past the correct time and then turn it back to the correct time. -
Page 10: Using The Chronograph
9. Using the Chronograph Note: • Do not subject the chronograph to strong impacts while chronograph timing is in progress. Subjecting the watch to a strong impact during chronograph timing or when the chronograph has stopped The chronograph function of this watch is able to measure and display elapsed automatically after 60 minutes have elapsed can cause the time up to 59 minutes, 59 seconds in 1 second units. -
Page 11: Zero Positioning Of Chronograph Second Hand
10. Zero Positioning of Chronograph [Chronograph Second Hand Zero Positioning] 1. Pull the crown out to the time correction Chronograph minute hand Second Hand position. Chronograph second hand 2. 1) Press button (A) for 3 seconds or more and release it, the watch enters When resetting the chronograph, if the chronograph second hand does not the chronograph second 0 position return to the 0 seconds position or if the chronograph second had has shifted... -
Page 12: Precautions
11. Precautions For correct use within the design limits of the watch, confirm the level of water- resistance of your watch, as indicated on the dial and case, and consult the table. CAUTION: Water-resistance performance There are several types of water-resistant watches, as Examples of use shown in the following table. - Page 13 NOTE: Avoid using solvents (thinner, benzine, etc.), as they may mar the finish. Citizen Service Center for repair. Leaving the watch in such a state will allow corrosion to form inside.
- Page 14 Other parts need to be inspected and replaced if necessary. • Do NOT place the watch close to a magnet. Ask for Citizen geuine parts upon replacement. Timekeeping will become inaccurate if you place the watch close to magnetic health equipment such as a magnetic necklace or a magnetic latch of a refrigerator door or handbag clasp or the earphone of a mobile phone.
-
Page 15: Specifications
12. Specifications 8. Continuous running times: • Fully charged to stopped without charging: About 5 months (continuous running time differ depending on which frequency 1. Caliber No.: H50* at which the chronograph is used and so forth) 2. Type: Analog solar-powered watch •...
