INSTRUCTION MANUAL
Color TFT LCD monitor
Moniteur LCD TFT couleurs
Monitor TFT LCD color
TFT-LCD-Farbmonitor
TFT LCD
カラーTFT液晶モニター
About this manual
•
This manual gives basic connections and operations instructions for 2 NTSC models (VMC-L2017, VMC-L2019) and
2 PAL models (VMC-L2017P, VMC-L2019P).
For more information on models variations, please refer to the specifications page.
•
Before installing and using this unit, please read this manual carefully. Be sure to keep it handy for later reference.
VMC-L2017/VMC-L2017P
VMC-L2019/VMC-L2019P
English
Français
Español
Deutsch
日本語
Advertisement
Table of Contents
Related Manuals for Sanyo VMC-L2017
Summary of Contents for Sanyo VMC-L2017
-
Page 1: Instruction Manual
カラーTFT液晶モニター 日本語 About this manual • This manual gives basic connections and operations instructions for 2 NTSC models (VMC-L2017, VMC-L2019) and 2 PAL models (VMC-L2017P, VMC-L2019P). For more information on models variations, please refer to the specifications page. • Before installing and using this unit, please read this manual carefully. Be sure to keep it handy for later reference. -
Page 2: Information To User
CAUTION FOR EU USERS RISK OF ELECTRIC SHOCK Please note: DO NOT OPEN Your SANYO product is designed and manufactured with high quality materials and components which can be recycled and reused. CAUTION: TO REDUCE THE RISK OF This symbol means that electrical and electronic equipment,... -
Page 3: Table Of Contents
Precautions Contents Use only the power source specified on the unit. Information to user ..........1 When not using this unit for a long period of time, or Precautions ............. 2 when cleaning it, be sure to disconnect the power plug from the AC outlet. -
Page 4: Accessories
Accessories REMOTE VGA SIGNAL CABLE POWER CORD INSTRUCTION CONTROLLER MANUAL Names of controls/parts Front View ❷ ❸ ❹ ❺ ❻ ❼ ❽ ❶ ❹ / FREEZE/AUTO Decrease the level of active function and move to 30º 30º the previous menu. Still picture function in Video mode when there is Within 7 m no OSD menu on the screen. -
Page 5: Rear & Left Side View
Rear & Left Side View Left Side View ❶ Rear View ❷ ❸ ❹ ❺ ❻ ❼ ❽ ❾ Left Side View Rear View ❶ AUDIO B ❸ POWER Audio B input for VIDEO B : Right (RED), AC power input. Left (White) ❹... -
Page 6: Remote Controller
Remote Controller ❶ POWER Turns the Power On or Off. ❶ There will be a few seconds delay before display appears. ❷ Number buttons Changes the ID for remote controller (Remote ID). ❷ While the SYSTEM ID button ❾ is pressed, enter the desired NUMBER(0 –... -
Page 7: Connecting To External Devices
Connecting to External Devices The product can be connected to external devices such as Camera, Recorder, External Monitor, etc. Camera Recorder External Monitor Recorder English... -
Page 8: Osd Menu Confi Gurations
OSD Menu Configurations Video mode No Signal Display Input Menu When there is no connection to the VGA and Video Input input, the On Screen Display will show this message. Source List : Video A Edit Name No Signal <Video mode> Move Enter Exit... -
Page 9: Picture Menu
Video mode Picture Menu Color Tone : Cool2, Cool1, Normal, Warm1, Picture Mode : Movie Warm2 Custom Color Tone : Warm2 Color Tone Size : 4:3 Cool2 Under Scan : Under Cool1 Normal Warm1 Warm2 Move Enter Exit Mode : Dynamic, Standard, Movie, Custom Move Enter Return... -
Page 10: Sound Menu
Video mode Sound Menu Picture Menu Under Scan : Over, Under Sound This menu is available when you selected “4:3” in Size. Mode : Movie Custom See “Size” on page 8. Size Over Under Move Enter Exit Mode : Standard, Music, Movie, Speech, Custom Move Enter Return... -
Page 11: Setup Menu
Video mode Setup Menu System ID : 0 – 9 Setup Language : English System ID Transparency : Medium System ID Blue Screen : On Reset Move Enter Exit Move Enter Return Language 1. Press the MENU and button to select the Setup menu. -
Page 12: Vga Mode
VGA mode Input Menu 4. Press the and ENTER button to select the Input Source List : VGA desired setting. Edit Name • This menu is available when you selected “On” in PIP. 640x480 31.5kHz/ 60Hz NN : On Move Enter Exit Source... -
Page 13: Picture Menu
VGA mode Picture Menu Color Control : Red, Green, Blue Picture Custom Color Control Color Tone : Normal Color Control Green Image Lock Blue Auto Adjustment PIP Picture Move Enter Exit Move Enter Return Custom : Contrast, Brightness 1. Press the MENU and button to select the Picture menu. -
Page 14: Sound Menu
VGA mode Sound Menu Picture Menu Auto Adjustment Sound 1. Press the MENU and button to select the Mode : Movie Custom Picture menu. 2. Press the ENTER or button. 3. Press the and ENTER button to select Auto Adjustment menu. Move Enter Exit... -
Page 15: Setup Menu
VGA mode Setup Menu Reset : Image, Color Setup Language : English Reset Transparency : Medium Image Reset System ID Color Reset Blue Screen : On Reset Move Enter Exit Move Enter Return Language 1. Press the MENU and button to select the See “... -
Page 16: Troubleshooting
Troubleshooting Before requesting service or repair, perform a check as described in the following section. If this does not work, return the unit to the place of purchase or authorized repair agent to undergo adjustment. Problem Points to check No image is displayed. •... -
Page 17: Specifi Cations
Specifications VMC-L2017/L2017P VMC-L2019/L2019P Display type SXGA a-Si TFT LCD Color system NTSC/PAL (Automatic detection) LCD display 17" active matrix 19" active matrix TFT LCD panel TFT LCD panel Viewable size (H x V) 338 x 270 mm/13.3 x 10.6 in. (4:3) 376 x 301 mm/14.8 x 11.9 in. -
Page 18: Dimensions/Angles
165˚ (Swivel) (Lift) (Tilt) Unit: mm (inch) Model VMC-L2017/L2017P 371 (14.6) 339 (13.4) 272 (10.7) 331 (13.0) 368 (14.5) 67 (2.6) 37 (1.5) 220 (8.7) VMC-L2019/L2019P 440 (17.3) 378 (14.9) 303 (11.9) 361 (14.2) 398 (15.7) 69 (2.7) About the tilt adjustment When adjusting the screen tilt, use a soft cloth to prevent damaging the screen. - Page 19 SANYO Electric Co., Ltd. AB68-00689A L8MAM/US, XE, JP, L8MAN/US, XE, JP (0807KR-TF) Printed in China...
