INSTALLATION AND MAINTENANCE INSTRUCTIONS FOR CASED PUREAIR™ MODELS PCO-12C-2, PCO-20C-2
General
The PureAir™ air purification system helps to signifi-
cantly reduce levels of airborne volatile organic
compounds, cooking odors, common household
odors, airborne dust particles, mold spores, and
pollen in residential spaces. The PureAir™ air purifi-
cation system (cased model) includes a MERV 9
pleated filter, UVA lamps, and a metal insert that is
coated with a titanium dioxide catalyst. As air enters
the system, a percentage of airborne particles and
bioaerosols, such as mold and bacteria, ranging in
size down to .3 microns, are captured by the pleat-
ed filter. The smaller airborne particles, odors, and
chemicals continue through the system. The UVA
lamp activates the catalyst on the metal insert. The
catalyst combines with water vapor in the air to form
hydroxyl radicals that destroy a percentage of the
remaining odors and chemicals.
In laboratory & field tests, we found greater than
(TVOC) within 24 hours of initial installation and
operation of the PureAir™ air purification system.
When the system is first started, it may take up to 48
hours to reduce the airborne chemicals that have
built up in your home over a long period of time.
After that period, there will be a balance between
chemicals emitted inside your home and chemicals
removed by your PureAir™ air purification system.
Please refer to the included Homeowners IAQ guide
for other measures to improve indoor air quality.
The PureAir™ air purification system is NOT intended to be used for
removal of active mold growth or continuous source of high levels
of chemicals in the air. For existing mold growth, the mold must be
appropriately removed PRIOR to installation of your PureAir™ air
purification system.
Electric shock hazard.
Can cause injury or death.
Disconnect all remote electrical
power supplies before servicing.
Access panels must be in place dur-
ing the appliance operation.
AIR CLEANERS/
FILTERS
504,745M
08/2003
WARNING
PUREAIR™ AIR PURIFICATION SYSTEM
PHOTOCATALYTIC OXIDATION TECHNOLOGY(PCO)
Shipping and Packing List
Package 1 of 1 contains:
1 - PureAir™ air purification system c/w:
1 - Metal cabinet, including insulated door
1 - One piece slide-in assembly
ballasts, with associated wiring.)
1 - MERV 9, 4" pleated filter
4 - Installed UVA lamps (PCO-12C)
6 - Installed UVA lamps (PCO-20C)
1 - Separately wrapped titanium dioxide metal insert
1 - Power cord
1 - Installation and maintenance instructions
1 - Homeowners IAQ Guide
1 - Warranty certificate
1 - Registration card
Unique Supplies
• Cotton gloves and cloth (to remove finger prints
from lamps.)
• Sealant: Aluminum foil duct tape or water based
mastic. (NOT silicone)
NOTICE
Possible odor emissions.
Odors may be present temporarily after initial start-
up, painting, cleaning, remodeling, hobby activities or
after lamp replacement.
Some occupants may notice irritation or discomfort
during this period.
If irritation or discomfort persists longer than 48
hours, unplug the PCO device and contact your
Lennox authorized dealer.
WARNING
Risk of property damage, injury, or death.
Installation, adjustments, alterations, service and
maintenance must be performed by a qualified
service technician.
HEALTHY CLIMATE
(Metal Frame and
212361-03 Rev. 1B 8/03
®
