HDUBARTK-T 1 Channel HD Analog Video UTP Transmitter/Reciever User Manual HDUBARTK-T User Manual...
Page 2
Transfer video signal in real-time via twisted-pair, active video transmission solution, max.1200m transmission distance. Notice Standard Cat5e/6 cable and 75 4 or above coax are strongly suggested for reaching the maximum transmission distance! Please use standard UTP cable and coax to ensure the stable transmission. HDUBARTK-T User Manual...
Connect power ports of RX and TX units by power cable; Check the installation and connection of equipments are correct and the equipments are working properly, then power on system; Make sure image displays and other devices are working. Installation Methods Indoor Wall-mounting HDUBARTK-T User Manual...
Storage Temperature -45°C - 75°C (0-95% Humidty) Weight Dimesnions (W x L x H) 45 x 113 x 29 (mm) Genie CCTV reserves the right to change specifications without notice. Please contact your representative to confirm current specifications. HDUBARTK-T User Manual...
Page 5
Restore switch of SV unit on 5X mark; b. Reboot; c. Adjust the switch when DVR works smoothly. 2.There are 2 marks of 10X on RM unit. Right mark features high definition and saturation. HDUBARTK-T User Manual...
