A501ZCBE
Instruction manual
Thank you very much for purchasing Cleansui. Read these instructions carefully before use. Installation instruction
and a warranty card are included with this product and must be retained for future reference.
1. About this Product
1. About this Product
●(A501ZCBE) consists of the faucet (A501) and cartridge (UZC2000E).
●Unique triple filtration system with high performance cartridge removes 13 substances based
on JIS S 3201.
●Use for drinking or cooking only.
●The cartridge cannot remove salt (seawater) or metallic ions (except lead) contained in water.
It is also not capable of converting hard water into soft water.
●Cleansui filtration system works when the water pressure is from 0.07MPa to 0.35MPa.
Please read the instruction manual carefully before use.
Under sink water purifier
Contents
11. After-sales Service
12. Specifications
● Warranty
Advertisement
Table of Contents
Related Manuals for Mitsubishi CLEANSUI
Summary of Contents for Mitsubishi CLEANSUI
-
Page 1: Table Of Contents
A501ZCBE Under sink water purifier Instruction manual Thank you very much for purchasing Cleansui. Read these instructions carefully before use. Installation instruction and a warranty card are included with this product and must be retained for future reference. Contents 1. About this Product 7. -
Page 2: Safety Precautions
Prohibition To keep the system clean ●Please run the filtered water for at least 15 seconds before using your Cleansui for the first time everyday. (for UZC2000E) Because there is no residual chlorine in the filtered water left in the system, bacteria may easily multiply. This may cause damage to your health. - Page 3 Attention To keep the system clean ●If the system has not been used for more than 2 weeks, please replace the cartridge. ●If the wateroutlet becomes soiled by splash back., run filtered water for more than 15 seconds. Bacteria may multiply. ●For maintenance of the wateroutlet, clean with a sterilized soft toothbrush etc.
- Page 4 Attention To prevent filtered water irregularities, leakage and ruptures ●Do not block faucet or connect it to other equipment, such as gas boiler etc. It may cause leakages. ●Do not use detergents that contain abrasive compounds or thinners for cleaning the faucet, cartridge and the hoses.
-
Page 5: Important Notes For Operation
3. Important Notes for Operation ●Use the recommended Cleansui cartridge with Cleansui faucet. ●Do not use this device to filter hot water with a temperature of 35 or higher through ℃ "filtration" mode. If you do so, the performance of activated carbon is reduced and the filtered water may temporarily exhibit an unpleasant odour temporarily. -
Page 6: Irregular Water Flow
4. Irregular Water Flow Please follow the steps if the water flow is irregular after the filter has been installed or replaced. Allow the filtered water to flow while turning the cartridge upside down several times. It will drain out air from inside the cartridge. -
Page 7: Features Of Cartridge
6. Features of Cartridge 1. Cleansui is a unique triple filtration system with high performance cartridge. Cartridge (model : UZC2000E) The 1st filter Non-woven fabric Removes large particles. Removes chlorine odour, 2-MIB (musty odour), organic Activated carbon and matter (JIS designated items), trihalomethane, CAT... -
Page 8: Maintenance
8. Maintenance If dirt on the product is not cleaned immediately, it may be difficult to remove afterwards. In order to ensure the product is in optimum condition, we recommend that regular maintenance be performed on the product. Attention ・Please clean the wateroutlet with a sterilized soft Please do not use the following items, as doing so may cause toothbrush. -
Page 9: Troubleshooting
9. Troubleshooting Problem Potential causes Solution Reduced filtered water volume Unsuitable components and lifespan. Unpleasant taste or odour. Please replace the cartridge. Please refer to P.10 “10. Replacing the Cartridge” The tap drips Cartridge is when turned off. clogged. Allow the filtered water to flow while turning the cartridge upside down a few times so as to Water flow does... -
Page 10: Replacing The Cartridge
10. Replacing the Cartridge Replacement period of the cartridge The replacement period will be approximately one year, but earlier replacement is recommended. Please replace the cartridge in the following situations. ●“Filtered water” volume has significantly decreased. ●Unpleasant taste or odour. Cartridge Replacement Method 1．... - Page 11 Do not buckle or distort the hoses handle. Ensure there are no when placing into the cartridge tray. leaks in the connection. To buy new cartridge, please contact the store where you bought Cleansui. Dispose of used cartridges in accordance with local waste regulations.
- Page 12 11. After-sale Service Warranty ■ Cleansui comes with a warranty. The validity of the warranty is one year from the date of purchase, subject to term & conditions listed on warranty. Please see the warranty for details. 【Parts replacement】 Abrasion and deterioration of parts may cause leakage, so some parts need to be replaced.
- Page 13 2. Having verified the situation details, please contact the store from which you purchased your product or the contractor who installed your water purifier. 3. When you make an inquiry, please inform them of the following points. ① Product Name (Under sink water filter “Cleansui”) ② Set Number (A501ZCBE) ③ Problems in detail ■Replacement of Cartridge (Sold Separately)
- Page 14 12. Specifications ●Specifications Set Number A501ZCBE UZC 2000E Cartridge Model Number ABS resin Cartridge Material Faucet Copper Polyethylene Connecting Hose Polyethylene hollow fibre membrane, ion exchange fibre, Cartridge components activated carbon, non woven fabric 3 litres / min Initial water flow rate Minimum working water pressure 0.07MPa Free residual chlorine...
- Page 15 12.A...
