Model: T83653
Manual
This Wireless Color Forecast Station with backlit display provides real-time weather straight from your
backyard. It has a USB charging port to charge your smartphone or other device. The animated color
forecast icons react to changing barometric pressure. Monitor indoor and outdoor temperature with daily
min/mix records and humidity, track weather trends and set your own high and low temperature alerts--all
in one convenient device for your desktop or bedside table. It also features heat index, dew point, digital
time and date with snooze alarm, and has a wireless transmission range of over 200 ft. to the backyard
temp./humidity sensor.
Wireless Color Forecast Station with TX141TH-B Outdoor Transmitter
Animated Forecast
Out Temperature
TX141TH-B
+ Trends
Humidity + Trends
In. Temperature
Humidity + Trends
Time, Calendar
+ Alarm
In/Out
Temp. Alerts
Function Buttons
Get Support: www.lacrossetechnology.com/t83653
Initial Startup
Step 1: Insert the included 5-volt AC power adapter into forecast station and then into wall outlet.
Step 2: Insert 3 NEW AAA batteries (not included) into the forecast station. Observe the correct polarity.
Step 3: Insert 2 NEW AA batteries (not included) into the TX141TH-B transmitter. Observe the correct
polarity.
Restart: If there is no outdoor temperature data after 3 minutes, unplug the AC adapter and remove
batteries from the forecast station & transmitter for 15 minutes. Return to Step 1 above.
Model: T83653
www.lacrossetechnology.com/support
Page | 1
Advertisement
Table of Contents
Related Manuals for La Crosse Technology TX141TH-B
Summary of Contents for La Crosse Technology TX141TH-B
-
Page 1: Wireless Color Forecast Station With Tx141Th-B Outdoor Transmitter
Step 1: Insert the included 5-volt AC power adapter into forecast station and then into wall outlet. Step 2: Insert 3 NEW AAA batteries (not included) into the forecast station. Observe the correct polarity. Step 3: Insert 2 NEW AA batteries (not included) into the TX141TH-B transmitter. Observe the correct polarity. -
Page 2: Table Of Contents
Table of Contents Wireless Color Forecast Station with TX141TH-B Outdoor Transmitter Initial Setup Restart Table of Contents Features Function Buttons Program Menu 12-hour or 24-hour Time Format Set Time Set Calendar Fahrenheit/Celsius Alarm Time Set Alarm Activate/Deactivate Alarm Snooze Alarm... -
Page 3: Features
Features Color forecast changes based on barometric pressure Forecast tendency indicator Outdoor temperature (°F/°C) Signal strength icon for sensor transmission Outdoor temp. trend indicator Outdoor humidity (%RH) Low battery icon for station Outdoor humidity trend indicator Indoor temperature (°F/°C) Indoor temp. trend indicator Indoor humidity (%RH) Indoor humidity trend indicator Customizable IN/OUT temp. -
Page 4: Program Menu
Program Menu (set 12/24 hour, time, calendar, °F or °C) The program menu allows you to select your preferences: 12/24-Hour Time Format Hour Minutes Year Month Date Celsius/Fahrenheit Program menu buttons: 1. Hold the SETTINGS button to enter time set mode. 2. -
Page 5: Alarm Time
Note: When no buttons are pressed for ten seconds, the forecast station will save the last change and default back to a normal time display. Alarm Time Time alarm buttons: 1. Hold the TIME ALARM button to enter alarm set mode. 2. -
Page 6: Backlight
Backlight AC Adapter The backlight is always on when operating the forecast station with the 5-volt AC adapter. The backlight has three settings: High, Low and OFF for your comfort. HIGH: The backlight will default to HI at setup when the adapter is in use. LOW: Press and release the HI/LOW/OFF button to dim the backlight. -
Page 7: Temperature Alerts Arm/Disarm
Arm/Disarm Temperature Alerts From a normal time display, press the TEMP ALERT button to view alerts in the window TEMP. ALERT. UP ARROW arms temperature alerts. DOWN ARROW disarms temperature alerts. ALERT BELL ICON appears when armed. Note: When no temperature alerts are set, the Temperature Alert area will show ALERTS OFF. 1. -
Page 8: Forecast Trend Arrows
Forecast Trend Arrows In the upper right corner of the forecast display, you can see forecast trend arrows that indicate the rising or falling pressure trend. The up trending arrow indicates the weather is improving. The down trending arrow indicates the weather may worsen. When there is no arrow, the pressure is steady. -
Page 9: Outdoor Temperature/Humidity Flashes
Dew Point Temperature Dew Point Temperature is the saturation point of the air, or the temperature to which the air has to cool in order to create condensation. The higher the dew points, the higher the moisture content of the air at a given temperature. -
Page 10: Install Batteries In The Outdoor Transmitter
If the forecast station does not display indoor temperature after 60 seconds, remove adapter and batteries and wait for at least 60 seconds before repeating the setup process. Install Batteries in the Outdoor Transmitter 1. Slide the battery cover down, then lift off the back of the transmitter. 2. -
Page 11: Care And Maintenance
cannot reach the outdoor transmitter. Mount the outdoor transmitter on a North-facing wall or in any well shaded area. Under an eave or deck rail work well. The maximum transmitting range in open air is over 200 feet (60 meters). Obstacles such as walls, windows, stucco, concrete, and large metal objects can reduce the range. -
Page 12: Power Requirements
1.57" x 0.79" x 5.12" (40 x 20 x 130mm) Warranty and Support Information La Crosse Technology, Ltd. provides a 1-year limited time warranty (from date of purchase) on this product relating to manufacturing defects in materials & workmanship. View full warranty details online at: www.lacrossetechnology.com/warranty_info.pdf...
