CHAPTER 1 GENERAL ADJUSTMENTS SAFETY INSTRUCTIONS WARNING: BEFORE SERVICING THIS CHASSIS, READ THE “X-RAY RADIATION PRECAUTION”, “SAFETY PRECAU- TION” AND “PRODUCT SAFETY NOTICE” INSTRUCTIONS BELOW. X-RAY RADIATION PRECAUTION 1. Excessive high voltage can produce potentially hazard- 2. The only source of X-RAY RADIATION in this TV receiver ous X-RAY RADIATION.
WARNING: BEFORE SERVICING THIS CHASSIS, READ THE “X-RAY RADIATION PRECAUTION”, “SAFETY PRECAU- TION” AND “PRODUCT SAFETY NOTICE” ON PAGE 3 OF THIS MANUAL. SET-UP ADJUSTMENT I The following adjustments should be made when a complete realignment is required or a new picture tube is installed. Perform the adjustments in order as follows : 1.
Page 5
I CIRCUMFERENCE CONVERGENCE ADJUSTMENT CONVERGENCE ADJUSTMENTS NOTE: Before attempting any convergence adjustments, the 1. Loosen the clamping screw of deflection yoke slightly to receiver should be operated for at least fifteen min- allow the yoke to tilt. utes. 2. Temporarily put a wedge as shown in figure 1. (Do not remove cover paper on adhesive part of the wedge.) I CENTER CONVERGENCE ADJUSTMENT 3.
SERVICE MODE 1. ENTERING TO SERVICE MODE 1) Press o button once on 2) Press o button again to 3) While pressing the o button, Remote Control. keep pressing. press MENU button on TV set. Item Data Mute or (Service mode display) 2.
Page 7
4. SELECTING THE ADJUSTING ITEMS 1) Every pressing of CHANNEL s button in the service mode changes the adjustment items in the order of table-2. (t button for reverse order) Refer to table-2 for preset data of adjustment mode. (See SETTING & ADJUSTING DATA on page 18) 5.
Page 8
8. SELF DIAGNOSTIC FUNCTION 1) Press “9” button on Remote Control during display of adjustment menu in the service mode. The diagnosis will begin to check if interface among IC’s are executed properly. 2) During diagnosis, the following displays are shown. Indicated color of mode now selected : Green and Red Indicated color of other modes : White...
DESIGN MODE 1. ENTERING TO DESIGN MODE 1) Select the Service mode. 2) While pressing o or CALL button on 3) Press MENU button on TV. Remote and press MENU button on TV. ITEM Press DATA Press (Design mode) (Adjustment mode) When QA02 is initialized, items “OPT0”...
ELECTRICAL ADJUSTMENTS ITEM ADJUSTMENT PROCEDURE FOCUS VR ADJ 1. Enter the service mode, then select any register item. 2. Press the TV/VIDEO button on the Remote until the black cross-bar pattern ap- pears on the screen. 3. Adjust the FOCUS control (on T461) for well defined scanning lines on the picture screen.
Page 11
ITEM ADJUSTMENT PROCEDURE WHITE BALANCE 1. Set Contrast to 40, and brightness to +20 by picture control. ADJUSTMENT 2. Set the TV in service mode, and get the inside W/B adjusting signal with VIDEO button. • CUTOFF ADJUSTMENT 3. Select RCUT, GCUT and BCUT with CHANNEL s, t buttons, to set individual (RCUT) values to Initial reference data, and to set GDRV and BDRV to Initial reference (GCUT)
CIRCUIT CHECK HIGH VOLTAGE CHECK CAUTION: There is no HIGH VOLTAGE ADJUSTMENT on this chassis. Checking should be done following the steps below. 1. Connect an accurate high voltage meter to the second anode of the picture tube. 2. Turn on the receiver. Set the BRIGHTNESS and CONTRAST controls to minimum (zero beam current). 3.
CHAPTER 2 SPECIFIC INFORMATIONS SETTING & ADJUSTING DATA SAFETY INSTRUCTIONS 32” HIGH VOLTAGE AT ZERO BEAM: 31.9 kV MAX HIGH VOLTAGE: 34.0 kV AC VOLTAGE 220~240 V Table-1 SERVICE MODE ADJUSTING ITEMS AND DATAS IN THE SERVICE MODE: Item Adjustment Reference data Item Adjustment...
LOCATION OF CONTROLS Front MENU EXIT S-VIDEO VIDEO L/MONO AUDIO HEAD PHONE MAIN SWITCH MENU POWER INDICATOR (VIDEO-3) S-VIDEO TERMINAL VOLUME DOWN ON-TIMER INDICATOR STEREO INDICATOR VOLUME UP VIDEO-3 POSITION DOWN BILINGUAL INDICATOR POSITION UP EXIT Rear terminals WOOFER MAIN (8Ω) (S-VIDEO) (S-VIDEO) AUDIO...
Page 20
ENTER MENU EXIT MENU Buttons EXIT • Stereo/Bilingual • Sound Mute V T R / D V D Volume Video Recoder/DVD Buttons to operate your Toshiba Video Recorder & DVD V T R / D V D – 20 –...
• The part number must be used when ordering parts, in order to assist in processing, be sure to include the Model number and Description. • The PC board assembly with mark is no longer available after the end of the production. Models : 32Z17B Capacitors ..... CD Ceramic Disk : Plastic Film : Electrolytic Resistors ....
Page 23
Location Location Part No. Description Part No. Description EL, 1?F, ±20%, 50V C475 24820103 PF, 0.01?F, 630V C644 24797010 EL, 22?F, ±20%, 16V EL, 47?F, ±20%, 25V C476 24794220 C645 24795470 C477 24567104 PF, 0.1?F C647 24591102 PF, 1000pF CD, 470pF, ±10%, 500V C479 24214471 C648...
Page 24
Location Location Part No. Description Part No. Description EL, 220?F, ±20%, 25V EL, 10?F, ±20%, 16V C808 24667221 CB30 24794100 EL, 330?F, ±20%, 400V C810 24086063 CB31 24232103 CD, 0.01?F, +80%, -20% EL, 1000?F, ±20%, 16V C810 24763102 CB32 24567474 PF, 0.47?F CD, 1000pF, ±20%, AC250V CD, 4700pF, ±10%...
SPECIFICATIONS (Representative: 32Z17B) Input Power Rating: AC 220 ~ 240 Volts, 143±10W 50 Hz Aerial Input Impedance: 75 ohm unbalanced type for VHF, UHF and CATV Receiving Channels: System Channel CATV PAL I 21 ~ 69 PAL, /60 Hz (For Video Disk play back) 4.43 NTSC (For VCR playback), 3.58 NTSC (For VCR playback)
