21 Pin Connector (SCART)

HDMI Connector

15 Pin D Sub Connector (PC)

CONNECTORS

21
20
19
18
17
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
1
Published in Heiloo, Holland.
Pin No 1 2 Signal
1 Audio output B
(right)
Audio input B
2 (right)
Audio output A
3 (left)
4 Ground (audio)
5 Ground (blue)
6 Audio input A
(left)
7 Blue input
8 Function select
(AV control)
9 Ground (green)
10 AVlink
11 Green
12 Open
13 Ground (red)
14 Ground (blanking)
_ _ Red input
15
_ (S signal Chroma
- -
input)
16 Blanking input
(Ys signal)
17 Ground (video
output)
18 Ground (video
input)
19 Video output
Video input 1V +/- 3dB, 75ohms, positive sync 0.3V
20
Video input
- -
Y (S signal)
21 Common ground
(plug, shield)
Connected Not Connected (open)
Pin No Signal Assignment
1 TMDS Data2+
2 TMDS Data2 Shield
3 TMDS Data2-
4 TMDS Data1+
5 TMDS Data1 Shield
6 TMDS Data1-
7 TMDS Data0+
8 TMDS Data0 Shield
9 TMDS Data0-
10 TMDS Clock+
Pin No Signal Assignment
1 Red Out
2 Green Out
3 Blue Out
4 Unused
5 Ground
6 Red Return
7 Green Return (Ground)
8 Blue Return (Ground)
- 7 -
Signal level
Standard level : 0.5V rms
Output impedence : Less than 1kohm*
Standard level : 0.5V rms
Output impedence : More than 10kohm*
Standard level : 0.5V rms
Output impedence : Less than 1kohm*
Standard level : 0.5V rms
Output impedence : More than 10kohm*
0.7 +/- 3dB, 75 ohms positive
High state (9.5-12V) : Part mode
Low state (0-2V) : TV mode
Input impedence : More than 10K ohms
Input capacitance : Less than 2nF
Green signal : 0.7 +/- 3dB, 75 ohms,
positive
0.7 +/- 3dB, 75 ohms, positive
0.3 +/- 3dB, 75 ohms, positive
High state (1-3V) Low state (0-0.4V)
Input impedence : 75 ohms
1V +/- 3dB, 75ohms, positive sync 0.3V
(-3+10dB)
(-3+10dB)
1V +/- 3dB, 75ohms, positive sync 0.3V
(-3+10dB)
* at 20Hz - 20kHz
Pin No Signal Assignment
11 TMDS Clock Shield
12 TMDS Clock-
13 CEC
14 Reserved (N.C. on device)
15 SCL
16 SDA
17 DDC/CEC Ground
18 +5V Power
19 Hot Plug Detect
Pin No Signal Assignment
9 +5V DC
10 Sync Return (Ground)
11 Monitor ID0 in Display
12 DCC Serial Data
13 Horizontal Sync
14 Vertical Sync
15 DCC Serial Clock
4/3/16
