- Page 1 Lenovo System x3750 M4 Rack Installation Instructions Machine Type: 8753...
- Page 2 Second (November 2015) © Copyright Lenovo 2015. LIMITED AND RESTRICTED RIGHTS NOTICE: If data or software is delivered pursuant a General Services Administration “GSA” contract, use, reproduction, or disclosure is subject to restrictions set forth in Contract No. GS-35F-05925...
-
Page 3: Table Of Contents
....side of the rack ....Connecting and routing the cables ..© Copyright Lenovo 2015, and 2012, 2015... - Page 4 Lenovo System x3750 M4 Rack Installation Instructions...
-
Page 5: Chapter 1. Safety Information
Note: The maximum distance between the front and the rear EIA rails of the rack is 810 mm (31.9 in.). Statement 4 Three graphic illustrations for safety practices when lifting. © Copyright Lenovo 2015, and 2012, 2015... - Page 6 Multiple devices extended into the service position can cause your rack cabinet to tip. • If you are not using the IBM 9308 rack cabinet, securely anchor the rack cabinet to ensure its stability. Lenovo System x3750 M4 Rack Installation Instructions...
-
Page 7: Chapter 2. Rack Kit Parts Inventory
The cable management arm box kit includes the following hardware. This kit ships with the server. • One cable management support bar • One cable management arm assembly • One cable management arm stop bracket © Copyright Lenovo 2015, and 2012, 2015... - Page 8 Cable Management Arm box contents Cable management Cable-management support bar arm assembly (large capacity) Cable management arm stop bracket Lenovo System x3750 M4 Rack Installation Instructions...
-
Page 9: Chapter 3. Rack Installation
2. If your front slide rails are shipped with the front latches in the closed position, complete the following step: a. Open the latch by pushing the blue button in and pushing the latch back © Copyright Lenovo 2015, and 2012, 2015... -
Page 10: Opening The Rear Slide Rail Hooks
2U on the rear of the rack cabinet. 2. Push the rails so that the pins go into the holes. 3. Slide the rails into the rack cabinet to lock the rear of the slide rails into the rack cabinet. Lenovo System x3750 M4 Rack Installation Instructions... -
Page 11: Aligning The Front Of The Slide Rails To The Rack Cabinet
Square hole rack Rack Rear Round hole rack Aligning the front of the slide rails to the rack cabinet This topic provides information about how to align the front of the slide rails to the rack cabinet. To align the front of the slide rails to the rack cabinet, complete the following steps: 1. -
Page 12: Installing The Server On The Slide Rails
Note: Make sure the front latch covers the front nailhead to ensure the server is secured to the slide rails. Lenovo System x3750 M4 Rack Installation Instructions... -
Page 13: Sliding The Server Into The Rack Cabinet
Lift point Lift point Sliding the server into the rack cabinet This topic provides information about how to slide the server into the rack cabinet. To slide the server into the rack cabinet, complete the following steps: 1. Lift the locking levers on the slide rails. -
Page 14: Installing The Cable Management Support Bar
2. Lower the end of the cable management support bar to the same slide rail to which you plan to attach the cable management arm. 3. Rotate the cable management support bar towards the rear of the server Rack Rear Lenovo System x3750 M4 Rack Installation Instructions... -
Page 15: Connecting The Cable Management Support Bar To The Cable Management Arm Stop Bracket
Connecting the cable management support bar to the cable management arm stop bracket This topic provides information on how to connect the cable management support bar to the cable management arm stop bracket. To connect the cable management support bar to the cable management arm stop bracket, complete the following steps: 1. -
Page 16: Installing The Cable Management Arm
1. Open the cable management arm stop bracket by pushing the tabs located above and below the support stop bracket. 2. Rotate the cable management arm away from the server after opening the support stop bracket. Lenovo System x3750 M4 Rack Installation Instructions... -
Page 17: Connecting And Routing The Cables
Rack Rear Connecting and routing the cables This topic provides information on how to connect and route the cables to the server. Notes: • The location of the cable straps may be slightly different on your server. • Use the cable straps provided on the rear of the server to retain the cables and prevent them from sagging. To connect and route the cables to the sever, complete the following steps: 1. -
Page 18: Securing The Cables With The Hook-And-Loop Fasteners
1. Insert the M6 screws to the rear of the slides. 2. Use a cable tie to secure the free end of the cable management arm to the rack, if needed. Lenovo System x3750 M4 Rack Installation Instructions... -
Page 19: Installing The Front Screws
Rack Rear Installing the front screws This topic provides information about installing the screws in the front of the server. To install the screws in the front of the server, if needed, when you move the rack cabinet, or if you install the rack cabinet in a vibration-prone area, complete the following steps: 1. - Page 20 Lenovo System x3750 M4 Rack Installation Instructions...
-
Page 21: Chapter 4. Removing The Server From The Rack
This topic provides information about how to lift the server off of the slide rails. Note: Use safe practices while lifting. To lift the server off of the slide rails, complete the following steps. © Copyright Lenovo 2015, and 2012, 2015... -
Page 22: Removing The Cable Management Arm
4. Remove the cable management arm from the rack cabinet. Rack Rear Disconnecting the cable management arm stop bracket from the slide rail This topic provides information on how to disconnect the cable management arm stop bracket from the slide rail. Lenovo System x3750 M4 Rack Installation Instructions... -
Page 23: Disconnecting The Cable Management Support Bar From The Cable Management Arm Stop Bracket
To disconnect the cable management arm stop bracket from the slide rail, complete the following steps: 1. Push the blue touchpoint on the cable management arm stop bracket. 2. Slide the stop bracket toward the rear to disconnect the stop bracket from the slide rail. Rack Rear Outside bracket Disconnecting the cable management support bar from the cable... -
Page 24: Removing The Slide Rails From The Front Of The Rack
Removing the slide rails from the rear of the rack This topic provides information on how to remove the slide rails from the rear of the rack. To disengage the slide rails from the rear of the rack, complete the following steps: Lenovo System x3750 M4 Rack Installation Instructions... - Page 25 1. Pull the front of the slide rail forward to unlatch the rear hooks. 2. Remove the slide rail from the rack. Rack Rear Chapter 4 Removing the server from the rack...
- Page 26 Lenovo System x3750 M4 Rack Installation Instructions...
-
Page 27: Chapter 5. Changing The Cable Management Arm For Installation On The Right Side Of The Rack
, and flip the mounting brackets 3. Insert the inner bracket (marked with ) and outer bracket (marked with ) into the inner and outer sections of the cable management arm Release bottons © Copyright Lenovo 2015, and 2012, 2015... - Page 28 Lenovo System x3750 M4 Rack Installation Instructions...
- Page 30 Part Number: 00MV580 Printed in China (1P) P/N: 00MV580 *1P00MV580*...
