Summary of Contents for Epson EB-1460Ui

  • Page 1 Installation Guide...

  • Page 2: Using The Product Safely

    Using the Product Safely Safety Instructions For your safety, read all the instructions in this guide before using this product. Incorrect handling that ignores instructions in this guide could damage this product or could result in personal injury or property damage. Keep this installation guide at hand for future reference.
  • Page 3 Use M10 nuts and bolts. Nuts and bolts smaller than M10 could cause the setting plate to fall. Epson accepts no responsibility for any damage or injury caused by lack of wall strength or inadequate installation.

  • Page 4: Notes On Handling The Touch Unit (Eb-1460Ui/Eb-1450Ui Only)

    The Touch Unit contains a high power laser product that could cause a fire, electric shock, or an accident. Only connect the Touch Unit to the EB-1460Ui/EB-1450Ui. Do not connect it to any other projectors or devices. The device could malfunction, or laser light that is higher than normal intensity could be emitted.

  • Page 5: About This Installation Guide

    A powerful magnet within the unit could corrupt data or cause a malfunction. About This Installation Guide This guide describes how to mount the ultra short-throw projector EB-1460Ui/EB-1450Ui/EB-1440Ui on a wall. It also describes how to install the Touch Unit (EB-1460Ui/EB-1450Ui only), Control Pad, and Pen Stand after mounting on a wall.

  • Page 6: Choosing An Installation Location

    Using the Product Safely Choosing an Installation Location Projector installation location • Carry out power supply wiring work for the installation location of the setting plate in advance. • Install the projector away from other electric devices such as fluorescent lights or air conditioners. Some kinds of fluorescent lights could interfere with the remote control of the projector.

  • Page 7: Touch Unit Installation Location (Eb-1460Ui/Eb-1450Ui Only)

    Using the Product Safely Touch Unit installation location (EB-1460Ui/EB-1450Ui only) • When using the Touch Unit, install the projector using one of the following methods. The Touch Unit cannot be used if another installation method is used. • Mount the projector on a wall or suspend it from a ceiling and project images from in front of the screen.
  • Page 8 Using the Product Safely • If the distance from the wall to the surface of the screen (f) is more than 51 mm, you cannot install the Touch Unit outside the whiteboard. • If there is a frame around the screen, make sure that the thickness of the top of the frame (e) is less than 3 mm. If the thickness of the top of the screen exceeds 3 mm, the Touch Unit will not operate correctly.

  • Page 9: Table Of Contents

    Control Pad ......13 Adjusting the Position of the Projector ..46 Touch Unit (EB-1460Ui/EB-1450Ui only) ..13 Sticking the infrared deflectors (EB-1460Ui/ Touch Unit Bracket .
  • Page 10 Contents Angle Adjustment ....91 Appendix Installing Multiple Projectors in Parallel (Multi-Projection) ... . 95 Multi-Projection settings .

  • Page 11: Installation Guide

    When installing the Touch Unit, finish installing the projector first, and then follow the procedures below. (EB-1460Ui/EB-1450Ui only) The procedure differs depending on where the Touch Unit is to be installed. When installing the Touch Unit outside the whiteboard (using the Touch Unit Bracket) Installing the Touch Unit ( p.64)

  • Page 12: When Two Or More Projectors Are Installed In Parallel

    Installation Guide Installing the Touch Unit ( p.87) Adjusting the Angle of Laser Diffusion ( p.91) Performing Touch Calibration ( p.84) When two or more projectors are installed in parallel When using the multi-projection function (when multiple projectors are installed in parallel to project one, large screen), follow the steps below.

  • Page 13: Package Contents

    Installation Guide Package Contents Setting plate The following supplied items are necessary to mount the projector on a wall. Confirm that you have all items before beginning. Depending on the area in which you purchased the product, the Setting Plate is not supplied.

  • Page 14: Control Pad

    When installing the Control Pad on a wall and so on, prepare commercially available M4 screws (20 mm x4). When installing the Pen Stand on a wall and so on, prepare commercially available M4 screws (20 mm x2). Touch Unit (EB-1460Ui/EB-1450Ui only) The following supplied products are necessary when attaching the Touch Unit. Confirm that you have all items before beginning.

  • Page 15: Touch Unit Bracket

    Installation Guide Spacer for screw hole x3 Label x4 Tape for securing the markers (approx. 6 cm) x12 When installing the Touch Unit on a non-magnetic whiteboard, prepare three commercially available M4 screws. Touch Unit Bracket Installation plate Securing plate M4 x 12 mm hexagon socket head M4 x 25 mm hexagon socket head M4 x 55 mm hexagon socket head cap...

  • Page 16: Specifications

    Installation Guide Specifications Setting plate Item Specification Remark Reference Page Setting plate weight Approx. 7.2 kg Setting plate (2.9 kg), 3-axis adjustment unit (1.0 kg), slide plate (0.6 kg), wall plate (2.0 kg), wall plate cover and end cap (0.7 Maximum load capacity 9.5 kg Forward/backward slide ad-...

  • Page 17: Wall Plate

    Installation Guide Wall plate The following figure shows two frames connected to one plate (separate when shipped). [Unit: mm] The offset value for the position of the center of the projected image and the center of the wall plate is 27 mm. Cable routing holes When routing cables to connect to the projector through a wall, use positions ( ) and (...

  • Page 18: Horizontal Slide Adjustment Range

    Installation Guide Horizontal slide adjustment range [Unit: mm] Forward/backward slide adjustment range Arm slide adjustment range [Unit: mm] Adjustment range for 3-axis adjustment unit installation position [Unit: mm]...

  • Page 19: Position For Installing Accessories

    Installation Guide Position for installing accessories These screw holes allow you to secure peripheral devices and accessories such as external tuners. Use commercially available M4 screws. [Unit: mm] 2 x M4 30.5 49.7 60.8 Control Pad/Pen Stand Control Pad (external dimensions/weight) [Unit: mm] 109.5 135.9...

  • Page 20: Cable Routing Holes

    ) and route the cables from there. Route the printer cable along the groove at the back of the Control Pad. Pen Stand (external dimensions/weight) [Unit: mm] 101.9 28.8 44.4 28.8 2 x M4 The Pen Stand weighs approximately 93 g. Touch Unit (EB-1460Ui/EB-1450Ui only) Touch Unit (external dimensions/weight) [Unit: mm]...

  • Page 21: Touch Unit Bracket (External Dimensions/Adjustment Range/Weight)

    Installation Guide The Touch Unit weighs approximately 450 g. Touch Unit Bracket (external dimensions/adjustment range/weight) [Unit: mm] 229.8 Front [Unit: mm] Installation plate (front) [Unit: mm] Ø4.2 2-5.7...

  • Page 22: Attached Labels

    Installation Guide When the Touch Unit is installed (side) [Unit: mm] 100.8 Touch Unit Bracket weights approximately 750 g. Attached labels The Touch Unit is a Class 1 laser product that conforms to the IEC/EN60825-1:2007 standard. There are warning labels affixed to the Touch Unit to indicate that it is a Class 1 laser product. The labels contain the following information.
  • Page 23 Installation Guide...

  • Page 24: Projection Distance Table

    Installation Guide Projection Distance Table Figures of Installation Dimensions To find the appropriate projection distance, see the following figures when installing. The values are only rough estimates. The recommended range for the projection distance (a) is 62 to 244 mm. The offset value for the position of the center of the projected image and the center of the wall plate is 27 mm.

  • Page 25: When Installing The Touch Unit (Eb-1460Ui/Eb-1450Ui Only)

    Installation Guide When installing the Touch Unit (EB-1460Ui/EB-1450Ui only) By using the supplied Touch Unit Bracket, you can install the Touch Unit outside the whiteboard. When installing the Touch Unit outside the whiteboard, measure the length from the surface where the Touch Unit is installed to the whiteboard surface ((f) in the following figure).
  • Page 26 Installation Guide If there are any obstacles such as a frame or tray at the bottom of the screen, touch operations will not operate correctly. Stick the supplied infrared deflectors along the locations of the obstacles p.52). Make sure there is a space of approximately 20 mm between the place where the infrared deflector is stuck and the bottom of the projected image.
  • Page 27 Installation Guide • If there are any obstacles such as a frame or tray at the bottom of the screen, touch operations will not operate correctly. Stick the supplied infrared deflectors over the locations of the obstacles ( p.52). Make sure there is a space of at least 20 mm between the place where the infrared deflector is stuck and the bottom of the projected image.

  • Page 28: When Installing The Control Pad And The Pen Stand

    Installation Guide When installing the Control Pad and the Pen Stand When installing the Control Pad, leave enough space around it to install/remove the cover or to connect/ disconnect cables easily as shown in the following figure. [Unit: mm] When installing the Pen Stand next to the Control Pad, do not install it so that it covers the groove in the front cover as shown in the following figure.

  • Page 29: When Projected Image Is Smaller Than 85 Inches

    Installation Guide When Projected Image is Smaller than 85 Inches Mount the 3-axis adjustment unit at the position marked with a stamp ( The projection distance table provides the figures when mounting the 3-axis adjustment unit at the position marked with a stamp ( The distance from the top of the projected image to the bottom wall plate installation screw hole (c) is the number given when the vertical slide is set to the standard position (...

  • Page 30: 16:10 Projected Image

    Installation Guide 16:10 projected image [Unit: cm] Projected image size Projection Dis- Numbers on Distance to Distance from Height of tance the arm slide the bottom the top of the projected Minimum scale wall plate in- projected im- image (Wide) to Maxi- stallation age to the wall mum (Tele)

  • Page 31: When Projected Image Is 85 Inches Or More

    Installation Guide When Projected Image is 85 inches or more Mount the 3-axis adjustment unit at the position marked with a stamp ( The projection distance table provides the figures when mounting the 3-axis adjustment unit at the position marked with a stamp ( The distance from the top of the projected image to the bottom wall plate installation screw hole (c) is the number given when the vertical slide is set to the standard position (...

  • Page 32: 16:10 Projected Image

    Installation Guide 16:10 projected image [Unit: cm] Projected image size Projection Numbers on Distance to the Distance from Height of Distance the arm slide bottom wall the top of the projected im- Minimum scale plate installa- projected im- (Wide) to tion screw hole age to the wall Maximum...

  • Page 33: Installing The Setting Plate

    Additionally, prepare the necessary cables according to the devices being used. • USB cable supplied • Touch Unit connection cable supplied (EB-1460Ui/EB-1450Ui only) • Stereo mini cable supplied • Optional computer cables and other cables (prepare according to the connected devices) For details, see the projector's User's Guide (on the Document CD-ROM).
  • Page 34 You need a computer with two USB-A ports. Necessary cables when installing the Touch Unit (EB-1460Ui/EB-1450Ui only) You need the supplied Touch Unit connection cable when installing the Touch Unit and connecting it to the projector.
  • Page 35 • H771x (where x is any from A to Z) If you want to connect a different projector or if you have any queries, check the Epson Projector Contact List provided on the Document CD-ROM and contact your local dealer.
  • Page 36 Installation Guide Prepare cables for the connected devices (example) Document camera Computer Dedicated USB cable (supplied with document cam- Computer cable (optional accessory) era) External speakers External monitor LAN device Audio cable (commercially available) DVI-D cable (commercially LAN cable (commercially available) available)

  • Page 37: Installation Procedure

    Installation Guide Installation Procedure Make sure to follow the steps below to install the setting plate. If these steps are not followed, the product could fall and cause personal injury or property damage. Warning Do not use adhesives, lubricants, or oils to install or adjust the setting plate. If you use adhesives to prevent the screws from loosening or things such as lubricants or oils on the slide plate fixing part of the projector, the case may crack and cause the projector to fall, resulting in personal injury or property damage.
  • Page 38 Installation Guide Check that the 3-axis adjustment unit is aligned with the slide plate's standard position If the standard position ( ) is not correct, loosen the M4 bolt and adjust the position of the slide plate. When you have finished making adjustments, tighten the bolt. Secure the 3-axis adjustment unit and the slide plate to the base of the projector with the M4 x 12 mm bolts (x4) supplied Bolt installation positions...

  • Page 39: Install The Wall Plate On The Wall

    Installation Guide Install the wall plate on the wall Determine the projection position based on the projected image size See the projection distance table to check the following values. • Projected image size (S) • Distance from the top of the projected image to the bottom wall plate installation screw hole (c) •...
  • Page 40 Installation Guide Attach the template sheet to the wall • Match the center line ( ) checked in step 1 to the Image Center B line on the template sheet. Confirm where the beams are within the wall, and shift the position left or right as necessary. (The position can be shifted horizontally left or right from the center line of the projection surface up to a maximum of 45 mm.) •...

  • Page 41: Determine The Projection Distance, And Then Pass The Cables Through The Setting Plate

    Installation Guide Drill the holes in the wall Drill diameter: 10.5 mm Pilot hole depth: 45 mm Anchor hole depth: 40 mm Remove the template sheet, and clean the concrete dust from the holes with a dust pump Position the wall plate on the wall and insert M10 x 60 mm commercially available anchors into the holes Attach the nut and tap it with a hammer until the core touches the top of the an-...
  • Page 42 Do not hang the rest of the cable over the setting plate. They could fall and cause an accident. • Route the Touch Unit connection cable through the setting plate (EB-1460Ui/EB-1450Ui only). Route the cable so that the end that connects to the Touch Unit appears from the lower part of the setting plate.

  • Page 43: Attaching The Setting Plate To The Wall Plate

    Insert the top of the hexagonal axis into the wall plate, and then insert it into the slot at the bottom. Caution • Do not wire the Touch Unit connection cable into the wall (EB-1460Ui/EB-1450Ui only). If it is wired into the wall, it cannot be connected to the Touch Unit. •...
  • Page 44 Installation Guide Secure the setting plate and the wall plate Secure the supplied M6 screws (x3) with a commercially available No.3 cross-head screwdriver, and then lightly tighten the supplied M6 bolt (x1) with the spanner. Adjust the vertical slide with the open-ended spanner, and align it with the standard position ( •...

  • Page 45: Securing The Projector To The Setting Plate

    Installation Guide Tighten the M6 bolt (x1) to fix the setting plate in position Securing the projector to the setting plate Loosen the screws (x2) and remove the cable cover from the projector...
  • Page 46 Installation Guide Attach the 3-axis adjustment unit to the setting plate with the M4 x 12 mm bolts (x4) supplied • When a projected image is smaller than 85 inches: Mount the unit at the stamp ( • When a projected image is 85 inches or more: Mount the unit at the stamp ( : Smaller than 85 inches : 85 inches or more...

  • Page 47: Adjusting The Position Of The Projector

    Installation Guide Connect the cables to the projector "Connecting Devices" p.32 Connect the power cord last. Use commercially available M4 screws to secure peripheral devices and accessories such as external tuners to the screw holes in the following figure. Install the wireless LAN module supplied in the wireless LAN unit module slot. Adjusting the Position of the Projector •...
  • Page 48 Installation Guide When installing the Touch Unit (EB-1460Ui/EB-1450Ui only), if there are any obstacles at the bottom of the whiteboard such as a frame or trays, stick the infrared deflectors along the bottom edge of the whiteboard before adjusting the projector.
  • Page 49 Installation Guide Change the aspect ratio of the projected image (only when necessary) Project images from a connected device, and then press the [Aspect] button on the remote control. Each time you press the button, the aspect name is displayed on the screen and the aspect ratio changes.
  • Page 50 Installation Guide After loosening the adjustment dial at the bottom, adjust the horizontal roll using the adjustment dial at the top. Repeat steps 6 to 11 as necessary. After you finish making adjustments, tighten the adjustment dial at the bottom. Loosen the M4 screw (x1) with the hexagon wrench, and then adjust the horizontal rotation with the adjustment dial After you finish making adjustments, tighten the M4 screws that you loosened.
  • Page 51 Installation Guide After loosening the adjustment dial at the bottom, adjust the vertical tilt using the adjustment dial at the top. After you finish making adjustments, tighten the adjustment dial at the bottom. Loosen the M4 bolt with the hexagon wrench, and then adjust the horizontal slide After you finish making adjustments, tighten the M4 bolt that you loosened.
  • Page 52 Installation Guide Loosen the M4 bolts (x2) with the hexagon wrench, and then adjust the forward/backward slide After you finish making adjustments, tighten the M4 bolts that you loosened. Loosen the M6 bolt (x1) with the open-ended spanner, and then adjust the vertical slide Adjust the vertical slide with the hexagonal axis at the top or the bottom.

  • Page 53: Sticking The Infrared Deflectors (Eb-1460Ui/Eb-1450Ui Only)

    Press the [Esc] button on the remote control or the control panel to remove the guidance screen Sticking the infrared deflectors (EB-1460Ui/EB-1450Ui only) When installing the Touch Unit, if there are any obstacles at the bottom of the whiteboard such as a frame or trays, touch operations will not operate correctly.

  • Page 54: Arc Correction

    Installation Guide • Do not remove an infrared deflector once it has been stuck in place. This can weaken the adhesive strength of the tape. • Do not stick tape or place anything on the infrared deflectors. The infrared deflector will not function correctly.

  • Page 55: Calibrating The Pen

    Installation Guide Select Arc Correction Select Arc Correction Select the side you want to correct Correct the selected side If the message "Cannot adjust any further."is displayed while adjusting, you cannot adjust the shape any further in the direction indicated by the gray triangle. Repeat steps 5 and 6 as needed to adjust any remaining sides Calibrating the pen Check that adjusting the position of the projector is complete before you start calibrating the interactive pen.
  • Page 56 Installation Guide There are two methods available for calibrating the pen; Auto Calibration and Manual Calibration. When calibrating the pen for the first time after installing the projector, perform Manual Calibration for optimum calibration. For the Auto Calibration method, see the projector's User's Guide (on the Document CD-ROM). When two projectors are installed in parallel and you are using the interactive function, set the multi- projection interactive features before adjusting the pen.
  • Page 57 Installation Guide Check that the screen is in focus, and then select Yes A green dot is displayed at the top left of the projection screen. Touch the center of the dot with the pen tip of the interactive pen The dot disappears and moves to the next position.
  • Page 58 Installation Guide Repeat step 5 until all of the dots disappear The dot appears at the top left first and then moves towards the bottom right. When all of the dots disappear, calibration is complete. • Check that there are no obstacles between the interactive pen and the Interactive pen receiver ( •...

  • Page 59: Attaching The Covers

    Installation Guide Attaching the Covers Attach the wall plate covers Install the right cover first. • Depending on the cable configurations, you may need to cut notches ( ) in the wall plate covers to route the cables. Perform deburring on the cut sides to smooth off any sharp edges. Make sure you do not damage the cables when routing them through the cut holes.
  • Page 60 Installation Guide Fit the end cap to the setting plate If you are concerned about the groove in the arm, stick the supplied masking sticker. Attach the cable cover to the projector, and then secure it with the screws (x2)
  • Page 61 Installation Guide Caution Only a specialist should remove or reinstall the projector, including for maintenance and repairs. See the projector's User's Guide for instructions on maintenance and repairs. Warning • Never loosen the bolts and nuts after installation. Confirm that the screws have not become loose on a regular basis.

  • Page 62: Stand

    Installation Guide Installing the Control Pad and the Pen Stand Installing the Control Pad See the following for the installation location of the Control Pad. "When installing the Control Pad and the Pen Stand" p.27 Remove the front cover Check the installation position and secure with commercially available M4 screws (20 mm Warning •...

  • Page 63: Installing The Pen Stand

    Installation Guide Connect the cable that is connected to the projector to the Control Pad For details on connecting cables, see the following. "Necessary cables when installing the Control Pad" p.34 Paste the port protection stickers supplied to the plugs on the Control Pad that are not being used "Control Pad"...
  • Page 64 Installation Guide Check the installation position and secure with commercially available M4 screws (20 mm Warning • Be careful not to tilt the screw to the installation surface when securing. • Make sure that the Pen Stand is secured properly. •...

  • Page 65: Installing The Touch Unit

    Check that the screen is parallel to the surface on which the Touch Unit is installed. Caution Only connect the Touch Unit to the EB-1460Ui/EB-1450Ui. Do not connect it to any other projectors or devices. Turn on the projector, and then press the [Menu] button...
  • Page 66 Installation Guide Select Touch Unit Setup Select Installation Pattern The installation pattern is displayed on the projected image. Loosen the screw at the bottom of the dial cover using a commercially available No.2 cross- head screwdriver...
  • Page 67 Installation Guide Slide the dial cover down to remove it Determine the installation position for the Touch Unit Bracket We recommend marking the following installation positions (positions of the screw holes) to make installation easier. ): Center line of installation pattern. Align with the center line ( ) of the installation plate.
  • Page 68 Installation Guide Install the installation plate using three M4 commercially available 4 mm wood screws, or three M4 anchor bolts. Attach the securing plate to the rear of the Touch Unit with the two M4 x 25 mm bolts supplied Adjust the position so that the two screw holes of the Touch Unit and the two screw holes of the securing plate are aligned.
  • Page 69 Installation Guide Use the supplied M4 x 12 mm bolts (x2) to install the securing plate on the installation plate Tighten the bolts to the securing plate using the supplied hexagon wrench. Measure the distance from the wall to the surface of the screen (f) Adjust the height of the left and right according to the value (f) measured in step 11 Loosen the two screws and move the Touch Unit back and forth to adjust the left and right so that the arrow aligns with the value on the scale the same as (f).

  • Page 70: Angle Adjustment

    Installation Guide Secure the Touch Unit and the installation plate with the hexagon socket head cap bolt The bolt used varies according to the distance (f) from the wall to the surface of the screen measured in step 11. Tighten the bolt to the installation plate using the supplied hexagon wrench. When (f) = 20 to 35 mm: M4 x 55 mm bolt When (f) = 35 to 50 mm: M4 x 70 mm bolt Connect the Touch Unit connection cable that is connected to the projector to the TCH...
  • Page 71 Installation Guide Adjust the angle of the laser light coming from the Touch Unit so that the projector can correctly detect the position of your finger. A: Infrared laser emission unit B: Fulcrum C: Vertical movable point If the laser is not emitted parallel to the screen, the projector will not detect touch operations or the position of your finger correctly.
  • Page 72 If there are any obstacles at the bottom of the whiteboard such as a frame or trays, the laser will be reflected and the location of your finger will not be detected correctly. Stick infrared deflectors on the frame and the trays to prevent them from reflecting the laser. "Sticking the infrared deflectors (EB-1460Ui/EB-1450Ui only)" p.52 •...
  • Page 73 Installation Guide Select Easy Interactive Function from the projector's Extended menu Select Touch Unit Setup Set Power to On The Touch Unit power turns on and the indicator is lit blue. When Power is set to On, the next time the projector is turned on, the Touch Unit automatically turns on.
  • Page 74 Installation Guide Select Angle Adjustment Select Installing the Touch Unit with the bracket The following screen is displayed.
  • Page 75 Installation Guide Turn the adjustment screw for the Touch Unit fully clockwise using the hexagon wrench supplied with the setting plate Turn the adjustment dials on the Touch Unit counterclockwise until you hear a clicking sound When you hear a clicking sound coming from the adjustment dial, stop turning, and then press the ] button on the remote control.
  • Page 76 Installation Guide Attach the supplied two markers to the marker positions ( ) on the projection screen Match the positions so that the crosses ( ) for the markers overlap with the points ( ) for the • Magnetic screens: Place the bottom of the markers onto the screen. •...
  • Page 77 Installation Guide Turn the adjustment screw on the Touch Unit counterclockwise to display the pointers Adjusting the angle of the Touch Unit using the adjustment screw Before adjustment After adjustment When the pointers overlap in the correct position, the colors become solid (...
  • Page 78 Installation Guide Turn the adjustment screw clockwise to move the pointer down as needed. • When turning the adjustment screw, make sure shadows from your arm or body do not overlap with the markers. • If the pointers are not solid colors ( ), check if the Touch Unit and screen are parallel.
  • Page 79 Installation Guide Turn the adjustment dials on the Touch Unit to move the pointers ( ) so that they overlap with the target ( ) of the same color on either side When you turn the adjustment dial clockwise, the pointer moves diagonally up towards the center of the projected image.
  • Page 80 Installation Guide When the pointers on the left and right become solid colors ( ), press the [ button on the remote control The following screen is displayed. Place the markers at the top marker positions [1] ( When angle adjustment is performed correctly, the upper pointers become solid colors ( If the upper pointers do not become solid colors ( ), start again from step 1.
  • Page 81 Installation Guide Place the markers at the bottom marker positions [2] ( When angle adjustment is performed correctly, the bottom pointers become solid colors ( If the bottom pointers do not become solid colors ( ), start again from step 4. When you have finished checking, remove the markers, and then press the [ ] button on the remote control...
  • Page 82 Installation Guide Trace the dots ( ) with your finger When angle adjustment is performed correctly, the dots you have traced disappear. Touch operations may not perform correctly if you are wearing artificial nails or nail polish, or if your fingers are obstructed by bandages and so on. When all of the dots have disappeared, select Complete and press the [ ] button on the remote control.
  • Page 83 Installation Guide Attach the dial cover, and then tighten the screw at the bottom of the dial cover When you have finished making adjustments, perform a touch calibration. "Touch Calibration" p.84 Make sure you store the markers in a safe place. Additional adjustments Perform additional adjustments if the dots on the left and right remain after adjusting the angle.
  • Page 84 Installation Guide Select Additional Adjustment The following screen is displayed. After this, adjust using the same procedure for angle adjustment from step 11. Follow the on-screen instructions to make adjustments. "Angle Adjustment" p.69 When you have finished making adjustments, perform a touch calibration. "Touch Calibration"...

  • Page 85: Touch Calibration

    Installation Guide Touch Calibration Perform touch calibration so that the projector can recognize touch operations precisely. When two projectors are installed in parallel and you are using the interactive function, check the following before performing touch calibration. • The multi-projection interactive features are set "When two projectors are installed in parallel and you are using the interactive function"...
  • Page 86 Installation Guide Select Touch Calibration The focus adjustment message is displayed. Check that the screen is in focus, and then select Yes A dot is displayed at the top left of the projection screen.
  • Page 87 Installation Guide Touch the center of the dot with your finger When the dot disappears and moves to the next position, remove your finger. • Make sure you touch the center of the dot. Otherwise, it may not be positioned correctly. •...

  • Page 88: When Installing The Touch Unit On The Whiteboard (Without Using The Touch Unit Bracket)

    Installation Procedure Install the Touch Unit, and then connect to the projector. Caution Only connect the Touch Unit to the EB-1460Ui/EB-1450Ui. Do not connect it to any other projectors or devices. Turn on the projector, and then press the [Menu] button...
  • Page 89 Installation Guide Select Touch Unit Setup Select Installation Pattern The installation pattern is displayed on the projected image. Loosen the screw at the bottom of the dial cover using a commercially available No.2 cross- head screwdriver...
  • Page 90 Installation Guide Slide the dial cover down to remove it Determine the installation position for the Touch Unit We recommend marking the following installation positions to make installation easier. ): Center line of installation pattern. Align with the center line of the Touch Unit ( ): 25 to 100 mm from the top edge of the projected image.
  • Page 91 Installation Guide Secure the Touch Unit • Magnetic screens: Place the back of the Touch Unit on the screen surface, and then secure. Caution When installing the Touch Unit on a magnetic surface, be careful not to trap your fingers or any other part of your body between the magnets and the installation surface.

  • Page 92: Angle Adjustment

    Installation Guide [Unit: mm] Screw hole cross-section Connect the Touch Unit connection cable that is connected to the projector to the TCH port on the Touch Unit Angle Adjustment This section explains how to adjust the angle of the Touch Unit. For details on angle adjustment, see p.69. •...
  • Page 93 Installation Guide Select Easy Interactive Function from the projector's Extended menu Select Touch Unit Setup Set Power to On The Touch Unit power turns on and the indicator is lit blue. When Power is set to On, the next time the projector is turned on, the Touch Unit automatically turns on.
  • Page 94 Installation Guide Select Angle Adjustment...
  • Page 95 Installation Guide Select Installing the Touch Unit without the bracket The following screen is displayed. The next procedures are the same as for adjusting the angle (after step 11) when installing outside the whiteboard using the bracket. "Angle Adjustment" p.69 •...

  • Page 96: Appendix

    Appendix Installing Multiple Projectors in Parallel (Multi- Projection) By installing multiple projectors in parallel, you can project one, large image (Multi-Projection). Check the following when installing multiple projectors in parallel.( "Installation Work Flow" p.10) When projecting the screen from one computer, you need to make the following preparations. See the documentation provided with your computer to check how to make settings.
  • Page 97 Appendix Select Multi-Projection from Extended Select Projector ID Select the ID number for the target projector Press the [Menu] button to close the menu Repeat steps 1 to 5 for the remaining projectors.
  • Page 98 Appendix Point the remote control at the projector you want to operate, and then press the [ID] button The ID set for the projector is displayed on the projected screen. The display turns off after approximately three seconds. While holding down the [ID] button, press the button with the same number as the projector ID for the projector you want to operate Remote control operations for the projector with the selected ID are enabled.

  • Page 99: Adjusting The Image In Multi-Projection

    Appendix Press the [ID] button and check the ID setting The following is displayed. • Remote Control: On is displayed: You can operate the projector currently being operated. • Remote Control: Off is displayed: You cannot operate the projector with the remote control. Repeat the procedure above to enable remote control operations.

  • Page 100: When Two Projectors Are Installed In Parallel And You Are Using The Interactive Function

    Appendix Select Multi-Projection from Extended Set Multi-Projection to On Press the [Esc] button to return to the previous screen. Make each setting Color Mode Set the same item for each projector. Color Uniformity Adjust the color balance for the entire screen (only when necessary). Brightness Level If the brightness for each lamp is different, adjust the lamp brightness from level 1 to 5.

  • Page 101: Setting The Projectors In Sync

    Appendix Setting the projectors in sync When using the interactive function for multi-projection, interactive pen operations become unstable due to infrared interference. Follow the steps below to stabilize operations for the interactive pen. Check that installation is complete for both projectors before making settings. "Installing the Setting Plate"...

  • Page 102: Setting Multi-Projection Interactive

    Appendix Select Advanced Set Sync of Projectors to Wired Setting Multi-Projection Interactive Before setting Multi-Projection Interactive, check that you have finished adjusting the image for multi- projection. If you perform image adjustment after setting interactive, the pen position may not be correct. "Adjusting the Image in Multi-Projection"...
  • Page 103 Appendix Press the [Menu] button Using the Remote Control Using the Control Panel Select Easy Interactive Function from Extended Select Advanced from General Select Multi-Projection...
  • Page 104 Appendix Select Left Calibrate the pen ( p.54) Turn off the projector on the left Turn on the projector on the right, and perform steps 2 to 5 Select Right from Multi-Projection Calibrate the pen ( p.54)
  • Page 105 Appendix When using the Touch Unit (EB-1460Ui/EB-1450Ui only) Turn on the projector on the left and turn off the projector on the right Press the [Menu] button Using the Remote Control Using the Control Panel Select Easy Interactive Function from Extended...
  • Page 106 Appendix Select Advanced from General Select Multi-Projection Select Left Calibrate the pen ( p.54)
  • Page 107 Appendix Installing and adjusting the angle for the Touch Unit The procedure differs depending on where the Touch Unit is installed. When installing the Touch Unit outside the whiteboard (using the Touch Unit Bracket) Installing the Touch Unit ( p.64) Adjusting the Angle of Laser Diffusion ( p.69) When installing the Touch Unit on the whiteboard (without using the Touch Unit Bracket)
  • Page 108 Appendix Performing touch calibration for each projector ( p.84)

  • Page 109: Batch Setup Function

    Appendix Batch Setup Function After making the projector's menu settings for one projector, you can copy the settings to other projectors (batch setup function). The batch setup function is only for projectors with the same model number. Use one of the following methods. •...

  • Page 110: Setup Using A Usb Flash Drive

    Appendix Setup Using a USB flash drive This section explains how to perform batch setup using a USB flash drive. • Use a FAT format USB flash drive. • The batch setup function cannot be used by USB flash drives that incorporate security functions. Use a USB flash drive that does not incorporate security functions.
  • Page 111 Appendix While holding down the [Esc] button on the remote control or the control panel, connect the power cord to the projector The status indicator and the power indicator turn blue, and the lamp indicator and the temperature indicator turn orange. When all of the projector's indicators turn on, release the [Esc] button.

  • Page 112: Copying Saved Settings To Other Projectors

    Appendix Copying saved settings to other projectors Disconnect the power cord from the projector, and check that all of the projector's indicators have turned off Connect the USB flash drive containing the saved batch setup file to the projector's USB-A port •...

  • Page 113: When Setup Fails

    Writing the settings may have failed and an error may have occurred dicator flashing blue quickly, and the lamp in the projector's firmware. Stop using the projector, remove the indicator and the temperature indicator power plug from the electrical outlet, and contact Epson for help. flashing orange quickly?

  • Page 114: Attaching A Security Cable

    The security slot on this product is compatible with the Microsaver Security System manufactured by Kensington. See the following for more details on the Microsaver Security System. http://www.kensington.com/ Projector Touch Unit (EB-1460Ui/EB-1450Ui only) (cannot be used when attached to bracket)

  • Page 115: General Notice

    Appendix General Notice OS X is a trademark of Apple Inc. Microsoft and Windows are trademarks or registered trademarks of Microsoft Corporation in the United States and/or other countries. ©SEIKO EPSON CORPORATION 2016. All rights reserved.
