Page 1: Technical Data
Air Conditioners Technical Data I n d o o r u n i t s w w w . d a i k i n . e u FTXS-G... - Page 2 Air Conditioners Technical Data I n d o o r u n i t s w w w . d a i k i n . e u FTXS-G...
-
Page 3: Table Of Contents
• Indoor Units • R-410A • FTXS-G TABLE OF CONTENTS FTXS-G Features ............. 2 Specifications . -
Page 4: Features
• Indoor Units • R-410A • FTXS-G Features U n i U n i o o r o o r S - G 1 0 A I n d I n d F T X R - 4 • ECONO mode decreases power consumption so that other •... -
Page 5: Specifications
• Indoor Units • R-410A • FTXS-G Specifications 2-1 Technical Specifications FTXS20G2V1B FTXS25G2V1B FTXS35G2V1B FTXS42G2V1B FTXS50G2V1B Casing Colour White Dimensions Packing Height Width Depth Unit Height Width Depth Weight Unit Packed Unit Heat Exchanger Dimensions Length 605 + 602.7 605 + 602.7 605 + 602.7... - Page 6 • Indoor Units • R-410A • FTXS-G Specifications 2-1 Technical Specifications FTXS20G2V1B FTXS25G2V1B FTXS35G2V1B FTXS42G2V1B FTXS50G2V1B Air Filter Removable/washable/Mildew proof Air direction control Right, Left, Horizontal, Downward Temperature control Microcomputer control Standard Item Titanium apatite photocatalytic air purification filter Accessories...
-
Page 7: Electrical Specifications
Infrared remote control Quantity Item Batteries Quantity Item Remote control holder Quantity Item Indoor unit fixing screws Quantity Item Mounting plate Quantity 2-1 Electrical Specifications FTXS20G2V1B FTXS25G2V1B FTXS35G2V1B FTXS42G2V1B FTXS50G2V1B Power Supply Name Phase Frequency Voltage 220-230-240 Current Nominal running Cooling 0.09-0.08-0.08 0.09-0.08-0.08... -
Page 8: Dimensional Drawing & Centre Of Gravity
• Indoor Units • R-410A • FTXS-G Dimensional drawing & centre of gravity 3 - 1 Dimensional drawing FTXS20-42G The mark (→) shows piping direction Air flow (Indoor) Rear Including Right Left mounting plate 50 Min 50 Min Space for Space for REQUIRED SPACE maintenance... - Page 9 • Indoor Units • R-410A • FTXS-G Dimensional drawing & centre of gravity 3 - 1 Dimensional drawing FTXS60GV The mark shows piping direction Air flow (indoor) (For performance and maintenance) Left Rear Rear Right (Including installation plate) Min. 50 Min.
-
Page 10: Centre Of Gravity
• Indoor Units • R-410A • FTXS-G Dimensional drawing & centre of gravity 3 - 2 Centre of gravity FTXS20-50G 4D059112B FTXS60-71GV 4D065274 • Split Sky Air • Indoor Units... -
Page 11: Piping Diagram
• Indoor Units • R-410A • FTXS-G Piping diagram FTXS20-42G INDOOR UNIT 6.4CuT Heat exchanger Thermistor on Cross flow fan heat exch. Field piping 6.4CuT Fan motor Field piping 9.5CuT 9.5CuT Refrigerant flow Cooling Heating 4D058897C FTXS50G INDOOR UNIT 6.4CuT Heat exchanger Thermistor on Cross flow fan... - Page 12 • Indoor Units • R-410A • FTXS-G Piping diagram FTXS60GV Indoor unit (7.9 CuT) Heat exchanger Thermistor on heat exch. Cross flow fan Field piping (6.4 CuT) Fan motor Field piping (12.7 CuT) (12.7 CuT) Refrigerant flow Cooling Heating 4D040081V FTXS71GV Indoor unit (7.9 CuT)
-
Page 13: Wiring Diagram
• Indoor Units • R-410A • FTXS-G Wiring diagram 5 - 1 Wiring diagram FTXS20-50G WIRING DIAGRAM FIELD WIRING RECTIFIER OUTDOOR CAUTION Note that operation will restart automatically if TRANSMISSION the main power supply is turned off and than CIRCUIT back on again. -
Page 14: Sound Data
• Indoor Units • R-410A • FTXS-G Sound data 6 - 1 Sound pressure spectrum FTXS20G FTXS20G COOLING HEATING Approximate Approximate threshold hearing threshold hearing for continuous for continuous noise noise Octave band center frequency (Hz) Octave band center frequency (Hz) 3D059555 3D059555 NOTES... - Page 15 • Indoor Units • R-410A • FTXS-G Sound data 6 - 1 Sound pressure spectrum FTXS35G FTXS35G COOLING HEATING Approximate Approximate threshold hearing threshold hearing for continuous for continuous noise noise Octave band center frequency (Hz) Octave band center frequency (Hz) 3D059557C 3D059557C NOTES...
- Page 16 • Indoor Units • R-410A • FTXS-G Sound data 6 - 1 Sound pressure spectrum FTXS50G FTXS50G COOLING HEATING Approximate Approximate threshold hearing threshold hearing for continuous for continuous noise noise Octave band center frequency (Hz) Octave band center frequency (Hz) 3D059559B 3D059559B NOTES...
- Page 17 • Indoor Units • R-410A • FTXS-G Sound data 6 - 1 Sound pressure spectrum FTXS71GV Cooling Heating Approximate Approximate threshold hearing threshold hearing for continuous for continuous noise noise Octave band center frequency - IEC (Hz) Octave band center frequency - IEC (Hz) NOTES NOTES 50Hz...
- Page 18 The present publication is drawn up by way of information only and does not constitute an offer binding conditioning equipment, compressors and refrigerants upon Daikin Europe N.V.. Daikin Europe N.V. has compiled the content of this publication to the best of its has led to its close involvement in environmental issues.
