- Page 1 ® ® 601™ II DIRECT/REFLECTING SPEAKER SYSTEM Service Manual P/N 118915...
-
Page 2: Table Of Contents
Contents TECHNICAL DESCRIPTION ......................2 Specifications ........................... 3 Figure 1. 601™ II Ports ........................3 601 II Test Procedures ........................4 Disassembly/Assembly Procedures ....................5 601 II Part List ........................... 6 Figure 2. Front View ........................6 Figure 3. Top View........................... 6 Figure 4. -
Page 3: Technical Description
TECHNICAL DESCRIPTION SPATIAL CHARACTERISTICS ® The Bose 601™ Series II system is a high performance floor-standing speaker designed to achieve the highest level of spatial realism and spectral accuracy in a non-equalized Direct/ ® Reflecting speaker system. The new 601 Series II speaker incorporates two new concepts in ®... -
Page 4: Specifications
SPECIFICATIONS Speaker Compliment Two 8" Woofers per cabinet Four 3" Tweeters per cabinet Nominal Impedance 8Ω Power Requirements 20 watts minimum 150 watts maximum Major Port Frequency 35HZ Subport Frequency Broad band tuning centered at 240HZ Dual Frequency™ Crossover Woofer transition frequency: 2.5kHZ Tweeter transition frequency: 1.5kHZ Shipping Weight 46 LB per speaker... -
Page 5: 601 Ii Test Procedures
601™ II TEST PROCEDURES 4. Phase Test 1. Sweep Test 4.1 Momentarily apply 10VDC to the input 1.1 Apply a 10Vrms, 15HZ signal to the terminal of the speaker. Observe the input terminals of the speaker. polarity when connecting the DC supply. 1.2 Sweep the oscillator from 15HZ to 4.2 The woofer should move outwards with 2.5kHZ. -
Page 6: Disassembly/Assembly Procedures
DISASSEMBLY/ASSEMBLY PROCEDURES 1. Grille Removal 5. Tweeter Removal 1.1 Reach behind the top part of the grille 5.1 Perform procedure 1. and gently lift up on the grille. 5.2 Perform Procedure 3. It is necessary to 1.2 Once the grille has been pulled off of remove the woofer to gain access to the the four top clips, gently pull the grille away tweeter's service loop. -
Page 7: 601 Ii Part List
601 II PART LIST Item Description Part Item Description Part Number Number Number Number Grille, Side Plastic 116927 Screw, F Tweeter 119095-22 Screw, Hex Head 118065-12 Screw, R Tweeter 119094-14 Grille Assembly 115143-1 Port Trim Ring 117529-1 Nameplate 110009 Top Woofer Cup 122101 Screw, #8 x 30mm 129027-16... -
Page 8: Figure 4. Part 1 (Left) Three Terminal Schematic
RIGHT LEFT FRONT FRONT REAR WOOFER TWEETER TWEETER RIGHT LEFT REAR WOOFER FRONT TWEETER TWEETER Figure 4. Part 1 (Left) Three terminal Schematic RIGHT LEFT FRONT REAR WOOFER TWEETER TWEETER RIGHT FRONT LEFT REAR WOOFER FRONT TWEETER TWEETER Figure 5. Part 2 (Right) Three Terminal Schematic... -
Page 9: Figure 6. Two Terminal Schematic
RIGHT FRONT TWEETER LEFT REAR TWEETER WOOFER LEFT FRONT FRONT TWEETER WOOFER RIGHT REAR TWEETER Figure 6. Two Terminal Schematic... - Page 11 SPECIFICATIONS AND FEATURES SUBJECT TO CHANGE WITHOUT NOTICE ® Bose Corporation The Mountain Framingham, Massachusetts USA 01701 P/N 118915 3/96: Rev 3 FOR TECHNICAL ASSISTANCE OR PART ORDERS, CALL 1-800-367-4008...
