PASECO WKH-2310 Owner's Manual

Portable kerosene heater
Hide thumbs

Advertisement

Table of Contents




K E R OS E N E -H E A T E R
"OWNER'S MANUAL "




























Before the first use of this heater, please read this OWNER'S MANUAL very
carefully. This OWNER'S MANUAL has been designed to instruct you as to the
proper manner in which to assemble the heater, maintain the heater, store the
heater, and most importantly, how to operate the heater in a safe and efficient
manner, please keep this manual for future reference.
P O R TA B L E
MODEL: WKH-2310

Advertisement

Table of Contents
loading

Related Manuals for PASECO WKH-2310

Summary of Contents for PASECO WKH-2310

  • Page 1                           MODEL: WKH-2310                         Before the first use of this heater, please read this OWNER'S MANUAL very carefully.
  • Page 3   NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING!     CAUTIONS - SAFETY GUIDE -   T O MANU F ACTURER’S I NSTRUC T IONS M A Y WARNING!! RISK OF EXPLOSION / RISK OF FIRE   RESULT IN CONDITIONS WHICH CAN PRODUCE use any fuel other than 1-K kerosene.

  • Page 4: Table Of Contents

      NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING!       CONTENTS OF OWNER'S MANUAL     ITEM PAGE ITEM PAGE     CAUTIONS-SAFETY GUIDE TO TAKE CARD OF WICK INTRODUCTION WICK REPLACEMENT FEATURES EXTINGUISHING THE HEATER UNPACKING AND ASSEMBLY AUTOMATIC SAFETY SHUT-OFF DEVICE KEROSENE (1-K ONLY) LONG TERM STORAGE OF YOUR HEATER 13...

  • Page 5: Unpacking And Assembly

      NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING!     UNPACKING AND ASSEMBLY   CAUTION: "RISK OF BURNS"   DO NOT OPERATE HEATER WITHOUT THE PROTECTIVE NET SAFTY.   1. REMOVE THE HEATER AND ALL PACKING MATERIALS FROM THE BOX. (Fig.2)  ...

  • Page 6: Kerosene (1-K Only)

      NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING!     KEROSENE (1-K ONLY)     It is EXTREMELY IMPORTANT to the operation of this heater that you use the proper grade of kerosene. The proper grade of kerosene is identified as 1-K Kerosene. DO NOT OPERATE THIS HEATER WITH ANY FUEL OTHER THAN 1-K KEROSENE! 1-K Kerosene has been refined to virtually eliminate contaminants such as sulphur, which can cause a rotten egg odor during operation of the heater.

  • Page 7: Fueling Your Heater

      NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING!     FUELING YOUR HEATER     NEVER FILL THE HEATER FUEL TANK IN THE LIVING SPACE:   FILL THE TANK OUTDOORS.   Before fueling the heater, take the heater, the kerosene, and the manual  ...

  • Page 8: Ignition

      NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING!     IGNITION     The procedure is as follows: –Turn the wick adjuster knob clockwise until the wick has been raised to its maximum height. –Lift the burner assembly by using the burner knob. –Touch a lighted match to the exposed top edge of the wick.

  • Page 9: Wick Maintenance

      NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING!         NOTE : During start-up, small adjustments to the flame can be performed by using the burner knob on the front of the burner and MOVING THE BURNER FROM SIDE TO SIDE until the flame at the top of burner is as even as possible.

  • Page 10: Wick Replacement

      NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING!     TO TAKE CARE OF THE WICK   1. The wick which is made from glass fiber needs to have its top cut off from time to time. This should only be done if the below burning off does not reduce or clear the deposits.
  • Page 11   NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING!       4. Pull off the wick control knob by hand.   5. Remove the Stopper Screw & E-ring and then remove Rachet Gear & Spring in order.        ...
  • Page 12   NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING!         11. Replace the wick holder assembly in the Fuel Tank.   Rotate 90 degrees left and right as well as up and down until the wick Wick Holder slides freely.
  • Page 13   NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING!       18. Check for correct clearance between wick holder and draft tube. It should be the same all around.                     19. Reinstall burner & body to fuel tank reinstall dome nuts to body.  ...

  • Page 14: Extinguishing The Heater

      NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! EXTINGUISHING THE HEATER   1. Turn the wick-adjust-handle knob counter-clockwise slowly until it stops. The wick will be lowered to the bottom and the fire will be out in 3-5 minutes.   2.

  • Page 15: Long Term Storage Of Your Heater

      NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING!     LONG TERM STORAGE OF YOUR HEATER   Carefully following the instructions for storage given below will insure that your heater will operate efficiently and safely next season(Fig. 9).   Using a small amount of kerosene, swirl and rinse the inside of the tank. NEVER mix water with the kerosene as it will cause rust inside the tank.

  • Page 16: Trouble Shooting Guide

      NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! TROUBLE SHOOTING GUIDE   TROUBLE CORRECTIVE ACTION   Heater Will Not Light ;     1. Fuel tank is empty 1. Fill tank with 1-K kerosene. 2. Water present in kerosene 2. Drain tank. Remove wick assembly & replace wick.  ...

  • Page 17: Parts List

      HANDLE ASS'Y 2115-0003-00   PLATE TOP 3111-0237-00           SPECIFICATIONS   Model No. WKH-2310 Fuel consumption 0.27ltr/hr Heating output 9,000 BTU Fuel tank Integrated Tank capacity 5.3ltr Burning time 18hrs Fuel consumption 0.27ltr/hr Ignition method Manual ignition...
