Kia, THE COMPANY

Thank you for becoming the owner of a new Kia vehicle.

As a global car manufacturer focused on building high-quality, value for

money prices, Kia Motors is dedicated to providing you with a customer

service experience that exceeds your expectations.

At all of our Kia dealerships you will be treated with warmth, hospitality

and professionalism by people who care based on our "Family-like Care"

promise.

All information contained in this Owner's Manual is accurate at the

time of publication. However, Kia reserves the right to make changes

at any time so that our policy of continual product improvement can be

carried out.

This manual applies to all models of this vehicle and includes descrip-

tions and explanations of optional as well as standard equipment. As a

result, you may encounter material in this manual that is not applicable

to your specific Kia vehicle.

Enjoy your vehicle and Kia's "Family-like Care" experience!

Table of Contents

Summary of Contents for Kia picanto 2014

Page 1 Kia Motors is dedicated to providing you with a customer service experience that exceeds your expectations. At all of our Kia dealerships you will be treated with warmth, hospitality and professionalism by people who care based on our “Family-like Care”...
Page 2 Thank you for choosing a Kia vehicle. The information and specifications provided in this man- ual were accurate at the time of printing. Kia reserves the When you require service, remember that your dealer right to discontinue or change specifications or design at knows your vehicle best.
Page 3: Table Of Contents
Introduction Your vehicle at a glance Safety features of your vehicle Features of your vehicle Driving your vehicle table of contents What to do in an emergency Maintenance Specifications & Consumer information Index...
Page 4 Introduction How to use this manual / 1-2 Fuel requirements / 1-2 Vehicle break-in process / 1-4 Indicator symbols on the instrument cluster / 1-5...
Page 5 Except Europe vided in the Table of Contents. Use the CAUTION Your new Kia vehicle is designed to use index when looking for a specific area or only unleaded fuel having an Octane subject; it has an alphabetical listing of all...
Page 6: Introduction
(also known as grain alcohol), the catalytic converter and will ask an authorized Kia dealer whether and gasoline or gasohol containing damage the engine control sys- leaded gasoline in your vehicle is avail- methanol (also known as wood alcohol) tem’s oxygen sensor and affect...
Page 7 Fuel Additives between 2,000 rpm and 4,000 rpm. vapor lock or hard starting. Kia recommends that you use good qual- • Do not maintain a single speed for long ity gasolines meet Europe Fuel stan- periods of time, either fast or slow.
Page 8 Introduction INDICATOR SYMBOLS ON THE INSTRUMENT CLUSTER Parking brake & Brake fluid Air bag warning light* Malfunction indicator light warning light ABS warning light* Charging system warning light ESP indicator* Tailgate open ajar warning light ESP OFF indicator* Seat belt warning light Turn signal indicator Door ajar warning light Overspeed warning light*...
Page 9: Your Vehicle At A Glance
Your vehicle at a glance Interior overview / 2-2 Instrument panel overview / 2-3 Engine compartment / 2-4...
Page 10: Table Of Contents
Your vehicle at a glance INTERIOR OVERVIEW 1. Door lock/unlock button ....4-16 2. Central door lock switch* ....4-17 3. Power window switches*....4-21 4. Power window lock button* ....4-24 5. Outside rearview mirror control switch*..........4-39 6. Outside rearview mirror folding switch*..........4-40 7.
Page 11: Table Of Contents
Your vehicle at a glance INSTRUMENT PANEL OVERVIEW 1. Instrument cluster......4-42 2. Horn ..........4-37 3. Driver’s front air bag* .......3-46 4. Light control/Turn signals ....4-70 5. Wiper/Washer........4-76 6. Ignition switch* or ENGINE START/STOP button* ..5-4, 5-6 7. Hazard warning flasher switch ..4-68, 6-2 8.
Page 12: Table Of Contents
Your vehicle at a glance ENGINE COMPARTMENT 1.25 Gasoline ■ ■ 1. Engine coolant reservoir ..7-24 2. Radiator cap ....7-25 3.
Page 13 Seats / 3-2 Seat belts / 3-15 Child restraint system / 3-28 Air bag - supplemental restraint system / 3-39 Safety features of your vehicle...
Page 14: Safety Features Of Your Vehicle
Safety features of your vehicle SEATS Driver’s seat (1) Forward and rearward (2) Seatback angle (3) Seat cushion height* (4) Seat warmer* (5) Headrest Front passenger’s seat (6) Forward and rearward (7) Seatback angle (8) Seat warmer* (9) Walk-in seat (for 3 door vehicle only) (10) Headrest Rear seat (11) Headrest*...
Page 15: Features Of Your Vehicle
Safety features of your vehicle WARNING WARNING WARNING Loose objects Driver respon- - Driver’s seat sibility for passengers Loose objects in the driver’s foot • Never attempt to adjust the seat area could interfere with the opera- while the vehicle is moving. This Riding in a vehicle with the seat- tion of the foot pedals, possibly could result in loss of control,...
Page 16 Safety features of your vehicle (Continued) WARNING - Rear seatbacks • To avoid the possibility of burns, • The rear seatback must be do not remove the carpet in the securely latched. If not, passen- cargo area. Emission control gers and objects could be thrown devices beneath this floor gener- forward resulting in serious ate high temperatures.
Page 17 Safety features of your vehicle OTA030003L OTA030004L OPA039052 Seatback angle Seat cushion height (for driver’s seat) Headrest (if equipped) To recline the seatback: The driver's and front passenger's seats To change the height of the seat cushion, 1. Lean forward slightly and lift up on the are equipped with a headrest for the push the lever that is located on the out- seatback recline lever.
Page 18 Safety features of your vehicle WARNING • For maximum effectiveness in case of an accident, the headrest should be adjusted so the middle of the headrest is at the same height as the center of gravity of an occupant's head. Generally, the center of gravity of most peo- ple's head is similar with the height of the top of their eyes.
Page 19 Safety features of your vehicle ✽ ✽ NOTICE With the seat warmer switch in the ON position, the heating system in the seat turns off or on automatically depending on the seat temperature. CAUTION • When cleaning the seats, do not use an organic solvent such as paint thinner, benzene, alcohol and gasoline.
Page 20 Safety features of your vehicle WARNING - Seat warmer burns Passengers should use extreme caution when using seat warmers due to the possibility of excess heating or burns. The occupants must be able to feel if the seat is becoming too warm and to turn the seat warmer off.
Page 21 Safety features of your vehicle WARNING • Since stored items may move while driving, be sure to position them in the tray so that they do not make noise or cause a poten- tial safety hazard when the vehi- cle is moving. •...
Page 22 Safety features of your vehicle WARNING • For maximum effectiveness in case of an accident, the headrest should be adjusted so the middle of the headrest is at the same height as the center of gravity of an occupant's head. Generally, the center of gravity of most peo- ple's head is similar with the height of the top of their eyes.
Page 23 Safety features of your vehicle Folding the rear seat (if equipped) To fold the rear seat cushion and seat back: The rear seatbacks (or cushions) may be The rear seatbacks may be folded for- folded to facilitate carrying long items or to increase the luggage capacity of the ward to provide additional cargo space vehicle.
Page 24 Safety features of your vehicle Type A Type A ■ ■ CAUTION • When folding or unfolding the rear seat, make sure to move the front seat fully forward. If there are not enough space to fold the rear seat, never fold it by force. It will cause damage to the head- rest or the related parts of the seat.
Page 25 Safety features of your vehicle Type A Type A Type A ■ ■ ■ OSA037011 OSA037012 OSA037014 Type B Type B ■ ■ OSA037019 OSA037038 OSA037039 5. Move the seat cushion firmly (3). 6. Lower the headrest as low as possible 8.
Page 26 Safety features of your vehicle To unfold the rear seat: CAUTION - Rear seat belts WARNING 1. Lift and push the seatback backward When returning the rear seatbacks firmly until it clicks into place. When you return the rear seatback to the upright position, remember to its upright position after being 2.
Page 27 Safety features of your vehicle SEAT BELTS Seat belt restraint system (Continued) (Continued) • Avoid wearing twisted seat belts. Care should be taken to avoid con- WARNING A twisted belt can't do its job as tamination of the webbing with pol- •...
Page 28 Safety features of your vehicle WARNING • No modifications or additions should be made by the user which will either prevent the seat belt adjusting devices from oper- ating to remove slack, or prevent the seat belt assembly from being adjusted to remove slack.
Page 29 Safety features of your vehicle If you continue not to fasten the seat belt If the rear seat belt is disconnected when and you drive over 20km/h the seat belt you drive over the 20km/h, the corre- warning chime will sound for approxi- sponding seat belt warning light will blink mately 100 seconds and the correspon- and warning chime will sound for 35 sec-...
Page 30 Safety features of your vehicle To raise the height adjuster, pull it up (1). Front seat To lower it, push it down (3) while press- ing the height adjuster button (2). Release the button to lock the anchor into position. Try sliding the height adjuster to make sure that it has locked into position.
Page 31 Safety features of your vehicle ✽ ✽ NOTICE If you are not able to pull out the seat belt from the retractor, firmly pull the belt out and release it. Then you will be able to pull the belt out smoothly. B200A02NF OTA030049L When using the rear center seat belt, the...
Page 32 Safety features of your vehicle Shorten Lengthen OEN036030 B210A01NF-1 OBH038067 Lap belt (if equipped) To release the seat belt: The seat belt is released by pressing the To fasten your seat belt: release button (1) on the locking buckle. To fasten a 2-point static type belt, insert Too high When it is released, the belt should auto- the metal tab (1) into the locking buckle...
Page 33 Safety features of your vehicle OTA032025 B210A02NF-2 OTA030027 When using the rear center seat belt, the Stowing the rear seat belt To release the seat belt: buckle with the “CENTER” mark must be When you want to release the seat belt, The rear seat belt buckles can be stowed used.
Page 34 Safety features of your vehicle When the vehicle stops suddenly, or if the occupant tries to lean forward too quickly, the seat belt retractor will lock into position. In certain collisions, the pre- tensioner will activate and pull the seat belt into tighter contact against the occu- pant's body.
Page 35 • Although it is harmless, the fine dust always wear seat belts properly. authorized Kia dealer. may cause skin irritation and should not be breathed for prolonged periods. Wash all exposed skin areas thorough- ly after an accident in which the pre- tensioner seat belts were activated.
Page 36 Properly worn seat belts greatly tact an authorized Kia dealer. after they have been activated. reduce these hazards. • Do not attempt to inspect or...
Page 37 Safety features of your vehicle Infant or small child Larger children ✽ ✽ NOTICE You should be aware of the specific Children who are too large for child Small children are best protected from requirements in your country. Child restraint systems should always occupy injury in an accident when properly and/or infant seats must be properly the rear seat and use the available...
Page 38 Safety features of your vehicle Pregnant women One person per belt If the shoulder belt portion slightly touch- es the child’s neck or face, try placing the The use of a seat belt is recommended Two people (including children) should child closer to the center of the vehicle.
Page 39 This should be done even if no damage backs upright. replaced immediately. is visible. We recommend that you con- sult an authorized Kia dealer. 3 27...
Page 40 Safety features of your vehicle CHILD RESTRAINT SYSTEM Children riding in the car should sit in the rear seat and must always be properly WARNING WARNING restrained to minimize the risk of injury in • A child restraint system must be To reduce the chance or serious or an accident, sudden stop or sudden placed in the rear seat.
Page 41 Forward-facing child restraint system • Never allow two children, or any that the system be checked by an two persons, to use the same authorized Kia dealer. seat belt. • If there is not enough space to • Children often squirm and repo- place the child restraint system sition themselves improperly.
Page 42 Installing a child restraint system by recommend that the system be lap/shoulder belt checked by an authorized Kia To install a child restraint system on the dealer. outboard or center rear seats, do the fol- •...
Page 43 Safety features of your vehicle E2BLD310 MMSA3030 E2BLD347 2. Fasten the lap/shoulder belt latch into 3. Buckle the seat belt and allow the seat Installing a child restraint system by the buckle. Listen for the distinct “click” belt to take up any slack. After installa- lap belt (on the center rear seat) sound.
Page 44 Safety features of your vehicle WARNING Tether strap • A child can be seriously injured or killed in a collision if the child restraint is not properly anchored to the car and the child is not properly restrained in the child restraint.
Page 45 Safety features of your vehicle WARNING - Child restraint anchorage • Child restraint anchorages are designed to withstand only those loads imposed by correctly fitted child restraints. Under no circum- stances are they to be used for adult seat belts or harnesses or for attaching other items or equipment to the vehicle.
Page 46 Safety features of your vehicle Both rear outboard seats are equipped To secure the child restraint seat with a pair of ISOFIX anchorages as well WARNING 1. To engage the child restraint seat to as a corresponding top tether anchorage the ISOFIX anchor, insert the child Install the child restraint seat fully on the back side of the back rest.
Page 47 Safety features of your vehicle (Continued) WARNING • Attach the ISOFIX or ISOFIX-com- • Do not install a child restraint patible child restraint seat only to seat at the center of the rear seat the appropriate locations shown using vehicle's ISOFIX in the illustration.
Page 48 Safety features of your vehicle Child Seat Restraint Suitability For Seat Position using the Seat Belt WARNING - For Europe recommend that child Use child safety seats that have been officially approved and are appropriate for your restraint seat be installed in the children.
Page 49 Safety features of your vehicle Child seat restraint suitability for vehicle ISOFIX positions - For Europe vehicle ISOFIX positions Mass Group Size Class Fixture Rear Outboard Rear Outboard Front Passenger Rear Center (Driver side) (Passenger side) ISO/L1 Carrycot ISO/L2 0 : UP to 10kg ISO/R1 ISO/R1 0+ : UP to 13kg...
Page 50 Safety features of your vehicle Recommended child restraint systems – For Europe ECE-R44 Mass Group Name Manufacturer Type of Fixation Approval No. E4 03443416 (Seat) Rearward facing with vehicle Bimbo G0/1 S FAIR specific ISOFIX platform type “A” E4 0443718 (Platform) Group 0-1 (0-18kg) Baby-Safe Plus II...
Page 51: Driver's Front Air Bag*
Safety features of your vehicle AIR BAG - SUPPLEMENTAL RESTRAINT SYSTEM (IF EQUIPPED) (1) Driver’s front air bag* (2) Passenger’s front air bag* (3) Side impact air bag* (4) Curtain air bag* (5) Driver’s knee air bag* (6) Front passenger’s air bag ON/OFF switch* * : if equipped WARNING...
Page 52 Safety features of your vehicle How does the air bag system It is much more likely that you will sim- ply see the deflated air bags hanging WARNING operate out of their storage compartments after • To avoid severe personal injury •...
Page 53 Safety features of your vehicle Noise and smoke In addition, do not place a front-facing ■ Type A child restraints in the front passenger’s When the air bags inflate, they make a seat. If the front passenger air bag loud noise and they leave smoke and powder in the air inside of the vehicle.
Page 54 Safety features of your vehicle W7-147 OTA030044L OTA030045L Air bag warning light Passenger’s front air bag Passenger’s front air bag ON indicator (if equipped) OFF indicator (if equipped) The purpose of the air bag warning light in your instrument panel is to alert you of a potential problem with your air bag - The passenger's front air bag ON indica- The passenger’s front air bag OFF indi-...
Page 55 11. Passenger’s front air bag ON/OFF system be inspected by an author- occurs, this indicates a malfunction switch* ized Kia dealer. of the SRS. We recommend that the 12. Passenger’s front air bag ON/OFF system be inspected by an author- indicator* ized Kia dealer.
Page 56 Safety features of your vehicle Driver’s front air bag (1) Driver’s front air bag (2) Driver’s front air bag (3) OHM039102N OHM039103N OHM039104N The front air bag modules are located Upon deployment, tear seams molded A fully inflated air bag, in combination both in the center of the steering wheel, directly into the pad covers will separate with a properly worn seat belt, slows the...
Page 57 If this occurs, we recom- instrument panel surface. mend that the system be inspect- It may become a dangerous pro- ed by an authorized Kia dealer. jectile and cause injury if the pas- (Continued) senger's air bag inflates. 3 45...
Page 58 Safety features of your vehicle The indications of the system's presence Driver’s front air bag Passenger’s front air bag are the letters "AIR BAG" embossed on the air bag pad cover in the steering wheel and/or on the cover of the driver’s side knee bolster located below the steering wheel and the passenger's side front panel pad above the glove box.
Page 59 (Continued) booster seat in the front seat. ed by an authorized Kia dealer. • ABC – Always Buckle Children in • Air bags can only be used once – the back seat. It is the safest place we recommend that the system for children of any age to ride.
Page 60 Safety features of your vehicle (Continued) (Continued) (Continued) • The SRS is designed to deploy • Children age 12 and under must • Sitting improperly or out of posi- the front air bags only when an always be properly restrained in tion can result in serious or fatal impact is sufficiently severe and the rear seat.
Page 61 Safety features of your vehicle WARNING The front air bag ON/OFF switch could turn by using a similar small rigid device. Always check the sta- tus of the front air bag ON/OFF switch and passenger's front air bag ON/OFF indicator. ✽...
Page 62 OFF indicator ( ) will not illumi- function may occur in the SRS authorized Kia dealer. nate (The passenger's front air Control Module. bag ON indicator comes on and And there may be a danger that...
Page 63 Safety features of your vehicle The side impact air bags are designed to Front (Continued) deploy only during certain side-impact • Even though your vehicle is collisions, depending on the crash sever- equipped with the passenger's ity, angle, speed and point of impact. The front air bag ON/OFF switch, do side impact air bags are not designed to not install a child restraint sys-...
Page 64 Kia dealer. (Continued) They are designed to help protect the heads of the front seat occupants and the rear outboard seat occupants in cer-...
Page 65 We recommend tion, front seat occupants and that the system be serviced by an outboard rear occupants should authorized Kia dealer. sit in an upright position with the seat belts properly fastened. Failure to follow the above instruc-...
Page 66 Safety features of your vehicle Why didn’t my air bag go off in a collision? (Inflation and non-infla- tion conditions of the air bag) There are many types of accidents in which the air bag would not be expect- ed to provide additional protection. These include rear impacts, second or third collisions in multiple impact accidents, as well as low speed...
Page 67 We recommend that the result in serious personal injury system be serviced by an author- or death. ized Kia dealer. • If the installation location or • Your vehicle has been designed angle of the sensors is altered in...
Page 68 Safety features of your vehicle Although the front air bags (driver’s and front passenger’s air bags) are designed to inflate only in frontal collisions, they also may inflate in other types of colli- sions if the front impact sensors detect a sufficient impact.
Page 69 Safety features of your vehicle OPA037042 OSA038121 1VQA2089 • Frontal air bags are not designed to • Front air bags may not inflate in side • In an angled collision, the force of inflate in rear collisions, because occu- impact collisions, because occupants impact may direct the occupants in a pants are moved backward by the move to the direction of the collision,...
Page 70 Safety features of your vehicle OPA037043 1VQA2091 OSA038122 • Just before impact, drivers often brake • Air bags does not inflate in most • Air bags may not inflate if the vehicle heavily. Such heavy braking lowers the rollover accidents (even if the vehicle is collides with objects such as utility front portion of the vehicle causing it to equipped with side impact air bags and...
Page 71 If the SRS air bag by an authorized Kia dealer. of any kind of badges to the pad warning light does not illuminate •...
Page 72 Safety features of your vehicle Additional safety precautions • Keep occupants away from the air bag covers. All occupants should sit WARNING • Never let passengers ride in the upright, fully back in their seats with cargo area or on top of a folded- •...
Page 73 Safety features of your vehicle OTA030040L Air bag warning label (if equipped) Air bag warning labels are attached to alert the driver and passengers of poten- tial risk of air bag system. Note that these government warnings focus on the risk of children. We also want you to be aware of the risks which adults are exposed to.
Page 74 Keys / 4-3 Remote keyless entry / 4-6 Smart key / 4-9 Theft-alarm system / 4-12 Door locks / 4-15 Tailgate / 4-19 Windows / 4-21 Hood / 4-26 Features of your vehicle Fuel filler lid / 4-28 Sunroof / 4-31 Steering wheel / 4-35 Mirrors / 4-38 Instrument cluster / 4-42...
Page 75 Storage compartments / 4-101 Interior features / 4-103 Audio system / 4-109 Features of your vehicle...
Page 76 Should you lose your keys, we recom- mend that you contact an authorized Kia dealer. Remove the key code tag and store it in a safe place. Also, record the key number and keep it in a safe and handy place, but not in the vehicle.
Page 77 WARNING With the immobilizer system, whenever you insert your ignition key into the igni- Use only Kia original parts for the tion switch and turn it to ON, it checks ignition key in your vehicle. If an and determines and verifies if the ignition aftermarket key is used, the ignition key is valid or not.
Page 78 We recommend engine from being started. that the system be serviced by an To deactivate the immobilizer sys- authorized Kia dealer. tem: Malfunctions caused by improper Insert the ignition key into the key cylin- ✽ ✽ NOTICE alterations, adjustments or modifi- der and turn it to the ON position.
Page 79 Features of your vehicle REMOTE KEYLESS ENTRY (IF EQUIPPED) Lock (1) Tailgate unlock (3) (if equipped) Type A ■ All doors (and tailgate) are locked if the The tailgate is unlocked if the button is lock button is pressed while all doors are pressed for more than 1 second.
Page 80 If you have a problem with OYDECO2006CN the transmitter, we recommend that you Type C ■ contact an authorized Kia dealer. CAUTION Keep the transmitter away from water or any liquid. If the keyless entry system is inoperative due to...
Page 81 Be sure to use For transmitter replacement, we recom- the correct battery. mend that you contact an authorized Kia dealer. • To avoid damaging the transmit- ter or smart key, don't drop it, get...
Page 82 Features of your vehicle SMART KEY (IF EQUIPPED) Type A ■ WARNING If the battery of accessory smart key is totally discharged, it is impossible to enter the vehicle. In this case, you can enter the vehicle with a mechan- ical key.
Page 83 Features of your vehicle Unlocking Tailgate unlocking Even though you press the outside door handle buttons, the doors will not lock Pressing the button of the front outside If you are within 0.7 m ~ 1 m (28 ~ 40 in.) and the chime will sound for 3 seconds if door handles with all doors (and tailgate) from the outside tailgate handle, with...
Page 84 Avoid placing you contact an authorized Kia dealer. the transmitter (or smart key) and • The smart key will not work if any of your cell phone or smart phone in the...
Page 85 Features of your vehicle THEFT-ALARM SYSTEM (IF EQUIPPED) Armed stage Using the smart key Park the vehicle and stop the engine. Armed Arm the system as described below. stage 1. Turn off the engine. 2. Make sure that all doors (and tailgate) and the engine hood are closed and latched.
Page 86 Features of your vehicle Using the transmitter Theft-alarm stage • Lock the doors by pressing the lock button on the smart key. Park the vehicle and stop the engine. The alarm will be activated if any of the After completion of the steps above, Arm the system as described below.
Page 87 • If you lose your keys, we recommend - The engine is started. that you consult an authorized Kia dealer. After the doors are unlocked, the hazard warning lights will blink twice to indicate ✽...
Page 88 Features of your vehicle DOOR LOCKS Transmitter/Smart key ✽ ✽ NOTICE • Doors can be locked and unlocked with • In cold and wet climates, door locks the transmitter (or smart key). (if and door mechanisms may not work equipped) properly due to freezing conditions.
Page 89 Features of your vehicle • If the inner door handle of the front doors is pulled when the door lock but- ton is in lock position, the button is unlocked and door opens. (if equipped) • Front door cannot be locked if the igni- tion key is in the ignition switch and the door is open.
Page 90: Central Door Lock Switch*
Features of your vehicle Driver’s door WARNING - WARNING Doors Unlocked vehicles • The doors should always be fully closed and locked while the vehi- Leaving your vehicle unlocked can cle is in motion to prevent acci- invite theft or possible harm to you dental opening of the door.
Page 91 Features of your vehicle Impact sensing door unlock sys- 3. Close the rear door. tem (if equipped) To open the rear door, pull the outside door handle. All doors will automatically unlock after Even though the doors may be unlocked, an impact causes the air bags to deploy.
Page 92: Driving Your Vehicle
Features of your vehicle TAILGATE ✽ ✽ NOTICE In cold and wet climates, door lock and door mechanisms may not work proper- ly due to freezing conditions. WARNING The tailgate swings upward. Make sure no objects or people are near the rear of the vehicle when open- ing the tailgate.
Page 93 Features of your vehicle WARNING Exhaust fumes If you drive with the tailgate open, you will draw dangerous exhaust fumes into your vehicle which can cause serious injury or death to vehicle occupants. If you must drive with the tailgate open, keep the air vents and all win- dows open so that additional out- side air comes into the vehicle.
Page 94 Features of your vehicle WINDOWS (1) Driver’s door power window switch (2) Front passenger’s door power win- dow switch (3) Rear door (left) power window switch* (4) Rear door (right) power window switch* (5) Window opening and closing (6) Automatic power window up*/down* (Driver’s window) (7) Power window lock switch* * : if equipped...
Page 95 Features of your vehicle Power windows (if equipped) The ignition switch must be in the ON position for power windows to operate. Each door has a power window switch that controls the door's window. The driver has a power window lock switch which can block the operation of passenger win- dows.
Page 96 Features of your vehicle ✽ ✽ NOTICE The automatic reverse feature for the driver’s window is only active when the “auto up” feature is used by fully pulling up the switch. The automatic reverse feature will not operate if the window is raised using the halfway posi- tion on the power window switch.
Page 97: Power Window Lock Button*
Features of your vehicle Except Europe WARNING - Windows The driver can disable the power window switches on the front and rear passen- • Never leave the keys in your vehi- ger's doors by pressing the power window cle with unsupervised children, lock switch to lock position (pressed).
Page 98 Features of your vehicle OSA028222 Manual windows (if equipped) To raise or lower the window, turn the window regulator handle clockwise or counterclockwise. WARNING When opening or closing the win- dows, make sure your passenger's arms, hands and body are safely out of the way.
Page 99 Features of your vehicle HOOD OTA040017 OTA040018 OTA040019 Opening the hood 2. Go to the front of the vehicle, raise the 3. Pull the support rod from the hood. hood slightly, pull the secondary latch 4. Hold the hood open with the support 1.
Page 100 Features of your vehicle Closing the hood WARNING 1. Before closing the hood, check the fol- lowing: • Always double check to be sure that the hood is firmly latched • All filler caps in engine compartment before driving away. If it is not must be correctly installed.
Page 101 Features of your vehicle FUEL FILLER LID Closing the fuel filler lid 1. To install the cap, turn it clockwise until it “clicks”. This indicates that the cap is securely tightened. 2. Close the fuel filler lid and push it light- ly and make sure that it is securely closed.
Page 102 Features of your vehicle (Continued) (Continued) WARNING - Refueling dan- Use only approved portable plas- • Do not get back into a vehicle gers tic fuel containers designed to once you have begun refueling Automotive fuels are flammable carry and store gasoline. since you can generate static materials.
Page 103 • If the fuel filler cap requires then contact the local fire depart- replacement, use only a genuine ment. Follow any safety instruc- Kia cap or the equivalent speci- tions they provide. fied for your vehicle. An incorrect fuel filler cap can result in a seri- ous malfunction of the fuel sys- tem or emission control system.
Page 104 Features of your vehicle SUNROOF (IF EQUIPPED) ✽ ✽ NOTICE ✽ ✽ NOTICE • In cold and wet climates, the sunroof The sunroof cannot slide when it is in may not work properly due to freez- the tilt position nor can it be tilted while ing conditions.
Page 105 Features of your vehicle To open the sunroof automatically: Pull the sunroof control lever backward to the second detent position and then release it. The sunroof will slide all the way open. To stop the sunroof sliding at any point, pull or push the sunroof control lever momentarily.
Page 106 Features of your vehicle CAUTION WARNING • Periodically remove any dirt that • Never try pinching any part of may accumulate on the guide rail. your body intentionally to acti- • If you try to open the sunroof vate the Automatic reversal func- when the temperature is below tion.
Page 107 Resetting the sunroof ❈ For more detailed information, we rec- ommend that you contact an author- Whenever the vehicle battery is discon- ized Kia dealer. nected or discharged, or related fuse is blown, you must reset your sunroof sys- tem as follows:...
Page 108: Steering Wheel
We recommend that you wheel both up and down to be effort required to steer during normal contact an authorized Kia dealer. certain it is locked in position. vehicle operation, we recommend that • The steering effort increases if the...
Page 109 Features of your vehicle CAUTION • Do not install any grip to operate the steering wheel. This causes damage to the heated steering wheel system. • When cleaning the heated steering wheel, do not use an organic sol- vent such as paint thinner, ben- zene, alcohol and gasoline.
Page 110: Horn
Features of your vehicle CAUTION Do not strike the horn severely to operate it, or hit it with your fist. Do not press on the horn with a sharp- pointed object. OTA040027 Horn To sound the horn, press the horn sym- bols on your steering wheel.
Page 111 Features of your vehicle MIRRORS Inside rearview mirror Outside rearview mirror Adjust the rearview mirror to center on Be sure to adjust mirror angles before the view through the rear window. Make driving. this adjustment before you start driving. Your vehicle is equipped with both left- Night hand and right-hand outside rearview mirrors.
Page 112 Features of your vehicle CAUTION Do not scrape ice off the mirror face; this may damage the surface of the glass. If ice should restrict movement of the mirror, do not force the mirror for adjustment. To remove ice, use a deicer spray, or a sponge or soft cloth with very warm water.
Page 113 Features of your vehicle CAUTION CAUTION • The mirrors stop moving when The electric type outside rearview they reach the maximum adjust- mirror operates even though the ing angles, but the motor contin- ignition switch is in the OFF posi- ues to operate while the switch is tion.
Page 114 Features of your vehicle OTA040031 Manual type To fold outside rearview mirror, grasp the housing of mirror and then fold it toward the rear of the vehicle. 4 41...
Page 115: Instrument Cluster
Features of your vehicle INSTRUMENT CLUSTER Type A ■ ■ 1. Tachometer 2. Turn signal indicators 3. Speedometer 4. Fuel gauge 5. Warning and indicator lights 6. Odometer/Trip computer* Type B ■ ■ 7. LCD display* 8. Shift position indicator* (A/T) * : if equipped ❈...
Page 116 Features of your vehicle Type A ■ OTA040034 Type B ■ OTA042209L OTA040035 Instrument panel illumination Tachometer (if equipped) The tachometer indicates the approxi- mate number of engine revolutions per The instrument panel illumination intensi- minute (rpm). ty can be adjusted by rotating the control Use the tachometer to select the correct knob with the headlight switch in the shift points and to prevent lugging and/or...
Page 117 Features of your vehicle On inclines or curves, the fuel gauge ■ Type A pointer may fluctuate or the low fuel warn- ing light may come on earlier than usual due to the movement of fuel in the tank. WARNING - Fuel gauge Running out of fuel can expose vehicle occupants to danger.
Page 118 Features of your vehicle Type A Type A TRIP A ■ ■ TRIP B Distance to empty* OTA040038 OTA040039 Type B Type B ■ ■ Average fuel consumption* Average refuel consumption* OTA042038 OTA042039 Odometer (km or mi.) Tripmeter (km or mi.) Instant fuel consumption* The odometer indicates the total dis- TRIP A : Tripmeter A...
Page 119 Features of your vehicle Type A Type A Type A ■ ■ ■ OTA040040 OTA040041L OTA040205L Type B Type B Type B ■ ■ ■ OTA042040 OTA042041L OTA042205L Distance to empty (km or mi.) Average fuel consumption (if equipped) Average refuel consumption (if equipped) (if equipped) (L/100 km or MPG) (l/100 km or MPG)
Page 120 Features of your vehicle Type A Type A Type A ■ ■ ■ OTA040042L OTA040043 OTA040044 Type B Type B Type B ■ ■ ■ OTA042042 OTA042043 OTA042044 Instant fuel consumption (if equipped) Elapsed time Outside thermometer (if equipped) (L/100 km or MPG) This mode indicates the total time trav- This mode indicates the outside temper- Type A...
Page 121 Features of your vehicle Type A Type B ■ ■ WARNING Never remove the radiator cap when the engine is hot. The engine coolant is under pressure and could cause severe burns. Wait until the engine is cool before adding coolant to the reservoir. OTA043360E OTA040045/OTA042045 ECO ON/OFF mode (if equipped)
Page 122 Features of your vehicle LCD display informations • Manual transaxle (if equipped) You can turn the manual transaxle shift Door/Tailgate open indicator on/off on the instrument cluster in this mode. ■ Door If you select the ECO OFF in the trip computer, the manual transaxle shift indi- cator will not illuminate.
Page 123 Features of your vehicle Align steering wheel (if equipped) Align steering wheel (if equipped) Illumination intensity OTA042229L OTA042228L OTA042227L If you start the engine when the steering If you start the engine when the steering The illumination intensity of the instru- wheel is turned 90 degrees to the left wheel is turned 90 degrees to the right ment panel is shown when adjusting it...
Page 124 Features of your vehicle For vehicle’s equipped with smart key system Key is not in vehicle Key is not detected Please press start button with smart key OTA042221L OTA042219L OTA042225L If the smart key is not in the vehicle and If the smart key is not in the vehicle or is If you press the engine start/stop button if any door is opened or closed with the...
Page 125 Features of your vehicle For vehicle’s equipped with smart key system Low key battery Press brake pedal to start engine Press clutch pedal to start engine (for automatic transaxle) (for manual transaxle) OTA042213L OTA042217L If the engine start/stop button changes to OTA042218L the OFF position when the smart key in If the engine start/stop button changes to...
Page 126 10 seconds. (if equipped) If the warning illuminates each time you press the engine start/stop button, we recommend that you have the vehicle inspected by an authorized Kia dealer as soon as possible. 4 53...
Page 127 Features of your vehicle For vehicle’s equipped with smart key system Press start button while turn steering Check steering wheel lock system Steering wheel unlock (if equipped) (if equipped) OTA042215L OTA042214L If the steering wheel does not lock nor- OTA042216L If the steering wheel does not unlock nor- If the steering wheel does not lock nor- mally when the ENGINE START/STOP...
Page 128 Features of your vehicle Warnings and indicators ECO indicator Check stop lamp fuse (if equipped) All warning lights are checked by turning (Automatic transaxle) the ignition switch ON (do not start the engine). If any light is still ON, this indi- cates a situation that needs attention.
Page 129 ON position or start- In this case, we recommend that you have ed the engine, or if it comes on while the vehicle inspected by an authorized Kia driving, we recommend that you have the WARNING dealer.
Page 130 Kia dealer. 3. Do not drive the vehicle if leaks are indicated. In this case, we recommend found, the warning light remains on or that you have the vehicle inspected by an the brakes do not operate properly.
Page 131 Features of your vehicle High beam indicator Front fog light indicator Low Beam Indicator Light (if equipped) (if equipped) This indicator illuminates when the head- This indicator light illuminates when the This indicator illuminates when the front lights are on and in the high beam posi- headlights are on.
Page 132 : Indicates that shifting up to the 3rd the engine and check the oil level. If inspected by an authorized Kia dealer as gear is desired (currently the shift the oil level is low, fill the engine oil soon as possible.
Page 133 With smart key system you have the vehicle inspected by an If any of the following occurs in a vehicle authorized Kia dealer as soon as pos- equipped with the smart key, the immobi- sible. lizer indicator illuminates, blinks or goes off.
Page 134 When it comes on, you Control System which monitors various Kia dealer as soon as possible. should add fuel as soon as possible. emission control system components. If • When the battery is weak, if the...
Page 135 In this case, we recommend case, we recommend that you have the that you have the vehicle inspected vehicle inspected by an authorized Kia by an authorized Kia dealer as soon dealer. as possible. ESP OFF indicator (if equipped)
Page 136 Features of your vehicle KEY OUT indicator Key reminder warning chime Overspeed warning (if equipped) (if equipped) (if equipped) km/h When the ENGINE START/STOP button Without smart key system Overspeed warning light is in the ACC or ON position, if any door If the driver’s door is opened while the If you drive with the speed of 120 km/h or is open, the system checks for the smart...
Page 137 Replace the battery with new one. blink for 5 seconds. ommend that you have the vehicle inspected by an authorized Kia dealer. For more details, refer to the ISG (Idle Stop and Go) system in chapter 5. Icy road warning light (if equipped) ✽...
Page 138 Features of your vehicle REAR PARKING ASSIST SYSTEM (IF EQUIPPED) Operation of the rear parking WARNING assist system The rear parking assist system is a Operating condition supplementary function only. The • This system will activate when backing operation of the rear parking assist up with the ignition switch ON.
Page 139 Features of your vehicle Non-operational conditions of Rear parking assist system pre- The detecting range may decrease when: rear parking assist system cautions 1. The sensor is stained with foreign mat- The rear parking assist system may • The rear parking assist system may ter such as snow or water.
Page 140 If this occurs, we recommend that be detected by the sensors. the system be checked by an authorized Always visually check behind the vehi- Kia dealer. cle when backing up. Be sure to inform any drivers of the WARNING...
Page 141 Features of your vehicle HAZARD WARNING FLASHER OTA040049 The hazard warning flasher should be used whenever you find it necessary to stop the car in a hazardous location. When you must make such an emer- gency stop, always pull off the road as far as possible.
Page 142 Features of your vehicle LIGHTING Battery saver function Headlight escort function Headlight welcome function (if equipped) (if equipped) • The purpose of this feature is to pre- vent the battery from being dis- The headlights (and/or taillights) will When the headlight switch is in the ON or charged.
Page 143 Features of your vehicle ■ Type A ■ Type A ■ Type A OTA040050E ORBC040047 ORBC040048 ■ Type B ■ Type B ■ Type B OTA040050L ORB040047E ORB040048E Lighting control Parking light position ( Headlight position ( The light switch has a Headlight and a When the light switch is in the parking When the light switch is in the headlight Parking light position.
Page 144 Features of your vehicle ■ Type A CAUTION • Never place anything over sensor (1) located on the instrument panel. This will ensure better auto-light system control. • Don’t clean the sensor using a window cleaner. The cleaner may ORBC040049 leave a light film which could ■...
Page 145 Features of your vehicle They will self-cancel after a turn is com- Type A ■ ■ Type A pleted. If the indicator continues to flash after a turn, manually return the lever to the OFF position. To signal a lane change, move the turn signal lever slightly and hold it in position (B).
Page 146 Features of your vehicle ■ Type A ■ Type C CAUTION When in operation, the fog lights consume large amounts of vehicle electrical power. Only use the fog lights when visibility is poor or unnecessary battery and generator drain could occur. ✽...
Page 147 Features of your vehicle To turn off the rear fog lights, turn the switch to OFF (without ■ Type A ■ Type C Auto light) ✽ ✽ NOTICE To turn on the rear fog light switch, the ignition switch must be in the ON position.
Page 148: Headlight Leveling Device*
Features of your vehicle Loading condition Switch position Driver only Driver + Front passenger Full passengers Full passengers + Maximum permissible loading Driver + Maximum permis- sible loading OTA040200L Headlight leveling device (if equipped) Manual type To adjust the headlight beam level according to the number of passengers and loading weight in the luggage area, turn the beam leveling switch.
Page 149: Wiper/Washer
Features of your vehicle WIPERS AND WASHERS A : Wiper speed control Windscreen wiper/washer · MIST ( ) – Single wipe Type A Type C ■ ■ · OFF (O) – Off · INT (---) – Intermittent wipe · LO (1) – Low wiper speed ·...
Page 150 Features of your vehicle Windshield wipers D : Rear wiper/washer control Rear window wiper/washer (if equipped) (if equipped) Operates as follows when the ignition · – Wash with brief wipes switch is turned ON. Type C ■ MIST ( ) : For a single wiping cycle, ·...
Page 151 Features of your vehicle Type A Type C ■ ■ CAUTION To prevent possible damage to the washer pump, do not operate the washer when the fluid reservoir is empty. WARNING Do not use the washer in freezing ORBC040056E OTA040056 temperatures without first warming Type B Type D...
Page 152 Features of your vehicle INTERIOR LIGHT Type C ■ - Spraying washer fluid and wiping CAUTION - Normal wiper operation Do not use the interior lights for extended periods when the engine OFF (O) - Wiper is not in operation is not running.
Page 153 Features of your vehicle The map lamp goes out gradu- ally after approximately 30 sec- onds if the door is closed. However, if the ignition switch is ON or all doors are locked, the map lamp will turn off immedi- ately.
Page 154 Features of your vehicle However, if a door is opened with the ignition switch in the ON posi- tion, the room lamp stays on con- tinuously. • OFF : The lights turn off even if a door is opened. • ON : The room lamp stay on at all times.
Page 155 Features of your vehicle DEFROSTER Outside rearview mirror defroster Type A ■ CAUTION (if equipped) To prevent damage to the conduc- If your vehicle is equipped with the out- tors bonded to the inside surface of side rearview mirror defrosters, they will the rear window, never use sharp operate at the same time you turn on the instruments or window cleaners...
Page 156 Features of your vehicle MANUAL CLIMATE CONTROL SYSTEM (IF EQUIPPED) ■ ■ Type A 1. Mode selection knob 2. Air intake control knob 3. Fan speed control knob 4. Temperature control knob 5. Air conditioning button (if equipped) ■ ■ Type B 6.
Page 157 Features of your vehicle Heating and air conditioning 1. Start the engine. 2. Set the mode to the desired position. For improving the effectiveness of heating and cooling; - Heating: - Cooling: 3. Set the temperature control to the desired position. 4.
Page 158 Features of your vehicle Face-Level (B, D) Floor/Defrost-Level (A, C, D) Most of the air flow is directed to the floor Air flow is directed toward the upper body and the windshield with a small amount and face. Additionally, each outlet can be directed to the side window defrosters.
Page 159 Features of your vehicle OTA040064 OTA040065 OTA040066 Temperature control Air intake control Instrument panel vents You can adjust the direction of air deliv- The temperature control knob allows you The air intake control is used to select ery from these vents using the vent con- to control the temperature of the air flow- the outside (fresh) air position or recircu- trol lever as shown.
Page 160 Features of your vehicle Recirculated air position ✽ ✽ NOTICE WARNING With the recirculated air Prolonged operation of the heater in the position selected, air from • Continue using the climate con- recirculated air position (without air the passenger compart- trol system in the recirculated air conditioning selected) may cause fogging ment will be drawn through...
Page 161 Features of your vehicle System operation Ventilation 1. Set the mode to the position. 2. Set the air intake control to the outside (fresh) air position. 3. Set the temperature control to the desired position. 4. Set the fan speed control to the desired speed.
Page 162 Air conditioning Operation Tips ✽ ✽ NOTICE • To keep dust or unpleasant fumes from Kia Air Conditioning Systems are filled • When using the air conditioning sys- entering the vehicle through the venti- with environmentally friendly R-134a tem, monitor the temperature gauge lation system, temporarily set the air refrigerant.
Page 163 (fresh) air position is selected. If this hap- pens, we recommend that the climate control air filter be replaced by an author- ized Kia dealer.
Page 164 Therefore, if abnormal operation is • When the air flow rate suddenly found, we recommend that the system be decreases, we recommend that the inspected by an authorized Kia dealer. system be checked by an authorized Kia dealer. ✽ ✽ NOTICE It is important that the correct type and amount of oil and refrigerant is used.
Page 165 Features of your vehicle AUTOMATIC CLIMATE CONTROL SYSTEM (IF EQUIPPED) Type A ■ ■ 1. Temperature control knob 2. AUTO (automatic control) button 3. OFF button 4. Climate control display 5. Fan speed control knob 6. Air conditioning button (if equipped) 7.
Page 166 Features of your vehicle OTA040070 OTA040074 OTA040071 Automatic heating and air condi- 2. Set the temperature control knob to ✽ ✽ NOTICE tioning set the desired temperature. Never place anything over the sensor 1. Push the AUTO button. The modes, located on the instrument panel to ✽...
Page 167 Features of your vehicle Manual heating and air condition- Floor & Defrost (A, C, D) The heating and cooling system can be controlled manually by pushing buttons Most of the air flow is directed to the floor other than the AUTO button. In this case, and the windshield with a small amount the system works sequentially according directed to the side window defrosters.
Page 168 Features of your vehicle OTA040073 OTA040064 OTA040074 Temperature control Defrost-Level Instrument panel vents Most of the air flow is directed to the You can adjust the direction of air deliv- The temperature control knob allows you windshield with a small amount of air ery from these vents using the vent con- to control the temperature of the air flow- directed to the side window defrosters.
Page 169 Features of your vehicle Temperature conversion Recirculated air position You can switch the temperature mode With the recirculated air between Centigrade to Fahrenheit as fol- position selected, air from lows: the passenger compart- ment will be drawn through While pressing the OFF button, press the the heating system and AUTO button for 4 seconds or more.
Page 170 Features of your vehicle WARNING • Continued climate control system operation in the recirculated air position may allow humidity to increase inside the vehicle which may fog the glass and obscure visibility. • Do not sleep in a vehicle with the air conditioning or heating sys- tem on.
Page 171 Features of your vehicle OTA040078 OFF mode Press the OFF button to turn off the air climate control system. However, you can still operate the mode and air intake but- tons as long as the ignition switch is in the ON position.
Page 172 Features of your vehicle WINDSHIELD DEFROSTING AND DEFOGGING • For maximum defrosting, set the tem- WARNING perature control to the extreme Windshield right/hot position and the fan speed heating control to the highest speed. Do not use the position • If warm air to the floor is desired while during cooling operation...
Page 173 Features of your vehicle OTA040080 OTA040081 OTA040082 To defrost outside windshield Automatic climate control system To defrost outside windshield 1. Set the fan speed to the highest posi- 1. Set the fan speed to the highest To defog inside windshield tion.
Page 174 Features of your vehicle STORAGE COMPARTMENTS Defogging logic These compartments can be used to store small items required by the driver To reduce the probability of fogging up or passengers. the inside of the windshield, the air intake or air conditioning are controlled auto- matically according to certain conditions CAUTION such as...
Page 175: Glove Box
Features of your vehicle WARNING • Do not keep objects except sun- glasses inside the sunglass hold- er. Such objects can be thrown from the holder in the event of a sudden stop or an accident, pos- sibly injuring the passengers in the vehicle.
Page 176: Cigarette Lighter*
“ready” position. If it is necessary to replace the cigarette OTA042086 lighter, use only a genuine Kia replace- Ashtray (if equipped) ment or its approved equivalent. To use the ashtray, open the cover.
Page 177 Features of your vehicle Cup holder WARNING - Ashtray use • Do not use the vehicle’s ashtrays WARNING Hot liquids as waste receptacles. • Do not place uncovered cups of • Putting lit cigarettes or matches in hot liquid in the cup holder while an ashtray with other combustible the vehicle is in motion.
Page 178 Features of your vehicle OTA040094 ORBR040085 OTA040182 To use the cup holder space as a storage Sunvisor Vanity mirror lamp (if equipped) compartment, turn the half part of the Use the sunvisor to shield direct light Opening the lid of the vanity mirror will cup holder (2) to the direction of the through the front or side windows.
Page 179: Power Outlet*
Features of your vehicle (Continued) CAUTION • Make sure that the electric • Use power outlet only when the devices are plugged in securely. If engine is running and remove the not, it could cause a malfunction accessory plug after use. Using of electric systems.
Page 180 Features of your vehicle With audio on Type A Type C ■ ■ 1. Press the [SETUP] or [Clock] button until the clock adjust mode displayed. 2. Set the clock by turning the knob(1) and press it. WARNING Do not adjust the clock while driv- ing.
Page 181 To avoid any interference with pedal operation, Kia recommends that only the Kia floor mat designed for use in your vehicle be installed.
Page 182: Audio*
Features of your vehicle AUDIO SYSTEM ✽ ✽ NOTICE CAUTION If you install an aftermarket HID head • Before entering a place with a low lamp, your vehicle’s audio and electron- height clearance or a car wash, ic device may malfunction. remove surely the antenna by rotating it counter-clockwise.
Page 183: Steering Wheel Audio Control*
Features of your vehicle Steering wheel audio controls Type A SEEK/PRESET ( ) (2) ■ (if equipped) The SEEK/PRESET lever has different The steering wheel may incorporate functions based on the system mode. For audio control buttons. the following functions the lever should be pressed for 0.8 seconds or more.
Page 184 Features of your vehicle Type A ✽ ✽ NOTICE MODE ( ) (3) ■ Press the button to change audio source. When using a portable audio device FM(1~2) USB AUX(iPod) connected to the power outlet, noise may ➟ ➟ ➟ FM...
Page 185 Features of your vehicle FM reception AM(MW, LW) reception FM radio station JBM001 JBM002 JBM003 How car audio works AM (MW, LW) broadcasts can be FM broadcasts are transmitted at high received at greater distances than FM frequencies and do not bend to follow the AM (MW, LW) and FM radio signals are broadcasts.
Page 186 Features of your vehicle Using a cellular phone or a two-way radio When a cellular phone is used inside the vehicle, noise may be produced from the audio equipment. This does not mean that something is wrong with the audio equipment.
Page 187 Features of your vehicle Care of discs • Keep CDs in their cases after use to protect them from scratches or dirt. • If the temperature inside the car is too • Depending on the type of CD-R/CD- high, open the car windows for ventila- RW CDs, certain CDs may not operate tion before using your car audio.
Page 188 Features of your vehicle AC9901YGG (GENERAL) ■ ■ ® ❋There will be no logo if the Bluetooth Wireless Technology feature is not supported. TA_H800_GEN_AUDIO 4 115...
Page 189 Features of your vehicle • Press CLOCK Button for 0.8 seconds or SEEK Button longer to adjust clock setting mode and • When the button is pressed, it SEEK Use the TUNE knob to adjust hour & increases the band frequency to auto- minute.
Page 190 Features of your vehicle • BASS Control • BALANCE Control To increase the BASS, rotate the knob Rotate the knob clockwise to emphasize clockwise, while to decrease the BASS, right speaker sound(left speaker sound rotate the knob counterclockwise. will be attenuated). TA_H800_GEN_AUDIO When the control knob is turned counter 6.
Page 191 Features of your vehicle (Continued) (Continued) CAUTION IN USING • An encrypted MP3 PLAYER is not • If you disconnect the external USB USB DEVICE recognizable. device during playback in USB • To use an external USB device, mode, the external USB device can •...
Page 192 Features of your vehicle (Continued) (Continued) • If the USB device is divided by • The data in the USB memory may logical drives, only the music files be lost while using this audio. on the highest-priority drive are Always back up important data on recognized by car audio.
Page 193 Features of your vehicle • Press the button for less than SEEK 0.8 seconds to move to the next song. Button (FAST FORWARD) Press the button for 0.8 seconds or longer to initiate forward direction high speed sound search of current song. Button (REWIND) TA_H800_GEN_AUDIO TA_H800_GEN_AUDIO...
Page 194 Features of your vehicle TUNE Knob & ENTER Button • Turn this knob clockwise to browse songs after current song, or counter clockwise to browse songs before cur- rent song. To play the displayed song, press the knob. • Pressing this knob without turning enters to AUDIO CONTROL mode.
Page 195 • When the iPod cable is connected, iPod DEVICE the system can be switched to AUX • Some iPod models might not sup- • The Kia iPod Power Cable is mode even without iPod device port the communication protocol needed in order to operate iPod and may cause noise.
Page 196 Features of your vehicle Button (REPEAT) TRACK Button Repeats the song currently played. TRACK • Press the button for less than 0.8 seconds to play from the beginning Button (RANDOM) of the song currently played. • Press this button for less than 0.8 sec- Press the button for less than 0.8 sec- onds to shuffle order of all songs in onds and press it again within 1 sec-...
Page 197 Features of your vehicle TA_H800_GEN_AUDIO TA_H800_GEN_AUDIO Button (MENU) MENU TUNE Knob & ENTER Button When you rotate the knob clockwise, it Moves to the upper category from cur- will display the songs (category) ahead rently played category of the iPod. To move to (play) the category (song) of the song currently played (category in displayed, press...
Page 198 Features of your vehicle CD Player : AM110TAG (GENERAL) ■ ■ ® ❋There will be no logo if the Bluetooth Wireless Technology feature is not supported. TA_GEN_RADIO 4 125...
Page 199 Features of your vehicle POWER VOLUME Button & Knob Turns on/off the set when the IGNITION SWITCH is on ACC or ON. If the button 5. PRESET Buttons is turned to the right, it increases the vol- Push buttons less than ume and left,decreases the volume.
Page 200 Features of your vehicle If no action is taken for 5 seconds after SCAN • Press the button again to stop pressing the button, it will return to the the scan feature and to listen to the play mode. (After entering SETUP mode, currently selected channel.
Page 201 Features of your vehicle • Media (if equipped) • PHONE ® Select default display of MP3 play infor- Select this item to enter Bluetooth mation. “Folder/File” or “Artist/Title” can Wireless Technology setup mode. Refer to be selected. ® “ Bluetooth Wireless Technology PHONE OPERATION”...
Page 202 Features of your vehicle MIDDLE Control SEEK • Press button for less than TRACK To increase the MIDDLE, rotate the knob 0.8 seconds to play the next song. clockwise, while to decrease the MID- SEEK • Press button for 0.8 seconds TRACK DLE, rotate the knob counterclockwise.
Page 203 Features of your vehicle 5. CD Indicator icon TUNE Knob & ENTER Button When car ignition switch is ACC or ON • Turn this knob clockwise to browse and if the CD is loaded, this indicator songs after current song, or counter- icon is on.
Page 204 Features of your vehicle NOTE: 2. Folder playing order : ❋ If no song file is contained in the Order of playing files (folders) : folder, that folder is not displayed. 1. Song playing order : sequen- tially. 4 131...
Page 205 Features of your vehicle (Continued) (Continued) CAUTION IN USING • An encrypted MP3 PLAYER is not • If you disconnect the external USB USB DEVICE recognizable. device during playback in USB • To use an external USB device, mode, the external USB device can •...
Page 206 Features of your vehicle (Continued) (Continued) • If the USB device is divided by • The data in the USB memory may logical drives, only the music files be lost while using this audio. on the highest-priority drive are Always back up important data on recognized by car audio.
Page 207 Features of your vehicle TRACK Button Button (REPEAT) SEEK • Press the button for less • Press this button for less than 0.8 sec- TRACK onds to repeat current song. than 0.8 seconds to play from the • Press this button for 0.8 seconds or longer beginning of the current song.
Page 208 Features of your vehicle FOLDER Button • Press button to move to child FOLDER folder of the current folder and display the first song in the folder. Press knob to move to the fold- TUNE er displayed. It will play the first song in the folder.
Page 209 • When the iPod cable is connected, iPod DEVICE the system can be switched to AUX • Some iPod models might not sup- • The Kia iPod Power Cable is mode even without iPod device port the communication protocol needed in order to operate iPod and may cause noise.
Page 210 Features of your vehicle TRACK Button Button (RANDOM) SEEK • Press this button for less than 0.8 sec- • Press the button for less TRACK onds to shuffle order of all songs in than 0.8 seconds to play from the current category.
Page 211 Features of your vehicle Button (MENU) Moves to the upper category from cur- rently played category of the iPod. To move to (play) the category (song) displayed, press knob. TUNE You will be able to search through the lower category of the selected category. The standard order of iPod’s category is Playlist, Artist, Albums, Genes, Songs, TA_GEN_iPod...
Page 212 Features of your vehicle (continued) CAUTION IN USING • If the cellular phone signal is poor ® BLUETOOTH WIRELESS or the vehicles interior noise is TECHNOLOGY CELLULAR too loud, it may be difficult to hear PHONE the other person’s voice during a •...
Page 213 ® trademarks owned by Bluetooth What is Bluetooth ® Wireless ■ Wireless Technology SIG, Inc. and any Technology? use of such marks by Kia is under ® Bluetooth Wireless Technology is a wire- ® license. Bluetooth Wireless less technology that allows multiple...
Page 214 For example, if the vehicles' name is - If you want to use the deleted phone varies according to each phone Kia PICANTO, you may need to change with the audio system again, pairing model. Before attempting to pair the name displayed on you phone from procedure must be completed once phone, please see your phone’s...
Page 215 Features of your vehicle Receiving a Phone Call Making a Phone Call 2. Select “PHONE”, then “PRIORITY” in ■ ■ PHONE menu. When receiving a phone call, a ringtone A Call Back can be made by pressing 3. Select desired phone name from the is audible from speakers and the audio button on the steering wheel.
Page 216 Features of your vehicle Using the head unit as Bluetooth ® NOTE: ■ Wireless Technology music • Not only MP3 files, all the sounds that the phone supports can be This audio system supports A2DP (Audio heard by the audio system. Advanced Distribution Profile)
Page 217 Features of your vehicle CD Player : AM110TAE(EUROPE) ■ ■ ® ❋There will be no logo if the Bluetooth feature is not supported. TA_EU_AUDIO...
Page 218 Features of your vehicle 6. PRESET Buttons Button • Press buttons less TA(Traffic announcement) Channels in than 0.8 seconds to play the station FM, CD, AUX mode, turns on/off the saved in each button. reception of TA channels of RDS. •...
Page 219 Features of your vehicle • Moves button when search- FOLDER ing PTY in RDS Broadcasting Program Type selection. DARK Button Turn the LCD Display & Backlight ON/OFF when DARK button press. TA_EU_AUDIO TA_EU_AUDIO SETUP Button SCAN Button Button(AUTO STORE Press this button to enter SETUP mode, Button) If no action is taken for 8 seconds, it will •...
Page 220 Features of your vehicle • MAIN • MEDIA Select this ithem to enter the Scroll and Select default display of MP3 play infor- SDVC setup. mation. “Folder/File” or “Artist/Title” can • AF(AF MENU indication is possible with be selected. • SCROLL RDS MENU) •...
Page 221 Features of your vehicle • REGION(REGION MENU indication is • Auto • P.BASS (PowerBass) possible with RDS MENU) Select “Auto” button to enter Automatic This function creates virtual sound Selects whether REGION code is used RDS Time menu. effects and allows adjustments to the (ON) or not (OFF) once the radio deter- Bass level.
Page 222 Features of your vehicle • MIDDLE Control To increase the MIDDLE, rotate the knob clockwise, while to decrease the MID- DLE, rotate the knob counterclockwise. • TREBLE Control To increase the TREBLE, rotate the knob clockwise, while to decrease the TRE- BLE, rotate the knob counterclockwise.
Page 223 Features of your vehicle • FLD RPT (MP3/WMA Only) : Only files SEEK • Press button for 0.8 seconds TRACK in a folder are repeatedly played back. or longer to initiate reverse direction high speed sound search of current song. SEEK •...
Page 224 Features of your vehicle NOTE: knob & ENTER Button Order of playing files (folders) : • Turn this knob clockwise to browse 1. Song playing order : sequen- songs after current song, or counter- tially. clockwise to browse songs before cur- rent song.
Page 225 Features of your vehicle 2. Folder playing order : ❋ If no song file is contained in the folder, that folder is not displayed.
Page 226 Features of your vehicle (Continued) (Continued) CAUTION IN USING • An encrypted MP3 PLAYER is not • If you disconnect the external USB USB DEVICE recognizable. device during playback in USB • To use an external USB device, mode, the external USB device can •...
Page 227 Features of your vehicle (Continued) (Continued) • If the USB device is divided by • Please avoid using USB memory logical drives, only the music files products which can be used as on the highest-priority drive are key chains or cellular phone recognized by car audio.
Page 228 Features of your vehicle TRACK Button Button (RANDOM) SEEK • Press this button for less than 0.8 seconds • Press the button for less TRACK to play songs randomly in current folder. than 0.8 seconds to play from the • Press this button for 0.8 seconds or beginning of the current song.
Page 229 Features of your vehicle FOLDER Button • Press button to move to FOLDER child folder of the current folder and display the first song in the folder. Press knob to move to the fold- er displayed. It will play the first song in the folder.
Page 230 • When the iPod cable is connected, iPod DEVICE the system can be switched to AUX • Some iPod models might not sup- • The Kia iPod Power Cable is mode even without iPod device port the communication protocol needed in order to operate iPod and may cause noise.
Page 231 Features of your vehicle TRACK Button Button (RANDOM) SEEK • Press this button for less than 0.8 sec- • Press the button for less TRACK onds to shuffle order of all songs in than 0.8 seconds to play from the current category.
Page 232 Features of your vehicle Button (MENU) Moves to the upper category from cur- rently played category of the iPod. To move to (play) the category (song) displayed, press knob. You will be able to search through the lower category of the selected category. The standard order of iPod’s category is Playlist, Artist, Albums, Genes, Songs, Composers.
Page 233 Features of your vehicle (continued) CAUTION IN USING • Do not place the phone near or ® BLUETOOTH CELLULAR inside metallic objects, otherwise PHONE ® communications with Bluetooth • Do not use a cellular phone or system or cellular service sta- ®...
Page 234 A2DP feature) wirelessly. ® Bluetooth SIG, Inc. and any use of • Voice recognition engine such marks by Kia is under license. ® Bluetooth system supports 10 types of A Bluetooth enabled cell phone is languages: ® required to use Bluetooth...
Page 235 Features of your vehicle Voice Recognition Activation ® • At any time if you say “help”, the system Bluetooth Language Setting ■ ■ will announce what commands are The system language can be changed by • The voice recognition engine contained ®...
Page 236 Features of your vehicle Voice Operation Tip <Voice Recognism> 2) Select “PHONE” item by rotating the ■ TUNE knob, then push the knob. To get the best performance out of the Voice Recognition System, observe the followings: - Keep the interior of the vehicle as quiet as possible.
Page 237 ® Bluetooth device list. Then attempt that phone again unless the phone is vehicles are Kia PICANTO, some pairing on your phone ® deleted manually from the audio sys- phones may not handle Bluetooth 10.
Page 238 Features of your vehicle • Connecting phone • Deleting Phone • Changing Priority The paired phone can be deleted. ® When several phones are paired to the When the Bluetooth system is enabled, audio system, the system attempts to the phone previously used is automati- - When the phone is deleted, all the infor- connect following order when the cally selected and re-connected.
Page 239 Features of your vehicle Phone Book (In-Vehicle) 2. Adjusting Bluetooth language ® • Turning Bluetooth ON/OFF ■ • Select “BT Voice Recognition lan- ® Bluetooth system can be enabled (ON) • Adding Entry guage” in PHONE menu, adjust lan- or disabled (OFF) by this menu. Phone numbers and voice tags can be guage to desired language by turning ®...
Page 240 Features of your vehicle ✽ ✽ NOTICE • Adding Entry by Phone • Deleting Name 1. Press button. The registered names can be deleted. - The system can recognize single digits from zero to nine. Numbers that are 2. Say “Phonebook”. 1.
Page 241 Features of your vehicle Receiving a Phone Call Talking on the Phone • Dialing by Number ■ ■ A phone call can be made by dialing the When receiving a phone call, a ringtone When talking on the phone, “Active Call” spoken numbers.
Page 242 Features of your vehicle NOTE: ® Bluetooth Audio Music Streaming ■ • In addition to streaming MP3 files, ® The audio system supports Bluetooth all music and sound files your cellu- A2DP (Audio Advanced Distribution lar phone supports can be played Profile) and AVRCP (Audio Video by the audio system.
Page 243 Features of your vehicle Key matrix ■ Class Connected Paired H/P Disconnected Incoming Call Outgoing Call Active Call 2nd Call Empty Normal mode BT SETUP menu 2nd call 2nd Call Not Paired Not Connecting Accept Call 1st Call:waiting 2nd Call:waiting SHORT 2nd Call:active 1st Call:active...
Page 244 Before driving / 5-3 Key positions / 5-4 ENGINE START/STOP button / 5-6 Starting the engine / 5-9 ISG (Idle Stop and Go) system / 5-12 Manual transaxle / 5-17 Automatic transaxle / 5-20 Brake system / 5-26 Economical operation / 5-38 Special driving conditions / 5-40 Winter driving / 5-44 Driving your vehicle...
Page 245 Kia dealer. • Do not run the engine in an enclosed area.
Page 246 Driving your vehicle BEFORE DRIVING Before entering vehicle Before starting WARNING - Driving under • Be sure that all windows, outside mir- • Close and lock all doors. the influence of alcohol or ror(s), and outside lights are clean. • Position the seat so that all controls are drugs •...
Page 247 Driving your vehicle KEY POSITIONS ACC (Accessory) WARNING The steering wheel is unlocked and elec- trical accessories are operative. • When you intend to park or stop the vehicle with the engine on, be careful not to depress the accel- ✽...
Page 248 Driving your vehicle (Continued) WARNING Ignition switch • Do not place any movable objects • Never turn the ignition switch to around the driver’s seat as they LOCK or ACC while the vehicle is may move while driving, interfere moving. This would result in loss with the driver and lead to an of directional control and braking accident.
Page 249 Try locking the steering wheel again. If the problem is not solved, we recommend that the system be checked by an authorized Kia dealer. In addition, if the ENGINE START/STOP button is in the OFF position after the dri-...
Page 250 Driving your vehicle ACC(Accessory) CAUTION You are able to turn off the engine (START/RUN) or vehicle power (ON), only when the vehicle is not in motion. In an emergency situation Orange indicator Green indicator while the vehicle is in motion, you are able to turn the engine off and •...
Page 251 Driving your vehicle START/RUN ✽ ✽ NOTICE (Continued) If you leave the ENGINE START/ STOP • Never reach for the ENGINE button in the ACC or ON position for a START/STOP button or any other long time, the battery will discharge. controls through the steering wheel while the vehicle is in Not illuminated...
Page 252 Driving your vehicle STARTING THE ENGINE 3. Turn the ignition switch to START and CAUTION WARNING hold it there until the engine starts (a maximum of 10 seconds), then Do not engage the starter for more Always wear appropriate shoes release the key.
Page 253 Driving your vehicle 1. Carry the smart key or leave it inside CAUTION the vehicle. If the engine stalls while you are in 2. Make sure the parking brake is firmly motion, do not attempt to move the applied. shift lever to the P (Park) position. If 3.
Page 254 Driving your vehicle (Continued) ■ Type A WARNING • When the stop lamp fuse is blown, you can't start the engine normally. The engine will start by pressing the Replace the fuse with a new one. If it ENGINE START/STOP button, only is not possible, you can start the when the smart key is in the vehicle.
Page 255 Driving your vehicle ISG (IDLE STOP AND GO) SYSTEM (IF EQUIPPED) Your vehicle may be equipped with the ■ Type A ISG system, which reduces fuel con- sumption by automatically shutting down the engine, when the vehicle is at a standstill.
Page 256 Driving your vehicle The engine will also restart automati- cally without the driver’s any actions if the following occurs: - The fan speed of manual climate con- trol system is set above the 3rd position when the air conditioning is on. - The fan speed of automatic climate control system is set above the 6th position when the air conditioning is on.
Page 257 Driving your vehicle Condition of ISG system opera- tion The ISG system will operate under the following condition: - The driver’s seat belt is fastened. - The driver’s door and engine hood are closed. - The brake vaccum pressure is ade- quate.
Page 258 ISG system con- tinuously does not work correctly, we recommend that you contact an authorized Kia dealer as soon as pos- sible. • When the ISG OFF button light comes on, it may stop illuminating after driv-...
Page 259 Driving your vehicle WARNING When the engine is in Idle Stop mode, it's possible to restart the engine without the driver taking any action. Before leaving the car or doing any- thing in the engine room area, stop the engine by turning the ignition switch to the LOCK(OFF) position or removing the ignition key.
Page 260 Driving your vehicle MANUAL TRANSAXLE (IF EQUIPPED) Make sure the vehicle is completely • During cold weather, shifting may be stopped before shifting into R (Reverse). difficult until the transaxle lubricant is warmed up. This is normal and not Never operate the engine with the harmful to the transaxle.
Page 261 Driving your vehicle Using the clutch Downshifting WARNING The clutch should be pressed all the way When you must slow down in heavy traf- to the floor before shifting, then released fic or while driving up steep hills, down- • Before leaving the driver’s seat, slowly.
Page 262 Driving your vehicle Good driving practices WARNING • Never take the vehicle out of gear and • Always buckle-up! In a collision, coast down a hill. This is extremely an unbelted occupant is signifi- hazardous. Always leave the vehicle in cantly more likely to be seriously gear.
Page 263 Driving your vehicle AUTOMATIC TRANSAXLE (IF EQUIPPED) Automatic transaxle operation The automatic transaxle has 4 forward speeds and one reverse speed. The indi- vidual speeds are selected automatically, depending on the position of the shift lever. ✽ ✽ NOTICE The first few shifts on a new vehicle, if the battery has been disconnected, may be somewhat abrupt.
Page 264 Driving your vehicle For smooth operation, depress the brake Transaxle ranges CAUTION pedal when shifting from N (Neutral) to a The indicator in the instrument cluster forward or reverse gear. • To avoid damage your displays the shift lever position when the transaxle, do not accelerate the ignition switch is in the ON position.
Page 265 Driving your vehicle R (Reverse) N (Neutral) 3 (Third gear) Use this position to drive the vehicle The wheels and transaxle are not Use for towing a trailer during hill climb- backward. engaged. The vehicle will roll freely even ing or to use engine braking downhill. on the slightest incline unless the parking "3"...
Page 266 Driving your vehicle Shift lock system (if equipped) 1 (First gear) CAUTION Use for driving up a very steep grade or For your safety, the automatic transaxle • Shift into "R" and "P" position for engine braking when descending has a shift lock system which prevents only when the vehicle has com- steep hills.
Page 267 Driving your vehicle Good driving practices • Always use the parking brake. Do not depend on placing the transaxle in P WARNING • Never move the shift lever from P (Park) to keep the car from moving. • Always buckle-up! In a collision, (Park) or N (Neutral) to any other posi- •...
Page 268 Driving your vehicle Moving up a steep grade from a stand- WARNING ing start To move up a steep grade from a stand- If your vehicle becomes stuck in ing start, depress the brake pedal, shift snow, mud, sand, etc., then you the shift lever to D (Drive).
Page 269 Driving your vehicle BRAKE SYSTEM Power brakes In the event of brake failure (Continued) If service brakes fail to operate while the Your vehicle has power-assisted brakes • When descending a long or steep vehicle is in motion, you can make an that adjust automatically through normal hill, shift to a lower gear and emergency stop with the parking brake.
Page 270 Driving your vehicle Disc brakes wear indicator Rear drum brakes (if equipped) Your vehicle has disc brakes. Your rear drum brakes do not have wear indicators. Therefore, have the rear brake When your brake pads are worn and new linings inspected if you hear a rear brake pads are required, you will hear a high- rubbing noise.
Page 271 (2) while holding the button. tent movement of the vehicle which can injure occupants or If the parking brake does not release or pedestrians. does not release all the way, we recom- mend that the system be checked by an authorized Kia dealer.
Page 272 Driving your vehicle Anti-lock brake system (ABS) (Continued) (if equipped) • On roads where the road surface is pitted or has different surface WARNING height. The safety features of an ABS (or ABS (or ESP) will not prevent acci- ESP) equipped vehicle should not dents due to improper or danger- be tested by high speed driving or driving...
Page 273 ABS will go through self-diagnosis and the light will go off if everything is normal. If the light stays on, you may have a problem with your ABS.We recom- mend that you contact an author- ized Kia dealer.
Page 274 ABS. Electronic stability program (ESP) We recommend that you contact (if equipped) an authorized Kia dealer. The Electronic Stability Program (ESP) system is designed to stabilize the vehicle during cornering maneuvers. ESP checks where you are steering and where the vehicle is actually going.
Page 275 Driving your vehicle ✽ ✽ NOTICE The Electronic Stability Program (ESP) WARNING system is an electronic system designed A click sound may be heard in the to help the driver maintain vehicle control Never drive too fast for the road engine compartment when the vehicle under adverse conditions.
Page 276 Driving your vehicle ESP operation ESP operation off When operating When the ESP is in operation, ESP ON condition ESP OFF state the ESP indicator light blinks. • When the ignition is turned • To cancel ESP operation, • When the Electronic Stability ON, ESP and ESP OFF indi- press the ESP OFF button Program is operating proper-...
Page 277 Driving your vehicle ESP OFF usage ■ ESP indicator light CAUTION When driving Driving with varying tire or wheel • ESP should be turned on for daily driv- sizes may cause the ESP system to ing whenever possible. malfunction. When replacing tires, •...
Page 278 Driving your vehicle Hill-start assist control (HAC) Vehicle stability management ✽ ✽ NOTICE (if equipped) (VSM) (if equipped) • The HAC does not operate when the transaxle shift lever is in the P (Park) Hill start Assist Control is a comfort func- This system provides further enhance- or N (Neutral) position.
Page 279 The Emergency Stop Signal system including driving inclement authorized Kia dealer. will not work if the hazard warning weather and on a slippery road. flasher is already on. • Driving with varying tire or wheel ✽...
Page 280 If your car is facing brake as far as possible and fully authorized Kia dealer for assistance. uphill, turn the front wheels away from engage the vehicle's transaxle the curb to help keep the car from •...
Page 281 Driving your vehicle ECONOMICAL OPERATION Your vehicle's fuel economy depends • Don't "ride" the brake pedal. This can • Keep your car in good condition. For mainly on your style of driving, where you increase fuel consumption and also better fuel economy and reduced drive and when you drive.
Page 282 Therefore, we recommend that the steering which could cause seri- system be serviced by an authorized Kia ous injury or death. dealer. 5 39...
Page 283 Driving your vehicle SPECIAL DRIVING CONDITIONS Rocking the vehicle WARNING - If it is necessary to rock the vehicle to Do not pump the brake pedal on a free it from snow, sand, or mud, first turn vehicle equipped with ABS. the steering wheel right and left to clear the area around your front wheels.
Page 284 Driving your vehicle WARNING - Spinning tires Do not spin the wheels, especially at speeds more than 56 km/h (35 mph). Spinning the wheels at high speeds when the vehicle is station- ary could cause a tire to overheat which could result in tire damage that may injure bystanders.
Page 285 Driving your vehicle • Adjust your mirrors to reduce the glare • If your tires are not in good condition, from other driver's headlights. making a quick stop on wet pavement can cause a skid and possibly lead to • Keep your headlights clean and prop- an accident.
Page 286 Driving your vehicle Driving in flooded areas WARNING Avoid driving through flooded areas • Underinflated or overinflated tires unless you are sure the water is no high- can cause poor handling, loss of er than the bottom of the wheel hub. vehicle control, and sudden tire Drive through any water slowly.
Page 287 Driving your vehicle WINTER DRIVING Snowy or icy conditions Snow tires If you mount snow tires on your vehicle, To drive your vehicle in deep snow, it may make sure they are radial tires of the be necessary to use snow tires or to same size and load range as the original install tire chains on your tires.
Page 288 Driving your vehicle Chain installation CAUTION When installing chains, follow the manu- • Make sure the snow chains are facturer's instructions and mount them as the correct size and type for your tightly as you can. Drive slowly with tires. Incorrect snow chains can chains installed.
Page 289 Be sure to replace or replenish Kia dealer. • Drive carefully and avoid bumps, your coolant in accordance with the holes, sharp turns, and other maintenance schedule in section 7.
Page 290 Window washer anti-freeze is Under some conditions, snow and ice available from an authorized Kia dealer can build up under the fenders and inter- and most auto parts outlets. Do not use fere with the steering. When driving in...
Page 291 We recommend Remember that trailering is different than exceeded by not more than 10 % or that you ask an authorized Kia dealer. 100 kg (220.4 lbs), whichever value is just driving your vehicle by itself.
Page 292 Use only a frame-mounted nal position. hitch that does not attach to the bumper. • Kia trailer hitch accessory is available at an authorized Kia dealer. 5 49...
Page 293 Driving your vehicle Safety chains Trailer brakes Driving with a trailer should always attach chains If your trailer is equipped with a braking Towing a trailer requires a certain between your vehicle and your trailer. system, make sure it conforms to your amount of experience.
Page 294 Always back up slowly Use only an approved trailer wiring har- and, if possible, have someone guide ness. you. An authorized Kia dealer can assist you in installing the wiring harness. Making turns When you’re turning with a trailer, make WARNING wider turns than normal.
Page 295 Driving your vehicle Parking on hills 5. Start the vehicle, hold the brakes, shift CAUTION to neutral, release the parking brake Generally, if you have a trailer attached to and slowly release the brakes until the • When towing a trailer on steep your vehicle, you should not park your trailer chocks absorb the load.
Page 296 Driving your vehicle Maintenance when trailer towing When you are ready to leave after park- CAUTION ing on a hill Your vehicle will need service more often • Due to higher load during trailer 1. With the manual transaxle in Neutral when you regularly pull a trailer.
Page 297 (Ibs.) damage. • When towing a trailer, we recommend Recommended distance from rear wheel that you consult an authorized Kia center to coupling point 635 (25) 635 (25) dealer on additional requirements such mm (inch) as a towing kit, etc.
Page 298 Driving your vehicle The trailer tongue should weigh a maxi- mum of 10% of the total loaded trailer weight, within the limits of the maximum trailer tongue load permissible. After you've loaded your trailer, weigh the trail- er and then the tongue, separately, to see if the weights are proper.
Page 299 Driving your vehicle VEHICLE WEIGHT Cargo weight GVWR (Gross vehicle weight rat- This section will guide you in the proper loading of your vehicle, to keep your ing) This figure includes all weight added to loaded vehicle weight within its design the Base Curb Weight, including cargo This is the maximum allowable weight of rating capability.
Page 300: What To Do In An Emergency
Road warning / 6-2 In case of an emergency while driving / 6-3 If the engine will not start / 6-4 Emergency starting / 6-5 If the engine overheats / 6-7 If you have a flat tire / 6-8 If you have a flat tire (with TireMobilityKit) / 6-16 Towing / 6-22 Emergency commodity / 6-26 What to do in an emergency...
Page 301 What to do in an emergency ROAD WARNING • The hazard warning flasher operates whether your vehicle is running or not. • The turn signals do not work when the hazard flasher is on. • Care must be taken when using the hazard warning flasher while the vehi- cle is being towed.
Page 302 When the car has slowed to such not equipped with a ignition lock that you consult an authorized Kia a speed that it is safe to do so, brake switch, the vehicle can move forward dealer.
Page 303 Kia dealer. 4. Check the starter connections to be sure they are securely tightened. 5. Do not push or pull the vehicle to start it.
Page 304 What to do in an emergency EMERGENCY STARTING Jump starting WARNING - Battery Jump starting can be dangerous if done • Keep all flames or sparks away incorrectly. Therefore, to avoid harm to from the battery. The battery pro- yourself or damage to your vehicle or duces hydrogen gas which may battery, follow the jump starting proce- explode if exposed to flame or...
Page 305: Maintenance
• Absorbent Glass Matt (AGM) bat- not apparent, we recommend that the tion. First connect one end of a jumper teries are maintenance-free and system be checked by an authorized Kia cable to the positive terminal of the should only be serviced by an dealer.
Page 306 If the that you call an authorized Kia dealer. fan is not running, turn the engine off. WARNING Do not remove the radiator cap when the engine is hot.
Page 307 What to do in an emergency IF YOU HAVE A FLAT TIRE Jacking instructions (Continued) The jack is provided for emergency • Be sure to use the correct tire changing only. front and rear jacking posi- To prevent the jack from “rattling” tions on the vehicle;...
Page 308 What to do in an emergency OTA060002 1VQA4022 OSA067007 Removing and storing the spare Changing tires 4. Remove the wheel lug nut wrench, tire jack, jack handle, and spare tire 1. Park on a level surface and apply from the vehicle. Turn the tire hold-down wing bolt the parking brake firmly.
Page 309 What to do in an emergency WARNING - Changing a tire • To prevent vehicle movement while changing a tire, always set the parking brake fully, and always block the wheel diagonally opposite the wheel being changed. • We recommend that wheels of the vehicle be blocked, and that no person...
Page 310 What to do in an emergency 9. Loosen the wheel nuts and WARNING - Jack location remove them with your fingers. Slide the wheel off the studs and To reduce the possibility of lay it flat so it cannot roll away. To injury, be sure to use only the put the wheel on the hub, pick up jack provided with the vehicle...
Page 311 Then double-check each nut for tightness. After changing wheels, we recommend that the system be checked by an authorized Kia dealer. Wheel nut tightening torque: Steel wheel & aluminum alloy wheel: 9~11 kg·m (65~79 lb·ft)
Page 312 Adjust it to the for thread style before installing specified pressure, if necessary. aftermarket lug nuts or wheels. Refer to “Tires and wheels” sec- If in doubt, consult an author- tion 8. ized Kia dealer. 6 13...
Page 313 What to do in an emergency Important - use of compact spare tire When using a compact spare tire, (if equipped) WARNING observe the following precautions: Your vehicle is equipped with a com- The compact spare tire is for • Under no circumstances should you pact spare tire.
Page 314 What to do in an emergency • Do not take this vehicle through an • The compact spare tire should not automatic car wash while the com- be used on any other wheels, nor pact spare tire is installed. should standard tires, snow tires, wheel covers or trim rings be used •...
Page 315 Kia dealer as soon as inflating with the Tire Mobility possible. After you ensured that the tire is Kit.
Page 316 Tire Mobility Kit 22°F (-30°C). for your safety. • Use of the Tire Mobility Kit may not be effective for tire damage larger than approximately 0.24 in (6 mm). We recommend that you contact an authorized Kia dealer. 6 17...
Page 317 What to do in an emergency 9. Hose to connect compressor and sealant bottle or compressor and wheel Connectors, cable and connection hose are stored in the compressor housing. WARNING - Expired sealant Do not use the Tire sealant after the sealant has expired (i.e.
Page 318 What to do in an emergency Using the Tire Mobility Kit CAUTION - Tire pressure 1. Detach the speed restriction label Do not attempt to drive your (0) from the sealant bottle (1), and vehicle if the tire pressure is place it in a highly visible place below 29 PSI(200kpa).
Page 319 What to do in an emergency Distributing the sealant Checking the tire inflation pres- ✽ ✽ NOTICE sure 11. Immediately drive approximately The pressure gauge may show high- 1.After driving approximately 4 4~6miles (7~10km or, about er than actual reading when the ~6miles(7~10km or about 10min), 10min) to evenly distribute the compressor is running.
Page 320 We recommend that you use the Amperage rating: max. 15 A sealant of Tire Mobility Kit from Suitable for use at temperatures: an authorized Kia dealer. -30 ~ +70°C (-22 ~ +158°F) The sealant on the tire pressure Max. working pressure:...
Page 321 • Do not tow the vehicle with the recommend having it done by an author- front wheels on the ground as ized Kia dealer or a commercial tow-truck this may cause damage to the service. Proper lifting and towing proce- vehicle.
Page 322 OTA060012 secured. Emergency towing 4. Remove the towing hook and install If towing is necessary, we recommend the cover after use. you to have it done by an authorized Kia dealer or a commercial tow truck service. 6 23...
Page 323 • If the disabled vehicle is unable to be moved, do not forcibly con- tinue the towing. We recommend that you contact an authorized Kia dealer or a commercial tow truck service for assistance. • Tow the vehicle as straight ahead as possible.
Page 324 What to do in an emergency Emergency towing precautions CAUTION - Automatic • Place the ignition switch in ACC so the transaxle steering wheel isn’t locked. • If the car is being towed with all • Place the transaxle shift lever in N four wheels on the ground, it can (Neutral).
Page 325 What to do in an emergency EMERGENCY COMMODITY (IF EQUIPPED) First aid kit There are some emergency commodities To check the tire pressure, take the fol- in the vehicle to help you respond to the lowing steps; There are some items such as scissors, emergency situation.
Page 326 Engine compartment / 7-2 Maintenance services / 7-3 Owner maintenance / 7-4 Scheduled maintenance service / 7-6 Explanation of scheduled maintenance items / 7-18 Engine oil / 7-21 Engine coolant / 7-23 Brake fluid / 7-26 Automatic transaxle fluid / 7-27 Washer fluid / 7-29 Parking brake / 7-29 Air cleaner / 7-30...
Page 327: Fuse Box
Maintenance ENGINE COMPARTMENT 1.25 Gasoline ■ ■ 1. Engine coolant reservoir 2. Radiator cap 3. Brake fluid reservoir 4. Air cleaner 5. Engine oil dipstick 6. Engine oil filler cap 7. Windshield washer fluid reservoir 8. Fuse box 1.0 Gasoline ■...
Page 328 Improper owner maintenance during al injury. Kia dealer. the warranty period may affect warran- ty coverage. For details, read the sepa- You should retain documents that show rate Warranty & Maintenance book proper maintenance has been performed provided with the vehicle.
Page 329 If you have any question, we recommend can be seriously injured while • Check the windshield washer fluid that you consult an authorized Kia dealer. performing some maintenance level. These Owner Maintenance Checks are procedures. If you lack sufficient •...
Page 330 Maintenance While operating your vehicle: At least monthly: At least once a year: • Note any changes in the sound of the • Check coolant level in the engine • Clean body and door drain holes. exhaust or any smell of exhaust fumes coolant reservoir.
Page 331 Maintenance SCHEDULED MAINTENANCE SERVICE If your vehicle is operated under the Follow Normal Maintenance Schedule if the vehicle is usually operated where above conditions, you should inspect, none of the following conditions apply. If replace or refill more frequently than the any of the following conditions apply, fol- following Normal Maintenance Schedule.
Page 332 If drive belt noise occurred, readjust drive belt tension before result in serious malfunction or engine damage. replace. : Kia recommends that you use good quality gasolines meet : Check the engine oil level and leak every 500 km (350 Europe Fuel standards (EN228) or equivalents.
Page 333 Maintenance NORMAL MAINTENANCE SCHEDULE (CONT.) 15,000 km (10,000 miles) or 12months (Continued) ❑ Inspect air cleaner filter - Except China, India, Middle East ❑ Replace engine oil and filter - For Middle East, Brazil * (Every 10,000 km (6,500 miles) or 12months* ❑...
Page 334 Maintenance NORMAL MAINTENANCE SCHEDULE (CONT.) 30,000 km (20,000 miles) or 24months (Continued) ❑ Replace engine oil and filter - Except Middle East, Brazil * ❑ Inspect air cleaner filter - Except China, India, Middle East ❑ Inspect air conditioner refrigerant/compressor (if equipped) ❑...
Page 335 Maintenance NORMAL MAINTENANCE SCHEDULE (CONT.) 45,000 km (30,000 miles) or 36months (Continued) ❑ Inspect air conditioner refrigerant/compressor (if equipped) ❑ Replace engine oil and filter - For Middle East, Brazil * (Every 10,000 km (6,500 miles) or 12months* ❑ Inspect battery condition ❑...
Page 336 Maintenance NORMAL MAINTENANCE SCHEDULE (CONT.) 60,000 km (40,000 miles) or 48months (Continued) ❑ Replace air cleaner filter - For China, India, Middle East ❑ Inspect air cleaner filter - Except China, India, Middle East ❑ Replace climate control air filter (if equipped) ❑...
Page 337 Maintenance NORMAL MAINTENANCE SCHEDULE (CONT.) (Continued) 75,000 km (50,000 miles) or 60months ❑ Replace engine oil and filter - For Middle East, Brazil * ❑ Inspect air cleaner filter - Except China, India, Middle East (Every 10,000 km (6,500 miles) or 12months * ❑...
Page 338 Maintenance NORMAL MAINTENANCE SCHEDULE (CONT.) 90,000 km (60,000 miles) or 72months (Continued) ❑ Replace air cleaner filter ❑ Inspect air conditioner refrigerant/compressor (if equipped) ❑ Replace climate control air filter (if equipped) ❑ Inspect battery condition ❑ Replace engine oil and filter - Except Middle East, Brazil * ❑...
Page 339 Maintenance NORMAL MAINTENANCE SCHEDULE (CONT.) 105,000 km (70,000 miles) or 84months (Continued) ❑ Replace engine oil and filter - Except Middle East, Brazil * ❑ Inspect air cleaner filter - Except China, India, Middle East ❑ Inspect air conditioner refrigerant/compressor (if equipped) ❑...
Page 340 Maintenance NORMAL MAINTENANCE SCHEDULE (CONT.) 120,000 km (80,000 miles) or 96months (Continued) ❑ Replace air cleaner filter - For China, India, Middle East ❑ Inspect air cleaner filter - Except China, India, Middle East ❑ Replace climate control air filter (if equipped) ❑...
Page 341 Maintenance MAINTENANCE UNDER SEVERE USAGE CONDITIONS The following items must be serviced more frequently on cars mainly used under severe driving conditions. Refer to the chart below for the appropriate maintenance intervals. R : Replace I : Inspect and if necessary, adjust, correct, clean or replace Maintenance Maintenance item Maintenance intervals...
Page 342 Maintenance Maintenance Maintenance item Maintenance intervals Driving condition operation Inspect more frequently Disc brakes and pads, calipers and rotors C, D, E, G, H depending on the condition Inspect more frequently Parking brake C, D, G, H depending on the condition Inspect more frequently B, C, D, E, F, Driveshaft and boots...
Page 343 Make sure ized Kia dealer. tension and adjusted as necessary. that a new vapor hose or fuel filler cap is correctly replaced. Air cleaner filter A Genuine Kia air cleaner filter is recom- mended when the filter is replaced.
Page 344 We recommend that the system be serv- Inspect the manual transaxle fluid parking brake properly applied. iced by an authorized Kia dealer. according to the maintenance schedule. Cooling system Check cooling system components, such as radiator, coolant reservoir, hoses and connections for leakage and damage.
Page 345 For more information on checking the pads or lining wear limit, we recommend Brake fluid Air conditioning refrigerant to refer to the Kia web site. (if equipped) Check brake fluid level in the brake fluid (http://brakemanual.kia.co.kr) reservoir. The level should be between Check the air conditioning lines and con- “MIN”...
Page 346 Maintenance ENGINE OIL WARNING - Radiator hose Be very careful not to touch the radiator hose when checking or adding the engine oil as it may be hot enough to burn you. 5. Pull the dipstick out again and check the level.
Page 347 Maintenance Changing the engine oil and filter We recommend that the engine oil and filter be replaced by an authorized Kia dealer. WARNING Used engine oil may cause irrita- tion or cancer of the skin if left in contact with the skin for prolonged periods of time.
Page 348: Radiator Cap
Maintenance ENGINE COOLANT Checking the coolant level The high-pressure cooling system has a (Continued) reservoir filled with year-round antifreeze • Even if the engine is not operat- coolant. The reservoir is filled at the fac- WARNING ing, do not remove the radiator tory.
Page 349 If the coolant level is low, add enough distilled (deionized) water to provide pro- tection against freezing and corrosion. Bring the level to F (Full) , but do not overfill. If frequent additions are required, we recommend that the system be inspected by an authorized Kia dealer.
Page 350 Type A ■ WARNING We recommend that the coolant be Radiator cap replaced by an authorized Kia dealer. CAUTION Put a thick cloth around the radiator Do not remove the radiator cap cap before refilling the coolant in when the engine and radiator are order to prevent the coolant from hot.
Page 351 (Maximum) level. The level will fall with brake system parts. accumulated mileage. This is a normal condition associated with the wear of the brake linings. If the fluid level is excessive- ly low, we recommend that the system be checked by an authorized Kia dealer.
Page 352 Maintenance AUTOMATIC TRANSAXLE FLUID (IF EQUIPPED) 2. After the transaxle is warmed up suffi- ciently [fluid temperature 70~80°C (158~176°F)], for example by 10 min- utes usual driving, move the shift lever through all positions then place the shift lever in N(Neutral) or P(Park) position.
Page 353 Exercise great transaxle fluid be changed by an author- ✽ ✽ NOTICE care not to burn yourself during ized Kia dealer according to the this procedure. The “COLD” range is for reference only Maintenance Schedule at the beginning and should NOT be used to determine of this section.
Page 354 Kia dealer. Stroke : 6~8 “clicks’’ at a force of 20 kg (44 lbs, 196 N). 7 29...
Page 355 Maintenance AIR CLEANER OTA070013L OTA070010L OTA070011L Filter replacement 1. Loosen the air cleaner cover attaching clips and open the cover. It must be replaced when necessary, and should not be washed. You can clean the filter when inspecting the air cleaner element. Clean the filter by using compressed air.
Page 356 “Maintenance under severe usage condi- ter, be careful that dust or dirt tions” in this section.) does not enter the air intake, or damage may result. • Use a Kia genuine part. Use of non-genuine parts could damage the air flow sensor. 7 31...
Page 357 Maintenance CLIMATE CONTROL AIR FILTER Filter inspection The climate control air filter should be replaced according to the maintenance schedule. If the vehicle is operated in the severely air-polluted cities or on dusty rough roads for a long period, it should be inspected more frequently and replaced earlier.
Page 358 Maintenance OTA070016 3. Replace the climate control air filter. 4. Reassemble in the reverse order of disassembly. ✽ ✽ NOTICE When replacing the climate control air filter install it properly. Otherwise, the system may produce noise and the effec- tiveness of the filter may be reduced. 7 33...
Page 359 Maintenance WIPER BLADES Blade replacement Contamination of either the windshield or the wiper blades with foreign matter can When the wipers no longer clean ade- reduce the effectiveness of the wind- quately, the blades may be worn or shield wipers. Common sources of con- cracked, and require replacement.
Page 360 Maintenance 1JBA7037 1LDA5023 OHM078062 Front windshield wiper blade Rear window wiper blade 1. Raise the wiper arm and turn the wiper 1. Raise the wiper arm and pull out the blade assembly to expose the plastic wiper blade assembly. locking clip. CAUTION Do not allow the wiper arm to fall against the windshield, since it may...
Page 361 We recommend that you the wiper arm until it clicks into place. • Keep the battery top clean and dry. contact an authorized Kia dealer. 3. Make sure the blade assembly is • Keep the terminals and connections installed firmly by trying to pull it slightly.
Page 362 We recommend that handling a battery. 15 minutes and get immedi- you contact an authorized ate medical attention. Kia dealer. Keep lighted cigarettes and all other flames or sparks If electrolyte gets on your • When lifting a plastic-cased bat- away from the battery.
Page 363 Separating the battery from the (see the example) vehicle is recommended to an authorized Kia dealer. 1. CMF60L-BCI : The Kia model name of battery 2. 12V : The nominal voltage 3. 60Ah(20HR) : The nominal capacity (in Ampere hours) 4.
Page 364 • For your safety, we recommend the following order. that you use parts for replacement 1. Turn off the battery charger main from an authorized Kia dealer. switch. 2. Unhook the negative clamp from the negative battery terminal. 3. Unhook the positive clamp from the positive battery terminal.
Page 365 Recommended cold tire inflation we recommend that the sys- pressures tem be checked by an author- All tire pressures (including the ized Kia dealer. OTA080002 spare) should be checked when the • Overinflation produces All specifications (sizes and pres- tires are cold.
Page 366 Maintenance Checking tire inflation pressure CAUTION CAUTION - Tire pressure Check your tires once a month or • Warm tires normally exceed Always observe the following: more. recommended cold tire pres- • Check tire pressure when the Also, check the tire pressure of the sures by 28 to 41 kPa (4 to 6 tires are cold.
Page 367 Refer to “Tire and wheels” in section 8. • Remember to check the pres- sure of your spare tire. Kia recommends that you check the spare every time you check the pressure of the other tires on your vehicle.
Page 368 Maintenance Disc brake pads should be inspected Wheel alignment and tire balance With a full-size spare tire (if equipped) for wear whenever tires are rotated. The wheels on your vehicle were aligned and balanced carefully at the factory to give you the longest tire life ✽...
Page 369 • Replace tires that are worn, • Wheels that do not meet Kia’s show uneven wear, or are specifications may fit poorly damaged. Worn tires can and result in damage to the...
Page 370 Maintenance Compact spare tire replacement Wheel replacement Tire traction (if equipped) When replacing the metal wheels for Tire traction can be reduced if you A compact spare tire has a shorter any reason, make sure the new drive on worn tires, tires that are tread life than a regular size tire.
Page 371 Maintenance 2. Tire size designation Wheel size designation Wheels are also marked with impor- A tire’s sidewall is marked with a tire tant information that you need if you size designation. You will need this ever have to replace one. The follow- information when selecting replace- ing explains what the letters and ment tires for your car.
Page 372 Maintenance DOT : XXXX XXXX OOOO 4. Tire ply composition and material Speed The number of layers or plies of rub- The front part of the DOT means a Rating Maximum Speed ber-coated fabric in the tire. Tire plant code number, tire size and Symbol manufacturers also must indicate the tread pattern and the last four num-...
Page 373 Maintenance 7. Uniform tire quality grading These grades are molded on the Temperature - A, B & C side-walls of passenger vehicle tires. The temperature grades are A (the Quality grades can be found where The tires available as standard or highest), B, and C, representing the applicable on the tire sidewall optional equipment on your vehicle...
Page 374 - If the tire is impacted, we rec- ommend that you inspect the tire condition or contact an authorized Kia dealer. - To prevent damage to the tire, inspect the tire condition and pressure every 3,000km.
Page 375 Avoid using the system involved and we recommend ✽ ✽ NOTICE that you consult an authorized Kia dealer. The actual fuse/relay panel label may Four kinds of fuses are used: blade type OTA070039 for lower amperage rating, cartridge type, differ from equipped items.
Page 376 1. Turn the ignition switch and all other we recommend that you consult switches off. with an authorized Kia dealer. 2. Open the fuse panel cover. • Do not input any other objects except...
Page 377 Maintenance If you do not have a spare, use a fuse of ✽ ✽ NOTICE the same rating from a circuit you may • If the memory fuse is pulled up from not need for operating the vehicle, such the fuse panel, the warning chime, as the cigarette lighter fuse.
Page 378 If not, Multi fuse electrical failures may occur from If the multi fuse is blown, we recommend water contact. that you consult an authorized Kia dealer. OTA070040 Engine compartment fuse replacement 1. Turn the ignition switch and all other switches off.
Page 379 Maintenance Fuse/relay panel description Inside the fuse/relay panel covers, you can find the fuse/relay label describing fuse/relay name and capacity. Instrument panel fuse panel Engine compartment fuse panel ✽ ✽ NOTICE Not all fuse panel descriptions in this manual may be applicable to your vehi- cle.
Page 380 Maintenance Instrument panel (Driver’s side fuse panel) Fuse Name Symbol Fuse rating Protected Component Luggage Lamp, A/C Control Module, BCM/TACM, Auto Light & Photo Sensor, Cup Holder ROOM1 ILL., Instrument Cluster, Ignition Key ILL. & Door Warning Switch, Driver Vanity Lamp, Overhead Console Lamp (With Sunroof), Room Lamp(W/O Sunroof) AUDIO Audio (W/O ISG), Low DC-DC Convertor (With ISG)
Page 381 Maintenance Fuse Name Symbol Fuse rating Protected Component H/LP RH Instrument Cluster, Head Lamp RH HAZARD Hazard Relay, Flasher Unit, Hazard Switch PDM1 Smart Key Control Module S/ROOF Sunroof Motor PDM/2 Smart Key Control Module, Immobilizer Module, Start/Stop Button Switch Pulse Generator 'A'/'B', Vehicle Speed Sensor, Transaxle Range Switch Sunroof Motor, Rear Defogger Timer, Dual Pressure Switch, Head Lamp Leveling Device IGN2...
Page 382 Maintenance Fuse Name Symbol Fuse rating Protected Component Stop Lamp Switch, Alternator(G3LA/G4LA), Rear Parking Assist Sensor RH/LH, Rear IGN1 Parking Assist Sensor (Center) RH/LH, Seat Heater Switch, Driver/Passenger Seat Heater, Crash Pad Switch , Low DC-DC Convertor, Electro Chromic Mirror Yaw Rate Sensor, Check Connector, ESP Control Module ABS Control Module, PCB Fuse &...
Page 383 Maintenance Engine compartment main fuse panel Symbol Fuse rating Protected Component EPS Control Module MULTI FUSE 125A Alternator, PCB Fuse & Relay Box I/P Junction Box (Power Connector Fuse : F1 10A / F2 20A, Fuse : F24 10A / F25 10A / F26 10A / F27 15A, Tail Lamp Relay) Projection Type : E/R Sub Fuse Box (Fuse : F1 10A / F2 20A / F4 15A / F5 10A / F7 10A ) I/P Junction Box (Fuse : F8 20A / F9 25A / F10 15A / F16 15A / F17 25A / F18 15A / F19 10A / F35 10A, Power Window Relay)
Page 384 Maintenance Symbol Fuse rating Protected Component PCB Fuse & Relay Box (Fuel Pump #1 Relay) PCB Fuse & Relay Box (Head Lamp (HI) Relay) PCB Fuse & Relay Box (Head Lamp (LO) Relay) PCB Fuse & Relay Box (Horn Relay, Burglar Alarm Horn Relay) PCB Fuse &...
Page 385 Maintenance Engine compartment fuse panel (Projection head lamp type only) Symbol Fuse rating Protected Component PCB Fuse & Relay Box (A/C Relay) PCB Fuse & Relay Box (Head Lamp (LO) Relay) PCB Fuse & Relay Box (Fuel Pump #1 Relay) PCB Fuse &...
Page 386 Kia dealer. that the ignition switch is turned to between the lamp inside and outside. In many cases, it is difficult to...
Page 387 Maintenance Type A Type B ■ ■ OTA070025 OTA070042 OHD076046 Headlight, position light, turn sig- Type B nal light, front fog light bulb (1) Front turn signal light replacement WARNING (2) Headlight (High/Low) - Halogen bulbs Type A (3) Position light (Bulb type)* •...
Page 388 Kia dealer. • Wear eye protection when chang- ing a bulb. Allow the bulb to cool ❋ ❋ Traffic Change (For Europe) down before handling it.
Page 389 Position light + DRL (LED type) or Position light (LED type) (if equipped) If the light bulb does not operate, we rec- ommend that you checked an authorized Kia dealer. OTA070027 OTA070045L Turn signal light Front fog light or DRL or Front fog light + DRL (if equipped) 1.
Page 390 If the light (LED) does not operate, we 4. Remove the bulb by pulling it straight recommend that the vehicle checked by out. an authorized Kia dealer. 5. Insert a new bulb in the socket. 6. Reassemble the socket and the lens part.
Page 391 Maintenance OTA070031 OTA070032 OTA070046L Rear turn signal light/Stop and tail light 3. Remove the socket from the assembly Back-up light/Rear fog light by turning the socket counterclockwise (if equipped) 1. Open the tail gate. until the tabs on the socket align with 1.
Page 392 Maintenance LED type ■ If the light (LED) does not operate, we recommend that the vehicle checked by an authorized Kia dealer. OTA070034 OTA070033 High mounted stop light License plate light bulb replace- replacement (if equipped) ment Bulb type 1. Remove the lens by pressing the tabs.
Page 393 Maintenance Interior light bulb replacement Map lamp 1. Using a flat-blade screwdriver, gently pry the lens from the interior light housing. 2. Remove the bulb by pulling it straight out. WARNING Prior to working on the Interior Lights, ensure that the “OFF” but- ton is depressed to avoid burning your fingers or receiving an electric shock.
Page 394 Maintenance APPEARANCE CARE Exterior care Finish maintenance CAUTION Washing Exterior general caution • Do not use strong soap, chemical To help protect your vehicle’s finish from It is very important to follow the label detergents or hot water, and do rust and deterioration, wash it thoroughly directions when using any chemical not wash the vehicle in direct...
Page 395 Maintenance Finish damage repair Waxing Wax the vehicle when water will no Deep scratches or stone chips in the longer bead on the paint. painted surface must be repaired promptly. Exposed metal will quickly rust Always wash and dry the vehicle before and may develop into a major repair waxing.
Page 396 Maintenance Bright-metal maintenance Underbody maintenance WARNING • To remove road tar and insects, use a Corrosive materials used for ice and tar remover, not a scraper or other snow removal and dust control may col- After washing the vehicle, test the sharp object.
Page 397 Maintenance Aluminum or chrome wheel mainte- Corrosion protection High-corrosion areas nance If you live in an area where your car is Protecting your vehicle from corrosion regularly exposed to corrosive materials, The aluminum or chrome wheels are By using the most advanced design and coated with a clear protective finish.
Page 398 Maintenance To help prevent corrosion • When cleaning lower door panels, Keep paint and trim in good condition rocker panels and frame members, be You can help prevent corrosion from get- Scratches or chips in the finish should be sure that drain holes are kept open so ting started by observing the following: covered with "touch-up"...
Page 399 Maintenance Interior care Cleaning the upholstery and interior Cleaning the lap/shoulder belt web- trim bing Interior general precautions Vinyl Clean the belt webbing with any mild Prevent chemicals such as perfume, cos- soap solution recommended for cleaning Remove dust and loose dirt from vinyl metic oil, sun cream, hand cleaner and upholstery or carpet.
Page 400 Kia dealer or other repair shops that use qualified technicians in accordance with the maintenance schedule in this manual.
Page 401 Maintenance Canister 3. Exhaust emission control Engine exhaust gas precautions (car- bon monoxide) system Fuel vapors generated inside the fuel tank are absorbed and stored in the • Carbon monoxide can be present with The Exhaust Emission Control System is onboard canister.
Page 402 We recommend that the system be or do not coat the vehicle for cor- inspected by an authorized Kia dealer. rosion control. It may present a • Avoid driving with a extremly low fuel fire risk under certain conditions.
Page 403: Specifications & Consumer Information
Engine / 8-2 Dimensions / 8-2 Bulb wattage / 8-2 Tires and wheels / 8-3 Weight/Volume / 8-3 Recommended lubricants and capacities / 8-4 Vehicle identification number (VIN) / 8-6 Vehicle certification label / 8-6 Tire specification and pressure label / 8-7 Engine number / 8-7 Air conditioner compressor label / 8-7 Declaration of conformity / 8-8...
Page 404 Specifications & Consumer information ENGINE BULB WATTAGE Light Bulb Wattage Bulb type Item Gasoline 1.0 Gasoline 1.25 Headlights (Low/High) 55/60 H4 L/L Displacement [cc(cu.in)] 998 (60.9) 1,248 (76.2) Headlights (Low/High)* H7 L/L 71 x 84 71 x 78.8 Front turn signal lights* PY21W Bore x Stroke [mm(in)] (2.80 x 3.31)
Page 405 Specifications & Consumer information TIRES AND WHEELS Inflation pressure / bar(psi,kPa) Wheel lug nut torque / Item Tire size Wheel size Normal load Maximum load kg.m(lb.ft, N.m) Front Rear Front Rear 155/70 R13 4.0B×13 Full size tire 165/60 R14 5.0J×14 (33, 230) (31, 210) (36, 250)
Page 406 Specifications & Consumer information RECOMMENDED LUBRICANTS AND CAPACITIES To help achieve proper engine and powertrain performance and durability, use only lubricants of the proper quality. The correct lubricants also help promote engine efficiency that results in improved fuel economy. These lubricants and fluids are recommended for use in your vehicle. Lubricant Volume Classification...
Page 407 Specifications & Consumer information Recommended SAE viscosity Engine oil viscosity (thickness) has an When choosing an oil, consider the range effect on fuel economy and cold weather number of temperature your vehicle will be oper- operating (engine start and engine oil ated in before the next oil change.
Page 408 Specifications & Consumer information VEHICLE IDENTIFICATION NUMBER (VIN) VEHICLE CERTIFICATION LABEL Frame number VIN label (if equipped) OTA080001 OBH088005N OTA080002 The vehicle identification number (VIN) is The VIN is also on a plate attached to the The vehicle certification label attached the number used in registering your car top of the dashboard.
Page 409 Specifications & Consumer information TIRE SPECIFICATION AND ENGINE NUMBER AIR CONDITIONER PRESSURE LABEL COMPRESSOR LABEL ■ 1.0 Gasoline OTA080003L OMG055004 OHC081001 ■ 1.25 Gasoline The tires supplied on your new vehicle A compressor label informs you the type are chosen to provide the best perform- of compressor your vehicle is equipped ance for normal driving.
Page 410 DECLARATION OF CONFORMITY ■ Example CE0678 The radio frequency components of the vehicle comply with requirements and other relevant provisions of Directive 1995/5/EC. Further information including the manu- facturer's declaration of conformity is available on Kia web site as follows; http://www.kia-hotline.com...
Page 411 Index...
Page 412 Index Air bags................3-39 Base curb weight ............5-56 Air bag warning label ..........3-61 Battery................7-37 Air bag warning light ..........3-42 Battery saver function............4-69 Curtain air bag............3-52 Before driving ..............5-3 Driver's and passenger's front air bag ......3-46 Bottle holders, see cup holders........4-104 Side air bag ..............3-51 Brake system..............5-26 Air cleaner ..............7-30 Anti-lock brake system (ABS) ........5-29...
Page 413 Index Cargo weight ..............5-56 Central door lock switch ..........4-17 Changing tires ..............6-9 Dashboard, see instrument cluster ........4-42 Chains Daytime running light ............4-69 Tire chains ..............5-45 Declaration of conformity ..........8-8 Checking tire inflation pressure........7-41 Defogging (Windshield) ..........4-99 Child restraint system ............3-28 Defogging logic (Windshield) ........4-101 Lap belt..............3-31 Defroster (Rear window) ..........4-82...
Page 414 Index Economical operation ............5-38 Flat tire................6-8 Electronic power steering ..........4-35 Changing tires ............6-9 Electronic stability program (ESP) ........5-31 Jack and tools ..............6-8 Emergency starting ............6-5 Removing and storing the spare tire ......6-9 Jump starting ..............6-5 Fluid Push starting ..............6-6 Automatic transaxle fluid..........7-27 Emergency stop signal (ESS) ........5-36 Washer fluid ..............7-29 Emergency towing ............6-23...
Page 415 Index Trip computer ............4-44 Warning and indicators ..........4-55 Instrument panel overview..........2-3 Hazard warning flasher ..........4-68 Interior care ..............7-74 Hazardous driving conditions ........5-40 Interior features ............4-103 Headlight escort function..........4-69 Ashtray ..............4-103 Headlight leveling device..........4-75 Cigarette lighter ............4-103 Headlight welcome function ..........4-69 Clothes hanger ............4-108 Headrest ..............3-5, 3-9 Cup holder ..............4-104...
Page 416 Index Manual climate control system ........4-83 Air conditioning ............4-88 Climate control air filter..........4-90 Label Heating and air conditioning ........4-84 Air bag warning label..........3-61 Manual heating and air conditioning ......4-94 Tire sidewall labeling ..........7-46 Manual transaxle ............5-17 Tire specification and pressure label ......8-7 Memory fuse ..............7-52 Vehicle certification label..........8-6 Mirrors ................4-38...
Page 417 Index Parking brake ..............5-27 Scheduled maintenance service ........7-6 Passenger's front air bag ..........3-46 Maintenance under severe usage conditions ....7-16 Power brakes ..............5-26 Normal maintenance schedule ........7-7 Power outlet ..............4-106 Seat belts ................3-15 Power steering (Electronic) ..........4-35 Pre-tensioner seat belt ..........3-22 Power window lock button ..........4-24 Lap belt..............3-20 Pre-tensioner seat belt ............3-22...
Page 418 Index Special driving conditions ..........5-40 Driving at night ............5-41 Driving in flooded areas..........5-43 Tachometer..............4-43 Driving in the rain ............5-42 Tailgate................4-19 Hazardous driving conditions ........5-40 Tilt steering ..............4-35 Highway driving............5-43 Tire specification and pressure label ........8-7 Rocking the vehicle ..........5-40 Tires and wheels ............7-40, 8-3 Smooth cornering ............5-41 Checking tire inflation pressure ........7-41 Speedometer..............4-43...
Page 419 Index Wheel alignment and tire balance ........7-43 Wheel replacement ............7-45 Windows ................4-21 Vanity mirror lamp............4-105 Auto down window ..........4-22 Vehicle break-in process ..........1-4 Auto up/down window ..........4-23 Vehicle certification label ..........8-6 Power window lock button........4-24 Vehicle identification number (VIN) ........8-6 Windshield defrosting and defogging ......4-99 Vehicle stability management (VSM) ......5-35 Defogging logic ............4-101...
Page 420 Kia Motors is dedicated to providing you with a customer service experience that exceeds your expectations. At all of our Kia dealerships you will be treated with warmth, hospitality and professionalism by people who care based on our “Family-like Care”...
Page 421 Thank you for choosing a Kia vehicle. The information and specifications provided in this man- ual were accurate at the time of printing. Kia reserves the When you require service, remember that your dealer right to discontinue or change specifications or design at knows your vehicle best.
Page 422 Introduction Your vehicle at a glance Safety features of your vehicle Features of your vehicle Driving your vehicle table of contents What to do in an emergency Maintenance Specifications & Consumer information Index...
Page 423: How To Use This Manual /
Introduction How to use this manual / 1-2 Fuel requirements / 1-2 Vehicle break-in process / 1-4 Indicator symbols on the instrument cluster / 1-5...
Page 424: Octane Rating Of Ron 91~94 / Aki
Except Europe vided in the Table of Contents. Use the CAUTION Your new Kia vehicle is designed to use index when looking for a specific area or only unleaded fuel having an Octane subject; it has an alphabetical listing of all...
Page 425 (also known as grain alcohol), and petrol the catalytic converter and will authorized Kia dealer whether leaded or gasohol containing methanol (also damage the engine control sys- petrol in your vehicle is available or not.
Page 426: Seats
Fuel Additives between 2,000 rpm and 4,000 rpm. vapour lock or hard starting. Kia recommends that you use good qual- • Do not maintain a single speed for long ity petrols meet Europe Fuel standards periods of time, either fast or slow.
Page 427: Seat Belts
Introduction INDICATOR SYMBOLS ON THE INSTRUMENT CLUSTER Parking brake & Brake fluid Air bag warning light* Malfunction indicator light warning light ABS warning light* Charging system warning light ESP indicator* Tailgate open warning light ESP OFF indicator* Seat belt warning light Turn signal indicator Door ajar warning light Overspeed warning light*...
Page 428 Your vehicle at a glance Interior overview / 2-2 Instrument panel overview / 2-3 Engine compartment / 2-4...
Page 429: Door Lock/Unlock Button
Your vehicle at a glance INTERIOR OVERVIEW 1. Door lock/unlock button ....4-15 2. Central door lock switch* ....4-16 3. Power window switches*....4-20 4. Power window lock button* ....4-23 5. Outside rearview mirror control switch*..........4-38 6. Outside rearview mirror folding switch*..........4-39 7.
Page 430: Ignition Switch* Or Engine Start/Stop Button* ....5-4,
Your vehicle at a glance INSTRUMENT PANEL OVERVIEW 1. Instrument cluster......4-41 2. Horn ..........4-36 3. Driver’s front air bag* .......3-46 4. Light control/Turn signals ....4-70 5. Wiper/Washer........4-74 6. Ignition switch* or ENGINE START/STOP button* ..5-4, 5-6 7. Hazard warning flasher switch ..4-66, 6-2 8.
Page 431: Brake Fluid Reservoir
Your vehicle at a glance ENGINE COMPARTMENT 1.0 Petrol ■ ■ 1. Engine coolant reservoir ....7-23 2. Radiator cap ........7-24 3. Brake fluid reservoir......7-26 4. Air cleaner.........7-30 5. Engine oil dipstick ......7-21 6. Engine oil filler cap ......7-21 7. Windscreen washer fluid reservoir..7-29 8.
Page 432 Seats / 3-2 Seat belts / 3-15 Child restraint system / 3-28 Air bag - supplemental restraint system / 3-39 Safety features of your vehicle...
Page 433 Safety features of your vehicle SEATS Driver’s seat (1) Forward and rearward (2) Seatback angle (3) Seat cushion height* (4) Seat warmer* (5) Headrest Front passenger’s seat (6) Forward and rearward (7) Seatback angle (8) Seat warmer* (9) Walk-in seat (for 3 door vehicle only) (10) Headrest Rear seat (11) Headrest*...
Page 434 Safety features of your vehicle WARNING WARNING WARNING Loose objects Driver respon- - Driver’s seat sibility for passengers Loose objects in the driver’s foot • Never attempt to adjust the seat area could interfere with the opera- whilst the vehicle is moving. This Riding in a vehicle with the seat- tion of the foot pedals, possibly could result in loss of control,...
Page 435 Safety features of your vehicle (Continued) WARNING - Rear seatbacks • To avoid the possibility of burns, • The rear seatback must be do not remove the carpet in the securely latched. If not, passen- cargo area. Emission control gers and objects could be thrown devices beneath this floor gener- forward resulting in serious ate high temperatures.
Page 436 Safety features of your vehicle OTA030003L/H OTA030004L/H OPA039052 Seatback angle Seat cushion height (for driver’s seat) Headrest (if equipped) To recline the seatback: The driver's and front passenger's seats To change the height of the seat cushion, 1. Lean forward slightly and lift up on the are equipped with a headrest for the push the lever that is located on the out- seatback recline lever.
Page 437 Safety features of your vehicle WARNING • For maximum effectiveness in case of an accident, the headrest should be adjusted so the middle of the headrest is at the same height as the centre of gravity of an occupant's head. Generally, the centre of gravity of most peo- ple's head is similar with the height of the top of their eyes.
Page 438 Safety features of your vehicle ✽ ✽ NOTICE With the seat warmer switch in the ON position, the heating system in the seat turns off or on automatically depending on the seat temperature. CAUTION • When cleaning the seats, do not use an organic solvent such as paint thinner, benzene, alcohol and petrol.
Page 439 Safety features of your vehicle WARNING - Seat warmer burns Passengers should use extreme caution when using seat warmers due to the possibility of excess heating or burns. The occupants must be able to feel if the seat is becoming too warm and to turn the seat warmer off.
Page 440 Safety features of your vehicle WARNING • Since stored items may move whilst driving, be sure to position them in the tray so that they do not make noise or cause a poten- tial safety hazard when the vehi- cle is moving. •...
Page 441 Safety features of your vehicle WARNING • For maximum effectiveness in case of an accident, the headrest should be adjusted so the middle of the headrest is at the same height as the centre of gravity of an occupant's head. Generally, the centre of gravity of most peo- ple's head is similar with the height of the top of their eyes.
Page 442 Safety features of your vehicle Folding the rear seat (if equipped) To fold the rear seat cushion and seat back: The rear seatbacks (or cushions) may be The rear seatbacks may be folded for- folded to facilitate carrying long items or to increase the luggage capacity of the ward to provide additional cargo space vehicle.
Page 443 Safety features of your vehicle Type A Type A ■ ■ CAUTION • When folding or unfolding the rear seat, make sure to move the front seat fully forward. If there are not enough space to fold the rear seat, never fold it by force. It will cause damage to the head- rest or the related parts of the seat.
Page 444 Safety features of your vehicle Type A Type A Type A ■ ■ ■ OSA037011 OSA037012 OSA037014 Type B Type B ■ ■ OSA037038 OSA037019 OSA037039 5. Move the seat cushion firmly (3). 6. Lower the headrest as low as possible 8.
Page 445 Safety features of your vehicle CAUTION - Rear seat belts WARNING WARNING When returning the rear seatbacks After folding the rear seat, unless When you return the rear seatback to the upright position, remember the driver’s position is properly set to its upright position after being to return the rear shoulder belts to according to the driver’s physical...
Page 446 Safety features of your vehicle SEAT BELTS Seat belt restraint system (Continued) (Continued) • Avoid wearing twisted seat belts. Care should be taken to avoid con- WARNING A twisted belt can't do its job as tamination of the webbing with pol- •...
Page 447 Safety features of your vehicle WARNING • No modifications or additions should be made by the user which will either prevent the seat belt adjusting devices from oper- ating to remove slack, or prevent the seat belt assembly from being adjusted to remove slack.
Page 448 Safety features of your vehicle If you continue not to fasten the seat belt If the rear seat belt is disconnected when and you drive over 20km/h the seat belt you drive over the 20km/h, the corre- warning chime will sound for approxi- sponding seat belt warning light will blink mately 100 seconds and the correspon- and warning chime will sound for 35 sec-...
Page 449 Safety features of your vehicle To raise the height adjuster, pull it up (1). Front seat To lower it, push it down (3) whilst press- ing the height adjuster button (2). Release the button to lock the anchor into position. Try sliding the height adjuster to make sure that it has locked into position.
Page 450 Safety features of your vehicle ✽ ✽ NOTICE If you are not able to pull out the seat belt from the retractor, firmly pull the belt out and release it. Then you will be able to pull the belt out smoothly. B200A02NF/H OTA030049L When using the rear centre seat belt, the...
Page 451 Safety features of your vehicle Shorten Lengthen OEN036030 B210A01NF-1/H OBH038067 Lap belt (if equipped) To release the seat belt: The seat belt is released by pressing the To fasten your seat belt: release button (1) on the locking buckle. To fasten a 2-point static type belt, insert Too high When it is released, the belt should auto- the metal tab (1) into the locking buckle...
Page 452 Safety features of your vehicle OTA032025 B210A02NF-2 OTA030027 When using the rear centre seat belt, the Stowing the rear seat belt To release the seat belt: buckle with the “CENTER” mark must be When you want to release the seat belt, The rear seat belt buckles can be stowed used.
Page 453 Safety features of your vehicle When the vehicle stops suddenly, or if the occupant tries to lean forward too quickly, the seat belt retractor will lock into position. In certain collisions, the pre- tensioner will activate and pull the seat belt into tighter contact against the occu- pant's body.
Page 454 2. Be sure you and your passengers Kia dealer inspect the pre-tensioner • Although it is harmless, the fine dust always wear seat belts properly. seat belt and SRS air bag system as may cause skin irritation and should soon as possible.
Page 455 Properly worn seat belts greatly seat belt must be discarded, con- after they have been activated. reduce these hazards. tact an authorised Kia dealer. • Do not attempt to inspect or Always follow the precautions about replace the pre-tensioner seat seat belts, air bags and occupant belts yourself.
Page 456 Safety features of your vehicle Infant or small child Larger children ✽ ✽ NOTICE You should be aware of the specific Children who are too large for child Small children are best protected from requirements in your country. Child restraint systems should always occupy injury in an accident when properly and/or infant seats must be properly the rear seat and use the available...
Page 457 Safety features of your vehicle Pregnant women One person per belt If the shoulder belt portion slightly touch- es the child’s neck or face, try placing the The use of a seat belt is recommended Two people (including children) should child closer to the centre of the vehicle.
Page 458 This should be done even if no damage backs upright. replaced immediately. is visible. Additional questions concern- ing seat belt operation should be directed to an authorised Kia dealer. 3 27...
Page 459 Safety features of your vehicle CHILD RESTRAINT SYSTEM Children riding in the car should sit in the rear seat and must always be properly WARNING WARNING restrained to minimise the risk of injury in • A child restraint system must be To reduce the chance or serious or an accident, sudden stop or sudden placed in the rear seat.
Page 460 Forward-facing child restraint system • Never allow two children, or any • After an accident, have an autho- two persons, to use the same rised Kia dealer check the child seat belt. restraint system, seat belt, tether • Children often squirm and repo- anchor and lower anchor.
Page 461 Installing a child restraint system by the system checked immediately lap/shoulder belt by your authorised Kia dealer. To install a child restraint system on the • Failure to observe this manual's outboard or centre rear seats, do the fol-...
Page 462 Safety features of your vehicle E2BLD310 MMSA3030 E2BLD347 2. Fasten the lap/shoulder belt latch into 3. Buckle the seat belt and allow the seat Installing a child restraint system by the buckle. Listen for the distinct “click” belt to take up any slack. After installa- lap belt (on the centre rear seat) sound.
Page 463 Safety features of your vehicle WARNING Tether strap • A child can be seriously injured or killed in a collision if the child restraint is not properly anchored to the car and the child is not properly restrained in the child restraint.
Page 464 Safety features of your vehicle WARNING - Child restraint anchorage • Child restraint anchorages are designed to withstand only those loads imposed by correctly fitted child restraints. Under no circum- stances are they to be used for adult seat belts or harnesses or for attaching other items or equipment to the vehicle.
Page 465 Safety features of your vehicle Both rear outboard seats are equipped To secure the child restraint seat with a pair of ISOFIX anchorages as well WARNING 1. To engage the child restraint seat to as a corresponding top tether anchorage the ISOFIX anchor, insert the child Install the child restraint seat fully on the back side of the back rest.
Page 466 Safety features of your vehicle (Continued) WARNING • Attach the ISOFIX or ISOFIX-com- • Do not install a child restraint patible child restraint seat only to seat at the centre of the rear seat the appropriate locations shown using vehicle's ISOFIX in the illustration.
Page 467 Safety features of your vehicle Child Seat Restraint Suitability For Seat Position using the Seat Belt WARNING - For Europe recommend that child Use child safety seats that have been officially approved and are appropriate for your restraint seat be installed in the children.
Page 468 Safety features of your vehicle Child seat restraint suitability for vehicle ISOFIX positions - For Europe vehicle ISOFIX positions Mass Group Size Class Fixture Rear Outboard Rear Outboard Front Passenger Rear Centre (Driver side) (Passenger side) ISO/L1 Carrycot ISO/L2 0 : UP to 10kg ISO/R1 ISO/R1 0+ : UP to 13kg...
Page 469 Safety features of your vehicle Recommended child restraint systems – For Europe ECE-R44 Mass Group Name Manufacturer Type of Fixation Approval No. E4 03443416 (Seat) Rearward facing with vehicle Bimbo G0/1 S FAIR specific ISOFIX platform type “A” E4 0443718 (Platform) Group 0-1 (0-18kg) Baby-Safe Plus II...
Page 470 Safety features of your vehicle AIR BAG - SUPPLEMENTAL RESTRAINT SYSTEM (IF EQUIPPED) (1) Driver’s front air bag* (2) Passenger’s front air bag* (3) Side impact air bag* (4) Curtain air bag* (5) Driver’s knee air bag* (6) Front passenger’s air bag ON/OFF switch* * : if equipped WARNING...
Page 471 Safety features of your vehicle How does the air bag system It is much more likely that you will sim- ply see the deflated air bags hanging WARNING operate out of their storage compartments after • To avoid severe personal injury •...
Page 472 Safety features of your vehicle Noise and smoke In addition, do not place a front-facing ■ Type A child restraints in the front passenger’s When the air bags inflate, they make a seat. If the front passenger air bag loud noise and they leave smoke and powder in the air inside of the vehicle.
Page 473 Safety features of your vehicle W7-147 OTA030044R OTA030045R Air bag warning light Passenger’s front air bag Passenger’s front air bag ON indicator (if equipped) OFF indicator (if equipped) The purpose of the air bag warning light in your instrument panel is to alert you of a potential problem with your air bag - The passenger's front air bag ON indica- The passenger’s front air bag OFF indi-...
Page 474 11. Passenger’s front air bag ON/OFF SRS air bag system as soon as pos- occurs, this indicates a malfunction switch* sible. of the SRS. Have an authorised Kia 12. Passenger’s front air bag ON/OFF dealer inspect the air bag system indicator* as soon as possible.
Page 475 Safety features of your vehicle Driver’s front air bag (1) Driver’s front air bag (2) Driver’s front air bag (3) OHM039102N/H OHM039103N/H OHM039104N/H The front air bag modules are located Upon deployment, tear seams molded A fully inflated air bag, in combination both in the centre of the steering wheel, directly into the pad covers will separate with a properly worn seat belt, slows the...
Page 476 If this occurs, instrument panel surface. have your vehicle immediately It may become a dangerous pro- inspected by an authorised Kia jectile and cause injury if the pas- dealer. senger's air bag inflates. (Continued)
Page 477 Safety features of your vehicle The indications of the system's presence Driver’s front air bag Passenger’s front air bag are the letters "AIR BAG" embossed on the air bag pad cover in the steering wheel and/or on the cover of the driver’s side knee bolster located below the steering wheel and the passenger's side front panel pad above the glove box.
Page 478 • Never place a child in any child or the vehicle is being driven, have crash. booster seat in the front seat. an authorised Kia dealer inspect (Continued) • ABC – Always Buckle Children in the air bag system as soon as the back seat.
Page 479 Safety features of your vehicle (Continued) (Continued) (Continued) • The SRS is designed to deploy • Children age 12 and under must • Sitting improperly or out of posi- the front air bags only when an always be properly restrained in tion can result in serious or fatal impact is sufficiently severe and the rear seat.
Page 480 Safety features of your vehicle WARNING The front air bag ON/OFF switch could turn by using a similar small rigid device. Always check the sta- tus of the front air bag ON/OFF switch and passenger's front air bag ON/OFF indicator. ✽...
Page 481 • Deactivate the passenger's front nates whilst the vehicle is being illuminate. air bag only when the ignition driven, have an authorised Kia And, the passenger's front air bag switch is switched off, or the mal- dealer inspect the passenger’s...
Page 482 Safety features of your vehicle The side impact air bags are designed to Front (Continued) deploy only during certain side-impact • Even though your vehicle is collisions, depending on the crash sever- equipped with the passenger's ity, angle, speed and point of impact. The front air bag ON/OFF switch, do side impact air bags are not designed to not install a child restraint sys-...
Page 483 Kia dealer because your vehicle (Continued) They are designed to help protect the is equipped with side impact air heads of the front seat occupants and bags.
Page 484 This should only tion, front seat occupants and be done by an authorised Kia outboard rear occupants should dealer. sit in an upright position with the seat belts properly fastened.
Page 485 Safety features of your vehicle Why didn’t my air bag go off in a collision? (Inflation and non-infla- tion conditions of the air bag) There are many types of accidents in which the air bag would not be expect- ed to provide additional protection. These include rear impacts, second or third collisions in multiple impact accidents, as well as low speed...
Page 486 Kia dealer. • If the installation location or • Your vehicle has been designed angle of the sensors is altered in to absorb impact and deploy the any way, the air bags may deploy air bag(s) in certain collisions.
Page 487 Safety features of your vehicle Although the front air bags (driver’s and front passenger’s air bags) are designed to inflate only in frontal collisions, they also may inflate in other types of colli- sions if the front impact sensors detect a sufficient impact.
Page 488 Safety features of your vehicle OPA037042/H OSA038121 1VQA2089 • Frontal air bags are not designed to • Front air bags may not inflate in side • In an angled collision, the force of inflate in rear collisions, because occu- impact collisions, because occupants impact may direct the occupants in a pants are moved backward by the move to the direction of the collision,...
Page 489 Safety features of your vehicle OPA037043 1VQA2091 OSA038122 • Just before impact, drivers often brake • Air bags does not inflate in most • Air bags may not inflate if the vehicle heavily. Such heavy braking lowers the rollover accidents (even if the vehicle is collides with objects such as utility front portion of the vehicle causing it to equipped with side impact air bags and...
Page 490 • If the air bags inflate, they must • Modification to SRS components and so there are no parts you can safely be replaced by an authorised Kia or wiring, including the addition service by yourself. If the SRS air bag dealer.
Page 491 Safety features of your vehicle Additional safety precautions • Keep occupants away from the air bag covers. All occupants should sit WARNING • Never let passengers ride in the upright, fully back in their seats with cargo area or on top of a folded- •...
Page 492 Safety features of your vehicle Type A ■ Type B ■ OTA030040L/OTA030040L/H Air bag warning label (if equipped) Air bag warning labels are attached to alert the driver and passengers of poten- tial risk of air bag system. Note that these government warnings focus on the risk of children.
Page 493 Keys / 4-3 Remote keyless entry / 4-6 Smart key / 4-9 Theft-alarm system / 4-11 Door locks / 4-14 Tailgate / 4-18 Windows / 4-20 Bonnet / 4-25 Features of your vehicle Fuel filler lid / 4-27 Sunroof / 4-30 Steering wheel / 4-34 Mirrors / 4-37 Instrument cluster / 4-41...
Page 494 Storage compartments / 4-99 Interior features / 4-101 Audio system / 4-107 Features of your vehicle...
Page 495 Should you lose your keys, we recommend that you contact an authorised Kia dealer. Remove the key code tag and store it in a safe place. Also, record the key code number and keep it in a safe place (not in the vehicle).
Page 496 WARNING With the immobiliser system, whenever Use only Kia original parts for the you insert your ignition key into the igni- ignition key in your vehicle. If an tion switch and turn it to ON, it checks...
Page 497 Kia To deactivate the immobiliser sys- dealer. tem: Malfunctions caused by improper Insert the ignition key into the key cylin- ✽...
Page 498 Features of your vehicle REMOTE KEYLESS ENTRY (IF EQUIPPED) Lock (1) Tailgate unlock (3) (if equipped) Type A ■ All doors (and tailgate) are locked if the The tailgate is unlocked if the button is lock button is pressed whilst all doors are pressed for more than 1 second.
Page 499 If you have a problem OYDECO2006CN with the transmitter, contact an autho- Type C ■ rised Kia dealer. CAUTION Keep the transmitter away from water or any liquid. If the keyless entry system is inoperative due to...
Page 500 Be sure to use the correct battery. For transmitter replacement, see an authorised Kia dealer to reprogram the • To avoid damaging the transmit- transmitter. ter or smart key, don't drop it, get it wet, or expose it to heat or sun- light.
Page 501 Features of your vehicle SMART KEY (IF EQUIPPED) Type A ■ WARNING If the battery of accessory smart key is totally discharged, it is impossible to enter the vehicle. In this case, you can enter the vehicle with a mechan- ical key.
Page 502 Pressing the button of the front outside authorised Kia dealer to protect it door handles with all doors (and tailgate) ❈ The word “HOLD” is written on the but- from potential theft.
Page 503 Features of your vehicle THEFT-ALARM SYSTEM (IF EQUIPPED) (Continued) • If the transmitter (or smart key) is in close proximity to your cell phone or smart phone, the signal from the Armed stage transmitter (or smart key) could be blocked by normal operation of your cell phone or smart phone.
Page 504 Features of your vehicle Armed stage If any door (and tailgate) or engine • Do not arm the system until all pas- bonnet remains open, the hazard sengers have left the vehicle. If the Using the smart key warning lights won't operate and system is armed whilst a passen- Park the vehicle and stop the engine.
Page 505 - The ignition switch is in the “ON” posi- iced by an authorised Kia dealer. If the system is not disarmed with the tion for 30 seconds or more. Malfunctions caused by improper...
Page 506 Features of your vehicle DOOR LOCKS Transmitter/Smart key ✽ ✽ NOTICE • Doors can be locked and unlocked with • In cold and wet climates, door locks the transmitter (or smart key). (if and door mechanisms may not work equipped) properly due to freezing conditions.
Page 507 Features of your vehicle • If the inner door handle of the front doors is pulled when the door lock but- ton is in lock position, the button is unlocked and door opens. (if equipped) • Front door cannot be locked if the igni- tion key is in the ignition switch and the door is open.
Page 508 Features of your vehicle Driver’s door WARNING - WARNING Doors Unlocked vehicles • The doors should always be fully closed and locked whilst the Leaving your vehicle unlocked can vehicle is in motion to prevent invite theft or possible harm to you accidental opening of the door.
Page 509 Features of your vehicle Impact sensing door unlock sys- 3. Close the rear door. tem (if equipped) To open the rear door, pull the outside door handle. All doors will automatically unlock after Even though the doors may be unlocked, an impact causes the air bags to deploy.
Page 510 Features of your vehicle TAILGATE ✽ ✽ NOTICE In cold and wet climates, door lock and door mechanisms may not work proper- ly due to freezing conditions. WARNING The tailgate swings upward. Make sure no objects or people are near the rear of the vehicle when open- ing the tailgate.
Page 511 Features of your vehicle WARNING Exhaust fumes If you drive with the tailgate open, you will draw dangerous exhaust fumes into your vehicle which can cause serious injury or death to vehicle occupants. If you must drive with the tailgate open, keep the air vents and all win- dows open so that additional out- side air comes into the vehicle.
Page 512 Features of your vehicle WINDOWS (1) Driver’s door power window switch (2) Front passenger’s door power win- dow switch (3) Rear door (right) power window switch* (4) Rear door (left) power window switch* (5) Window opening and closing (6) Automatic power window up*/down* (Driver’s window) (7) Power window lock switch* * : if equipped...
Page 513 Features of your vehicle Power windows (if equipped) The ignition switch must be in the ON position for power windows to operate. Each door has a power window switch that controls the door's window. The driver has a power window lock switch which can block the operation of passenger win- dows.
Page 514 Features of your vehicle ✽ ✽ NOTICE The automatic reverse feature for the driver’s window is only active when the “auto up” feature is used by fully pulling up the switch. The automatic reverse feature will not operate if the window is raised using the halfway posi- tion on the power window switch.
Page 515 Features of your vehicle Except Europe WARNING - Windows The driver can disable the power window switches on the front and rear passen- • NEVER leave the ignition key in gers' doors by pressing the power window the vehicle. lock switch to lock position (pressed). •...
Page 516 Features of your vehicle OSA028222/H Manual windows (if equipped) To raise or lower the window, turn the window regulator handle clockwise or counterclockwise. WARNING When opening or closing the win- dows, make sure your passenger's arms, hands and body are safely out of the way.
Page 517 Features of your vehicle BONNET OTA040017R OTA040018 OTA040019 Opening the bonnet 2. Go to the front of the vehicle, raise the 3. Pull the support rod from the bonnet. bonnet slightly, pull the secondary 4. Hold the bonnet open with the support 1.
Page 518 Features of your vehicle Closing the bonnet WARNING 1. Before closing the bonnet, check the following: • Always double check to be sure that the bonnet is firmly latched • All filler caps in engine compartment before driving away. If it is not must be correctly installed.
Page 519 Features of your vehicle FUEL FILLER LID Closing the fuel filler lid 1. To install the cap, turn it clockwise until it “clicks”. This indicates that the cap is securely tightened. 2. Close the fuel filler lid and push it light- ly and make sure that it is securely closed.
Page 520 Features of your vehicle (Continued) (Continued) WARNING - Refuelling Use only approved portable plas- • Do not get back into a vehicle dangers tic fuel containers designed to once you have begun refuelling Automotive fuels are flammable carry and store petrol. since you can generate static materials.
Page 521 • If the fuel filler cap requires and then contact the local fire replacement, use only a genuine department. Follow any safety Kia cap or the equivalent speci- instructions they provide. fied for your vehicle. An incorrect fuel filler cap can result in a seri- ous malfunction of the fuel sys- tem or emission control system.
Page 522 Features of your vehicle SUNROOF (IF EQUIPPED) ✽ ✽ NOTICE ✽ ✽ NOTICE • In cold and wet climates, the sunroof The sunroof cannot slide when it is in may not work properly due to freez- the tilt position nor can it be tilted whilst ing conditions.
Page 523 Features of your vehicle To open the sunroof automatically: Pull the sunroof control lever backward to the second detent position and then release it. The sunroof will slide all the way open. To stop the sunroof sliding at any point, pull or push the sunroof control lever momentarily.
Page 524 Features of your vehicle CAUTION WARNING • Periodically remove any dirt that • Never try pinching any part of may accumulate on the guide rail. your body intentionally to acti- • If you try to open the sunroof vate the Automatic reversal func- when the temperature is below tion.
Page 525 Features of your vehicle Resetting the sunroof ❈ For more detailed information, contact an authorised Kia dealer. Whenever the vehicle battery is discon- nected or discharged, or related fuse is blown, you must reset your sunroof sys- CAUTION tem as follows:...
Page 526 Kia dealer. • The steering effort increases if the steering wheel is rotated continuously when the vehicle is not in motion.
Page 527 Features of your vehicle CAUTION • Do not install any grip to operate the steering wheel. This causes damage to the heated steering wheel system. • When cleaning the heated steering wheel, do not use an organic sol- vent such as paint thinner, ben- zene, alcohol and petrol.
Page 528 Features of your vehicle CAUTION Do not strike the horn severely to operate it, or hit it with your fist. Do not press on the horn with a sharp- pointed object. OTA040027 Horn To sound the horn, press the horn sym- bols on your steering wheel.
Page 529 Features of your vehicle MIRRORS Inside rearview mirror Outside rearview mirror Adjust the rearview mirror to centre on Be sure to adjust mirror angles before the view through the rear window. Make driving. this adjustment before you start driving. Your vehicle is equipped with both left- hand and right-hand outside rearview mirrors.
Page 530 Features of your vehicle CAUTION Do not scrape ice off the mirror face; this may damage the surface of the glass. If ice should restrict movement of the mirror, do not force the mirror for adjustment. To remove ice, use a deicer spray, or a sponge or soft cloth with very warm water.
Page 531 Features of your vehicle CAUTION CAUTION • The mirrors stop moving when The electric type outside rearview they reach the maximum adjust- mirror operates even though the ing angles, but the motor contin- ignition switch is in the OFF posi- ues to operate whilst the switch is tion.
Page 532 Features of your vehicle OTA040031/H Manual type To fold outside rearview mirror, grasp the housing of mirror and then fold it toward the rear of the vehicle.
Page 533 Features of your vehicle INSTRUMENT CLUSTER Type A ■ ■ 1. Tachometer 2. Turn signal indicators 3. Speedometer 4. Fuel gauge 5. Warning and indicator lights 6. Odometer/Trip computer* Type B ■ ■ 7. LCD display* 8. Shift position indicator* (A/T) * : if equipped ❈...
Page 534 Features of your vehicle Type A ■ OTA040034 Type B ■ OTA042209L OTA040035 Instrument panel illumination Tachometer (if equipped) The tachometer indicates the approxi- mate number of engine revolutions per The instrument panel illumination intensi- minute (rpm). ty can be adjusted by rotating the control Use the tachometer to select the correct knob with the headlight switch in the shift points and to prevent lugging and/or...
Page 535 Features of your vehicle ■ Type A ■ Type B WARNING - Fuel gauge Running out of fuel can expose vehicle occupants to danger. You must stop and obtain addition- al fuel as soon as possible after the warning light comes on or when the gauge indicator comes close to the E level.
Page 536 Features of your vehicle Type A Type A TRIP A ■ ■ TRIP B Distance to empty* OTA040038 OTA040039 Type B Type B ■ ■ Average fuel consumption* Average refuel consumption* OTA042038 OTA042039 Odometer (km or mi.) Tripmeter (km or mi.) Instant fuel consumption* The odometer indicates the total dis- TRIP A : Tripmeter A...
Page 537 Features of your vehicle Type A Type A Type A ■ ■ ■ OTA040040 OTA040041L OTA040205L Type B Type B Type B ■ ■ ■ OTA042040 OTA042041L OTA042205L Distance to empty (km or mi.) Average fuel consumption (if equipped) Average refuel consumption (if equipped) (if equipped) (L/100 km or MPG) (l/100 km or MPG)
Page 538 Features of your vehicle Type A Type A Type A ■ ■ ■ OTA040042L OTA040043 OTA040044 Type B Type B Type B ■ ■ ■ OTA042042 OTA042043 OTA042044 Instant fuel consumption (if equipped) Elapsed time Outside thermometer (if equipped) (L/100 km or MPG) This mode indicates the total time trav- This mode indicates the outside temper- This mode calculates the instant fuel...
Page 539 Features of your vehicle Type A Type B ■ ■ WARNING Never remove the radiator cap when the engine is hot. The engine coolant is under pressure and could cause severe burns. Wait until the engine is cool before adding coolant to the reservoir. OTA043360E OTA040045/OTA042045 ECO ON/OFF mode (if equipped)
Page 540 Features of your vehicle LCD display informations • Manual transaxle (if equipped) You can turn the manual transaxle shift Door/Tailgate open indicator on/off on the instrument cluster in this mode. ■ Door If you select the ECO OFF in the trip computer, the manual transaxle shift indi- cator will not illuminate.
Page 541 Features of your vehicle Align steering wheel (if equipped) Align steering wheel (if equipped) Illumination intensity OTA042228L OTA042227L OTA042229L If you start the engine when the steering If you start the engine when the steering The illumination intensity of the instru- wheel is turned 90 degrees to the left wheel is turned 90 degrees to the right ment panel is shown when adjusting it...
Page 542 Features of your vehicle For vehicle’s equipped with smart key system Key is not in vehicle Key is not detected Please press start button with smart key OTA042221L OTA042219L OTA042225L If the smart key is not in the vehicle and If the smart key is not in the vehicle or is If you press the engine start/stop button if any door is opened or closed with the...
Page 543 Features of your vehicle For vehicle’s equipped with smart key system Low key battery Press brake pedal to start engine Press clutch pedal to start engine (for automatic transaxle) (for manual transaxle) OTA042213L OTA042217L If the engine start/stop button changes to OTA042218L the OFF position when the smart key in If the engine start/stop button changes to...
Page 544 Also, the warning chime sounds for about or the theft alarm system is armed. 10 seconds. (if equipped) If the warning illuminates each time you press the engine start/stop button, take your vehicle to an authorised Kia dealer and have the system checked.
Page 545 Features of your vehicle For vehicle’s equipped with smart key system Press start button whilst turn steering Check steering wheel lock system Steering wheel unlock (if equipped) (if equipped) OTA042215L OTA042214L If the steering wheel does not lock nor- OTA042216L If the steering wheel does not unlock nor- If the steering wheel does not lock nor- mally when the ENGINE START/STOP...
Page 546 All warning lights are checked by turning (Automatic transaxle) the ignition switch ON (do not start the engine). Any light that does not illuminate should be checked by an authorised Kia The ECO indicator is a system that dealer. informs you to drive economically.
Page 547 If this occurs, have your vehicle checked ed the engine, or if it comes on whilst If the both ABS and brake warning by an authorised Kia dealer as soon as driving, have the SRS inspected by an lights are on and stay on, your vehi- possible.
Page 548 Your dealer should be consult- found, the warning light remains on or ed for repairs. the brakes do not operate properly. Have the vehicle towed to any autho- rised Kia dealer for a brake system inspection and necessary repairs.
Page 549 This indicator illuminates when the tail adding oil or if oil is not available, call an lights are on. Low Beam Indicator Light authorised Kia dealer. (if equipped) CAUTION If the engine is not stopped imme- This indicator light illuminates when the diately after the engine oil pressure headlights are on.
Page 550 Have an authorised : Indicates that shifting up to the 3rd soon as it is safe to do so, turn off Kia dealer correct the problem as soon gear is desired (currently the shift the engine and check the oil level. If as possible.
Page 551 This light illuminates when the immobilis- key in the vehicle, have the system er key is inserted and turned to the ON checked by an authorised Kia dealer. position to start the engine. • When the battery is weak, if the At this time, you can start the engine.
Page 552 System inspected as soon as pos- ON position, take your vehicle to your sible by an authorised Kia dealer. nearest authorised Kia dealer and have the system checked. Generally, your vehicle will continue to be drivable, but have the system checked by an authorised Kia dealer promptly.
Page 553 With smart key system indicator illuminates and stays on. Take If the driver’s door is opened whilst the your vehicle to an authorised Kia dealer smart key is in the vehicle with the and have the system checked. engine start/stop button in ACC, the key reminder warning chime will sound.
Page 554 If the battery of smart key in the vehicle an authorised Kia dealer. This happens because of the low battery is discharged with engine start/stop but- voltage. It does not mean the system is ton in the OFF position, this warning light malfunctioning.
Page 555 Features of your vehicle REAR PARKING ASSIST SYSTEM (IF EQUIPPED) Operation of the rear parking WARNING assist system The rear parking assist system is a Operating condition supplementary function only. The • This system will activate when backing operation of the rear parking assist up with the ignition switch ON.
Page 556 Features of your vehicle Non-operational conditions of Rear parking assist system pre- The detecting range may decrease when: rear parking assist system cautions 1. The sensor is stained with foreign mat- The rear parking assist system may • The rear parking assist system may ter such as snow or water.
Page 557 If this occurs, have your vehicle be detected by the sensors. checked by an authorised Kia dealer as Always visually check behind the vehi- soon as possible. cle when backing up.
Page 558 Features of your vehicle HAZARD WARNING FLASHER OTA040049 The hazard warning flasher should be used whenever you find it necessary to stop the car in a hazardous location. When you must make such an emer- gency stop, always pull off the road as far as possible.
Page 559 Features of your vehicle LIGHTING Battery saver function Headlight escort function Headlight welcome function (if equipped) (if equipped) • The purpose of this feature is to pre- vent the battery from being dis- The headlights (and/or taillights) will When the headlight switch is in the ON or charged.
Page 560 Features of your vehicle ■ Type A ■ Type A ■ Type A OTA040050E ORBC040047 ORBC040048 ■ Type B ■ Type B ■ Type B OTA040050L ORB040047E ORB040048E ■ Type C ■ Type C ■ Type C OTA040050R OTA040211R OTA040212R Lighting control Parking light position ( Headlight position (...
Page 561 Features of your vehicle ■ Type A ■ Type A CAUTION • Never place anything over sensor (1) located on the instrument panel. This will ensure better auto-light system control. ORBC040049 • Don’t clean the sensor using a ■ Type B window cleaner.
Page 562 Features of your vehicle Type A ■ Type A ■ WARNING Do not use high beam when there are other vehicles. Using high beam could obstruct the other driver's vision. ORBC040050 ■ Type B ORBC040051 Type B ■ ORB040050E ■ Type C OTA040214R ORB040051E Flashing headlights...
Page 563 Features of your vehicle The ignition switch must be on for the Type A Type D ■ ■ turn signals to function. To turn on the turn signals, move the lever up or down (A). The green arrow indicators on the instrument panel indicate which turn sig- nal is operating.
Page 564 Features of your vehicle Fog lights are used to provide improved Type A Type D ■ ■ visibility and avoid accidents when visibil- ity is poor due to fog, rain or snow etc. The fog lights will turn on when fog light switch (1) is turned to ON after the park- ing light is turned on.
Page 565 Features of your vehicle To turn the rear fog lights on, turn the Loading condition Switch position headlight switch to the headlight on posi- Driver only tion and turn the rear fog light switch (1) Driver + Front passenger to the on position. Full passengers The rear fog lights turn on when the rear fog light switch is turned on after the...
Page 566: Wipers And Washers
Features of your vehicle WIPERS AND WASHERS A : Wiper speed control Windscreen wiper/washer · MIST ( ) – Single wipe Type A ■ Type D ■ · OFF (O) – Off · INT (---) – Intermittent wipe · LO (1) – Low wiper speed ·...
Page 567 Features of your vehicle Windscreen wipers D : Rear wiper/washer control Rear window wiper/washer (if equipped) (if equipped) Operates as follows when the ignition · – Wash with brief wipes switch is turned ON. Type D ■ MIST ( ) : For a single wiping cycle, ·...
Page 568 Features of your vehicle Windscreen washers Type A Type D ■ ■ In the OFF (O) position, pull the lever gently toward you to spray washer fluid on the windscreen and to run the wipers 1-3 cycles. Use this function when the windscreen is dirty.
Page 569 Features of your vehicle Rear window wiper and washer Type D ■ WARNING switch (if equipped) Do not use the washer in freezing The rear window wiper and washer temperatures without first warming switch is located at the end of the wiper the windscreen with the defrosters;...
Page 570 Features of your vehicle INTERIOR LIGHT The map lamp goes out gradu- CAUTION ally after approximately 30 sec- onds if the door is closed. Do not use the interior lights for However, if the ignition switch is extended periods when the engine ON or all doors are locked, the is not running.
Page 571 Features of your vehicle However, if a door is opened with the ignition switch in the ON posi- tion, the room lamp stays on con- tinuously. • OFF : The lights turn off even if a door is opened. • ON : The room lamp stay on at all times.
Page 572 Features of your vehicle DEFROSTER Type A ■ CAUTION To prevent damage to the conduc- tors bonded to the inside surface of the rear window, never use sharp instruments or window cleaners containing abrasives to clean the Type B ■ window.
Page 573 Features of your vehicle MANUAL CLIMATE CONTROL SYSTEM (IF EQUIPPED) ■ ■ Type A 1. Temperature control knob 2. Air intake control knob 3. Fan speed control knob 4. Mode selection knob 5. Rear window defroster button ■ ■ Type B 6.
Page 574 Features of your vehicle Heating and air conditioning 1. Start the engine. 2. Set the mode to the desired position. For improving the effectiveness of heating and cooling; - Heating: - Cooling: 3. Set the temperature control to the desired position. 4.
Page 575 Features of your vehicle Face-Level (B, D) Floor/Defrost-Level (A, C, D) Most of the air flow is directed to the floor Air flow is directed toward the upper body and the windscreen with a small amount and face. Additionally, each outlet can be directed to the side window defrosters.
Page 576 Features of your vehicle OTA040064R OTA040065 OTA040066R Temperature control Air intake control Instrument panel vents You can adjust the direction of air deliv- The temperature control knob allows you The air intake control is used to select ery from these vents using the vent con- to control the temperature of the air flow- the outside (fresh) air position or recircu- trol lever as shown.
Page 577 Features of your vehicle Recirculated air position ✽ ✽ NOTICE WARNING With the recirculated air Prolonged operation of the heater in the position selected, air from • Continue using the climate con- recirculated air position (without air the passenger compart- trol system in the recirculated air conditioning selected) may cause fogging ment will be drawn through...
Page 578 Features of your vehicle To turn off the blowers To turn off the blowers, turn the fan speed control knob to the “0” position. OTA040068 OTA040067R Fan speed control Air conditioning (A/C) The ignition switch must be in the ON Press the A/C button to turn the air con- position for fan operation.
Page 579 Features of your vehicle System operation Air conditioning Operation Tips • To keep dust or unpleasant fumes from Kia Air Conditioning Systems are filled Ventilation entering the vehicle through the venti- with environmentally friendly R-134a 1. Set the mode to the position.
Page 580 Features of your vehicle Air conditioning system operation tips • When using the air conditioning sys- ✽ ✽ NOTICE tem, you may notice clear water drip- • If the vehicle has been parked in direct • When using the air conditioning sys- ping (or even puddling) on the ground sunlight during hot weather, open the tem, monitor the temperature gauge...
Page 581 Blower decreases, the system should be Evaporator core authorised Kia dealer. checked at an authorised Kia dealer. Climate control air filter Heater core ✽ ✽ NOTICE OHM048209 It is important that the correct type and Climate control air filter amount of oil and refrigerant is used.
Page 582 Features of your vehicle AUTOMATIC CLIMATE CONTROL SYSTEM (IF EQUIPPED) Type A ■ ■ 1. Temperature control knob 2. AUTO (automatic control) button 3. OFF button 4. Climate control display 5. Fan speed control knob 6. Air conditioning button (if equipped) 7.
Page 583 Features of your vehicle OTA040070 OTA040074 OTA040071/H Automatic heating and air condi- 2. Set the temperature control knob to ✽ ✽ NOTICE tioning set the desired temperature. Never place anything over the sensor 1. Push the AUTO button. The modes, located on the instrument panel to ✽...
Page 584 Features of your vehicle Manual heating and air condition- Floor & Defrost (A, C, D) The heating and cooling system can be controlled manually by pushing buttons Most of the air flow is directed to the floor other than the AUTO button. In this case, and the windscreen with a small amount the system works sequentially according directed to the side window defrosters.
Page 585 Features of your vehicle OTA040073R OTA040064R OTA040074 Temperature control Defrost-Level Instrument panel vents Most of the air flow is directed to the You can adjust the direction of air deliv- The temperature control knob allows you windscreen with a small amount of air ery from these vents using the vent con- to control the temperature of the air flow- directed to the side window defrosters.
Page 586 Features of your vehicle Temperature conversion Recirculated air position You can switch the temperature mode With the recirculated air between Centigrade to Fahrenheit as fol- position selected, air from lows: the passenger compart- ment will be drawn through Whilst pressing the OFF button, press the heating system and heated or cooled according AUTO button for 4 seconds or more.
Page 587 Features of your vehicle WARNING • Continued climate control system operation in the recirculated air position may allow humidity to increase inside the vehicle which may fog the glass and obscure visibility. • Do not sleep in a vehicle with the air conditioning or heating sys- tem on.
Page 588 Features of your vehicle OTA040078 OFF mode Press the OFF button to turn off the air climate control system. However, you can still operate the mode and air intake but- tons as long as the ignition switch is in the ON position.
Page 589 Features of your vehicle WINDSCREEN DEFROSTING AND DEFOGGING • For maximum defrosting, set the tem- WARNING perature control to the extreme Windscreen right/hot position and the fan speed heating control to the highest speed. Do not use the position • If warm air to the floor is desired whilst during cooling operation...
Page 590 Features of your vehicle OTA040080R OTA040081 OTA040082 To defrost outside windscreen Automatic climate control system To defrost outside windscreen 1. Set the fan speed to the highest posi- 1. Set the fan speed to the highest To defog inside windscreen tion.
Page 591 Features of your vehicle STORAGE COMPARTMENTS Defogging logic These compartments can be used to store small items required by the driver To reduce the probability of fogging up or passengers. the inside of the windscreen, the air intake or air conditioning are controlled automatically according to certain condi- CAUTION tions such as...
Page 592 Features of your vehicle WARNING • Do not keep objects except sun- glasses inside the sunglass hold- er. Such objects can be thrown from the holder in the event of a sudden stop or an accident, pos- sibly injuring the passengers in the vehicle.
Page 593 “ready” position. If it is necessary to replace the cigarette OTA042086 lighter, use only a genuine Kia replace- Ashtray (if equipped) ment or its approved equivalent. To use the ashtray, open the cover.
Page 594 Features of your vehicle Cup holder WARNING - Ashtray use • Do not use the vehicle’s ashtrays WARNING Hot liquids as waste receptacles. • Do not place uncovered cups of • Putting lit cigarettes or matches hot liquid in the cup holder whilst in an ashtray with other com- the vehicle is in motion.
Page 595 Features of your vehicle OTA040094R OTA040207R OTA040182/H To use the cup holder space as a storage Sunvisor Vanity mirror lamp (if equipped) compartment, turn the half part of the Use the sunvisor to shield direct light Opening the lid of the vanity mirror will cup holder (2) to the direction of the through the front or side windows.
Page 596 Features of your vehicle Digital clock CAUTION Whenever the battery terminals or relat- • Use the power outlet only when ed fuses are disconnected, you must the engine is running and remove reset the time. the accessory plug after use. When the ignition switch is in the ACC or Using the accessory plug for pro- ON position, the clock buttons operate as...
Page 597 Features of your vehicle With audio on Type A Type C ■ ■ 1. Press the [SETUP] or [Clock] button until the clock adjust mode displayed. 2. Set the clock by turning the knob(1) and press it. WARNING Do not adjust the clock whilst driv- ing.
Page 598 To avoid any interference with pedal operation, Kia recommends that only the Kia floor mat designed for use in your vehicle be installed.
Page 599 Features of your vehicle AUDIO SYSTEM ✽ ✽ NOTICE CAUTION If you install an aftermarket HID head • Before entering a place with a low lamp, your vehicle’s audio and electron- height clearance or a car wash, ic device may malfunction. remove surely the antenna by rotating it counter-clockwise.
Page 600 Features of your vehicle Steering wheel audio controls Type A SEEK/PRESET ( ) (2) ■ (if equipped) The SEEK/PRESET lever has different The steering wheel may incorporate functions based on the system mode. For audio control buttons. the following functions the lever should be pressed for 0.8 seconds or more.
Page 601 Features of your vehicle Type A ✽ ✽ NOTICE MODE ( ) (3) ■ Press the button to change audio source. When using a portable audio device FM(1~2) USB AUX(iPod) connected to the power outlet, noise may ➟ ➟ ➟ FM...
Page 602 Features of your vehicle FM reception AM(MW, LW) reception FM radio station JBM001 JBM002 JBM003 How car audio works AM (MW, LW) broadcasts can be FM broadcasts are transmitted at high received at greater distances than FM frequencies and do not bend to follow the AM (MW, LW) and FM radio signals are broadcasts.
Page 603 Features of your vehicle Using a mobile phone or a two-way radio When a mobile phone is used inside the vehicle, noise may be produced from the audio equipment. This does not mean that something is wrong with the audio equipment.
Page 604 Features of your vehicle Care of discs • Keep CDs in their cases after use to protect them from scratches or dirt. • If the temperature inside the car is too • Depending on the type of CD-R/CD- high, open the car windows for ventila- RW CDs, certain CDs may not operate tion before using your car audio.
Page 605 Features of your vehicle AC9901YGG (GENERAL) ■ ■ ® logo if the Bluetooth ❋There will be no Wireless Technology feature is not supported. TA_H800_GEN_AUDIO 4 113...
Page 606 Features of your vehicle • Press CLOCK Button for 0.8 seconds or SEEK Button longer to adjust clock setting mode and • When the button is pressed, it SEEK Use the TUNE knob to adjust hour & increases the band frequency to auto- minute.
Page 607 Features of your vehicle • BASS Control • BALANCE Control To increase the BASS, rotate the knob Rotate the knob clockwise to emphasize clockwise, whilst to decrease the BASS, right speaker sound(left speaker sound rotate the knob counterclockwise. will be attenuated). TA_H800_GEN_AUDIO When the control knob is turned counter 6.
Page 608 Features of your vehicle (Continued) (Continued) CAUTION IN USING • An encrypted MP3 PLAYER is not • If you disconnect the external USB USB DEVICE recognizable. device during playback in USB • To use an external USB device, mode, the external USB device can •...
Page 609 Features of your vehicle (Continued) (Continued) • If the USB device is divided by • The data in the USB memory may logical drives, only the music files be lost whilst using this audio. on the highest-priority drive are Always back up important data on recognized by car audio.
Page 610 Features of your vehicle • Press the button for less than SEEK 0.8 seconds to move to the next song. Button (FAST FORWARD) Press the button for 0.8 seconds or longer to initiate forward direction high speed sound search of current song. Button (REWIND) TA_H800_GEN_AUDIO TA_H800_GEN_AUDIO...
Page 611 Features of your vehicle TUNE Knob & ENTER Button • Turn this knob clockwise to browse songs after current song, or counter clockwise to browse songs before cur- rent song. To play the displayed song, press the knob. • Pressing this knob without turning enters to AUDIO CONTROL mode.
Page 612 • When the iPod cable is connected, iPod DEVICE the system can be switched to AUX • Some iPod models might not sup- • The Kia iPod Power Cable is mode even without iPod device port the communication protocol needed in order to operate iPod and may cause noise.
Page 613 Features of your vehicle Button (REPEAT) TRACK Button Repeats the song currently played. TRACK • Press the button for less than 0.8 seconds to play from the beginning Button (RANDOM) of the song currently played. • Press this button for less than 0.8 sec- Press the button for less than 0.8 sec- onds to shuffle order of all songs in onds and press it again within 1 sec-...
Page 614 Features of your vehicle TA_H800_GEN_AUDIO TA_H800_GEN_AUDIO Button (MENU) MENU TUNE Knob & ENTER Button When you rotate the knob clockwise, it Moves to the upper category from cur- will display the songs (category) ahead rently played category of the iPod. To move to (play) the category (song) of the song currently played (category in displayed, press...
Page 615 Features of your vehicle CD Player : AM110TAG (GENERAL) ■ ■ ® ❋There will be no logo if the Bluetooth Wireless Technology feature is not supported. TA_GEN_RADIO 4 123...
Page 616 Features of your vehicle POWER VOLUME Button & Knob Turns on/off the set when the IGNITION SWITCH is on ACC or ON. If the button 5. PRESET Buttons is turned to the right, it increases the vol- Push buttons less than ume and left,decreases the volume.
Page 617 Features of your vehicle If no action is taken for 5 seconds after SCAN • Press the button again to stop pressing the button, it will return to the the scan feature and to listen to the play mode. (After entering SETUP mode, currently selected channel.
Page 618 Features of your vehicle • Media (if equipped) • PHONE ® Select default display of MP3 play infor- Select this item to enter Bluetooth Wireless mation. “Folder/File” or “Artist/Title” can Technology setup mode. Refer be selected. ® “ Bluetooth Wireless Technology PHONE OPERATION”...
Page 619 Features of your vehicle MIDDLE Control SEEK • Press button for less than TRACK To increase the MIDDLE, rotate the knob 0.8 seconds to play the next song. clockwise, whilst to decrease the MID- SEEK • Press button for 0.8 seconds TRACK DLE, rotate the knob counterclockwise.
Page 620 Features of your vehicle 5. CD Indicator icon TUNE Knob & ENTER Button When car ignition switch is ACC or ON • Turn this knob clockwise to browse and if the CD is loaded, this indicator songs after current song, or counter- icon is on.
Page 621 Features of your vehicle NOTE: 2. Folder playing order : ❋ If no song file is contained in the Order of playing files (folders) : folder, that folder is not displayed. 1. Song playing order : sequen- tially. 4 129...
Page 622 Features of your vehicle (Continued) (Continued) CAUTION IN USING • An encrypted MP3 PLAYER is not • If you disconnect the external USB USB DEVICE recognizable. device during playback in USB • To use an external USB device, mode, the external USB device can •...
Page 623 Features of your vehicle (Continued) (Continued) • If the USB device is divided by • The data in the USB memory may logical drives, only the music files be lost whilst using this audio. on the highest-priority drive are Always back up important data on recognized by car audio.
Page 624 Features of your vehicle TRACK Button Button (REPEAT) SEEK • Press the button for less • Press this button for less than 0.8 sec- TRACK onds to repeat current song. than 0.8 seconds to play from the • Press this button for 0.8 seconds or longer beginning of the current song.
Page 625 Features of your vehicle FOLDER Button • Press button to move to child FOLDER folder of the current folder and display the first song in the folder. Press knob to move to the fold- TUNE er displayed. It will play the first song in the folder.
Page 626 • When the iPod cable is connected, iPod DEVICE the system can be switched to AUX • Some iPod models might not sup- • The Kia iPod Power Cable is mode even without iPod device port the communication protocol needed in order to operate iPod and may cause noise.
Page 627 Features of your vehicle TRACK Button Button (RANDOM) SEEK • Press this button for less than 0.8 sec- • Press the button for less TRACK onds to shuffle order of all songs in than 0.8 seconds to play from the current category.
Page 628 Features of your vehicle Button (MENU) Moves to the upper category from cur- rently played category of the iPod. To move to (play) the category (song) displayed, press knob. TUNE You will be able to search through the lower category of the selected category. The standard order of iPod’s category is Playlist, Artist, Albums, Genes, Songs, TA_GEN_iPod...
Page 629 Features of your vehicle (continued) CAUTION IN USING • If the mobile phone signal is poor ® Bluetooth Wireless or the vehicles interior noise is Technology MOBILE too loud, it may be difficult to hear PHONE the other person’s voice during a •...
Page 630 ® trademarks owned by Bluetooth Wireless Technology SIG, Inc. and any What ® Bluetooth ■ Wireless use of such marks by Kia is under Technology license. A Bluetooth enabled cell ® Bluetooth Wireless Technology is a wire- ® phone is required to use Bluetooth less technology that allows multiple wireless technology.
Page 631 For example, if the vehicles' name is - If you want to use the deleted phone varies according to each phone Kia PICANTO, you may need to change with the audio system again, pairing model. Before attempting to pair the name displayed on you phone from procedure must be completed once phone, please see your phone’s...
Page 632 Features of your vehicle Receiving a Phone Call Making a Phone Call 2. Select “PHONE”, then “PRIORITY” in ■ ■ PHONE menu. When receiving a phone call, a ringtone A Call Back can be made by pressing 3. Select desired phone name from the is audible from speakers and the audio button on the steering wheel.
Page 633 Features of your vehicle ® NOTE: Using the head unit as Bluetooth ■ music Wireless Technology • Not only MP3 files, all the sounds that the phone supports can be This audio system supports A2DP (Audio heard by the audio system. Advanced Distribution Profile)
Page 634 Features of your vehicle CD Player : AM110TAE(EUROPE) ■ ■ ® ❋There will be no logo if the Bluetooth Wireless Technology feature is not supported. TA_EU_AUDIO...
Page 635 Features of your vehicle Button TA(Traffic announcement) Channels in FM, CD, AUX mode, turns on/off the 6. PRESET Buttons reception of TA channels of RDS. • Press buttons less than 0.8 seconds to play the station Button & Knob saved in each button. •...
Page 636 Features of your vehicle • Moves button when search- FOLDER ing PTY in RDS Broadcasting Program Type selection. DARK Button Turn the LCD Display & Backlight ON/OFF when DARK button press. TA_EU_AUDIO TA_EU_AUDIO SETUP Button SCAN Button Button(AUTO STORE Press this button to enter SETUP mode, Button) If no action is taken for 8 seconds, it will •...
Page 637 Features of your vehicle • MAIN • MEDIA • AF(AF MENU indication is possible with Select this ithem to enter the Scroll and Select default display of MP3 play infor- RDS MENU) SDVC setup. mation. “Folder/File” or “Artist/Title” can Select this item to turn the AF(Alternate be selected.
Page 638 Features of your vehicle • REGION(REGION MENU indication is • Auto • P.BASS (PowerBass) possible with RDS MENU) Select “Auto” button to enter Automatic This function creates virtual sound Selects whether REGION code is used RDS Time menu. effects and allows adjustments to the (ON) or not (OFF) once the radio deter- Bass level.
Page 639 Features of your vehicle • MIDDLE Control To increase the MIDDLE, rotate the knob clockwise, whilst to decrease the MID- DLE, rotate the knob counterclockwise. • TREBLE Control To increase the TREBLE, rotate the knob clockwise, whilst to decrease the TRE- BLE, rotate the knob counterclockwise.
Page 640 Features of your vehicle • FLD RPT (MP3/WMA Only) : Only files SEEK • Press button for 0.8 seconds TRACK in a folder are repeatedly played back. or longer to initiate reverse direction high speed sound search of current song. SEEK •...
Page 641 Features of your vehicle NOTE: knob & ENTER Button Order of playing files (folders) : • Turn this knob clockwise to browse 1. Song playing order : sequen- songs after current song, or counter- tially. clockwise to browse songs before cur- rent song.
Page 642 Features of your vehicle 2. Folder playing order : ❋ If no song file is contained in the folder, that folder is not displayed.
Page 643 Features of your vehicle (Continued) (Continued) CAUTION IN USING • An encrypted MP3 PLAYER is not • If you disconnect the external USB USB DEVICE recognizable. device during playback in USB • To use an external USB device, mode, the external USB device can •...
Page 644 Features of your vehicle (Continued) (Continued) • If the USB device is divided by • Please avoid using USB memory logical drives, only the music files products which can be used as on the highest-priority drive are key chains or mobile phone recognized by car audio.
Page 645 Features of your vehicle TRACK Button Button (RANDOM) SEEK • Press this button for less than 0.8 seconds • Press the button for less TRACK to play songs randomly in current folder. than 0.8 seconds to play from the • Press this button for 0.8 seconds or beginning of the current song.
Page 646 Features of your vehicle FOLDER Button • Press button to move to FOLDER child folder of the current folder and display the first song in the folder. Press knob to move to the fold- er displayed. It will play the first song in the folder.
Page 647 • When the iPod cable is connected, iPod DEVICE the system can be switched to AUX • Some iPod models might not sup- • The Kia iPod Power Cable is mode even without iPod device port the communication protocol needed in order to operate iPod and may cause noise.
Page 648 Features of your vehicle TRACK Button Button (RANDOM) SEEK • Press this button for less than 0.8 sec- • Press the button for less TRACK onds to shuffle order of all songs in than 0.8 seconds to play from the current category.
Page 649 Features of your vehicle Button (MENU) Moves to the upper category from cur- rently played category of the iPod. To move to (play) the category (song) displayed, press knob. You will be able to search through the lower category of the selected category. The standard order of iPod’s category is Playlist, Artist, Albums, Genes, Songs, Composers.
Page 650 Features of your vehicle (continued) CAUTION IN USING • If the mobile phone signal is poor ® BLUETOOTH WIRELESS or the vehicles interior noise is TECHNOLOGY MOBILE too loud, it may be difficult to hear PHONE the other person’s voice during a •...
Page 651 ® trademarks owned by Bluetooth Wireless Technology SIG, Inc. and any General Features ■ use of such marks by Kia is under ® • This audio system supports Bluetooth license. A Bluetooth enabled cell phone hands-free and stereo-headset features. ®...
Page 652 Features of your vehicle Bluetooth ® Voice Recognition Activation Wireless Technology • At any time if you say “help”, the sys- ■ ■ Language Setting tem will announce what commands are • The voice recognition engine contained The system language can be changed by ®...
Page 653 Features of your vehicle Voice Operation Tip <Voice Recognism> 2) Select “PHONE” item by rotating the ■ TUNE knob, then push the knob. To get the best performance out of the Voice Recognition System, observe the followings: - Keep the interior of the vehicle as quiet as possible.
Page 654 ® cle model name] on the Bluetooth that phone again unless the phone is vehicles are Kia PICANTO, some device list. Then attempt pairing on ® phones may not handle Bluetooth deleted manually from the audio sys- your phone tem (refer “Deleting Phone”...
Page 655 Features of your vehicle • Connecting phone • Deleting Phone • Changing Priority The paired phone can be deleted. ® Bluetooth When several phones are paired to the When Wireless audio system, the system attempts to Technology system is enabled, the phone - When the phone is deleted, all the infor- connect following order when the previously used is automatically selected...
Page 656 Features of your vehicle ® ® Phone Book (In-Vehicle) 2. Adjusting Bluetooth Wireless • Turning Bluetooth Wireless ■ Technology ON/OFF Technology language Select “BT • Adding Entry • ® Voice Recognition language” Bluetooth Wireless Technology system Phone numbers and voice tags can be PHONE menu, adjust language to can be enabled (ON) or disabled (OFF) registered.
Page 657 Features of your vehicle ✽ ✽ NOTICE • Adding Entry by Phone • Deleting Name 1. Press button. The registered names can be deleted. - The system can recognize single digits from zero to nine. Numbers that are 2. Say “Phonebook”. 1.
Page 658 Features of your vehicle Receiving a Phone Call Talking on the Phone • Dialing by Number ■ ■ A phone call can be made by dialing the When receiving a phone call, a ringtone When talking on the phone, “Active Call” spoken numbers.
Page 659 Features of your vehicle Bluetooth ® NOTE: Wireless Technology ■ Audio Music Streaming • In addition to streaming MP3 files, ® all music and sound files your The audio system supports Bluetooth mobile phone supports can be Wireless Technology A2DP (Audio played by the audio system.
Page 660 Features of your vehicle Key matrix ■ Class Connected Paired H/P Disconnected Incoming Call Outgoing Call Active Call 2nd Call Empty Normal mode BT SETUP menu 2nd call 2nd Call Not Paired Not Connecting Accept Call 1st Call:waiting 2nd Call:waiting SHORT 2nd Call:active 1st Call:active...
Page 661 Before driving / 5-3 Key positions / 5-4 ENGINE START/STOP button / 5-6 Starting the engine / 5-9 ISG(idle stop and go) system / 5-12 Manual transaxle / 5-16 Automatic transaxle / 5-19 Brake system / 5-25 Economical operation / 5-37 Special driving conditions / 5-39 Winter driving / 5-43 Driving your vehicle...
Page 662 Kia dealer. • Do not run the engine in an enclosed area.
Page 663 Driving your vehicle BEFORE DRIVING Before entering vehicle Before starting WARNING - Driving under • Be sure that all windows, outside mir- • Close and lock all doors. the influence of alcohol or ror(s), and outside lights are clean. • Position the seat so that all controls are drugs •...
Page 664 Driving your vehicle KEY POSITIONS ACC (Accessory) WARNING The steering wheel is unlocked and elec- trical accessories are operative. • When you intend to park or stop the vehicle with the engine on, be careful not to depress the accel- ✽...
Page 665 Driving your vehicle (Continued) WARNING Ignition switch • Do not place any movable objects • Never turn the ignition switch to around the driver’s seat as they LOCK or ACC whilst the vehicle may move whilst driving, inter- is moving. This would result in fere with the driver and lead to an loss of directional control and accident.
Page 666 Try locking the steering wheel again. If the problem is not solved, have it checked by an autho- rised Kia dealer. In addition, if the ENGINE START/STOP button is in the OFF position after the dri-...
Page 667 Driving your vehicle ACC(Accessory) CAUTION You are able to turn off the engine (START/RUN) or vehicle power (ON), only when the vehicle is not in motion. In an emergency situation Orange indicator Green indicator whilst the vehicle is in motion, you are able to turn the engine off and •...
Page 668 Driving your vehicle START/RUN ✽ ✽ NOTICE (Continued) If you leave the ENGINE START/ STOP • Never reach for the ENGINE button in the ACC or ON position for a START/STOP button or any other long time, the battery will discharge. controls through the steering wheel whilst the vehicle is in Not illuminated...
Page 669 Driving your vehicle STARTING THE ENGINE 3. Turn the ignition switch to START and CAUTION WARNING hold it there until the engine starts (a maximum of 10 seconds), then Do not engage the starter for more Always wear appropriate shoes release the key.
Page 670 Driving your vehicle 1. Carry the smart key or leave it inside CAUTION the vehicle. If the engine stalls whilst you are in 2. Make sure the parking brake is firmly motion, do not attempt to move the applied. shift lever to the P (Park) position. If 3.
Page 671 Driving your vehicle (Continued) WARNING • When the stop lamp fuse is blown, you can't start the engine normally. The engine will start by pressing the Replace the fuse with a new one. If it ENGINE START/STOP button, only is not possible, you can start the when the smart key is in the vehicle.
Page 672 Driving your vehicle ISG (IDLE STOP AND GO) SYSTEM (IF EQUIPPED) Your vehicle may be equipped with the ■ Type A ISG system, which reduces fuel con- sumption by automatically shutting down the engine, when the vehicle is at a standstill.
Page 673 Driving your vehicle The engine will also restart automati- cally without the driver’s any actions if the following occurs: - The fan speed of manual climate con- trol system is set above the 3rd position when the air conditioning is on. - The fan speed of automatic climate control system is set above the 6th position when the air conditioning is on.
Page 674 Driving your vehicle Condition of ISG system opera- tion The ISG system will operate under the following condition: - The driver’s seat belt is fastened. - The driver’s door and engine hood are closed. - The brake vaccum pressure is ade- quate.
Page 675 ISG OFF button again or if the ISG system con- tinuously does not work correctly, please contact an authorised Kia deal- er as soon as possible. • When the ISG OFF button light comes on, it may stop illuminating after driv-...
Page 676 Driving your vehicle MANUAL TRANSAXLE (IF EQUIPPED) Make sure the vehicle is completely • During cold weather, shifting may be stopped before shifting into R (Reverse). difficult until the transaxle lubricant is warmed up. This is normal and not Never operate the engine with the harmful to the transaxle.
Page 677 Driving your vehicle Using the clutch Downshifting WARNING The clutch should be pressed all the way When you must slow down in heavy traf- to the floor before shifting, then released fic or whilst driving up steep hills, down- Before leaving the driver’s seat, slowly.
Page 678 Driving your vehicle Good driving practices WARNING • Never take the vehicle out of gear and • Always buckle-up! In a collision, coast down a hill. This is extremely an unbelted occupant is signifi- hazardous. Always leave the vehicle in cantly more likely to be seriously gear.
Page 679 Driving your vehicle AUTOMATIC TRANSAXLE Automatic transaxle operation The automatic transaxle has 4 forward speeds and one reverse speed. The indi- vidual speeds are selected automatically, depending on the position of the shift lever. ✽ ✽ NOTICE The first few shifts on a new vehicle, if the battery has been disconnected, may be somewhat abrupt.
Page 680 Driving your vehicle For smooth operation, depress the brake Transaxle ranges CAUTION pedal when shifting from N (Neutral) to a The indicator in the instrument cluster forward or reverse gear. • To avoid damage your displays the shift lever position when the transaxle, do not accelerate the ignition switch is in the ON position.
Page 681 Driving your vehicle R (Reverse) N (Neutral) 3 (Third gear) Use this position to drive the vehicle The wheels and transaxle are not Use for towing a trailer during hill climb- backward. engaged. The vehicle will roll freely even ing or to use engine braking downhill. on the slightest incline unless the parking "3"...
Page 682 Driving your vehicle Shift lock system (if equipped) 1 (First gear) CAUTION Use for driving up a very steep grade or For your safety, the automatic transaxle • Shift into "R" and "P" position for engine braking when descending has a shift lock system which prevents only when the vehicle has com- steep hills.
Page 683 Driving your vehicle Good driving practices • Always use the parking brake. Do not depend on placing the transaxle in P WARNING • Never move the shift lever from P (Park) to keep the car from moving. • Always buckle-up! In a collision, (Park) or N (Neutral) to any other posi- •...
Page 684 Driving your vehicle Moving up a steep grade from a stand- WARNING ing start To move up a steep grade from a stand- If your vehicle becomes stuck in ing start, depress the brake pedal, shift snow, mud, sand, etc., then you the shift lever to D (Drive).
Page 685 Driving your vehicle BRAKE SYSTEM Power brakes In the event of brake failure (Continued) If service brakes fail to operate whilst the Your vehicle has power-assisted brakes • When descending a long or steep vehicle is in motion, you can make an that adjust automatically through normal hill, shift to a lower gear and emergency stop with the parking brake.
Page 686 Driving your vehicle Disc brakes wear indicator Rear drum brakes (if equipped) Your vehicle has disc brakes. Your rear drum brakes do not have wear indicators. Therefore, have the rear brake When your brake pads are worn and new linings inspected if you hear a rear brake pads are required, you will hear a high- rubbing noise.
Page 687: Parking Brake Lever
(2) whilst holding the button. tent movement of the vehicle which can injure occupants or If the parking brake does not release or pedestrians. does not release all the way, have the system checked by an authorised Kia dealer. 5 27...
Page 688 Driving your vehicle Anti-lock brake system (ABS) (Continued) (if equipped) • On roads where the road surface is pitted or has different surface WARNING height. The safety features of an ABS (or ABS (or ESP) will not prevent acci- ESP) equipped vehicle should not dents due to improper or danger- be tested by high speed driving or ous driving manoeuvres.
Page 689 ABS will go through self-diagnosis and the light will go off if everything is normal. If the light stays on, you may have a problem with your ABS. Contact an authorised Kia dealer as soon as possible. 5 29...
Page 690 Otherwise, you may have a prob- Electronic stability program (ESP) lem with the ABS. Contact an (if equipped) authorised Kia dealer as soon as The Electronic Stability Program (ESP) possible. system is designed to stabilize the vehicle during cornering manoeuvres. ESP checks where you are steering and where the vehicle is actually going.
Page 691 Driving your vehicle ✽ ✽ NOTICE The Electronic Stability Program (ESP) WARNING system is an electronic system designed A click sound may be heard in the to help the driver maintain vehicle control Never drive too fast for the road engine compartment when the vehicle under adverse conditions.
Page 692 Driving your vehicle ESP operation ESP operation off When operating When the ESP is in operation, ESP ON condition ESP OFF state the ESP indicator light blinks. • When the ignition is turned • To cancel ESP operation, • When the Electronic Stability ON, ESP and ESP OFF indi- press the ESP OFF button Program is operating proper-...
Page 693 Driving your vehicle ESP OFF usage ■ ESP indicator light CAUTION When driving Driving with varying tyre or wheel • ESP should be turned on for daily driv- sizes may cause the ESP system to ing whenever possible. malfunction. When replacing tyres, •...
Page 694 Driving your vehicle Hill-start assist control (HAC) Vehicle stability management ✽ ✽ NOTICE (if equipped) (VSM) (if equipped) • The HAC does not operate when the transaxle shift lever is in the P (Park) Hill start Assist Control is a comfort func- This system provides further enhance- or N (Neutral) position.
Page 695 ) or EPS warning light remains The Emergency Stop Signal system including driving inclement on, take your vehicle to an authorised Kia will not work if the hazard warning weather and on a slippery road. dealer and have the system checked. flasher is already on.
Page 696 • Be cautious when parking on a hill. brake as far as possible and fully an authorised Kia dealer for assis- Firmly engage the parking brake and engage the vehicle's transaxle tance.
Page 697 Driving your vehicle ECONOMICAL OPERATION Your vehicle's fuel economy depends • Don't "ride" the brake pedal. This can • Keep your car in good condition. For mainly on your style of driving, where you increase fuel consumption and also better fuel economy and reduced drive and when you drive.
Page 698 Therefore, have an authorised Kia speeds. loss of vehicle steering which dealer perform scheduled inspections could cause serious injury or and maintenance.
Page 699 Driving your vehicle SPECIAL DRIVING CONDITIONS Rocking the vehicle WARNING - If it is necessary to rock the vehicle to Do not pump the brake pedal on a free it from snow, sand, or mud, first turn vehicle equipped with ABS. the steering wheel right and left to clear the area around your front wheels.
Page 700 Driving your vehicle WARNING - Spinning tyres Do not spin the wheels, especially at speeds more than 56 km/h (35 mph). Spinning the wheels at high speeds when the vehicle is station- ary could cause a tyre to overheat which could result in tyre damage that may injure bystanders.
Page 701 Driving your vehicle • Adjust your mirrors to reduce the glare • If your tyres are not in good condition, from other driver's headlights. making a quick stop on wet pavement can cause a skid and possibly lead to • Keep your headlights clean and prop- an accident.
Page 702 Driving your vehicle Driving in flooded areas WARNING Avoid driving through flooded areas • Underinflated or overinflated tyres unless you are sure the water is no high- can cause poor handling, loss of er than the bottom of the wheel hub. vehicle control, and sudden tyre Drive through any water slowly.
Page 703 Driving your vehicle WINTER DRIVING Snowy or icy conditions Snow tyres If you mount snow tyres on your vehicle, To drive your vehicle in deep snow, it may make sure they are radial tyres of the be necessary to use snow tyres or to same size and load range as the original install tyre chains on your tyres.
Page 704 Driving your vehicle Chain installation CAUTION When installing chains, follow the manu- • Make sure the snow chains are facturer's instructions and mount them as the correct size and type for your tightly as you can. Drive slowly with tyres. Incorrect snow chains can chains installed.
Page 705 7. The level of charge in your battery can pension, body and wheels. be checked by an authorised Kia dealer • Stop driving and retighten the or a service station. chains any time you hear them hitting the vehicle.
Page 706 Window washer anti-freeze is Under some conditions, snow and ice available from an authorised Kia dealer can build up under the fenders and inter- and most auto parts outlets. Do not use fere with the steering. When driving in...
Page 707 Ask an Remember that trailering is different than exceeded by not more than 10 % or authorised Kia dealer for further details 100 kg (220.4 lbs), whichever value is just driving your vehicle by itself.
Page 708 Use only a frame-mounted nal position. hitch that does not attach to the bumper. • Kia trailer hitch accessory is available at an authorised Kia dealer.
Page 709 Driving your vehicle Safety chains Trailer brakes Driving with a trailer should always attach chains If your trailer is equipped with a braking Towing a trailer requires a certain between your vehicle and your trailer. system, make sure it conforms to your amount of experience.
Page 710 Always back up slowly Use only an approved trailer wiring har- and, if possible, have someone guide ness. you. An authorised Kia dealer can assist you in installing the wiring harness. Making turns When you’re turning with a trailer, make WARNING wider turns than normal.
Page 711 Driving your vehicle Parking on hills 5. Start the vehicle, hold the brakes, shift CAUTION to neutral, release the parking brake Generally, if you have a trailer attached to and slowly release the brakes until the • When towing a trailer on steep your vehicle, you should not park your trailer chocks absorb the load.
Page 712 Driving your vehicle Maintenance when trailer towing When you are ready to leave after park- CAUTION ing on a hill Your vehicle will need service more often • Due to higher load during trailer 1. With the manual transaxle in Neutral when you regularly pull a trailer.
Page 713 • When towing a trailer, be sure to con- 635 (25) centre to coupling point mm (inch) sult an authorised Kia dealer for further information on additional requirements such as a towing kit, etc. For South Africa • Always drive your vehicle at a moder- Petrol 1.0...
Page 714 Driving your vehicle The trailer tongue should weigh a maxi- mum of 10% of the total loaded trailer weight, within the limits of the maximum trailer tongue load permissible. After you've loaded your trailer, weigh the trail- er and then the tongue, separately, to see if the weights are proper.
Page 715 Driving your vehicle VEHICLE WEIGHT Cargo weight GVWR (Gross vehicle weight rat- This section will guide you in the proper loading of your vehicle, to keep your ing) This figure includes all weight added to loaded vehicle weight within its design the Base Kerb Weight, including cargo This is the maximum allowable weight of rating capability.
Page 716 Road warning / 6-2 In case of an emergency whilst driving / 6-3 If the engine will not start / 6-4 Emergency starting / 6-5 If the engine overheats / 6-7 If you have a flat tyre / 6-8 If you have a flat tyre (with tyreMobilityKit) / 6-16 Towing / 6-21 Emergency commodity / 6-25 What to do in an emergency...
Page 717 What to do in an emergency ROAD WARNING • The hazard warning flasher operates whether your vehicle is running or not. • The turn signals do not work when the hazard flasher is on. • Care must be taken when using the hazard warning flasher whilst the vehi- cle is being towed.
Page 718 Kia dealer or seek other qualified trol. When the car has slowed to such assistance. a speed that it is safe to do so, brake carefully and pull off the road.
Page 719 3. Turn on the interior light. If the light 3. If the engine still does not start, call an dims or goes out when you operate the authorised Kia dealer or seek other starter, the battery is discharged. qualified assistance.
Page 720 What to do in an emergency EMERGENCY STARTING Jump starting WARNING - Battery Jump starting can be dangerous if done • Keep all flames or sparks away incorrectly. Therefore, to avoid harm to from the battery. The battery pro- yourself or damage to your vehicle or duces hydrogen gas which may battery, follow the jump starting proce- explode if exposed to flame or...
Page 721 If the cause of your battery discharging is not apparent, you should have your vehi- of the jump start connector (4). Do not cle checked by an authorised Kia dealer. connect it to or near any part that moves when the engine is cranked.
Page 722 If there is no visible loss of 5. If the water pump drive belt is broken as possible by an authorised Kia engine coolant and no steam, leave or engine coolant is leaking out, stop dealer.
Page 723 What to do in an emergency IF YOU HAVE A FLAT TYRE Jacking instructions (Continued) The jack is provided for emergency • Be sure to use the correct tyre changing only. front and rear jacking posi- To prevent the jack from “rattling” tions on the vehicle;...
Page 724 What to do in an emergency OTA060002 1VQA4022/H OSA067007 Removing and storing the spare Changing tyres 4. Remove the wheel lug nut wrench, tyre jack, jack handle, and spare tyre 1. Park on a level surface and apply from the vehicle. Turn the tyre hold-down wing bolt the parking brake firmly.
Page 725 What to do in an emergency WARNING - Changing a tyre • To prevent vehicle movement whilst changing a tyre, always set the parking brake fully, and always block the wheel diagonally opposite the wheel being changed. • We recommend that wheels of the vehicle be blocked, and that no person...
Page 726 What to do in an emergency If this is difficult, tip the wheel 10. To reinstall the wheel, hold it on slightly and get the top hole in the the studs, put the wheel nuts on wheel lined up with the top stud. the studs and tighten them finger Then jiggle the wheel back and tight.
Page 727 Then double-check each nut for If in doubt, consult an autho- tightness. After changing wheels, rised Kia dealer. have an authorised Kia dealer tight- en the wheel nuts to their proper torque as soon as possible. Wheel nut tightening torque: Steel wheel &...
Page 728 What to do in an emergency Important - use of compact spare WARNING tyre (if equipped) WARNING - Wheel studs Your vehicle is equipped with a com- If the studs are damaged, they The compact spare tyre is for pact spare tyre. This compact spare may lose their ability to retain emergency use only.
Page 729 What to do in an emergency When using a compact spare tyre, • Do not take this vehicle through an • The compact spare tyre should not observe the following precautions: automatic car wash whilst the com- be used on any other wheels, nor pact spare tyre is installed.
Page 730 What to do in an emergency Jack label 1. Model Name 2. Maximum allowable load ■ Example ■ Type A 3. When using the jack, set your parking brake. 4. When using the jack, stop the engine. 5. Do not get under a vehicle that is supported by a jack.
Page 731 What to do in an emergency IF YOU HAVE A FLAT TYRE (WITH TYREMOBILITYKIT, IF EQUIPPED) Air pressure loss in the tyre may adversely affect tyre performance. For this reason, you should avoid abrupt steering or other driving manoeuvres, especially if the vehicle is heavily loaded or if a trailer is in use.
Page 732 What to do in an emergency 7. Pressure gauge for displaying the tyre inflation pressure 8. Button for reducing tyre inflation pressure 9. Hose to connect compressor and sealant bottle or compressor and wheel Connectors, cable and connection hose are stored in the compressor housing.
Page 733 What to do in an emergency Using the TyreMobilityKit 9) Switch off the compressor. 1. Filling the sealant 10) Detach the hoses from the sealant bottle connector and Strictly follow the specified sequence, from the tyre valve. otherwise the sealant may escape under high pressure.
Page 734 (0.16 in). speed and drive with caution until you can safely pull off of - To increase the inflation pres- Please contact the nearest Kia the side of the road. sure: Switch on the compressor, A/S centre, or a workshop that position I.
Page 735 What to do in an emergency Notes on the safe use of the Technical Data • Never leave the TyreMobilityKit TyreMobilityKit unattended whilst it is being used. System voltage: DC 12 V Working voltage: DC 10 - 15 V • Park your car at the side of the •...
Page 736 • Do not tow the vehicle with the recommend having it done by an autho- front wheels on the ground as rised Kia dealer or a commercial tow- this may cause damage to the truck service. Proper lifting and towing vehicle.
Page 737 OTA060012 secured. Emergency towing 4. Remove the towing hook and install If towing is necessary, we recommend the cover after use. you to have it done by an authorised Kia dealer or a commercial tow truck service.
Page 738 • If the disabled vehicle is unable to be moved, do not forcibly con- tinue the towing. Contact an authorised Kia dealer or a com- mercial tow truck service for assistance. • Tow the vehicle as straight ahead as possible.
Page 739 What to do in an emergency Emergency towing precautions CAUTION - Automatic • Place the ignition switch in ACC so the transaxle steering wheel isn’t locked. • If the car is being towed with all • Place the transaxle shift lever in N four wheels on the ground, it can (Neutral).
Page 740 What to do in an emergency EMERGENCY COMMODITY (IF EQUIPPED) First aid kit There are some emergency commodities To check the tyre pressure, take the fol- in the vehicle to help you respond to the lowing steps; There are some items such as scissors, emergency situation.
Page 741: Air Cleaner
Engine compartment / 7-2 Maintenance services / 7-3 Owner maintenance / 7-4 Scheduled maintenance service / 7-6 Explanation of scheduled maintenance items / 7-18 Engine oil / 7-21 Engine coolant / 7-23 Brake fluid / 7-26 Automatic transaxle fluid / 7-27 Washer fluid / 7-29 Parking brake / 7-29 Air cleaner / 7-30...
Page 742: Engine Oil Dipstick
Maintenance ENGINE COMPARTMENT 1.0 Petrol ■ ■ 1. Engine coolant reservoir 2. Radiator cap 3. Brake fluid reservoir 4. Air cleaner 5. Engine oil dipstick 6. Engine oil filler cap 7. Windscreen washer fluid reservoir 8. Fuse box 9. Positive battery terminal 1.25 Petrol ■...
Page 743 We recommend you have your vehicle maintained and repaired by an autho- rised Kia dealer. An authorised Kia deal- er meets Kia’s high service quality stan- dards and receives technical support from Kia in order to provide you with a high level of service satisfaction.
Page 744 WARNING inspections that should be performed by - Maintenance When you stop for fuel: the owner or an authorised Kia dealer at work • Check the engine oil level. the frequencies indicated to help ensure • Performing maintenance work on •...
Page 745 Maintenance While operating your vehicle: At least monthly: At least once a year: • Note any changes in the sound of the • Check coolant level in the engine • Clean body and door drain holes. exhaust or any smell of exhaust fumes coolant reservoir.
Page 746 Maintenance SCHEDULED MAINTENANCE SERVICE If your vehicle is operated under the Follow Normal Maintenance Schedule if the vehicle is usually operated where above conditions, you should inspect, none of the following conditions apply. If replace or refill more frequently than the any of the following conditions apply, fol- following Normal Maintenance Schedule.
Page 747 If drive belt noise occurred, readjust drive belt tension before result in serious malfunction or engine damage. replace. : Kia recommends that you use good quality petrols meet : Check the engine oil level and leak every 500 km (350 Europe Fuel standards (EN228) or equivalents.
Page 748 Maintenance NORMAL MAINTENANCE SCHEDULE (CONT.) 15,000 km (10,000 miles) or 12months (Continued) ❑ Inspect air cleaner filter - Except China, India, Middle East ❑ Replace engine oil and filter - For Middle East, Brazil * (Every 10,000 km (6,500 miles) or 12months* ❑...
Page 749 Maintenance NORMAL MAINTENANCE SCHEDULE (CONT.) 30,000 km (20,000 miles) or 24months (Continued) ❑ Replace engine oil and filter - Except Middle East, Brazil * ❑ Inspect air cleaner filter - Except China, India, Middle East ❑ Inspect air conditioner refrigerant/compressor (if equipped) ❑...
Page 750 Maintenance NORMAL MAINTENANCE SCHEDULE (CONT.) 45,000 km (30,000 miles) or 36months (Continued) ❑ Inspect air conditioner refrigerant/compressor (if equipped) ❑ Replace engine oil and filter - For Middle East, Brazil * (Every 10,000 km (6,500 miles) or 12months* ❑ Inspect battery condition ❑...
Page 751 Maintenance NORMAL MAINTENANCE SCHEDULE (CONT.) 60,000 km (40,000 miles) or 48months (Continued) ❑ Replace air cleaner filter - For China, India, Middle East ❑ Inspect air cleaner filter - Except China, India, Middle East ❑ Replace climate control air filter (if equipped) ❑...
Page 752 Maintenance NORMAL MAINTENANCE SCHEDULE (CONT.) (Continued) 75,000 km (50,000 miles) or 60months ❑ Replace engine oil and filter - For Middle East, Brazil * ❑ Inspect air cleaner filter - Except China, India, Middle East (Every 10,000 km (6,500 miles) or 12months * ❑...
Page 753 Maintenance NORMAL MAINTENANCE SCHEDULE (CONT.) 90,000 km (60,000 miles) or 72months (Continued) ❑ Replace air cleaner filter ❑ Inspect air conditioner refrigerant/compressor (if equipped) ❑ Replace climate control air filter (if equipped) ❑ Inspect battery condition ❑ Replace engine oil and filter - Except Middle East, Brazil * ❑...
Page 754 Maintenance NORMAL MAINTENANCE SCHEDULE (CONT.) 105,000 km (70,000 miles) or 84months (Continued) ❑ Replace engine oil and filter - Except Middle East, Brazil * ❑ Inspect air cleaner filter - Except China, India, Middle East ❑ Inspect air conditioner refrigerant/compressor (if equipped) ❑...
Page 755 Maintenance NORMAL MAINTENANCE SCHEDULE (CONT.) 120,000 km (80,000 miles) or 96months (Continued) ❑ Replace air cleaner filter - For China, India, Middle East ❑ Inspect air cleaner filter - Except China, India, Middle East ❑ Replace climate control air filter (if equipped) ❑...
Page 756 Maintenance MAINTENANCE UNDER SEVERE USAGE CONDITIONS The following items must be serviced more frequently on cars mainly used under severe driving conditions. Refer to the chart below for the appropriate maintenance intervals. R : Replace I : Inspect and if necessary, adjust, correct, clean or replace Maintenance Maintenance item Maintenance intervals...
Page 757 Maintenance Maintenance Maintenance item Maintenance intervals Driving condition operation Inspect more frequently Disc brakes and pads, calipers and rotors C, D, E, G, H depending on the condition Inspect more frequently Parking brake C, D, G, H depending on the condition Inspect more frequently B, C, D, E, F, Driveshaft and boots...
Page 758 Air cleaner filter After installing a new filter, run the engine Inspect all drive belts for evidence of A Genuine Kia air cleaner filter is recom- for several minutes, and check for leaks cuts, cracks, excessive wear or oil satu- mended when the filter is replaced.
Page 759 (if equipped) engine vibration and adjust if necessary. ning and the transaxle in neutral, with the An authorised Kia dealer should perform Inspect the manual transaxle fluid parking brake properly applied. the operation.
Page 760 For more information on checking the pads or lining wear limit, we recommend Brake fluid Air conditioning refrigerant to refer to the Kia web site. (if equipped) Check brake fluid level in the brake fluid (http://brakemanual.kia.co.kr) reservoir. The level should be between Check the air conditioning lines and con- “MIN”...
Page 761 Maintenance ENGINE OIL WARNING - Radiator hose Be very careful not to touch the radiator hose when checking or adding the engine oil as it may be hot enough to burn you. 5. Pull the dipstick out again and check the level.
Page 762 Maintenance Changing the engine oil and filter Have engine oil and filter changed by an authorised Kia dealer according to the Maintenance Schedule at the beginning of this section. WARNING Used engine oil may cause irrita- tion or cancer of the skin if left in contact with the skin for prolonged periods of time.
Page 763 Maintenance ENGINE COOLANT Checking the coolant level The high-pressure cooling system has a (Continued) reservoir filled with year-round antifreeze • Even if the engine is not operat- coolant. The reservoir is filled at the fac- WARNING ing, do not remove the radiator tory.
Page 764 (deionized) or soft water to pro- vide protection against freezing and cor- rosion. Bring the level to F (Full) , but do not overfill. If frequent additions are required, see an authorised Kia dealer for a cooling system inspection.
Page 765 Type A ■ WARNING Have coolant changed by an authorised Radiator cap Kia dealer according to the Maintenance Schedule at the beginning of this section. CAUTION Put a thick cloth around the radiator Do not remove the radiator cap cap before refilling the coolant in...
Page 766 (Maximum) level. The level will fall with accumulated mileage. This is a normal condition associated with the wear of the brake linings. If the fluid level is exces- sively low, have the brake system checked by an authorised Kia dealer.
Page 767 Maintenance AUTOMATIC TRANSAXLE FLUID (IF EQUIPPED) 2. After the transaxle is warmed up suffi- ciently [fluid temperature 70~80°C (158~176°F)], for example by 10 min- utes usual driving, move the shift lever through all positions then place the shift lever in N(Neutral) or P(Park) position.
Page 768 Have the automatic transaxle fluid etc., are very hot. Exercise great changed by an authorised Kia dealer ✽ ✽ NOTICE care not to burn yourself during according to the Maintenance Schedule this procedure.
Page 769 Kia dealer. Stroke : 6~8 “clicks’’ at a force of 20 kg (44 lbs, 196 N). 7 29...
Page 770 Maintenance AIR CLEANER OTA070013L OTA070010L OTA070011L Filter replacement 1. Loosen the air cleaner cover attaching clips and open the cover. It must be replaced when necessary, and should not be washed. You can clean the filter when inspecting the air cleaner element. Clean the filter by using compressed air.
Page 771 “Maintenance under severe usage condi- ter, be careful that dust or dirt tions” in this section.) does not enter the air intake, or damage may result. • Use a Kia genuine part. Use of non-genuine parts could damage the air flow sensor. 7 31...
Page 772 Maintenance CLIMATE CONTROL AIR FILTER Filter inspection The climate control air filter should be replaced according to the maintenance schedule. If the vehicle is operated in the severely air-polluted cities or on dusty rough roads for a long period, it should be inspected more frequently and replaced earlier.
Page 773 Maintenance OTA070016 3. Replace the climate control air filter. 4. Reassemble in the reverse order of disassembly. ✽ ✽ NOTICE When replacing the climate control air filter install it properly. Otherwise, the system may produce noise and the effec- tiveness of the filter may be reduced. 7 33...
Page 774 Maintenance WIPER BLADES Blade replacement Contamination of either the windscreen or the wiper blades with foreign matter When the wipers no longer clean ade- can reduce the effectiveness of the wind- quately, the blades may be worn or screen wipers. Common sources of con- cracked, and require replacement.
Page 775 Maintenance 1JBA7037/H 1LDA5023/H OHM078062 Front windscreen wiper blade Rear window wiper blade 1. Raise the wiper arm and turn the wiper 1. Raise the wiper arm and pull out the blade assembly to expose the plastic wiper blade assembly. locking clip. CAUTION Do not allow the wiper arm to fall against the windscreen, since it...
Page 776 We recommend that you the wiper arm until it clicks into place. • Keep the battery top clean and dry. contact an authorized Kia dealer. 3. Make sure the blade assembly is • Keep the terminals and connections installed firmly by trying to pull it slightly.
Page 777 (Continued) health. Dispose the battery according to your local law(s) or regulation. The battery contains lead. Do not dispose of it after use. Please return the bat- tery to an authorised Kia dealer to be recycled. (Continued) 7 37...
Page 778 Battery capacity label Separating the battery from the (see the example) vehicle should be done in an autho- 1. CMF65L-BCI : The Kia model name of rised Kia dealer. battery 2. 12V : The nominal voltage 3. 60Ah(20HR) : The nominal capacity (in Ampere hours) 4.
Page 779 • Disconnect the battery charger in • For your safety, use the authentic- the following order. ity by approved authorised Kia dealer, when you replace the bat- 1. Turn off the battery charger main tery. switch.
Page 780 If a tyre frequently needs refilling, Recommended cold tyre inflation have it checked by an autho- pressures rised Kia dealer. All tyre pressures (including the • Overinflation produces OTA080002/H spare) should be checked when the...
Page 781 Maintenance Checking tyre inflation pressure CAUTION CAUTION - Tyre pressure Check your tyres once a month or • Warm tyres normally exceed Always observe the following: more. recommended cold tyre pres- • Check tyre pressure when the Also, check the tyre pressure of the sures by 28 to 41 kPa (4 to 6 tyres are cold.
Page 782 Refer to “Tyre and wheels” in section • Remember to check the pres- sure of your spare tyre. Kia recommends that you check the spare every time you check the pressure of the...
Page 783 Maintenance Disc brake pads should be inspected Wheel alignment and tyre balance With a full-size spare tyre (if equipped) for wear whenever tyres are rotated. The wheels on your vehicle were aligned and balanced carefully at the factory to give you the longest tyre ✽...
Page 784 • Replace tyres that are worn, • Wheels that do not meet Kia’s show uneven wear, or are specifications may fit poorly damaged. Worn tyres can and result in damage to the...
Page 785 Maintenance Compact spare tyre replacement Wheel replacement Tyre traction (if equipped) When replacing the metal wheels for Tyre traction can be reduced if you A compact spare tyre has a shorter any reason, make sure the new drive on worn tyres, tyres that are tread life than a regular size tyre.
Page 786 Maintenance 2. tyre size designation Wheel size designation Wheels are also marked with impor- A tyre’s sidewall is marked with a tyre tant information that you need if you size designation. You will need this ever have to replace one. The follow- information when selecting replace- ing explains what the letters and ment tyres for your car.
Page 787 Maintenance DOT : XXXX XXXX OOOO 4. Tyre ply composition and material Speed The number of layers or plies of rub- The front part of the DOT means a Rating Maximum Speed ber-coated fabric in the tyre. Tyre plant code number, tyre size and Symbol manufacturers also must indicate the tread pattern and the last four num-...
Page 788 Maintenance 6. Maximum load rating Tread wear Traction - AA, A, B & C The traction grades, from highest to This number indicates the maximum The tread wear grade is a compara- lowest, are AA, A, B and C. Those load in kilograms and pounds that can tive rating based on the wear rate of grades represent the tyre’s ability to...
Page 789 50, are provided tyre condition or contact an heat and its ability to dissipate heat for sporty looks. authorised Kia dealer. when tested under controlled condi- Because the low aspect ratio tyres - To prevent damage to the tyre,...
Page 790 Avoid using because it may cause a short circuit the system involved and immediately and damage the system. consult an authorised Kia dealer. Four kinds of fuses are used: blade type ✽ ✽ NOTICE for lower amperage rating, cartridge type,...
Page 791 4. Check the removed fuse; replace it if it is blown. 5. Push in a new fuse of the same rating, and make sure it fits tightly in the clips. If it fits loosely, consult an authorised Kia dealer. 7 51...
Page 792 Maintenance If you do not have a spare, use a fuse of ✽ ✽ NOTICE the same rating from a circuit you may • If the memory fuse is pulled up from not need for operating the vehicle, such the fuse panel, the warning chime, as the cigarette lighter fuse.
Page 793 If not, Multi fuse electrical failures may occur from If the multi fuse is blown, consult an water contact. authorised Kia dealer. OTA070040R Engine compartment fuse replacement 1. Turn the ignition switch and all other switches off.
Page 794 Maintenance Fuse/relay panel description Inside the fuse/relay panel covers, you can find the fuse/relay label describing fuse/relay name and capacity. Instrument panel fuse panel Engine compartment fuse panel ✽ ✽ NOTICE Not all fuse panel descriptions in this manual may be applicable to your vehi- cle.
Page 795 Maintenance Instrument panel (Driver’s side fuse panel) Fuse Name Symbol Fuse rating Protected Component Luggage Lamp, A/C Control Module, BCM/TACM, Auto Light & Photo Sensor, Cup Holder ROOM1 ILL., Instrument Cluster, Ignition Key ILL. & Door Warning Switch, Driver Vanity Lamp, Overhead Console Lamp (With Sunroof), Room Lamp(W/O Sunroof) AUDIO Audio (W/O ISG), Low DC-DC Convertor (With ISG)
Page 796 Maintenance Fuse Name Symbol Fuse rating Protected Component H/LP RH Instrument Cluster, Head Lamp RH HAZARD Hazard Relay, Flasher Unit, Hazard Switch PDM1 Smart Key Control Module S/ROOF Sunroof Motor PDM3 Smart Key Control Module, Immobiliser Module, Start/Stop Button Switch Pulse Generator 'A'/'B', Vehicle Speed Sensor, Transaxle Range Switch IGN COIL Ignition Coil, Condenser...
Page 797 Maintenance Fuse Name Symbol Fuse rating Protected Component Stop Lamp Switch, Alternator(G3LA/G4LA), Rear Parking Assist Sensor RH/LH, Rear IGN1 Parking Assist Sensor (Centre) RH/LH, Seat Heater Switch, Driver/Passenger Seat Heater, Crash Pad Switch , Low DC-DC Convertor, Electro Chromic Mirror Yaw Rate Sensor, Check Connector, ESP Control Module ABS Control Module, PCB Fuse &...
Page 798 Maintenance Engine compartment main fuse panel Symbol Fuse rating Protected Component EPS Control Module MULTI FUSE 125A Alternator, PCB Fuse & Relay Box I/P Junction Box (Power Connector Fuse : F1 10A / F2 20A, Fuse : F24 10A / F25 10A / F26 10A / F27 15A, Tail Lamp Relay) Projection Type : E/R Sub Fuse Box (Fuse : F1 10A / F2 20A / F4 15A / F5 10A / F7 10A ) I/P Junction Box (Fuse : F8 20A / F9 25A / F10 15A / F16 15A / F17 25A / F18 15A / F19 10A...
Page 799 Maintenance Symbol Fuse rating Protected Component PCB Fuse & Relay Box (Fuel Pump #1 Relay) PCB Fuse & Relay Box (Head Lamp (HI) Relay) PCB Fuse & Relay Box (Head Lamp (LO) Relay) PCB Fuse & Relay Box (Horn Relay, Burglar Alarm Horn Relay) PCB Fuse &...
Page 800 Maintenance Engine compartment fuse panel (Projection head lamp type only) Symbol Fuse rating Protected Component PCB Fuse & Relay Box (A/C Relay) PCB Fuse & Relay Box (Head Lamp (LO) Relay) PCB Fuse & Relay Box (Fuel Pump #1 Relay) PCB Fuse &...
Page 801 Prior to working on the light, firmly consult an authorised Kia dealer. In apply the parking brake, ensure many cases, it is difficult to replace that the ignition switch is turned to...
Page 802 Maintenance Type B ■ (Continued) • If a bulb becomes damaged or cracked, replace it immediately and carefully dispose of it. • Wear eye protection when chang- ing a bulb. Allow the bulb to cool down before handling it. OTA070042 OHD076046 Type B WARNING...
Page 803 Maintenance ✽ ✽ NOTICE If the headlight aiming adjustment is nec- essary after the headlight assembly is rein- stalled, consult an authorised Kia dealer. ❋ ❋ Traffic Change (For Europe) The low beam light distribution is asym- metric. If you go abroad to a country with oppo- site traffic direction, this asymmetric part will dazzle oncoming car driver.
Page 804 Maintenance Position light + DRL (LED type) or Position light (LED type) (if equipped) If the light bulb does not operate, have the vehicle checked by an authorised Kia dealer. OTA070045L OTA070029 Front fog light or DRL or Front fog...
Page 805 Maintenance Stop and tail light (LED type) (if equipped) If the light (LED) does not operate, have the vehicle checked by an authorised Kia dealer. OTA070028 OTA070030 Type B Rear combination light bulb replacement 1. Remove the light assembly from the...
Page 806 Maintenance OTA070031 OTA070032 OTA070046L Rear turn signal light/Stop and tail light 3. Remove the socket from the assembly Back-up light/Rear fog light by turning the socket counterclockwise (if equipped) 1. Open the tail gate. until the tabs on the socket align with 1.
Page 807 Maintenance LED type ■ If the light (LED) does not operate, have the vehicle checked by an authorised Kia dealer. OTA070034 OTA070033 High mounted stop light License plate light bulb replace- replacement (if equipped) ment Bulb type 1. Remove the lens by pressing the tabs.
Page 808 Maintenance Interior light bulb replacement Map lamp 1. Using a flat-blade screwdriver, gently pry the lens from the interior light housing. 2. Remove the bulb by pulling it straight out. WARNING Prior to working on the Interior Lights, ensure that the “OFF” but- ton is depressed to avoid burning your fingers or receiving an electric shock.
Page 809 Maintenance APPEARANCE CARE Exterior care Finish maintenance CAUTION Washing Exterior general caution • Do not use strong soap, chemical To help protect your vehicle’s finish from It is very important to follow the label detergents or hot water, and do rust and deterioration, wash it thoroughly directions when using any chemical not wash the vehicle in direct...
Page 810 Maintenance Finish damage repair Waxing Wax the vehicle when water will no Deep scratches or stone chips in the longer bead on the paint. painted surface must be repaired promptly. Exposed metal will quickly rust Always wash and dry the vehicle before and may develop into a major repair waxing.
Page 811 Maintenance Bright-metal maintenance Underbody maintenance WARNING • To remove road tar and insects, use a Corrosive materials used for ice and tar remover, not a scraper or other snow removal and dust control may col- After washing the vehicle, test the sharp object.
Page 812 Maintenance Aluminum or chrome wheel mainte- Corrosion protection High-corrosion areas nance If you live in an area where your car is Protecting your vehicle from corrosion regularly exposed to corrosive materials, The aluminum or chrome wheels are By using the most advanced design and coated with a clear protective finish.
Page 813 Maintenance To help prevent corrosion • When cleaning lower door panels, Keep paint and trim in good condition rocker panels and frame members, be You can help prevent corrosion from get- Scratches or chips in the finish should be sure that drain holes are kept open so ting started by observing the following: covered with "touch-up"...
Page 814 Maintenance Interior care Cleaning the upholstery and interior Cleaning the lap/shoulder belt web- trim bing Interior general precautions Vinyl Clean the belt webbing with any mild Prevent chemicals such as perfume, cos- soap solution recommended for cleaning Remove dust and loose dirt from vinyl metic oil, sun cream, hand cleaner and upholstery or carpet.
Page 815 Kia dealer in accordance with the mainte- nance schedule in this manual. 7 75...
Page 816 Maintenance Canister 3. Exhaust emission control Engine exhaust gas precautions (car- bon monoxide) system Fuel vapors generated inside the fuel tank are absorbed and stored in the • Carbon monoxide can be present with The Exhaust Emission Control System is onboard canister.
Page 817 All inspections and adjustments or do not coat the vehicle for cor- must be made by an authorised Kia rosion control. It may present a dealer. fire risk under certain conditions.
Page 818 Engine / 8-2 Dimensions / 8-2 Bulb wattage / 8-2 Tyres and wheels / 8-3 Weight/Volume / 8-3 Recommended lubricants and capacities / 8-4 Vehicle identification number (VIN) / 8-6 Vehicle certification label / 8-6 Tyre specification and pressure label / 8-7 Engine number / 8-7 Declaration of conformity / 8-7 Specifications &...
Page 819 Specifications & Consumer information ENGINE BULB WATTAGE Item Petrol 1.0 Petrol 1.25 Light Bulb Wattage Bulb type Headlights (Low/High) 55/60 H4 L/L Displacement [cc(cu.in)] 998 (60.9) 1,248 (76.2) Headlights (Low/High)* H7 L/L 71 x 84 71 x 78.8 Bore x Stroke [mm(in)] Front turn signal lights* PY21W (2.80 x 3.31)
Page 820 Specifications & Consumer information TYRES AND WHEELS Inflation pressure / bar(psi,kPa) Wheel lug nut torque / Item Tyre size Wheel size Normal load Maximum load kg.m(lb.ft, N.m) Front Rear Front Rear 155/70 R13 4.0B×13 Full size tyre 165/60 R14 5.0J×14 (33, 230) (31, 210) (36, 250)
Page 821 Specifications & Consumer information RECOMMENDED LUBRICANTS AND CAPACITIES To help achieve proper engine and powertrain performance and durability, use only lubricants of the proper quality. The correct lubricants also help promote engine efficiency that results in improved fuel economy. These lubricants and fluids are recommended for use in your vehicle. Lubricant Volume Classification...
Page 822 Specifications & Consumer information Recommended SAE viscosity Engine oil viscosity (thickness) has an When choosing an oil, consider the range effect on fuel economy and cold weather number of temperature your vehicle will be oper- operating (engine start and engine oil ated in before the next oil change.
Page 823 Specifications & Consumer information VEHICLE IDENTIFICATION NUMBER (VIN) VEHICLE CERTIFICATION LABEL Frame number VIN label (if equipped) ■ ■ ■ ■ OBH088005N OTA080001 OTA080002 The vehicle identification number (VIN) is ■ ■ ■ ■ The vehicle certification label attached the number used in registering your car on the driver’s (or front passenger’s) side and in all legal matters pertaining to its centre pillar gives the vehicle identifica-...
Page 824 Further information including the manu- ommended for your car. facturer's declaration of conformity is available on Kia web site as follows; http://www.kia-hotline.com OTA080004L The engine number is stamped on the engine block as shown in the drawing.
Page 825 Index...
Page 826 Index Air bags................3-39 Base kerb weight ............5-55 Air bag warning label ..........3-61 Battery................7-36 Air bag warning light ..........3-42 Battery saver function............4-67 Curtain air bag............3-52 Before driving ..............5-3 Driver's and passenger's front air bag ......3-46 Bonnet................4-25 Side air bag ..............3-51 Bottle holders, see cup holders........4-102 Air cleaner ..............7-30 Brake system..............5-25 Antenna................4-107...
Page 827 Index Cargo weight ..............5-55 Central door lock switch ..........4-16 Changing tyres ..............6-9 Dashboard, see instrument cluster ........4-41 Chains Daytime running light ............4-67 Tyre chains ..............5-44 Declaration of conformity ..........8-7 Checking tyre inflation pressure ........7-41 Defogging (Windscreen) ..........4-97 Child restraint system ............3-28 Defogging logic (Windscreen)........4-99 Lap belt..............3-31 Defroster (Rear window) ..........4-80...
Page 828 Index Economical operation ............5-37 Flat tyre ................6-8 Electric power steering ..........4-34 Changing tyres ............6-9 Electronic stability program (ESP) ........5-30 Jack and tools ..............6-8 Emergency starting ............6-5 Removing and storing the spare tyre ......6-9 Jump starting ..............6-5 Fluid Push starting ..............6-6 Automatic transaxle fluid..........7-27 Emergency stop signal (ESS) ........5-35 Washer fluid ..............7-29...
Page 829 Index Trip computer ............4-43 Warning and indicators ..........4-47 Instrument panel overview..........2-3 Hazard warning flasher ..........4-66 Interior care ..............7-74 Hazardous driving conditions ........5-39 Interior features ............4-101 Headlight escort function..........4-67 Ashtray ..............4-101 Headlight levelling device ..........4-73 Cigarette lighter ............4-101 Headlight welcome function ..........4-67 Clothes hanger ............4-105 Headrest ..............3-5, 3-9 Cup holder ..............4-102...
Page 830 Index Manual climate control system ........4-81 Air conditioning ............4-86 Climate control air filter..........4-88 Label Heating and air conditioning ........4-82 Air bag warning label..........3-61 Manual heating and air conditioning ......4-92 Tyre sidewall labeling ..........7-46 Manual transaxle ............5-16 Tyre specification and pressure label ......8-7 Memory fuse ..............7-52 Vehicle certification label..........8-6 Mirrors ................4-37...
Page 831 Index Parking brake inspect............7-29 Scheduled maintenance service ........7-6 Parking brake ..............5-26 Maintenance under severe usage conditions ....7-16 Passenger's front air bag ..........3-46 Normal maintenance schedule ........7-7 Power brakes ..............5-25 Seat belts ................3-15 Power outlet ..............4-104 Pre-tensioner seat belt ..........3-22 Power steering (Electric) ..........4-34 Lap belt..............3-20 Power window lock button ..........4-23 Lap/shoulder belt ............3-18...
Page 832 Index Special driving conditions ..........5-39 Driving at night ............5-40 Driving in flooded areas..........5-42 Tachometer..............4-42 Driving in the rain ............5-41 Tailgate................4-18 Hazardous driving conditions ........5-39 Tilt steering ..............4-34 Highway driving............5-42 Towing ................6-21 Rocking the vehicle ..........5-39 Emergency towing ............6-22 Smooth cornering ............5-40 Transaxle Speedometer..............4-42 Automatic transaxle ..........5-19...
Page 833 Index Wheel alignment and tyre balance........7-43 Wheel replacement ............7-45 Windows ................4-20 Vanity mirror lamp............4-103 Auto down window ..........4-21 Vehicle break-in process ..........1-4 Auto up/down window ..........4-22 Vehicle certification label ..........8-6 Power window lock button........4-23 Vehicle identification number (VIN) ........8-6 Windscreen defrosting and defogging ......4-97 Vehicle stability management (VSM) ......5-34 Defogging logic ............4-99 Vehicle weight ..............5-55...
Page 834 Keys / 4-3 Remote keyless entry / 4-6 Smart key / 4-9 Theft-alarm system / 4-12 Door locks / 4-15 Tailgate / 4-19 Windows / 4-21 Hood / 4-26 Features of your vehicle Fuel filler lid / 4-28 Sunroof / 4-31 Steering wheel / 4-35 Mirrors / 4-38 Instrument cluster / 4-42...
Page 835 Storage compartments / 4-101 Interior features / 4-103 Audio system / 4-109 Features of your vehicle...
Page 836 Should you lose your keys, we recom- mend that you contact an authorized Kia dealer. Remove the key code tag and store it in a safe place. Also, record the key number and keep it in a safe and handy place, but not in the vehicle.
Page 837 WARNING With the immobilizer system, whenever you insert your ignition key into the igni- Use only Kia original parts for the tion switch and turn it to ON, it checks ignition key in your vehicle. If an and determines and verifies if the ignition aftermarket key is used, the ignition key is valid or not.
Page 838 We recommend engine from being started. that the system be serviced by an To deactivate the immobilizer sys- authorized Kia dealer. tem: Malfunctions caused by improper Insert the ignition key into the key cylin- ✽ ✽ NOTICE alterations, adjustments or modifi- der and turn it to the ON position.
Page 839 Features of your vehicle REMOTE KEYLESS ENTRY (IF EQUIPPED) Lock (1) Tailgate unlock (3) (if equipped) Type A ■ All doors (and tailgate) are locked if the The tailgate is unlocked if the button is lock button is pressed while all doors are pressed for more than 1 second.
Page 840 If you have a problem with OYDECO2006CN the transmitter, we recommend that you Type C ■ contact an authorized Kia dealer. CAUTION Keep the transmitter away from water or any liquid. If the keyless entry system is inoperative due to...
Page 841 Be sure to use For transmitter replacement, we recom- the correct battery. mend that you contact an authorized Kia dealer. • To avoid damaging the transmit- ter or smart key, don't drop it, get...
Page 842 Features of your vehicle SMART KEY (IF EQUIPPED) Type A ■ WARNING If the battery of accessory smart key is totally discharged, it is impossible to enter the vehicle. In this case, you can enter the vehicle with a mechan- ical key.
Page 843 Features of your vehicle Unlocking Tailgate unlocking Even though you press the outside door handle buttons, the doors will not lock Pressing the button of the front outside If you are within 0.7 m ~ 1 m (28 ~ 40 in.) and the chime will sound for 3 seconds if door handles with all doors (and tailgate) from the outside tailgate handle, with...
Page 844 Avoid placing you contact an authorized Kia dealer. the transmitter (or smart key) and • The smart key will not work if any of your cell phone or smart phone in the...
Page 845 Features of your vehicle THEFT-ALARM SYSTEM (IF EQUIPPED) Armed stage Using the smart key Park the vehicle and stop the engine. Armed Arm the system as described below. stage 1. Turn off the engine. 2. Make sure that all doors (and tailgate) and the engine hood are closed and latched.
Page 846 Features of your vehicle Using the transmitter Theft-alarm stage • Lock the doors by pressing the lock button on the smart key. Park the vehicle and stop the engine. The alarm will be activated if any of the After completion of the steps above, Arm the system as described below.
Page 847 • If you lose your keys, we recommend - The engine is started. that you consult an authorized Kia dealer. After the doors are unlocked, the hazard warning lights will blink twice to indicate ✽...
Page 848 Features of your vehicle DOOR LOCKS Transmitter/Smart key ✽ ✽ NOTICE • Doors can be locked and unlocked with • In cold and wet climates, door locks the transmitter (or smart key). (if and door mechanisms may not work equipped) properly due to freezing conditions.
Page 849 Features of your vehicle • If the inner door handle of the front doors is pulled when the door lock but- ton is in lock position, the button is unlocked and door opens. (if equipped) • Front door cannot be locked if the igni- tion key is in the ignition switch and the door is open.
Page 850 Features of your vehicle Driver’s door WARNING - WARNING Doors Unlocked vehicles • The doors should always be fully closed and locked while the vehi- Leaving your vehicle unlocked can cle is in motion to prevent acci- invite theft or possible harm to you dental opening of the door.
Page 851 Features of your vehicle Impact sensing door unlock sys- 3. Close the rear door. tem (if equipped) To open the rear door, pull the outside door handle. All doors will automatically unlock after Even though the doors may be unlocked, an impact causes the air bags to deploy.
Page 852 Features of your vehicle TAILGATE ✽ ✽ NOTICE In cold and wet climates, door lock and door mechanisms may not work proper- ly due to freezing conditions. WARNING The tailgate swings upward. Make sure no objects or people are near the rear of the vehicle when open- ing the tailgate.
Page 853 Features of your vehicle WARNING Exhaust fumes If you drive with the tailgate open, you will draw dangerous exhaust fumes into your vehicle which can cause serious injury or death to vehicle occupants. If you must drive with the tailgate open, keep the air vents and all win- dows open so that additional out- side air comes into the vehicle.
Page 854 Features of your vehicle WINDOWS (1) Driver’s door power window switch (2) Front passenger’s door power win- dow switch (3) Rear door (left) power window switch* (4) Rear door (right) power window switch* (5) Window opening and closing (6) Automatic power window up*/down* (Driver’s window) (7) Power window lock switch* * : if equipped...
Page 855 Features of your vehicle Power windows (if equipped) The ignition switch must be in the ON position for power windows to operate. Each door has a power window switch that controls the door's window. The driver has a power window lock switch which can block the operation of passenger win- dows.
Page 856 Features of your vehicle ✽ ✽ NOTICE The automatic reverse feature for the driver’s window is only active when the “auto up” feature is used by fully pulling up the switch. The automatic reverse feature will not operate if the window is raised using the halfway posi- tion on the power window switch.
Page 857 Features of your vehicle Except Europe WARNING - Windows The driver can disable the power window switches on the front and rear passen- • Never leave the keys in your vehi- ger's doors by pressing the power window cle with unsupervised children, lock switch to lock position (pressed).
Page 858 Features of your vehicle OSA028222 Manual windows (if equipped) To raise or lower the window, turn the window regulator handle clockwise or counterclockwise. WARNING When opening or closing the win- dows, make sure your passenger's arms, hands and body are safely out of the way.
Page 859 Features of your vehicle HOOD OTA040017 OTA040018 OTA040019 Opening the hood 2. Go to the front of the vehicle, raise the 3. Pull the support rod from the hood. hood slightly, pull the secondary latch 4. Hold the hood open with the support 1.
Page 860 Features of your vehicle Closing the hood WARNING 1. Before closing the hood, check the fol- lowing: • Always double check to be sure that the hood is firmly latched • All filler caps in engine compartment before driving away. If it is not must be correctly installed.
Page 861 Features of your vehicle FUEL FILLER LID Closing the fuel filler lid 1. To install the cap, turn it clockwise until it “clicks”. This indicates that the cap is securely tightened. 2. Close the fuel filler lid and push it light- ly and make sure that it is securely closed.
Page 862 Features of your vehicle (Continued) (Continued) WARNING - Refueling dan- Use only approved portable plas- • Do not get back into a vehicle gers tic fuel containers designed to once you have begun refueling Automotive fuels are flammable carry and store gasoline. since you can generate static materials.
Page 863 • If the fuel filler cap requires then contact the local fire depart- replacement, use only a genuine ment. Follow any safety instruc- Kia cap or the equivalent speci- tions they provide. fied for your vehicle. An incorrect fuel filler cap can result in a seri- ous malfunction of the fuel sys- tem or emission control system.
Page 864 Features of your vehicle SUNROOF (IF EQUIPPED) ✽ ✽ NOTICE ✽ ✽ NOTICE • In cold and wet climates, the sunroof The sunroof cannot slide when it is in may not work properly due to freez- the tilt position nor can it be tilted while ing conditions.
Page 865 Features of your vehicle To open the sunroof automatically: Pull the sunroof control lever backward to the second detent position and then release it. The sunroof will slide all the way open. To stop the sunroof sliding at any point, pull or push the sunroof control lever momentarily.
Page 866 Features of your vehicle CAUTION WARNING • Periodically remove any dirt that • Never try pinching any part of may accumulate on the guide rail. your body intentionally to acti- • If you try to open the sunroof vate the Automatic reversal func- when the temperature is below tion.
Page 867 Resetting the sunroof ❈ For more detailed information, we rec- ommend that you contact an author- Whenever the vehicle battery is discon- ized Kia dealer. nected or discharged, or related fuse is blown, you must reset your sunroof sys- tem as follows:...
Page 868 We recommend that you wheel both up and down to be effort required to steer during normal contact an authorized Kia dealer. certain it is locked in position. vehicle operation, we recommend that • The steering effort increases if the...
Page 869 Features of your vehicle CAUTION • Do not install any grip to operate the steering wheel. This causes damage to the heated steering wheel system. • When cleaning the heated steering wheel, do not use an organic sol- vent such as paint thinner, ben- zene, alcohol and gasoline.
Page 870 Features of your vehicle CAUTION Do not strike the horn severely to operate it, or hit it with your fist. Do not press on the horn with a sharp- pointed object. OTA040027 Horn To sound the horn, press the horn sym- bols on your steering wheel.
Page 871 Features of your vehicle MIRRORS Inside rearview mirror Outside rearview mirror Adjust the rearview mirror to center on Be sure to adjust mirror angles before the view through the rear window. Make driving. this adjustment before you start driving. Your vehicle is equipped with both left- Night hand and right-hand outside rearview mirrors.
Page 872 Features of your vehicle CAUTION Do not scrape ice off the mirror face; this may damage the surface of the glass. If ice should restrict movement of the mirror, do not force the mirror for adjustment. To remove ice, use a deicer spray, or a sponge or soft cloth with very warm water.
Page 873 Features of your vehicle CAUTION CAUTION • The mirrors stop moving when The electric type outside rearview they reach the maximum adjust- mirror operates even though the ing angles, but the motor contin- ignition switch is in the OFF posi- ues to operate while the switch is tion.
Page 874 Features of your vehicle OTA040031 Manual type To fold outside rearview mirror, grasp the housing of mirror and then fold it toward the rear of the vehicle. 4 41...
Page 875 Features of your vehicle INSTRUMENT CLUSTER Type A ■ ■ 1. Tachometer 2. Turn signal indicators 3. Speedometer 4. Fuel gauge 5. Warning and indicator lights 6. Odometer/Trip computer* Type B ■ ■ 7. LCD display* 8. Shift position indicator* (A/T) * : if equipped ❈...
Page 876 Features of your vehicle Type A ■ OTA040034 Type B ■ OTA042209L OTA040035 Instrument panel illumination Tachometer (if equipped) The tachometer indicates the approxi- mate number of engine revolutions per The instrument panel illumination intensi- minute (rpm). ty can be adjusted by rotating the control Use the tachometer to select the correct knob with the headlight switch in the shift points and to prevent lugging and/or...
Page 877 Features of your vehicle On inclines or curves, the fuel gauge ■ Type A pointer may fluctuate or the low fuel warn- ing light may come on earlier than usual due to the movement of fuel in the tank. WARNING - Fuel gauge Running out of fuel can expose vehicle occupants to danger.
Page 878 Features of your vehicle Type A Type A TRIP A ■ ■ TRIP B Distance to empty* OTA040038 OTA040039 Type B Type B ■ ■ Average fuel consumption* Average refuel consumption* OTA042038 OTA042039 Odometer (km or mi.) Tripmeter (km or mi.) Instant fuel consumption* The odometer indicates the total dis- TRIP A : Tripmeter A...
Page 879 Features of your vehicle Type A Type A Type A ■ ■ ■ OTA040040 OTA040041L OTA040205L Type B Type B Type B ■ ■ ■ OTA042040 OTA042041L OTA042205L Distance to empty (km or mi.) Average fuel consumption (if equipped) Average refuel consumption (if equipped) (if equipped) (L/100 km or MPG) (l/100 km or MPG)
Page 880 Features of your vehicle Type A Type A Type A ■ ■ ■ OTA040042L OTA040043 OTA040044 Type B Type B Type B ■ ■ ■ OTA042042 OTA042043 OTA042044 Instant fuel consumption (if equipped) Elapsed time Outside thermometer (if equipped) (L/100 km or MPG) This mode indicates the total time trav- This mode indicates the outside temper- Type A...
Page 881 Features of your vehicle Type A Type B ■ ■ WARNING Never remove the radiator cap when the engine is hot. The engine coolant is under pressure and could cause severe burns. Wait until the engine is cool before adding coolant to the reservoir. OTA043360E OTA040045/OTA042045 ECO ON/OFF mode (if equipped)
Page 882 Features of your vehicle LCD display informations • Manual transaxle (if equipped) You can turn the manual transaxle shift Door/Tailgate open indicator on/off on the instrument cluster in this mode. ■ Door If you select the ECO OFF in the trip computer, the manual transaxle shift indi- cator will not illuminate.
Page 883 Features of your vehicle Align steering wheel (if equipped) Align steering wheel (if equipped) Illumination intensity OTA042229L OTA042228L OTA042227L If you start the engine when the steering If you start the engine when the steering The illumination intensity of the instru- wheel is turned 90 degrees to the left wheel is turned 90 degrees to the right ment panel is shown when adjusting it...
Page 884 Features of your vehicle For vehicle’s equipped with smart key system Key is not in vehicle Key is not detected Please press start button with smart key OTA042221L OTA042219L OTA042225L If the smart key is not in the vehicle and If the smart key is not in the vehicle or is If you press the engine start/stop button if any door is opened or closed with the...
Page 885 Features of your vehicle For vehicle’s equipped with smart key system Low key battery Press brake pedal to start engine Press clutch pedal to start engine (for automatic transaxle) (for manual transaxle) OTA042213L OTA042217L If the engine start/stop button changes to OTA042218L the OFF position when the smart key in If the engine start/stop button changes to...
Page 886 10 seconds. (if equipped) If the warning illuminates each time you press the engine start/stop button, we recommend that you have the vehicle inspected by an authorized Kia dealer as soon as possible. 4 53...
Page 887 Features of your vehicle For vehicle’s equipped with smart key system Press start button while turn steering Check steering wheel lock system Steering wheel unlock (if equipped) (if equipped) OTA042215L OTA042214L If the steering wheel does not lock nor- OTA042216L If the steering wheel does not unlock nor- If the steering wheel does not lock nor- mally when the ENGINE START/STOP...
Page 888 Features of your vehicle Warnings and indicators ECO indicator Check stop lamp fuse (if equipped) All warning lights are checked by turning (Automatic transaxle) the ignition switch ON (do not start the engine). If any light is still ON, this indi- cates a situation that needs attention.
Page 889 ON position or start- In this case, we recommend that you have ed the engine, or if it comes on while the vehicle inspected by an authorized Kia driving, we recommend that you have the WARNING dealer.
Page 890 Kia dealer. 3. Do not drive the vehicle if leaks are indicated. In this case, we recommend found, the warning light remains on or that you have the vehicle inspected by an the brakes do not operate properly.
Page 891 Features of your vehicle High beam indicator Front fog light indicator Low Beam Indicator Light (if equipped) (if equipped) This indicator illuminates when the head- This indicator light illuminates when the This indicator illuminates when the front lights are on and in the high beam posi- headlights are on.
Page 892 : Indicates that shifting up to the 3rd the engine and check the oil level. If inspected by an authorized Kia dealer as gear is desired (currently the shift the oil level is low, fill the engine oil soon as possible.
Page 893 With smart key system you have the vehicle inspected by an If any of the following occurs in a vehicle authorized Kia dealer as soon as pos- equipped with the smart key, the immobi- sible. lizer indicator illuminates, blinks or goes off.
Page 894 When it comes on, you Control System which monitors various Kia dealer as soon as possible. should add fuel as soon as possible. emission control system components. If • When the battery is weak, if the...
Page 895 In this case, we recommend case, we recommend that you have the that you have the vehicle inspected vehicle inspected by an authorized Kia by an authorized Kia dealer as soon dealer. as possible. ESP OFF indicator (if equipped)
Page 896 Features of your vehicle KEY OUT indicator Key reminder warning chime Overspeed warning (if equipped) (if equipped) (if equipped) km/h When the ENGINE START/STOP button Without smart key system Overspeed warning light is in the ACC or ON position, if any door If the driver’s door is opened while the If you drive with the speed of 120 km/h or is open, the system checks for the smart...
Page 897 Replace the battery with new one. blink for 5 seconds. ommend that you have the vehicle inspected by an authorized Kia dealer. For more details, refer to the ISG (Idle Stop and Go) system in chapter 5. Icy road warning light (if equipped) ✽...
Page 898 Features of your vehicle REAR PARKING ASSIST SYSTEM (IF EQUIPPED) Operation of the rear parking WARNING assist system The rear parking assist system is a Operating condition supplementary function only. The • This system will activate when backing operation of the rear parking assist up with the ignition switch ON.
Page 899 Features of your vehicle Non-operational conditions of Rear parking assist system pre- The detecting range may decrease when: rear parking assist system cautions 1. The sensor is stained with foreign mat- The rear parking assist system may • The rear parking assist system may ter such as snow or water.
Page 900 If this occurs, we recommend that be detected by the sensors. the system be checked by an authorized Always visually check behind the vehi- Kia dealer. cle when backing up. Be sure to inform any drivers of the WARNING...
Page 901 Features of your vehicle HAZARD WARNING FLASHER OTA040049 The hazard warning flasher should be used whenever you find it necessary to stop the car in a hazardous location. When you must make such an emer- gency stop, always pull off the road as far as possible.
Page 902 Features of your vehicle LIGHTING Battery saver function Headlight escort function Headlight welcome function (if equipped) (if equipped) • The purpose of this feature is to pre- vent the battery from being dis- The headlights (and/or taillights) will When the headlight switch is in the ON or charged.
Page 903 Features of your vehicle ■ Type A ■ Type A ■ Type A OTA040050E ORBC040047 ORBC040048 ■ Type B ■ Type B ■ Type B OTA040050L ORB040047E ORB040048E Lighting control Parking light position ( Headlight position ( The light switch has a Headlight and a When the light switch is in the parking When the light switch is in the headlight Parking light position.
Page 904 Features of your vehicle ■ Type A CAUTION • Never place anything over sensor (1) located on the instrument panel. This will ensure better auto-light system control. • Don’t clean the sensor using a window cleaner. The cleaner may ORBC040049 leave a light film which could ■...
Page 905 Features of your vehicle They will self-cancel after a turn is com- Type A ■ ■ Type A pleted. If the indicator continues to flash after a turn, manually return the lever to the OFF position. To signal a lane change, move the turn signal lever slightly and hold it in position (B).
Page 906 Features of your vehicle ■ Type A ■ Type C CAUTION When in operation, the fog lights consume large amounts of vehicle electrical power. Only use the fog lights when visibility is poor or unnecessary battery and generator drain could occur. ✽...
Page 907 Features of your vehicle To turn off the rear fog lights, turn the switch to OFF (without ■ Type A ■ Type C Auto light) ✽ ✽ NOTICE To turn on the rear fog light switch, the ignition switch must be in the ON position.
Page 908 Features of your vehicle Loading condition Switch position Driver only Driver + Front passenger Full passengers Full passengers + Maximum permissible loading Driver + Maximum permis- sible loading OTA040200L Headlight leveling device (if equipped) Manual type To adjust the headlight beam level according to the number of passengers and loading weight in the luggage area, turn the beam leveling switch.
Page 909 Features of your vehicle WIPERS AND WASHERS A : Wiper speed control Windscreen wiper/washer · MIST ( ) – Single wipe Type A Type C ■ ■ · OFF (O) – Off · INT (---) – Intermittent wipe · LO (1) – Low wiper speed ·...
Page 910 Features of your vehicle Windshield wipers D : Rear wiper/washer control Rear window wiper/washer (if equipped) (if equipped) Operates as follows when the ignition · – Wash with brief wipes switch is turned ON. Type C ■ MIST ( ) : For a single wiping cycle, ·...
Page 911 Features of your vehicle Type A Type C ■ ■ CAUTION To prevent possible damage to the washer pump, do not operate the washer when the fluid reservoir is empty. WARNING Do not use the washer in freezing ORBC040056E OTA040056 temperatures without first warming Type B Type D...
Page 912 Features of your vehicle INTERIOR LIGHT Type C ■ - Spraying washer fluid and wiping CAUTION - Normal wiper operation Do not use the interior lights for extended periods when the engine OFF (O) - Wiper is not in operation is not running.
Page 913 Features of your vehicle The map lamp goes out gradu- ally after approximately 30 sec- onds if the door is closed. However, if the ignition switch is ON or all doors are locked, the map lamp will turn off immedi- ately.
Page 914 Features of your vehicle However, if a door is opened with the ignition switch in the ON posi- tion, the room lamp stays on con- tinuously. • OFF : The lights turn off even if a door is opened. • ON : The room lamp stay on at all times.
Page 915 Features of your vehicle DEFROSTER Outside rearview mirror defroster Type A ■ CAUTION (if equipped) To prevent damage to the conduc- If your vehicle is equipped with the out- tors bonded to the inside surface of side rearview mirror defrosters, they will the rear window, never use sharp operate at the same time you turn on the instruments or window cleaners...
Page 916 Features of your vehicle MANUAL CLIMATE CONTROL SYSTEM (IF EQUIPPED) ■ ■ Type A 1. Mode selection knob 2. Air intake control knob 3. Fan speed control knob 4. Temperature control knob 5. Air conditioning button (if equipped) ■ ■ Type B 6.
Page 917 Features of your vehicle Heating and air conditioning 1. Start the engine. 2. Set the mode to the desired position. For improving the effectiveness of heating and cooling; - Heating: - Cooling: 3. Set the temperature control to the desired position. 4.
Page 918 Features of your vehicle Face-Level (B, D) Floor/Defrost-Level (A, C, D) Most of the air flow is directed to the floor Air flow is directed toward the upper body and the windshield with a small amount and face. Additionally, each outlet can be directed to the side window defrosters.
Page 919 Features of your vehicle OTA040064 OTA040065 OTA040066 Temperature control Air intake control Instrument panel vents You can adjust the direction of air deliv- The temperature control knob allows you The air intake control is used to select ery from these vents using the vent con- to control the temperature of the air flow- the outside (fresh) air position or recircu- trol lever as shown.
Page 920 Features of your vehicle Recirculated air position ✽ ✽ NOTICE WARNING With the recirculated air Prolonged operation of the heater in the position selected, air from • Continue using the climate con- recirculated air position (without air the passenger compart- trol system in the recirculated air conditioning selected) may cause fogging ment will be drawn through...
Page 921 Features of your vehicle System operation Ventilation 1. Set the mode to the position. 2. Set the air intake control to the outside (fresh) air position. 3. Set the temperature control to the desired position. 4. Set the fan speed control to the desired speed.
Page 922 Air conditioning Operation Tips ✽ ✽ NOTICE • To keep dust or unpleasant fumes from Kia Air Conditioning Systems are filled • When using the air conditioning sys- entering the vehicle through the venti- with environmentally friendly R-134a tem, monitor the temperature gauge lation system, temporarily set the air refrigerant.
Page 923 (fresh) air position is selected. If this hap- pens, we recommend that the climate control air filter be replaced by an author- ized Kia dealer.
Page 924 Therefore, if abnormal operation is • When the air flow rate suddenly found, we recommend that the system be decreases, we recommend that the inspected by an authorized Kia dealer. system be checked by an authorized Kia dealer. ✽ ✽ NOTICE It is important that the correct type and amount of oil and refrigerant is used.
Page 925 Features of your vehicle AUTOMATIC CLIMATE CONTROL SYSTEM (IF EQUIPPED) Type A ■ ■ 1. Temperature control knob 2. AUTO (automatic control) button 3. OFF button 4. Climate control display 5. Fan speed control knob 6. Air conditioning button (if equipped) 7.
Page 926 Features of your vehicle OTA040070 OTA040074 OTA040071 Automatic heating and air condi- 2. Set the temperature control knob to ✽ ✽ NOTICE tioning set the desired temperature. Never place anything over the sensor 1. Push the AUTO button. The modes, located on the instrument panel to ✽...
Page 927 Features of your vehicle Manual heating and air condition- Floor & Defrost (A, C, D) The heating and cooling system can be controlled manually by pushing buttons Most of the air flow is directed to the floor other than the AUTO button. In this case, and the windshield with a small amount the system works sequentially according directed to the side window defrosters.
Page 928 Features of your vehicle OTA040073 OTA040064 OTA040074 Temperature control Defrost-Level Instrument panel vents Most of the air flow is directed to the You can adjust the direction of air deliv- The temperature control knob allows you windshield with a small amount of air ery from these vents using the vent con- to control the temperature of the air flow- directed to the side window defrosters.
Page 929 Features of your vehicle Temperature conversion Recirculated air position You can switch the temperature mode With the recirculated air between Centigrade to Fahrenheit as fol- position selected, air from lows: the passenger compart- ment will be drawn through While pressing the OFF button, press the the heating system and AUTO button for 4 seconds or more.
Page 930 Features of your vehicle WARNING • Continued climate control system operation in the recirculated air position may allow humidity to increase inside the vehicle which may fog the glass and obscure visibility. • Do not sleep in a vehicle with the air conditioning or heating sys- tem on.
Page 931 Features of your vehicle OTA040078 OFF mode Press the OFF button to turn off the air climate control system. However, you can still operate the mode and air intake but- tons as long as the ignition switch is in the ON position.
Page 932 Features of your vehicle WINDSHIELD DEFROSTING AND DEFOGGING • For maximum defrosting, set the tem- WARNING perature control to the extreme Windshield right/hot position and the fan speed heating control to the highest speed. Do not use the position • If warm air to the floor is desired while during cooling operation...
Page 933 Features of your vehicle OTA040080 OTA040081 OTA040082 To defrost outside windshield Automatic climate control system To defrost outside windshield 1. Set the fan speed to the highest posi- 1. Set the fan speed to the highest To defog inside windshield tion.
Page 934 Features of your vehicle STORAGE COMPARTMENTS Defogging logic These compartments can be used to store small items required by the driver To reduce the probability of fogging up or passengers. the inside of the windshield, the air intake or air conditioning are controlled auto- matically according to certain conditions CAUTION such as...
Page 935 Features of your vehicle WARNING • Do not keep objects except sun- glasses inside the sunglass hold- er. Such objects can be thrown from the holder in the event of a sudden stop or an accident, pos- sibly injuring the passengers in the vehicle.
Page 936 “ready” position. If it is necessary to replace the cigarette OTA042086 lighter, use only a genuine Kia replace- Ashtray (if equipped) ment or its approved equivalent. To use the ashtray, open the cover.
Page 937 Features of your vehicle Cup holder WARNING - Ashtray use • Do not use the vehicle’s ashtrays WARNING Hot liquids as waste receptacles. • Do not place uncovered cups of • Putting lit cigarettes or matches in hot liquid in the cup holder while an ashtray with other combustible the vehicle is in motion.
Page 938 Features of your vehicle OTA040094 ORBR040085 OTA040182 To use the cup holder space as a storage Sunvisor Vanity mirror lamp (if equipped) compartment, turn the half part of the Use the sunvisor to shield direct light Opening the lid of the vanity mirror will cup holder (2) to the direction of the through the front or side windows.
Page 939 Features of your vehicle (Continued) CAUTION • Make sure that the electric • Use power outlet only when the devices are plugged in securely. If engine is running and remove the not, it could cause a malfunction accessory plug after use. Using of electric systems.
Page 940 Features of your vehicle With audio on Type A Type C ■ ■ 1. Press the [SETUP] or [Clock] button until the clock adjust mode displayed. 2. Set the clock by turning the knob(1) and press it. WARNING Do not adjust the clock while driv- ing.
Page 941 To avoid any interference with pedal operation, Kia recommends that only the Kia floor mat designed for use in your vehicle be installed.
Page 942 Features of your vehicle AUDIO SYSTEM ✽ ✽ NOTICE CAUTION If you install an aftermarket HID head • Before entering a place with a low lamp, your vehicle’s audio and electron- height clearance or a car wash, ic device may malfunction. remove surely the antenna by rotating it counter-clockwise.
Page 943 Features of your vehicle Steering wheel audio controls Type A SEEK/PRESET ( ) (2) ■ (if equipped) The SEEK/PRESET lever has different The steering wheel may incorporate functions based on the system mode. For audio control buttons. the following functions the lever should be pressed for 0.8 seconds or more.
Page 944 Features of your vehicle Type A ✽ ✽ NOTICE MODE ( ) (3) ■ Press the button to change audio source. When using a portable audio device FM(1~2) USB AUX(iPod) connected to the power outlet, noise may ➟ ➟ ➟ FM...
Page 945 Features of your vehicle FM reception AM(MW, LW) reception FM radio station JBM001 JBM002 JBM003 How car audio works AM (MW, LW) broadcasts can be FM broadcasts are transmitted at high received at greater distances than FM frequencies and do not bend to follow the AM (MW, LW) and FM radio signals are broadcasts.
Page 946 Features of your vehicle Using a cellular phone or a two-way radio When a cellular phone is used inside the vehicle, noise may be produced from the audio equipment. This does not mean that something is wrong with the audio equipment.
Page 947 Features of your vehicle Care of discs • Keep CDs in their cases after use to protect them from scratches or dirt. • If the temperature inside the car is too • Depending on the type of CD-R/CD- high, open the car windows for ventila- RW CDs, certain CDs may not operate tion before using your car audio.
Page 948 Features of your vehicle AC9901YGG (GENERAL) ■ ■ ® ❋There will be no logo if the Bluetooth Wireless Technology feature is not supported. TA_H800_GEN_AUDIO 4 115...
Page 949 Features of your vehicle • Press CLOCK Button for 0.8 seconds or SEEK Button longer to adjust clock setting mode and • When the button is pressed, it SEEK Use the TUNE knob to adjust hour & increases the band frequency to auto- minute.
Page 950 Features of your vehicle • BASS Control • BALANCE Control To increase the BASS, rotate the knob Rotate the knob clockwise to emphasize clockwise, while to decrease the BASS, right speaker sound(left speaker sound rotate the knob counterclockwise. will be attenuated). TA_H800_GEN_AUDIO When the control knob is turned counter 6.
Page 951 Features of your vehicle (Continued) (Continued) CAUTION IN USING • An encrypted MP3 PLAYER is not • If you disconnect the external USB USB DEVICE recognizable. device during playback in USB • To use an external USB device, mode, the external USB device can •...
Page 952 Features of your vehicle (Continued) (Continued) • If the USB device is divided by • The data in the USB memory may logical drives, only the music files be lost while using this audio. on the highest-priority drive are Always back up important data on recognized by car audio.
Page 953 Features of your vehicle • Press the button for less than SEEK 0.8 seconds to move to the next song. Button (FAST FORWARD) Press the button for 0.8 seconds or longer to initiate forward direction high speed sound search of current song. Button (REWIND) TA_H800_GEN_AUDIO TA_H800_GEN_AUDIO...
Page 954 Features of your vehicle TUNE Knob & ENTER Button • Turn this knob clockwise to browse songs after current song, or counter clockwise to browse songs before cur- rent song. To play the displayed song, press the knob. • Pressing this knob without turning enters to AUDIO CONTROL mode.
Page 955 • When the iPod cable is connected, iPod DEVICE the system can be switched to AUX • Some iPod models might not sup- • The Kia iPod Power Cable is mode even without iPod device port the communication protocol needed in order to operate iPod and may cause noise.
Page 956 Features of your vehicle Button (REPEAT) TRACK Button Repeats the song currently played. TRACK • Press the button for less than 0.8 seconds to play from the beginning Button (RANDOM) of the song currently played. • Press this button for less than 0.8 sec- Press the button for less than 0.8 sec- onds to shuffle order of all songs in onds and press it again within 1 sec-...
Page 957 Features of your vehicle TA_H800_GEN_AUDIO TA_H800_GEN_AUDIO Button (MENU) MENU TUNE Knob & ENTER Button When you rotate the knob clockwise, it Moves to the upper category from cur- will display the songs (category) ahead rently played category of the iPod. To move to (play) the category (song) of the song currently played (category in displayed, press...
Page 958 Features of your vehicle CD Player : AM110TAG (GENERAL) ■ ■ ® ❋There will be no logo if the Bluetooth Wireless Technology feature is not supported. TA_GEN_RADIO 4 125...
Page 959 Features of your vehicle POWER VOLUME Button & Knob Turns on/off the set when the IGNITION SWITCH is on ACC or ON. If the button 5. PRESET Buttons is turned to the right, it increases the vol- Push buttons less than ume and left,decreases the volume.
Page 960 Features of your vehicle If no action is taken for 5 seconds after SCAN • Press the button again to stop pressing the button, it will return to the the scan feature and to listen to the play mode. (After entering SETUP mode, currently selected channel.
Page 961 Features of your vehicle • Media (if equipped) • PHONE ® Select default display of MP3 play infor- Select this item to enter Bluetooth mation. “Folder/File” or “Artist/Title” can Wireless Technology setup mode. Refer to be selected. ® “ Bluetooth Wireless Technology PHONE OPERATION”...
Page 962 Features of your vehicle MIDDLE Control SEEK • Press button for less than TRACK To increase the MIDDLE, rotate the knob 0.8 seconds to play the next song. clockwise, while to decrease the MID- SEEK • Press button for 0.8 seconds TRACK DLE, rotate the knob counterclockwise.
Page 963 Features of your vehicle 5. CD Indicator icon TUNE Knob & ENTER Button When car ignition switch is ACC or ON • Turn this knob clockwise to browse and if the CD is loaded, this indicator songs after current song, or counter- icon is on.
Page 964 Features of your vehicle NOTE: 2. Folder playing order : ❋ If no song file is contained in the Order of playing files (folders) : folder, that folder is not displayed. 1. Song playing order : sequen- tially. 4 131...
Page 965 Features of your vehicle (Continued) (Continued) CAUTION IN USING • An encrypted MP3 PLAYER is not • If you disconnect the external USB USB DEVICE recognizable. device during playback in USB • To use an external USB device, mode, the external USB device can •...
Page 966 Features of your vehicle (Continued) (Continued) • If the USB device is divided by • The data in the USB memory may logical drives, only the music files be lost while using this audio. on the highest-priority drive are Always back up important data on recognized by car audio.
Page 967 Features of your vehicle TRACK Button Button (REPEAT) SEEK • Press the button for less • Press this button for less than 0.8 sec- TRACK onds to repeat current song. than 0.8 seconds to play from the • Press this button for 0.8 seconds or longer beginning of the current song.
Page 968 Features of your vehicle FOLDER Button • Press button to move to child FOLDER folder of the current folder and display the first song in the folder. Press knob to move to the fold- TUNE er displayed. It will play the first song in the folder.
Page 969 • When the iPod cable is connected, iPod DEVICE the system can be switched to AUX • Some iPod models might not sup- • The Kia iPod Power Cable is mode even without iPod device port the communication protocol needed in order to operate iPod and may cause noise.
Page 970 Features of your vehicle TRACK Button Button (RANDOM) SEEK • Press this button for less than 0.8 sec- • Press the button for less TRACK onds to shuffle order of all songs in than 0.8 seconds to play from the current category.
Page 971 Features of your vehicle Button (MENU) Moves to the upper category from cur- rently played category of the iPod. To move to (play) the category (song) displayed, press knob. TUNE You will be able to search through the lower category of the selected category. The standard order of iPod’s category is Playlist, Artist, Albums, Genes, Songs, TA_GEN_iPod...
Page 972 Features of your vehicle (continued) CAUTION IN USING • If the cellular phone signal is poor ® BLUETOOTH WIRELESS or the vehicles interior noise is TECHNOLOGY CELLULAR too loud, it may be difficult to hear PHONE the other person’s voice during a •...
Page 973 ® trademarks owned by Bluetooth What is Bluetooth ® Wireless ■ Wireless Technology SIG, Inc. and any Technology? use of such marks by Kia is under ® Bluetooth Wireless Technology is a wire- ® license. Bluetooth Wireless less technology that allows multiple...
Page 974 For example, if the vehicles' name is - If you want to use the deleted phone varies according to each phone Kia PICANTO, you may need to change with the audio system again, pairing model. Before attempting to pair the name displayed on you phone from procedure must be completed once phone, please see your phone’s...
Page 975 Features of your vehicle Receiving a Phone Call Making a Phone Call 2. Select “PHONE”, then “PRIORITY” in ■ ■ PHONE menu. When receiving a phone call, a ringtone A Call Back can be made by pressing 3. Select desired phone name from the is audible from speakers and the audio button on the steering wheel.
Page 976 Features of your vehicle Using the head unit as Bluetooth ® NOTE: ■ Wireless Technology music • Not only MP3 files, all the sounds that the phone supports can be This audio system supports A2DP (Audio heard by the audio system. Advanced Distribution Profile)
Page 977 Features of your vehicle CD Player : AM110TAE(EUROPE) ■ ■ ® ❋There will be no logo if the Bluetooth feature is not supported. TA_EU_AUDIO...
Page 978 Features of your vehicle 6. PRESET Buttons Button • Press buttons less TA(Traffic announcement) Channels in than 0.8 seconds to play the station FM, CD, AUX mode, turns on/off the saved in each button. reception of TA channels of RDS. •...
Page 979 Features of your vehicle • Moves button when search- FOLDER ing PTY in RDS Broadcasting Program Type selection. DARK Button Turn the LCD Display & Backlight ON/OFF when DARK button press. TA_EU_AUDIO TA_EU_AUDIO SETUP Button SCAN Button Button(AUTO STORE Press this button to enter SETUP mode, Button) If no action is taken for 8 seconds, it will •...
Page 980 Features of your vehicle • MAIN • MEDIA Select this ithem to enter the Scroll and Select default display of MP3 play infor- SDVC setup. mation. “Folder/File” or “Artist/Title” can • AF(AF MENU indication is possible with be selected. • SCROLL RDS MENU) •...
Page 981 Features of your vehicle • REGION(REGION MENU indication is • Auto • P.BASS (PowerBass) possible with RDS MENU) Select “Auto” button to enter Automatic This function creates virtual sound Selects whether REGION code is used RDS Time menu. effects and allows adjustments to the (ON) or not (OFF) once the radio deter- Bass level.
Page 982 Features of your vehicle • MIDDLE Control To increase the MIDDLE, rotate the knob clockwise, while to decrease the MID- DLE, rotate the knob counterclockwise. • TREBLE Control To increase the TREBLE, rotate the knob clockwise, while to decrease the TRE- BLE, rotate the knob counterclockwise.
Page 983 Features of your vehicle • FLD RPT (MP3/WMA Only) : Only files SEEK • Press button for 0.8 seconds TRACK in a folder are repeatedly played back. or longer to initiate reverse direction high speed sound search of current song. SEEK •...
Page 984 Features of your vehicle NOTE: knob & ENTER Button Order of playing files (folders) : • Turn this knob clockwise to browse 1. Song playing order : sequen- songs after current song, or counter- tially. clockwise to browse songs before cur- rent song.
Page 985 Features of your vehicle 2. Folder playing order : ❋ If no song file is contained in the folder, that folder is not displayed.
Page 986 Features of your vehicle (Continued) (Continued) CAUTION IN USING • An encrypted MP3 PLAYER is not • If you disconnect the external USB USB DEVICE recognizable. device during playback in USB • To use an external USB device, mode, the external USB device can •...
Page 987 Features of your vehicle (Continued) (Continued) • If the USB device is divided by • Please avoid using USB memory logical drives, only the music files products which can be used as on the highest-priority drive are key chains or cellular phone recognized by car audio.
Page 988 Features of your vehicle TRACK Button Button (RANDOM) SEEK • Press this button for less than 0.8 seconds • Press the button for less TRACK to play songs randomly in current folder. than 0.8 seconds to play from the • Press this button for 0.8 seconds or beginning of the current song.
Page 989 Features of your vehicle FOLDER Button • Press button to move to FOLDER child folder of the current folder and display the first song in the folder. Press knob to move to the fold- er displayed. It will play the first song in the folder.
Page 990 • When the iPod cable is connected, iPod DEVICE the system can be switched to AUX • Some iPod models might not sup- • The Kia iPod Power Cable is mode even without iPod device port the communication protocol needed in order to operate iPod and may cause noise.
Page 991 Features of your vehicle TRACK Button Button (RANDOM) SEEK • Press this button for less than 0.8 sec- • Press the button for less TRACK onds to shuffle order of all songs in than 0.8 seconds to play from the current category.
Page 992 Features of your vehicle Button (MENU) Moves to the upper category from cur- rently played category of the iPod. To move to (play) the category (song) displayed, press knob. You will be able to search through the lower category of the selected category. The standard order of iPod’s category is Playlist, Artist, Albums, Genes, Songs, Composers.
Page 993 Features of your vehicle (continued) CAUTION IN USING • Do not place the phone near or ® BLUETOOTH CELLULAR inside metallic objects, otherwise PHONE ® communications with Bluetooth • Do not use a cellular phone or system or cellular service sta- ®...
Page 994 A2DP feature) wirelessly. ® Bluetooth SIG, Inc. and any use of • Voice recognition engine such marks by Kia is under license. ® Bluetooth system supports 10 types of A Bluetooth enabled cell phone is languages: ® required to use Bluetooth...
Page 995 Features of your vehicle Voice Recognition Activation ® • At any time if you say “help”, the system Bluetooth Language Setting ■ ■ will announce what commands are The system language can be changed by • The voice recognition engine contained ®...
Page 996 Features of your vehicle Voice Operation Tip <Voice Recognism> 2) Select “PHONE” item by rotating the ■ TUNE knob, then push the knob. To get the best performance out of the Voice Recognition System, observe the followings: - Keep the interior of the vehicle as quiet as possible.
Page 997 ® Bluetooth device list. Then attempt that phone again unless the phone is vehicles are Kia PICANTO, some pairing on your phone ® deleted manually from the audio sys- phones may not handle Bluetooth 10.
Page 998 Features of your vehicle • Connecting phone • Deleting Phone • Changing Priority The paired phone can be deleted. ® When several phones are paired to the When the Bluetooth system is enabled, audio system, the system attempts to the phone previously used is automati- - When the phone is deleted, all the infor- connect following order when the cally selected and re-connected.
Page 999 Features of your vehicle Phone Book (In-Vehicle) 2. Adjusting Bluetooth language ® • Turning Bluetooth ON/OFF ■ • Select “BT Voice Recognition lan- ® Bluetooth system can be enabled (ON) • Adding Entry guage” in PHONE menu, adjust lan- or disabled (OFF) by this menu. Phone numbers and voice tags can be guage to desired language by turning ®...
Page 1000 Features of your vehicle ✽ ✽ NOTICE • Adding Entry by Phone • Deleting Name 1. Press button. The registered names can be deleted. - The system can recognize single digits from zero to nine. Numbers that are 2. Say “Phonebook”. 1.

Kia picanto 2014 Owner's Manual

Quick Links

Related Manuals for Kia picanto 2014

Summary of Contents for Kia picanto 2014

Table of Contents
