  • Page 1 Projector ® User manual...

  • Page 2: Table Of Contents

    TablE of ConTEnTs safETY ....................4 Important Safety Instruction....................... 4 3D Safety Information ........................ 5 Copyright ........................... 6 Disclaimer ..........................6 Trademark Recognition ......................6 FCC ............................7 Declaration of Conformity for EU countries ................7 WEEE ............................7 InTRoDUCTIon .................. 8 Package Overview........................
  • Page 3 Image size and projection distance ..................42 Projector dimensions and ceiling mount installation ..............44 IR remote codes ........................45 IR remote control 2 codes ......................47 Troubleshooting ........................49 Warning indicators ........................51 Specifications ........................... 53 Optoma global offices ....................... 54 English...

  • Page 4: Safety

    safETY The lightning flash with arrow head within an equilateral triangle is intended to alert the user to the presence of uninsulated "dangerous voltage" within the product's enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.

  • Page 5: 3D Safety Information

    ‡ Do not attempt to service the unit yourself. Opening or removing covers may expose you to dangerous voltages or other hazards. Please call Optoma before you send the unit for repair. ‡ See projector enclosure for safety related markings.

  • Page 6: Copyright

    medical specialist: (1) altered vision; (2) light-headedness; (3) dizziness; (4) involuntary movements such as eye or muscle twitching; (5) confusion; (6) nausea; (7) loss of awareness; (8) convulsions; (9) cramps; and/ or (10) disorientation. Children and teenagers may be more likely than adults to experience these symptoms.

  • Page 7: Fcc

    This device has been tested and found to comply with the limits for a Class B digital device pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This device generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.

  • Page 8: Introduction

    InTRoDUCTIon Package overview Carefully unpack and verify that you have the items listed below under standard accessories. Some of the items under optional accessories may not be available depending on the model, specification and your region of purchase. Please check with your place of purchase. Some accessories may vary from region to region. The warranty card is only supplied in some specific regions.

  • Page 9: Product Overview

    InTRoDUCTIon Product overview notee: ‡ Do not block projector inlet or outlet air vents. ‡ Keep a minimum distance of 20 cm between the “inlet” and “outlet” labels. Item Item Lamp Cover Lens Focus Ring Ventilation (inlet) Zoom Lever 10. Ventilation (outlet) IR Receiver 11.

  • Page 10: Connections

    InTRoDUCTIon Connections Item HDMI 1 Connector HDMI 2 / MHL Connector USB Power Out (5V 1A) Connector / MOUSE / SERVICE Connector 3D Sync Connector 12V OUT Connector AUDIO OUT Connector Kensington Lock Port Power Socket notee: Remote mouse requires special remote control. English...

  • Page 11: Keypad

    InTRoDUCTIon Keypad Item Item On/Standby LED Enter Lamp LED Menu Keystone Correction Four Directional Select Keys Temp LED 10. Source Information 11. Power Re-Sync English...

  • Page 12: Remote Control

    InTRoDUCTIon Remote control User2 User1 User3 Contrast Brightness Mode Aspect ratio Keystone Mute Sleep Timer Volume Source Re-sync Menu Volume HDMI1 HDMI2 VGA1 VGA2 Video YPbPr Item Item Power On 15. User 3 User 2 16. Contrast User 1 17. Display Mode Brightness 18.

  • Page 13: Remote Control 2

    InTRoDUCTIon Remote control 2 Power Switch Freeze Enter Page- Laser Page+ Keystone Volume Menu HDMI Video User1 User2 User3 Source Resync Item Item Power On / Off 15. Brightness Mode Freeze 16. Mouse On / Off Display Blank / Audio Mute 17.

  • Page 14: Setup And Installation

    Do not operate the projector in any orientation other that table top or ceiling mount. The projector should be horizontal and not tilted either forwards/backwards or left/right. Any other orientation will invalidate the warranty and may shorten the lifetime of the projector lamp or the projector itself. For none standard installation advise please contact Optoma. English...

  • Page 15: Connecting Sources To The Projector

    sETUP anD InsTallaTIon Connecting sources to the projector MOLEX Item HDMI Cable HDMI / MHL Cable 3D Emitter Cable 12V DC Jack Audio Out Cable USB Cable (mouse control) USB Power Cable HDMI Dongle Power Cord English...

  • Page 16: Adjusting The Projector Image

    sETUP anD InsTallaTIon adjusting the projector image Image height The projector is equipped with elevator feet for adjusting the image height. Locate the adjustable foot you wish to adjust on the underside of the projector. Rotate the adjustable foot clockwise or counterclockwise to raise or lower the projector. Tilt-Adjustment Feet Tilt-Adjustment Ring Zoom and focus...

  • Page 17: Remote Setup

    sETUP anD InsTallaTIon Remote setup Installing / replacing the batteries Two AAA size batteries are supplied for the remote control. Remove the battery cover on the back of the remote control. Insert AAA batteries in the battery compartment as illustrated. Replace back cover on remote control.
  • Page 18 sETUP anD InsTallaTIon Approx. 15° English...

  • Page 19: Using The Projector

    UsInG THE PRoJECToR Powering on / off the projector User2 User1 User3 Contrast Brightness Mode Aspect ratio Keystone User2 User1 User3 Contrast Brightness Mode Mute Sleep Timer Aspect ratio Keystone Mute Sleep Timer Volume Source Re-sync Volume Menu Volume Source Re-sync HDMI1 HDMI2...

  • Page 20: Selecting An Input Source

    User2 User1 User3 UsInG THE PRoJECToR Contrast Brightness Mode Aspect ratio Keystone selecting an input source Mute Sleep Timer Turn on the connected source that you want to display on the screen, such as computer, notebook, video player, etc. The projector will automatically detect the source. If multiple sources are connected, push the source button on the projector keypad or the remote control to select the desired input.

  • Page 21: Using The Projector

    UsInG THE PRoJECToR menu navigation and features The projector has multilingual on-screen display menus that allow you to make image adjustments and change a variety of settings. The projector will automatically detect the source. To open the OSD menu, press on the remote control or the projector keyboard.

  • Page 22: Osd Menu Tree

    UsInG THE PRoJECToR osD menu tree main sub menu sub menu 2 sub menu 3 sub menu 4 Values menu Cinema Film Vivid Game Reference Display Mode Bright [Video] USER ISF Day ISF Night ISF 3D Brightness -50~50 Contrast -50~50 Sharpness 1~15 Color...
  • Page 23 UsInG THE PRoJECToR main sub menu sub menu 2 sub menu 3 sub menu 4 Values menu Red Gain -50~50 Green Gain -50~50 Blue Gain -50~50 Red Bias -50~50 RGB Gain/Bias Green Bias -50~50 Blue Bias -50~50 Cancel [Default] Reset Color Settings Exit Auto [Default]...
  • Page 24 UsInG THE PRoJECToR main sub menu sub menu 2 sub menu 3 sub menu 4 Values menu H: 0; V: -50 H: -50; V: 0 H: 50; V: 0 H: 0; V: 50 Image shift [Default:0] Display H: -50; V: 0 H: 0;...
  • Page 25 UsInG THE PRoJECToR main sub menu sub menu 2 sub menu 3 sub menu 4 Values menu Off [Default] Quick Resume Power Settings Off [Default] USB Power Auto Security Month Security Timer Security Hour Change Password HDMI Link Inclusive of TV HDMI Link Mutual Settings...
  • Page 26 UsInG THE PRoJECToR main sub menu sub menu 2 sub menu 3 sub menu 4 Values menu HDMI 2 Test Pattern Brightness Contrast Sleep Timer Color Matching User2 Color Temperature Gamma Projection Lamp Settings Zoom Freeze Remote Settings MHL [Default] HDMI 2 [depends on remote]...
  • Page 27 UsInG THE PRoJECToR main sub menu sub menu 2 sub menu 3 sub menu 4 Values menu Русский Magyar Čeština ไทย Language Türkçe Tiếng Việt Bahasa Indonesia România Slovakian Top left Top right Menu Location Center [Default] Bottom left Menu Settings Bottom right Menu Timer 5sec...
  • Page 28 UsInG THE PRoJECToR main sub menu sub menu 2 sub menu 3 sub menu 4 Values menu Cancel [Default] Reset OSD Setup Reset Cancel [Default] Reset to Default Regulatory Serial Number Source Resolution 00x00 Refresh Rate 0.00Hz Display Mode Bright 0 hr Eco.

  • Page 29: Display Image Settings Menu

    UsInG THE PRoJECToR Display menu Display image settings menu Display mode There are many factory presets optimized for various types of images. ‡ Cinema : Select this mode for home theater. ‡ film : Select to display the purest color settings for home theatre. ‡...

  • Page 30: Display 3D Menu

    UsInG THE PRoJECToR Color settings Configure the color settings. ‡ brilliantColor : This adjustable item utilizes a new color-processing algorithm and enhancements to enable higher brightness while providing true, more vibrant colors in picture. ‡ Color Temperature (data-mode only) : Select a color temperature from Warm, Standard, Cool, or Cold.

  • Page 31: Display Aspect Ratio Menu

    UsInG THE PRoJECToR 3D → 2D Use this option to specify how the 3D content should appear on the screen. ‡ 3De: Display 3D signal. ‡ l (left)e: Display the left frame of 3D content. ‡ R (Right)e: Display the right frame of 3D content. 3D format Use this option to select the appropriate 3D format content.

  • Page 32: Display Edge Mask Menu

    UsInG THE PRoJECToR 1080 scaling table: 16 e: 9 screen 480i/p 576i/p 1080i/p 720p Scale to 1440x1080. 16x9 Scale to 1920x1080. Scale to 1920x1440, then get the central 1920x1080 image to display. native mode 1:1 mapping centered. No scaling will be made; the image is displayed with the resolution based on input source. Display edge mask menu Edge mask Use this function to remove the video encoding noise on the edge of video source.

  • Page 33: Audio Mute Menu

    UsInG THE PRoJECToR Audio menu audio mute menu mute Use this option to temporarily turn off the sound. ‡ one: Choose the “On” to turn mute on. ‡ offe: Choose the “Off” to turn mute off. notee: “Mute” function affects both internal and external speaker volume. audio volume menu Volume Adjust the volume level.

  • Page 34: Setup Power Settings Menu

    UsInG THE PRoJECToR setup power settings menu Direct Power on Choose “On” to activate Direct Power mode. The projector will automatically power on when AC power is supplied, without pressing the “Power” key on the projector keypad or on the remote control. signal Power on Choose “On”...

  • Page 35: Setup Hdmi Link Settings Menu

    UsInG THE PRoJECToR setup HDmI link settings menu notee: ‡ When you connect HDMI CEC-compatible devices to the projector with HDMI cables, you can control them on the same power on or power off status using the HDMI Link control feature in the projector’s OSD.

  • Page 36: Setup 12V Trigger Menu

    UsInG THE PRoJECToR setup 12V trigger menu 12V Trigger Use this function to enable or disable the trigger. Reserved IR_IN & detect ‡ Off: Choose “Off” to disable the trigger. ‡ On: Choose “On” to enable the trigger. setup options menu language Select the multilingual OSD menu between English, German, French, Italian, Spanish, Portuguese, Polish, Dutch, Swedish, Norwegian/Danish, Finnish, Greek, traditional Chinese, simplified Chinese, Japanese, Korean, Russian,...

  • Page 37: Setup Reset Osd Menu

    UsInG THE PRoJECToR logo Use this function to set the desired startup screen. If changes are made, they will take effect the next time the projector is powered on. ‡ Defaulte: The default startup screen. ‡ neutrale: Logo is not displayed on startup screen. background Color Use this function to display a blue, red, green, grey color, none, or logo screen when no signal is available.

  • Page 38: Maintenance

    maInTEnanCE Replacing the lamp The projector automatically detects the lamp life. When the lamp life is nearing the end of use, a warning message will appear on the screen. Warning lamp Warning lamp life exceeded. When you see this message, please contact your local reseller or service center to change the lamp as soon as possible.
  • Page 39 maInTEnanCE Replacing the lamp (continued) Procedure: Switch off the power to the projector by pressing the " " button on the remote control or the projector keypad. Allow the projector to cool down for at least 30 minutes. Disconnect the power cord. Unscrew the screw on the cover.

  • Page 40: Installing And Cleaning The Dust Filter

    maInTEnanCE Installing and cleaning the dust filter Installing the dust filter notee: Dust filters are only required/supplied in the selected regions with excessive dust. Cleaning the dust filter We recommend you to clean the dust filter every three months. Clean it more often if the projector is used in a dusty environment.

  • Page 41: Additional Information

    If 3D input is 1080p@24hz, the DMD should replay with integral multiple with 3D mode. ‡ Support NVIDIA 3DTV Play if there is no patent fee from Optoma. 1080i@25hz and 720p@50hz will run in 100 hz; other 3D timing will run in 120hz.

  • Page 42: Image Size And Projection Distance

    aDDITIonal InfoRmaTIon Image size and projection distance (1080P) (image size and distance in meters and feet) Diagonal screen size W x H Projection Distance (D) offset (Hd) length (feet) (feet) (inch) size of Width Height Width Height Wide Tele Wide Tele (feet) 16e:9...
  • Page 43 aDDITIonal InfoRmaTIon Top View Screen Screen (W) Projection Distance (D) Width Screen (H) Screen Side View Offset (Hd) Projection Distance (D) English...

  • Page 44: Projector Dimensions And Ceiling Mount Installation

    InfoRmaTIon Projector dimensions and ceiling mount installation To prevent damage to your projector, please use the Optoma ceiling mount. If you wish to use a third party ceiling mount kit, please ensure the screws used to attach a mount to the projector meet the following specifications: ‡...

  • Page 45: Ir Remote Codes

    aDDITIonal InfoRmaTIon IR remote codes User2 User1 User3 Contrast Brightness Mode Aspect ratio Keystone Mute Sleep Timer Volume Source Re-sync Menu Volume HDMI1 HDMI2 VGA1 VGA2 Video YPbPr Data Custom code Printing-key code Description definition byte 1 byte 2 byte 3 Power on Press to turn on the projector.
  • Page 46 aDDITIonal InfoRmaTIon Data Custom code Printing-key code Description definition byte 1 byte 2 byte 3 Mute Mute Momentarily turns off / on the audio. Automatically adjusts the picture brightness (Dynamic Black) to give optimum contrast performance. Sleep timer Sleep Timer Sets the countdown timer interval.

  • Page 47: Ir Remote Control 2 Codes

    aDDITIonal InfoRmaTIon IR remote control 2 codes Power Switch Freeze Enter Page- Laser Page+ Keystone Volume Menu HDMI Video User1 User2 User3 Source Resync address Printing-key Key legend definition byte 3 byte 4 Description Power Power on/off Press to turn on / off the projector. Switch Switch Press to switch the USB mouse on / off.
  • Page 48 aDDITIonal InfoRmaTIon address Printing-key Key legend definition byte 3 byte 4 Description Laser Laser Use as laser pointer. Page + Page+ Press to page up. Keystone+ Press to adjust image distortion caused by tilting the Keystone projector. Keystone- Volume + Press to adjust to increase / decrease the volume.

  • Page 49: Troubleshooting

    aDDITIonal InfoRmaTIon Troubleshooting If you experience a problem with your projector, please refer to the following information. If a problem persists, please contact your local reseller or service center. Image problems No image appears on-screen ‡ Ensure all the cables and power connections are correctly and securely connected as described in the "Installation"...
  • Page 50 aDDITIonal InfoRmaTIon Two images, side-by-side format ‡ Press "3D" button and switch to "SBS" for input signal is HDMI 1.3 2D 1080i side-by-side. Image does not display in 3D ‡ Check if the battery of 3D glasses is drained. ‡ Check if the 3D glasses is turned on.

  • Page 51: Warning Indicators

    aDDITIonal InfoRmaTIon Warning indicators When the warning indicators (see below) light up or flash, the projector will automatically shutdown: ‡ "LAMP" LED indicator is lit red and if "On/Standby" indicator flashes red. ‡ "TEMP" LED indicator is lit red and if "On/Standby" indicator flashes red. This indicates the projector has overheated.
  • Page 52 aDDITIonal InfoRmaTIon ‡ Temperature warning: Warning TEmPERaTURE Too HIGH Please: 1. Make sure air in and outlets are not blocked. 2. Make sure the environment temperature is under 45 degree C. If the problem persists in spite of the above. Please contact a service center for repair.

  • Page 53: Specifications

    UsInG THE PRoJECToR Specifications optical Description - Video timing up to 1080P Maximum resolution - Graphics up to WUXGA@60Hz Native resolution 1080p (1920x1080) Lens - Manual zoom and manual focus Philips E20.9ie: - Bright Mode (Normal Mode) 5000 Hours Standard @190W, 50% Survival Rate Lamp life - STD Mode (ECO Mode) 6000 Hours Typical @160W, 50% Survival Rate - Dynamic mode 8000 Hours...

  • Page 54: Optoma Global Offices

    UsInG THE PRoJECToR Optoma global offices For service or support, please contact your local office. Japan 3178 Laurelview Ct. 888-289-6786 東京都足立区綾瀬3-25-18 Fremont, CA 94538, USA 510-897-8601 info@os-worldwide.com 株式会社オーエス www.optomausa.com services@optoma.com 0120-380-495 www.os-worldwide.com コンタクトセンター: Canada Taiwan 3178 Laurelview Ct. 888-289-6786 12F., No.213, Sec. 3, Beixin Rd.,...
  • Page 55 www.optoma.com...
