SPLIT TYPE
AIR CONDITIONER
DUCT
type (50Hz)
Models
Indoor unit
Outdoor unit
ARY30LUAN
AOY30LNAWL
ARY36LUAN
AOY36LNAWL
CONTENTS
SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . 1
OUTLINE AND DIMENSIONS . . . . . . . . . . . . 2
REFRIGERANT SYSTEM DIAGRAM . . . . . . 4
CIRCUIT DIAGRAM . . . . . . . . . . . . . . . . . . . . . 5
. . . . . . . . . . . . . . . . . . . 12
DISASSEMBLY ILLUSTRATION . . . . . . . . . 14
. . . . . . . . . . . . . . . . . . . . . . . . . . . 21
. . . . . . . . 6
. . . . . 7
. . . . . . . . . . . . 23
Advertisement
Table of Contents
Related Manuals for Fujitsu ARY30LUAN
Summary of Contents for Fujitsu ARY30LUAN
-
Page 1: Table Of Contents
AIR CONDITIONER DUCT type (50Hz) Models Indoor unit Outdoor unit ARY30LUAN AOY30LNAWL ARY36LUAN AOY36LNAWL CONTENTS SPECIFICATIONS ..... . 1 OUTLINE AND DIMENSIONS ... . 2 REFRIGERANT SYSTEM DIAGRAM . -
Page 2: Specifications
SPECIFICATIONS NOISE LEVEL TYPE COOLING & HEATING 43.0 dB / 43.0 dB HIGH SPEED INDOOR UNIT INDOOR UNIT ARY30LUAN ARY36LUAN MED SPEED 41.0 dB / 41.0 dB ( cool / heat ) OUTDOOR UNIT AOY30LNAWL AOY36LNAWL 39.0 dB / 39.0 dB... -
Page 3: Outline And Dimensions
DIMENSIONS INDOOR UNIT (Unit : mm) 1,177 1,015 1,135 2006.08.21... - Page 4 OUTDOOR UNIT (Unit : mm) Air Flow 2006.08.21...
-
Page 5: Refrigerant System Diagram
REFRIGERANT SYSTEM DIAGRAM Heat exchanger 3-Way valve ( Indoor unit ) 3-Way valve (Small) (Large) Muffler Pressure Strainer switch Expansion valve 4-Way valve Strainer Heat exchanger ( Outdoor unit ) Cooling Heating Refrigerant pipe diameter Liquid : 3/8" (9.52 mm) Gas : 5/8"... -
Page 6: Circuit Diagram
CIRCUIT DIAGRAM INDOOR UNIT THEMISTOR (ROOM TEMP.) THEMISTOR (PIPE TEMP.) MAIN PCB TERMINAL REMOTE CONTROL UNIT OUTDOOR UNIT HIGH PRESSUR SWITCH CN90 COMPRESSOR TEMP. THERMISTOR BROWN CN64 BROWN CN400 CN42 CN40 CN200 OUTDOOR TEMP. THERMISTOR BLUE CN62 BLUE PIPE TEMP. THERMISTOR BLACK CN61 BLACK... -
Page 7: Indoor Pcb Circuit Diagram
INDOOR PCB CIRCUIT DIAGRAM CONTROLLER PCB ASSEMBLY ARY30LUAN : K03BZ-0501HSE-C1 ARY36LUAN : K03BZ-0502HSE-C1 POWER SUPPLY PCB K04CW-0405HSE-P0 CN104 CN105 B2B-XARK-1-A R15 - R17 5V 12V 14V B04B-PASK-1 DC SUPPLY 10K <1/10W> x 3 I C 1 JM103 WHITE UL1430 AWG22... -
Page 8: Outdoor Pcb Circuit Diagram
OUTDOOR PCB CIRCUIT DIAGRAM INVERTER ASSEMBLY AOY30LNAWL : EZ-006PHUE AOY36LNAWL : EZ-006MHUE EMI FILTER UL1015 AWG14 EMI FILTER POWER WHITE UL1015 UL1015 SOURCE AWG14 AWG14 AC220-240V BLACK BLACK UL1015 F200 50 / 60Hz AWG20 TLC 25A - 250V, B (250V 25A) UL1015 POWER SUPPLY PCB ASSEMBLY AWG20... - Page 9 CONTROLLER PCB ASSY AOY30LNAWL : K05CU-0601HUE-C1 AOY36LNAWL : K05CU-0600HUE-C1 CN200 B2P4-VH-B DC HIGH VOLTAGE WHITE FH200 FH201 CURRENT DETECTION CIRCUIT DC VOLT I N PFC5000 F201 D12 1SS355 -0502 C210 R601 1.0K VOLTAGE LOCK OUT CIRCUIT I C5 3A <TSCR> <1/10W>...
- Page 10 TRANSISTOR PCB ASSEMBLY ( I P M ) K05CZ-0503HUE-TR0 DB CIRCUIT ORANGE TM101 W306 D100 BLACK BROWN WHITE D25XB60 TM102 TM301 W301 YELLOW C306 <HCP> CN303 E302 POWER-G B2B-XH-AM BLUE WHITE 195K <RN - 1/2W> x 6 TM302 BL02Rn1 W307 C302 BLACK L300...
- Page 11 POWER SUPPLY PCB ASSEMBLY K05CW-0501HUE-FL0 CT OUT ORANGE GRAY PTC OUT FILTER CIRCUIT ORANGE R100 ZPR0RCH400 PTC THERMISTOR BLACK R101 C104 - C105 ZPR0RCH400 PTC THERMISTOR VA100 0.033 470V <YE> <TNR> ORANGE VA101 0.022 L102 C109 - C110 470V N200500K1D7C 1000P <E>...
- Page 12 CAPACITOR PCB ASSY K05FB-0500HUE-P0 SMOOTHING CIRCUIT 660 / 450V x 4 WHITE YELLOW C202 C200 C201 C203 R200 220K <2W> VIOLET BLUE 2006.08.16...
-
Page 13: Error Contents
ER R OR C ON TE N TS ( indoor unit ) Error code Error contents CAUTION Communication error Supply power to the crankcase heater for at least (Indoor unit remote controller) 12 hours before the start of operation in winter. Communication error (Indoor unit outdoor unit) - Page 14 ERROR CONTENTS (outdoor unit) CAUTION SPECIAL INSTALLATION SETTING Always turn on the power 12 hours prior to the start of the operation in order to ensure compressor protection PUMP DOWN (Refrigerant collecting operation) Perform the following procedures to collect the refrigerant when moving 1.
-
Page 15: Disassembly Illustration
DISASSEMBLY ILLUSTRATION INDOOR UNIT Insulation Control Box Insulation Insulation 2006.08.21... - Page 16 INDOOR UNIT 2006.08.21...
- Page 17 INDOOR UNIT 2006.08.21...
- Page 18 OUTDOOR UNIT 2006.08.21...
- Page 19 OUTDOOR UNIT 2006.08.21...
- Page 20 OUTDOOR UNIT 2006.08.21...
- Page 21 OUTDOOR UNIT DISCHARGE TEMP THERMISTOR CONNECTOR : ORANGE OUTDOOR TEMP THERMISTOR CONNECTOR : BLUE COMPRESSOR TEMP THERMISTOR CONNECTOR : GREEN HEAT EXCHANGER THERMISTOR CONNECTOR : RED PRESSURE SWITCH WIRE CONNECTOR : RED 2006.08.21...
-
Page 22: Parts List
PARTS LIST INDOOR UNIT Part No. Ref. Ord. Description Q'ty ARY30LUAN ARY36LUAN Control Cover-A Sub Assy 9374516018 9374516018 Bracket Motor Assy 9374230013 9374230013 Casing B 9374234011 9374234011 Sirocco Fan Assy 9356531022 9356531022 Rubber 313659068604 313659068604 Bracket (pipe) Sub Assy 9374209019... - Page 23 OUTDOOR UNIT Part No. Ref. Ord. Description AOY30LNAWL AOY36LNAWL Q'ty Top Panel Sub Assy 9374417032 9374417032 Front Panel 9374094066 9374094066 Fan Guard 9374330010 9374330010 Grip Side 9374173013 9374173013 Service Panel Sub Assy 9374415052 9374415052 Right Panel Sub Assy 9374416127 9374416127 Emblem Rear 9351355005 9351355005...
-
Page 24: Standard Accessories
STA N D A R D A C C ESS OR IES The following installation parts are furnished. Use them as required. INDOOR UNIT ACCESSORIES Name and Shape Q'ty Application Name and Shape Q'ty Application Hanger For suspending the indoor Binder For fixing the drain hose unit from ceiling... -
Page 25: Connection Pipe Requirement
WARNING For the air conditioner to operate satisfactorily. install it as outlined in this installation instruction sheet. Connect the indoor unit and outdoor unit with the room air conditioner piping and cords available standards parts. This installation instruction sheet describes the correct connections using the installation set available from our standard parts. Installation work must be performed in accordance with national wiring standards by authorized personnel only. - Page 26 0608G3120...
