A local telephone company may make changes in its communications facilities or procedure. If these changes could reasonably be expected to affect the use of the KM555 or compatibility with the net work, the telephone company is required to give advanced written notice to the user, allowing the user to take appropriate steps to maintain telephone service.
Page 5
1. Introduction D. Maintenance Limitations Maintenance limitations on the KM555 must be performed only by the LGE or its authorized agent. The user may not make any changes and/or repairs expect as specifically noted in this manual. Therefore, note that unauthorized alternations or repair may affect the regulatory status of the system and may void any remaining warranty.
Page 24
3. BB Circuit Technical brief 3.2.5 GPIO map Over a hundred allowable resources, KM555 is using as follows except dedicated to SIM and Memory. KM555 GPIO(General Purpose Input/Output) Map, describing application, I/O state, and enable level, is shown in below table [Table 3.2.5-1] S-Gold®3H GPIO pin Map...
Page 36
3. BB Circuit Technical brief 3.3.2 Charging control - KM555 uses external charging IC which is BQ25040. Charging method : CC-CV Charger output voltage : 5.1 V Charging time : 2h 20m Charging current : 620 mA CV voltage : 4.2 V...
3. BB Circuit Technical brief 3.5 SIM Interface KM555 supports 1.8V & 2.9V plug in SIM. SIM_IO, SIM_CLK, SIM_RST ports are used to communicate with S-Gold3H-LC and the SIM power supply enabled by PMIC. SIM Interface SIM_CLK : SIM card reference clock...
Page 52
[Figure3.14] shows the WLAN system architecture in the KM555 3.13.2 Bluetooth The KM555 provides the Bluetooth 2.1 specification. The Bluetooth module is the optimal solution for any voice or data application that requires the Bluetooth SIG standard Host Controller Interface (HCI) using a high-speed UART and PCM.
4. RF Circuit Technical Brief [Figure 4.2.5-3] KM555 Front End Control Logic Table 4.3 WCDMA Part The single-chip transceiver is designed to fulfill the W-CDMA UTRA FDD system requirements for bands I, II, III, IV, V, VI and IX. It contains all active circuits required to simultaneously modulate an analog W-CDMA I/Q signal to the TX RF frequency and demodulate a RX RF W-CDMA signal to an I/Q baseband signal.
