with Indoor/Outdoor Temperature
--------------------
-------------------------
Wireless Rain Station
Table Of Contents
-----------------
------------
-------------
----
-------
---------------
--------
-------
--------------
------------------
1
2
(365 days maximum) -----------
2
4
5
5
---------------------------
6
7
9
9
9
10
11
-
Canada Statement -------------- 17
Model: 724-1710v2
Instructional Manual
Current Date: 070715
----------------------
----------
-----------
----------
----------
----------
------------------
11
12
----
12
12
-
12
13
13
-
13
13
---
14
15
15
16
Advertisement
Table of Contents
Related Manuals for La Crosse Technology 724-1710v2
Summary of Contents for La Crosse Technology 724-1710v2
-
Page 1: Table Of Contents
(365 days maximum) ----------- ------------ TX23R Rain Sensor Clear Daily History Records ------------- ---- TX23T Temperature Sensor Time Alarm ---- ---------------------- 724-1710v2 Rain Station Activate/Deactivate Time Alarm ------- LCD Features Snooze --------------------------- -------------------- Button Functions Search for Rain Sensor ----------... -
Page 2: Button Location
Button Location Front Buttons 1. Front View Time Settings Alarm Snooze Rain Alert History Rain Back View Back Buttons Daily History/Clear TX Search Page | 1 724-1710v2 www.lacrossetechnology.com/support... -
Page 3: Assembly And Setup
Tabs either end of funnel portion Base Rocker Tabs for Battery Compartment 1. Press the two tabs on each end of the rain sensor and lift off the funnel portion. Push both white tabs on each side 724-1710v2 www.lacrossetechnology.com/support Page | 2... - Page 4 3. Insert 2 “AA” Alkaline batteries below the rocker of the TX23R rain sensor. Two “AA” Batteries 4. Position the battery compartment over base and press down so all four tabs lock in place. Make sure the alignment tab is facing the arrow on the base. Page | 3 724-1710v2 www.lacrossetechnology.com/support...
-
Page 5: Tx23T Temperature Sensor
TX23T Temperature Sensor 1. Insert batteries into the outdoor temperature sensor. Observe the correct polarity. 2. The red LED will flash during transmission. 2 “AA” Batteries 724-1710v2 www.lacrossetechnology.com/support Page | 4... -
Page 6: 724-1710V2 Rain Station
724-1710v2 Rain Station 1. Insert batteries into the rain station. Observe the correct polarity. 2. Leave the rain station and sensors sit 5 -10 feet apart for 15 minutes to lock in both sensors. 3. Both the temperature and the rain sensor should appear on the rain station in the first minute. -
Page 7: Button Functions
Press to view rain alert Alerts Mode: Press to arm/disarm rain alert RAIN Button (History) Normal Mode: Hold to search for rain sensor. Press to view current rain readings. (1HR, 24HR, 7 DAYS, MONTH, TOTAL) 724-1710v2 www.lacrossetechnology.com/support Page | 6... -
Page 8: Settings
4. Date 5. Hour 6. Minutes 7. Language (English/Spanish/French) 8. °F/°C 9. MM/IN (millimeters or inches for rain) Note: The rain station will default out of set mode when no buttons are pressed for 20 seconds. Page | 7 724-1710v2 www.lacrossetechnology.com/support... - Page 9 2. Select Year 1. 12Hr (default) or 24Hr time 3. Select Month 4. Select Date 5. Select Hour 6. Select Minutes 7. Set Language 8. Set Fahrenheit or Celsius 9. Select Inches or Millimeter 724-1710v2 www.lacrossetechnology.com/support Page | 8...
-
Page 10: Rainfall Alert (24 Hour)
When the alert value is reached, the alarm will beep for 5 seconds, then once each minute. Press any button to stop the alert from sounding Low Battery Indicators Rain sensor batteries Rain station batteries Temperature sensor batteries Page | 9 724-1710v2 www.lacrossetechnology.com/support... -
Page 11: Rain Readings And Cylinder Graph
TOTAL Total rainfall since powered on or reset. Note: As time passes without rain, the 1 hour, 24 hour, and 7 day rain totals will count down to zero. 724-1710v2 www.lacrossetechnology.com/support Page | 10... -
Page 12: Clear Current Rainfall Readings
8. The Date will flash. Press the ARROW buttons to select the Date. 9. Press SETTINGS button to confirm and exit. Note: If no buttons are pressed for 20 seconds, the rain station will default to normal mode. Page | 11 724-1710v2 www.lacrossetechnology.com/support... -
Page 13: Clear Rainfall Daily History Records
When the alarm sounds, press the SNOOZE button to silence the alarm for 10 minutes. The snooze function may be repeated. Hold the SNOOZE to exit snooze mode. Press any other button to stop the alarm for one day. 724-1710v2 www.lacrossetechnology.com/support Page | 12... -
Page 14: Search For Rain Sensor
3. The maximum wireless transmission range to the rain station is over 300 feet (91 meters) in open air, not including walls or floors. 4. Be sure the outdoor sensor is mounted vertically. Page | 13 724-1710v2 www.lacrossetechnology.com/support... -
Page 15: Specifications
(108 x 38 x 99 mm) Dimensions TX23R Sensor: 6.00” L x 5.10” W x 4.21” H (152 x 130 x 107mm) TX23T Sensor: 1.67” L x 0.79” W x 6.1” H (42.5 x 20 x 155 mm) 724-1710v2 www.lacrossetechnology.com/support Page | 14... -
Page 16: Care And Maintenance
Remove expired batteries promptly. Warranty and Support La Crosse Technology, Ltd. provides a 1-year limited time warranty (from date of purchase) on this product relating to manufacturing defects in materials & workmanship. Before returning a product, please contact our friendly customer... -
Page 17: Fcc Statement
This booklet may contain errors or misprints. The information it contains is regularly checked and corrections are included in subsequent editions. We disclaim any responsibility for any technical error or printing error, or their consequences. All trademarks and patents are recognized. 724-1710v2 www.lacrossetechnology.com/support Page | 16... -
Page 18: Canada Statement
Canada. Son fonctionnement est soumis aux deux conditions suivantes:( 1 ) Ce dispositif ne peut causer d'interférences; et( 2 ) Ce dispositif doit accepter toute interférence, ycompris les interférences qui peuvent causerun mauvais fonctionnement de l'appareil. Page | 17 724-1710v2 www.lacrossetechnology.com/support...
