FRONT LOADING WASHING MACHINE
Suited model:
MANUAL CODE：
Front Load Washer
MODEL：HBF600T
Service Manual
HBF500T
Features：
●Free selection for cold or hot washing
●Selecting washing temperature according
to the type of fabrics
●
15 washing programs
●
Spin speed 500rpm
●
Capacity—5kg
●
HBF Aesthetic design,elegant and beautiful
Haier Group
Model:HBF600T
No.20050508001
Advertisement
Table of Contents
Troubleshooting
Related Manuals for Haier HBF600T
Summary of Contents for Haier HBF600T
-
Page 1: Service Manual
Front Load Washer Model:HBF600T MODEL：HBF600T FRONT LOADING WASHING MACHINE Service Manual Suited model: HBF500T Features： ●Free selection for cold or hot washing ●Selecting washing temperature according to the type of fabrics ● 15 washing programs ● Spin speed 500rpm ●... -
Page 2: Table Of Contents
Front Load Washer Model:HM500T Contents 1、 Content------------------------------------------------------------------------------------------1 2、 Product code illumination and series introduction------------------------------------2 3、 Features ----------------------------------------------------------------------------------------3 4、Specification --------------------------------------------------------------------------------4-5 5、 Safety caution ------------------------------------------------------------------------------6-7 6、Installation ----------------------------------------------------------------------------------8-9 7、 Net dimention --------------------------------------------------------------------------------10 8、 Names of the parts--------------------------------------------------------------------------11 9、 Functions----------------------------------------------------------------------------------12-13 10、Function Schedule------------------------------------------------------------------------14 11、TroubleShooting-----------------------------------------------------------------------15-20 11、 Wiring Circuit -------------------------------------------------------------------------------21 13、... -
Page 3: Product Code Illumination And Series Introduction
Front Load Washer Model:HBF600T Product code illumination and series introduction model code rule description Model identification： HBF 600 T A：Serial code B：Max spin speed C：Temprature adjustive Examples： HBF600T It represents HBF series appearance，600rpm spin speed,temprature is also adjustive.Outer drum is... -
Page 4: Features
Front Load Washer Model:HBF600T Features： ● Free selection for cold or hot washing Selecting washing temperature according to the type of fabrics ● 16 washing programs, ● Three types of laundry: cotton, synthetic and wool ● Spin speed 500rpm ● Changeable washing function: cold wash and hot wash,No soak and economic wash ●... -
Page 5: Specification
Front Load Washer Model:HM500T Specifications Front loaders washing machines, push button opening door HBF600T(EC4885) Last update 2002-5-13 Product identification Description of appliance Washing machine Type of appliance (FS = standing, BI = built-in) Supplier own brand Haier Supplier bar code... - Page 6 Front Load Washer Model:HM500T Adjustable feet n° Safety systems Auto door lock Motor overheating protection No heating without water Auto water cool-down (before drain 90°C boiled water) Water return protection Acqua Stop kit Child protection Programs 1) Strong action /cotton cycles n°...
-
Page 7: Safety Caution
Front Load Washer Model:HBF600T Safety caution：... - Page 8 Front Load Washer Model:HBF600T...
-
Page 9: Installation
Front Load Washer Model:HBF600T Installation... - Page 10 Front Load Washer Model:HBF600T...
-
Page 11: Net Dimention
Front Load Washer Model:HBF600T Net dimention height: 850mm / width: 595mm / depth: 520mm... -
Page 12: Names Of The Parts
Front Load Washer Model:HBF600T Names of the parts... -
Page 13: Functions
Front Load Washer Model:HBF600T Functions... - Page 14 Front Load Washer Model:HBF600T...
-
Page 15: Function Schedule
Front Load Washer Model:HBF600T Function Schedule... -
Page 16: Troubleshooting
Front Load Washer Model:HBF600T Troubleshooting I .The appliance does not work. Possible causes 1.The socket is not the required one or the connection is loose. 2.The door is not properly closed or the switch of micro delay is in poor contact. -
Page 17: Troubleshooting
Front Load Washer Model:HBF600T 1.Repeat the following steps. 1).Check whether the drainage pipe is twisted or blocked. The appropriate height of the water drainage outlet should be from 80 to100cm. 2).Check whether the program is properly selected. 3).Connect the power cable to the drainage pump to check whether the operation is normal. If not, make necessary replacement. - Page 18 Front Load Washer Model:HBF600T VI .The water level is too high. Possible causes 1.Gas leakage at pressure system of water supply. 2.The pressure switch is broken. Troubleshooting 1.Check whether the pipeline of pressure system is blocked or there is gas leakage. The pressure system...
- Page 19 Front Load Washer Model:HBF600T 4).Cushion of sight window 5).Hose connecting outer cylinder to pump 6).Drainage pump 7).Gas-collecting valve 8).Dispenser 9)Condenser 10) Hose connecting condenser to hose of outer cylinder 2.For leakage resulting from the welding defect of outer cylinder, replace the outer cylinder.
- Page 20 Front Load Washer Model:HBF600T XII .No function or malfunction of program controller Possible causes 1.The motor of program controller loses or the stub is sealing-off. 2.The knob of program controller is stuck. 3.Poor contact of wiring of program controller. 4.Poor contact at inner contacts of program controller (even after the all the plug wires are tightened.) Troubleshooting 1.Reassemble the motor of program controller and make spot welding of the stubs (the operation of...
- Page 21 Front Load Washer Model:HBF600T 4).Brackets are available for drainage pipe arrangement. Note: The water outlet should not be submerged in water. 2.Filling hose 1).Connect one end of the filling hose to the faucet and the other to the water electromagnetic valve of the washer.
-
Page 22: Wiring Circuit
Front Load Washer Model:HBF600T Wiring circuit... -
Page 23: Exploded View
Front Load Washer Model:HBF600T Exploded view... - Page 24 Front Load Washer Model:HBF600T...
- Page 25 Front Load Washer Model:HBF600T...
-
Page 26: List Of Parts
Front Load Washer Model:HBF600T List of part No. in exploded Spare parts number Spare parts description in english Model Remark view 0020202586 distribution handle HBF600T 0020202589 distribution box HBF600T 0020200717 the cover of glass HBF600T 00215200024102 the axis of porthole handle HBF600T ... - Page 27 HBF600T 0024000025 temperature selector HBF600T 00211320015200 clip HBF600T 00212500011100 sponge of the pipe for pressure switch HBF600T 0020400505 Micro delay HBF600T ★ 00215200015200 cable fixing stand(black) HBF600T 00216810220111 capacitance fastening screw HBF600T ...
- Page 28 Front Load Washer Model:HBF600T 00215000008800 fastening bolt for U-BOLT HBF600T 0020801982 drum assembly HBF600T 0020102351 spring HBF600T 00214800503000 spring support HBF600T 0020102731 the bracket of upper weight HBF600T 00221152310002 fastening nut for upper weight HBF600T 0020300477 upper counterweight HBF600T 00221152310002...
- Page 29 Front Load Washer Model:HBF600T Sincere Forever Haier Group Tel:86-532-8938356 Web site:http://www.haier.com...
