Fujitsu ASU24RLXQ Service Manual

Split type room air conditioner wall mounted type
Hide thumbs Also See for ASU24RLXQ:
Table of Contents

Advertisement

Quick Links

See also: Operating Manual
SPLIT TYPE
ROOM AIR CONDITIONER

WALL MOUNTED

Indoor unit
ASU24RLXQ
ASU30RLXQ
CONTENTS
SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . 1
DIMENSIONS . . . . . . . . . . . . . . . . . . . . . . . . . 2
CIRCUIT DIAGRAM . . . . . . . . . . . . . . . . . . . 5
ERROR CONTENTS . . . . . . . . . . . . . . . . .
PART (Indoor unit) . . . . . . . . . . . . . . . . . . . . 14
PARTS (Outdoor unit) . . . . . . . . . . . . . . . . . 18
STANDARD ACCESSORIES . . . . . . . . . .
type
Outdoor unit
AOU24RLXQ
AOU30RLXQ
6
9
13
22

Advertisement

Table of Contents
loading

Related Manuals for Fujitsu ASU24RLXQ

Summary of Contents for Fujitsu ASU24RLXQ

  • Page 1: Table Of Contents

    SPLIT TYPE ROOM AIR CONDITIONER WALL MOUNTED type Indoor unit Outdoor unit ASU24RLXQ AOU24RLXQ ASU30RLXQ AOU30RLXQ CONTENTS SPECIFICATIONS ..... 1 DIMENSIONS .

  • Page 2: Specifications

    SPECIFICATIONS ELECTRICAL DATA FAN MOTOR POWER SOURCE INDOOR UNIT ASU30RLXQ 208 V / 230 V ASU24RLXQ High OUTDOOR UNIT 1,480 r.p.m. AOU24RLXQ AOU30RLXQ 24,200 BTU/h 30,600 BTU/h Middle 1,300 r.p.m. COOLING CAPACITY INDOOR UNIT 7.10 kW 9.00 kW 1,100 r.p.m.
  • Page 3 OUTLINE AND DIMENSIONS INDOOR UNIT Unit : inch (mm) 12-5/8" (320) 39-1/4" (998) 9" (228) 2008.02.06...
  • Page 4 OUTDOOR UNIT Unit : inch (mm) 1/2" 13" (330) (12) 35-1/2" (900) 3"(77) 1-1/4" (31) 15-3/4" (400) Air Flow 25-5/8" (650) 5-3/4" (147) 6-3/4" (170) 2008.01.30...

  • Page 5: Refrigerant System Diagram

    REFRIGERANT SYSTEM DIAGRAM Heat exchanger (Indoor unit) 3-Way valve 2-Way valve High Muffler pressure Switch Compressor Strainer 4-Way valve Expansion valve -accumulator Strainer Heat exchanger (Outdoor unit) Refrigerant direction Cooling Heating Refrigerant pipe diameter Liquid : 3/8" (9.52 mm) Gas : 5/8" (15.88 mm) 2008.02.06...

  • Page 6: Circuit Diagram

    CIRCUIT DIAGRAM INDOOR UNIT OUTDOOR UNIT CONTROLLER PCB ASSY ( MAIN PCB ) HIGH PRESSUR CN90 BLUE SWITCH YELLOW CONTROLLER PCB ASSY ( MAIN PCB ) WHITE THERMISTOR TEST Wire : BROWN BLACK 9707843019 CN64 BROWN (COMPRESSOR) THERMISTOR CN42 CN200 CN400 CN40 ( PIPE TEMP.

  • Page 7: Indoor Pcb Circuit Diagram

    INDOOR PCB CIRCUIT DIAGRAM INVERTER ASSEMBLY EZ-00716HSE TERMINAL THERMAL FUSE OUTDOOR UNIT SERIAL EARTH TERMINAL EARTH PANEL SWITCH INDICATOR PCB ASSEMBLY K05CY-0500HSE-D0 22007 22007 22007 CN19 XMR-05V B04B-XASK-1-A CN19-1 WHITE CN19-2 YELLOW CN19-3 CN19-4 BLUE CONTROLLER PCB ASSEMBLY ( MAIN PCB ) AIR CLEAN B05B-XASK-1AA K05CX-0709HSE-C1...
  • Page 8 INDOOR UNIT CONTROLLER PCB ASSEMBLY ( MAIN PCB ) K05CX-0709HSE-C1 SERIAL H I C 340V MY064 0.01 <ECQE> POWER D12 D2F20U D9 D1FL20U R79, R81 - R84 D10 D1FL20U I C 2 6 10K <1/10W> x 5 GK-LV3011E2 T1-12 100K 5.6K <RS-2W>...
  • Page 9 INDOOR UNIT INDICATOR PCB ASSEMBLY K05CY-0500HSE-D0 CN201 07 JB20 / PAP 1061 L=230 D201 SLR-325VC D202 SLR-325MC GREEN C201 ORANGE <F> D203 SLR-325DC I C201 R201 GP1UM261R <1/4W> + C202 2007.11.09...

  • Page 10: Outdoor Pcb Circuit Diagram

    OUTDOOR PCB CIRCUIT DIAGRAM INVERTER ASSMBLY AOU24RLXQ : EZ-007PHUE AOU30RLXQ : EZ-007RHUE F200 UL3271 TLC 25A-250V, B AWG14 WHITE (250V 254) POWER SOURCE UL3271 UL3271 230 - 208V AWG14 AWG14 EMI FILTER BLACK BLACK 60Hz UL3271 TM101 AWG20 UL3271 AWG14 ORANGE UL3271 AWG20...
  • Page 11 OUTDOOR UNIT CONTROLLER PCB ASSEMBLY ( MAIN PCB ) AOU24RLXQ : K05CU-0702HUE-C1 AOU30RLXQ : K05CU-0703HUE-C1 CN200 B2P4-VH-B DC HIGH VOLTAGE WHITE CURRENT DETECTION CIRCUIT DC VOLT I N D12 1SS355 F201 C210 R601 1.0K FJL 250 3.15 (EM) VOLTAGE LOCK OUT CIRCUIT I C5 <1/10W>...
  • Page 12 DB CIRCUIT TM101 OUTDOOR UNIT TRANSISTOR PCB ASSEMBLY ( I P M ) K05CZ-0700HUE-TR0 TM102 BLACK D100 D25XB60 W306 WHITE W301 YELLOW C306 R300 - R302 0.035 <5W> x 3 <HCP> W302 POWER-G CN303 POWER-G BLUE B2B-XH-AM 195K <RN-1/2W> 1% x 6 I PM-G WHITE W307...
  • Page 13 OUTDOOR UNIT CT OUT POWER SUPPLY PCB ASSEMBLY ORANGE BLACK PTC OUT GRAY K05CW-0703HUE-FL0 ORANGE L101 L102 VA100, VA101 RCH3818 - 022PF07 N200500K1D7C 470V <TNR> ORANGE BLACK C104 0.033 C106 C103 C100 <YE> K101 C108 DW12D1 <LE> C105 <LE> <LE> <LE>...

  • Page 14: Error Contents

    ERROR CONTENTS Wired LED display remote Error contents Error Operation Timer Air clean control indication 2 flash Serial signal (reverse) error, at operation start up 3 flash Serial signal (reverse) error, during oeration Serial signal error Normal 4 flash Serial signal (forward) error, at operation start up 5 flash Serial signal (forward) error, during operation 8 flash...

  • Page 15: Parts (Outdoor Unit)

    PARTS INDOOR UNIT Ref. Descriprion Part number Front Panel Total Assy 9315335111 Front Panel 9314991042 Intake Grille Assy 9315336088 Air Filter 9315014016 Clamper Grille 9306755010 Receiver Window 9315010018 Air Cleaner Assy 9313148034 2008.02.08...
  • Page 16 INDOOR UNIT Ref. Descriprion Part number Evaporator Assy 9315347015 Evaporator Assy B 9315349019 Connection Pipe Assy 9315355010 Distributor Assy 9316794009 Water Seal 9315251015 Evaporater Holder R 9314994012 Evaporater Holder L 9314995019 Rear Bracket 9315022011 Filter Guide 9315013019 Filter Guard 9315411013 Crossflow Fan Assy 9315024015 Bearing C Assy...
  • Page 17 INDOOR UNIT Ref. Descriprion Part number Casing Cover B 9315016010 Casing Cover R 9315018014 Casing Cover L 9315017017 Casing Cover F 9315019011 Drain Hose Assy 9315769015 Drain Cap 9367677009 Diffuser U 9315002013 Diffuser Z 9315003010 Spring C 9314142017 Louver U 9315000019 Louver Z 9315001016...
  • Page 18 INDOOR UNIT Ref. Descriprion Part number Control Box 9314996023 Control Cover 9314997020 Controller PCB Assy 9707090444 Terminal 9900447014 Switch Micro 9900286026 Motor Case 9314998027 DC Brushless Motor 9602163021 Motor Cushion N 9312979011 Motor Cushion NR 9313168018 Display Assy 9707209020 Indicator PCB Assy 9707210019 Step Motor (Diffuser) 9900384029...
  • Page 19 PARTS OUTDOOR UNIT Ref. Description Part number Top Panel Sub Assy 9374417032 Front Panel 9374094066 Fan Guard 9374330010 Grip Side 9374173013 Right Panel 9374095148 Grip 9374172016 Service Panel Sub Assy 9374415052 Emblem Rear 9351355005 Panel Top Assy 9389406106 Protective Net 9375381011 2008.02.08...
  • Page 20 OUTDOOR UNIT Ref. Description Part number 11 Base Assy 9374166206 12 Separate Wall Sub Assy 9374413133 13 Condenser A Assy 9374433148 14 Fan Motor 9602114016 15 Propeller Fan Assy 9366378020 -- Drain Assy 9303029022 -- Drain Cap 313166024302 2008.02.08...
  • Page 21 Ref. Description Part number Accumulator Support Assy 313986353804 3-Way Valve Assy 9377958013 3-Way Valve Assy 9377959010 OUTDOOR UNIT Compressor Assy 9372558126 Check Joint Assy 9372802038 Accumulator 9385005006 4-Way Valve 9900164010 Solenoid 9900165079 Pressure Switch 9900186012 Inlet Pipe (Cond) A Assy 9373461067 Outlet Pipe (Cond) A Assy 9374266104...
  • Page 22 OUTDOOR UNIT Ref. Description Part number 41 Case (Inverter) 9375314019 42 Case (PCB) Assy 9375316013 43 Controller PCB Assy (24) 9707121391 43 Controller PCB Assy (30) 9707121407 44 Power Supply PCB Assy 9707128178 (K05CW-0703HUE-FLO) 45 Capacitor PCB Assy 9707257038 (K05FB-0701HUE-P0) 46 TR PCB Assy (IPM) 9707125139 47 ACTPM...

  • Page 23: Standard Accessories

    STANDARD ACCESSORIES INDOOR UNIT OUTDOOR UNIT Name and Shape Part number Name and Shape Part number Wall hook bracket Drain pipe 9315023018 9301102000 Drain cap Remote control 313166024302 9315027146 Remote control holder 9305642045 Battery (penlight) 0600185527 Cloth tape 9310519004 Tapping screw (big) 0700076046 Tapping screw (small) 0700019036...
  • Page 24 0801G3384...

This manual is also suitable for:

Asu30rlxqAou24rlxqAou30rlxq
