OPERATOR'S MANUAL
IMPORTANT: READ SAFETY RULES AND INSTRUCTIONS CAREFULLY
Warning:
This unit is equipped with an internal combustion engine and should not be used on or near any unimproved forest-
covered, brush-covered or grass-covered land unless the engine's exhaust system is equipped with a spark arrester meeting
applicable local or state laws (if any). If a spark arrester is used, it should be maintained in effective working order by the operator.
In the State of California the above is required by law (Section 4442 of the California Public Resources Code). Other states may have
similar laws. Federal laws apply on federal lands. A spark arrester for the muffler is available through your nearest engine authorized
service dealer or contact the service department, P.O. Box 361131 Cleveland, Ohio 44136-9722.
WHITE OUTDOOR PRODUCTS COMPANY P.O. BOX 361131 CLEVELAND, OHIO 44136-9722
PRINTED IN U.S.A.
Log Splitter
33-Ton
Model Number
24AD595C190
770-10041D.fm
FORM NO.
(7/01)
Advertisement
Table of Contents
Related Manuals for White Outdoor 24AD595C190
Summary of Contents for White Outdoor 24AD595C190
-
Page 1: Log Splitter
Federal laws apply on federal lands. A spark arrester for the muffler is available through your nearest engine authorized service dealer or contact the service department, P.O. Box 361131 Cleveland, Ohio 44136-9722. WHITE OUTDOOR PRODUCTS COMPANY P.O. BOX 361131 CLEVELAND, OHIO 44136-9722 770-10041D.fm PRINTED IN U.S.A. -
Page 2: Table Of Contents
A sample model plate is explained below. For future reference, please copy the model number and the serial number of the equipment in the space below. (Model Number) (Serial Number) Copy the model number here: WHITE OUTDOOR Copy the serial number here: PRODUCTS COMPANY P.O. BOX 361131 CLEVELAND, OHIO 44136... -
Page 3: Important Safe Operation Practices
SECTION 1: IMPORTANT SAFE OPERATION PRACTICES WARNING: This symbol points out important safety instructions which, if not followed, could endanger the personal safety and/or property of yourself and others. Read and follow all instructions in this manual before attempting to operate this machine. Failure to comply with these instructions may result in personal injury. - Page 4 9. To avoid personal injury or property damage use 10. For logs which are not cut square, the least square extreme care in handling gasoline. Gasoline is end and the longest portion of the log should be extremely flammable and the vapors are explosive. placed toward the beam and wedge, and the Serious personal injury can occur when gasoline is square end placed toward the end plate.
-
Page 5: Assembling Your Log Splitter
8. For your safety, replace all damaged or worn parts 9. Do not alter this machine in any manner, alterations immediately with original equipment such as attaching a rope or extension to the control manufacturer’s (O.E.M.) parts only. “Use of parts lever, or adding to the width or height of the wedge which do not meet the original equipment may result in personal injury. - Page 6 WARNING: Disconnect the spark plug wire • Insert hex bolts through upper holes in the bottom and ground against the engine to prevent of the mounting brackets and adjustable jack stand. unintended starting. Secure with lock washers and hex nuts. •...
- Page 7 Reservoir Lock Tank Fender Washer Bolts Bolts Tongue Flat Washer Reservoir Flat Tank Washer Nuts Lock Washers Wheel Figure 5 Hex Slotted Attaching Beam To Reservoir Tank (See Figure 6) • For shipping purposes, the pressure hose is Hub Cab Cotter Pin attached to the pump on the engine and to the control valve on the cylinder.
- Page 8 Attaching Engine-Pump Assembly • Remove the protective cap from the fitting on the bottom of the pump (some oil may flow from pump). (See Figure 7) Attach the end of the suction hose to the fitting on • Place the engine and pump assembly in position on the bottom of the pump.
- Page 9 • Attach the second cradle support bracket to the • Fill the reservoir tank with Dexron III automatic same side of the beam in the same manner. transmission fluid or 10W AW hydraulic fluid. • Place one log cradle over the support brackets and •...
-
Page 10: Know Your Log Splitter
SECTION 3: KNOW YOUR LOG SPLITTER WARNING: Be familiar with all controls Vertical: The vertical position lock is located next to the and their proper operation. Know how to oil filter. stop the machine and disengage them Horizontal: The horizontal position lock is part of the quickly. - Page 11 Never: WARNING: extreme care when handling gasoline. Gasoline is extremely • Use when fluid is below 20° F or above 150° F. flammable and the vapors are explosive. • Use a solid engine /pump coupling. Never fuel machine indoors or while the •...
-
Page 12: Adjusting Your Log Splitter
• Attach hitch coupler to a class I or higher hitch with a 1-7/8” ball on the towing vehicle, making certain to latch securely. • Connect the safety chains to the towing vehicle. Vertical • Do not tow faster than 45mph and check local, Beam Lock state, and federal requirements before towing on any public road. -
Page 13: Maintaining Your Log Splitter
SECTION 6: MAINTAINING YOUR LOG SPLITTER Engine WARNING: Before cleaning, lubricating, repairing, or inspecting, disengage the Refer to the separate engine manual for all engine control lever and stop engine. Disconnect maintenance instructions. the spark plug wire and ground it against the engine to prevent unintended starting. -
Page 14: Storing Your Log Splitter
Storing Your Log Splitter PUMP • Clean the unit thoroughly. • Wipe equipment with an oiled rag to prevent rust. Screw • Refer to engine manual for correct engine storage instructions Steel Nylon Coupling • Store unit in a clean, dry area. Do not store next to “Spider”... -
Page 15: Conditions That Will Void Warranty
SECTION 7: CONDITIONS THAT WILL VOID WARRANTY • Failure to maintain proper fluid level in reservoir will • Improper beam lubrication will cause premature cause permanent damage to pump by allowing air wear and looseness. Lubricate the beam regularly. to be drawn into pump. Fluid will become foamy. Lack of lubrication will void your warranty. - Page 16 HYDRAULIC TROUBLESHOOTING Problem Cause Remedy Cylinder rod will not move 1. Broken drive shaft. 1. See authorized service dealer. 2. Shipping plugs left in hydraulic 2. Disconnect hydraulic hoses, remove hoses. shipping plugs, reconnect hoses. 3. Set screws in coupling not adjusted 3.
- Page 17 Notes...
-
Page 18: Parts List
Model Number 24AD595C190... - Page 19 Model Number 24AD595C190 Ref. Ref. Part No. Part Description Part No. Part Description 781-0686 Log Tray Bracket 712-0123 Hex Nut 5/16-24 712-0431 Flanged Lock Nut 3/8-16 710-0409 Hex Cap Screw 5/16-24 x 1.75 781-0682 Log Tray 710-1253 Hex Cap Screw 5/16-24 x 5.25 710-3097 Carriage Bolt 3/8-16 x 1.0...
-
Page 20: P.o. Box
