Midland ALAN 95 D80 PLUS User Manual

ALAN 95 D80 PLUS

Your 80 channel Mobile CB represents the state-of-the art in high-tech engineering.
Designed for 80 FM-12 AMchannel
package is big in performance. Compact unit,
equipment, skillfully constructed from the finest components. The circuitry is all a solid -
state, mounted on rugged printed circuit boards. It is designed for many years of
reliable, trouble-free performance.Your mobile CB has a built 80 FM/12AM Channel
Phase-Locked Loop synthesizer circuit.
The PLL circuit achieves a new technique for generating all the required frequencies
with fewer crystals. The result is much tighter frequency control and superior reliability.

FUNCTION AND LOCATION OF THE CONTROLS

1. Antenna connector
With BNC connector type. For better results, use a telescopic antenna
2."Squelch" Control
For the maximum receiver sensivity, the control must be regulated exactly where the
receiver background noise disappears.
3. On/Off Volume Control
In ''off'' position your transceiver is off. Turn this control clockwise to switch on the unit.
Turn the knob clockwise a little more to set the audio level, until you get a comfortable
reception.
4.Multifunction backlighted display
This liquid crystal display has been projected to show the operative modality:
a. channel selected number( from 1 up 80)
b. the received signal strenght and the power of the transmitting signal
c. AM/FM mode
d. RX/TX:TX=transmit mode; RX=receive mode
e. SCAN function actived
f. EMG function actived
g. LOW function actived
h. "P": Save function actived
i. Lock: keyboard lock function actived
5. EMG button
Emergency channel. By pressing it, the unit
(emergency channel). The display will shows "EMG". It will not be possibile to change
accidentally the channel.
6. ''SCAN'' button
With this control, you can automatically seek for a busy channel.
Turn the Squelch clockwise until the background noise is no longer heard.
Press the ''SCAN'' button: the transceiver will scan automatically all the channels until a
carrier is being received.
Citizen Band Mobile operation, this compact
is a quality piece of electroni c
automatically skips to Channel 9
