Aiwa NSX-A222 Simple Manual
Compact disc / stereo cassette receiver
Hide thumbs
Also See for NSX-A222:
- Operating instructions manual (64 pages) ,
- Service manual (15 pages)
Related Manuals for Aiwa NSX-A222
Summary of Contents for Aiwa NSX-A222
- Page 1 NSX-A222 NSX-A223 NSX-S222 NSX-S333 COMPACT DISC / STEREO CASSETTE RECEIVER • TYPE U<A222/A223> LH<S222/S333> SIMPLE MANUAL • Replace this Service Manual with "Revision Publishing" when it is issued. S/M Code No 09–98C–312–6T1...
-
Page 2: Electrical Main Parts List
ELECTRICAL MAIN PARTS LIST - 1/8 NOTE: The characters in the suffix column indicate the part usage. LH(Lo) ....XX........A....U ......XX........B....LH(Hi) ....XX........C....KANRI REF.NO PARTS NO. DESCRIPTION SUFFIX 82-NF7-210-110 GUIDE,FL (*) ABC....8Z-NF9-201-010 GUIDE,OPE 1W ABC....8Z-NF9-202-010 GUIDE,OPE R .... - Page 3 ELECTRICAL MAIN PARTS LIST - 2/8 87-026-610-080 TR,KTC3198GR ABC....87-026-215-080 TR,DTC114YS ABC....87-026-610-080 TR,KTC3198GR ABC....87-026-610-080 TR,KTC3198GR ABC....87-A30-090-080 FET,2SK2541 ABC....87-A30-090-080 FET,2SK2541 ABC....87-A30-090-080 FET,2SK2541 ABC....87-026-287-080 TR,DTC143ES ABC....87-026-287-080 TR,DTC143ES ABC....87-026-287-080 TR,DTC143ES ABC....87-026-287-080 TR,DTC143ES ....87-026-287-080 TR,DTC143ES ABC....
- Page 4 ELECTRICAL MAIN PARTS LIST - 3/8 87-010-384-080 CAP, ELECT 100-25V ....87-010-384-080 CAP, ELECT 100-25V ....87-010-408-080 CAP, ELECT 47-50V AB....87-010-408-080 CAP, ELECT 47-50V AB....87-010-385-080 CAP, ELECT 220-25V ....87-010-394-080 CAP ELECT220-35V AB....87-010-409-080 CAP,E 220-50 SME ....87-020-465-080 DIODE,1SS133 (110MA) AB....
- Page 5 ELECTRICAL MAIN PARTS LIST - 4/8 87-010-403-080 CAP, ELECT 3.3-50V AB....87-010-544-080 CAP, ELECT 0.1-50V AB....87-A11-008-080 CAP,M 0.056-50 J DE AB....87-A11-008-080 CAP,M 0.056-50 J DE AB....87-A11-154-080 CAP,TC U 4700P-16 Z F AB....87-010-544-080 CAP, ELECT 0.1-50V AB....87-018-123-080 CAP, CER 220P-50V AB....
- Page 6 ELECTRICAL MAIN PARTS LIST - 5/8 87-020-465-080 DIODE,1SS133 (110MA) ..C....87-020-465-080 DIODE,1SS133 (110MA) ..C....87-020-465-080 DIODE,1SS133 (110MA) ..C....87-020-465-080 DIODE,1SS133 (110MA) ..C....87-020-465-080 DIODE,1SS133 (110MA) ..C....87-020-465-080 DIODE,1SS133 (110MA) ..C....87-020-465-080 DIODE,1SS133 (110MA) ..C....87-020-465-080 DIODE,1SS133 (110MA) ..C....87-020-465-080 DIODE,1SS133 (110MA) ..C....
- Page 7 ELECTRICAL MAIN PARTS LIST - 6/8 87-018-131-080 CAP, CER 1000P-50V ..C....87-018-131-080 CAP, CER 1000P-50V ..C....87-018-131-080 CAP, CER 1000P-50V ..C....87-010-374-080 CAP, ELECT 47-10V ..C....87-010-546-080 CAP, ELECT 0.33-50V ..C....87-010-546-080 CAP, ELECT 0.33-50V ..C....87-010-374-080 CAP, ELECT 47-10V ..C....
- Page 8 ELECTRICAL MAIN PARTS LIST - 7/8 87-A30-196-080 TR,2SC4115SRS AB....87-A70-061-010 VIB,XTAL 4.500MHZ CSA-309 AB....87-010-112-080 CAP, ELECT 100-16V ..C....87-010-248-080 CAP, ELECT 220-10V ..C....87-010-404-080 CAP, ELECT 4.7-50V ..C....87-018-131-080 CAP, CER 1000P-50V ..C....87-018-131-080 CAP, CER 1000P-50V ..C....87-018-131-080 CAP, CER 1000P-50V ..C....
- Page 9 ELECTRICAL MAIN PARTS LIST - 8/8 87-010-405-080 CAP, ELECT 10-50V ....87-010-405-080 CAP, ELECT 10-50V ....87-018-109-080 CAP, CER 22P-50V ....87-018-109-080 CAP, CER 22P-50V ....87-018-123-080 CAP, CER 220P-50V ....87-018-123-080 CAP, CER 220P-50V ....87-018-127-080 CAP, CER 470P-50V ....
-
Page 10: Mechanical Parts List
NOTE: The characters in the suffix column indicate the part usage. LH(Lo) ....XX........A....U ......XX........B....LH(Hi) ....XX........C....kanri REF.NO PARTS NO. DESCRIPTION SUFFIX 82-NE6-067-010 BADGE,AIWA 30N ABC....8Z-NF9-002-010 PANEL,TRAY H ABC....8Z-NF9-003-010 BOX,CASS 1 1WAY ABC....8Z-NF9-004-010 BOX,CASS 2 ABC.... -
Page 11: Accessories / Package List
ACCESSORIES / PACKAGE LIST - 1/1 NOTE: The characters in the suffix column indicate the part usage. KANRI REF.NO PARTS NO. DESCRIPTION SUFFIX 8Z-NF9-902-010 IB,LH(ESP)M A....8Z-NF9-903-010 IB,U(ESF)M .B....8Z-NF9-905-010 IB,K(E)E ....8Z-NF9-906-010 IB,EZ(9L)E ....8Z-NF9-912-010 IB,LH(ESP)M -333 ..C....8Z-NF9-916-010 IB,EZ(9L)E -223 .... - Page 12 SCHEMATIC DIAGRAM _ 1 (MAIN : U)
- Page 13 SCHEMATIC DIAGRAM _ 1 (MAIN : 2LH)
- Page 14 SCHEMATIC DIAGRAM _ 1 (MAIN : 3LH)
- Page 15 SCHEMATIC DIAGRAM _ 1 (FRONT : U,2LH,3LH)
- Page 16 9301896 Tokyo Japan Printed in Singapore...
