- Page 1 PLL True PLL True diversity diversity wireless wireless receiver receiver O P E R A T I N G G U I D E...
- Page 2 ATTENTION: Afin de réduire le risque de choc électrique, ne pas enlever le couvercle. Il ne se trouve à l’intérieur aucune pièce pouvant être reparée par l’utilisateur. Confiez I’entretien et la réparation de l’appareil à un réparateur Peavey agréé. AVERTISSEMENT: Afin de prévenir les risques de décharge électrique ou de feu, n’exposez pas cet appareil à...
- Page 3 INTRODUCTION Thank you for selecting a Peavey Pro Comm PCX- U302 quartz controlled single channel true diversity wireless microphone system. Before operating and installing this system please read this instruction manual carefully and thoroughly in order to attain the correct operating procedures and to achieve the best results.
- Page 4 Indicates the channel selected. RF Signal Level Indicator: Indicates the RF signal strength received from the microphone. As soon as the signal is emitted from the microphone the LED indicator illuminates. Audio Signal Level Indicator: Indicates the audio signal level. As soon as the microphone signal is modulated, the LED indicator illuminates.
-
Page 5: Rear Panel
XLR type connector Unbalanced Audio Output Jack: 1/4" Phone Jack Unbalanced Level Switch: “LOW” selection is for “Microphone-Level” output. “HIGH” selection is for “Line-Out” level output. Squelch Adjustment: Adjust the squelch level to eliminate the RF noise interference at the receiver. -
Page 6: Audio Output Connection
Connect the AC/DC adapter cable to the DC 12V input jack. Then plug the adapter unit into an appropriate AC outlet as shown in figure 3. Caution: Make sure the correct voltage is present at the AC outlet as indicated on the AC/DC adapter. AUDIO OUTPUT CONNECTION: Unbalanced Level Switch Setting Position: Make sure to match the unbalanced output... - Page 7 desired device. Make sure the unbalanced level switch is in the proper position before applying power. Balanced Output: Connect the male XLR connector into the balanced output connector on the back of the receiver. Connect the other end of the cable into the “Mic/Balanced”...
- Page 8 TWO 19/2-INCH UNITS RECEIVER INSTALLATION Setup for single half-rack receiver Push the rack mount brackets (RM-11) upwards until it is firmly attached to the receiver. (Figure 5) SETUP FOR DUAL HALF-RACK RECEIVERS Remove the screws at the top and bottom of the receiver where they will be joined together.
- Page 9 Place the receiver at least one meter above the ground and one meter away from noise sources. Place the microphone at least one meter away from the receiving antenna, as shown in figure 8.
- Page 10 Under normal circumstances, the SIGNAL indicator lights up when a microphone or transmitter is turned on near the receiver to indicate the receiver is ready for normal operation. Once sounds enter into the...
- Page 11 When the knob is turned to the twelve o’clock position the output sensitivity level of the wireless microphone is the same as a normal dynamic microphone. Once the receiver output level is appropriately adjusted, do not adjust the volume control again.
- Page 12 The output voltage of the external DC power supply should not be below 12V, otherwise it will not work properly.
- Page 13 Interference is the most commonly reported “fault” with wireless microphone systems; we offer thirty channels from which to choose to help solve the problem. If you are interfered with, please try changing the group/channel combination before picking up the phone.
- Page 14 HANDHELD WIRELESS MICROPHONE TRANSMITTER Like the receiver, the hand held microphone features advanced synthesized PLL design. It is preprogrammed with 30 user selectable frequencies and incorporates “Superior frequency tracking and muting techniques” dual squelch circuitry. The unique soft velvet rubber finish and overall balance of the microphone offers comfort and durability for the user.
- Page 15 RF present lamp will glow on the receiver), setting the receiver in to ‘stand by’ mode. AF signal is only transmitted when a RF link is active and the microphone threshold is opened, i.e. by speech. Group and channel selector cover: push this cover down and back as indicated to access the group and channel selector switches.
-
Page 16: Battery Installation
OPERATION OF THE HAND HELD TRANSMITTER When the microphone is switched on, the led indicator will flash briefly to indicate that the battery is OK and that the transmitter is powered up. At the receiver, the RF indicator... -
Page 17: Belt Pack Transmitter
When the microphone is not in use, please switch it off to conserve the battery BELT PACK TRANSMITTER Like the receiver, the belt pack transmitter features advanced synthesized PLL design. It is preprogrammed with 30 user selectable frequencies and incorporates Pilotone and Noise Lock dual squelch circuitry. - Page 18 with a system, this is one of the first places to look for the solution. Transmit antenna: 1/4 wave GT/MT level selector switch: This switch works in combination with the way you have wired the input device (as detailed above). Set this switch in the GT position if you are connecting to the output of and electric guitar.
- Page 19 Unused status indicator: this illuminates when the combination of group and channel you have selected is not connected. Group selector switch: make sure this setting matches the group selection on the receiver. Channel selector switch: make sure this setting matches the channel selection on the receiver.
- Page 20 Connect your lapel microphone, guitar lead, or other input. Connection details are as per figure 15. Adjust the gain control on the belt pack to the desired level. Figure 15...
-
Page 21: Af 4-Pin Input Connection Methods
AF 4-PIN INPUT CONNECTION METHODS 1. 2-Wire Electret condenser microphone Capsule 2. 3-Wire Electret condenser microphone Capsule 3. Dynamic Microphone 4. Electric Guitar 5. Line-in (Impedance 8KΩ Attenuated 10 dB) -
Page 22: Specifications
SPECIFICATIONS 1. Overall: UHF PCX-U302 Carrier Frequency Range: UHF Band 790~960 MHz Oscillation Mode: PLL synthesized Frequency: Pre-programmed 30 switchable frequencies Stability: + 0.005 % Max. Deviation: + 56 KHz with level limiting Dynamic Range: > 119 dB S/N Ratio: > 100 dB T.H.D.: <... -
Page 23: Troubleshooting Guide
Cause Solution low transmitter replace battery battery voltage out of range move transmitter closer to receiver or obstecles microphone or check input source other input source low transmitter replace battery battery voltage strong RFI identify source and eliminate, or change... - Page 24 NOTES:...
- Page 25 NOTES:...
- Page 26 What Peavey Will Do We will repair or replace (at Peavey's discretion) products covered by warranty at no charge for labor or materials. If the product or component must be shipped to Peavey for warranty service, the consumer must pay initial shipping charges.
-
Page 27: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS WARNING: When using electric products, basic cautions should always be followed, including the following: Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Do not use this apparatus near water. For example, near or in a bathtub, swimming pool, sink, wet basement, etc. Clean only with a damp cloth. - Page 28 Features and specifications subject to change without notice. Peavey Electronics Corporations • 711 A Street • Meridian MS • 39301 • (601) 483-5365 • Fax 486-1278 ©2000...
