INSTALLATION GUIDE
INSTALLATION GUIDE
MITEL MiVOICE 6920 IP PHONE
A
Setup
Network Jack
(if inline power provided,
do not install the power adapter)
Other Network Devices
B
Handset Connection
(Optional) To Other
Network Device
Ethernet Cables
48V
0.54A
To Handset
The Mitel word and logo are trademarks of Mitel Networks Corporation.
Any reference to third party trademarks are for reference only and Mitel makes no representation of the ownership of these marks.
Mitel's Power Over Ethernet (PoE) Powered Device (PD) products are covered by one or more of the U.S. patents (and any foreign patent
counterparts thereto) identified at Mitel's website: www.mitel.com/patents.
For more information on the PD patents that are licensed, please refer to www.cmspatents.com.
© Copyright 2016, Mitel Networks Corporation. All Rights Reserved.
To Network
C
Stand Attachment
30°
60°
48V
0.54A
Power Adapter
Connection
Power Adapter
60°
30°
