Dear customer
Thank you for purchasing this product.
For optimum performance and safety, please read these
instructions carefully.
These operating instructions are applicable to the following
systems.
System
Main unit
Front speakers
Subwoofer
SUPPLIED ACCESSORIES
SUPPLIED ACCESSORIES
Please check and identify the supplied accessories.
Use numbers indicated in parentheses when asking for
replacement parts. (As of January 2007)
1 x AC mains lead
For the United Kingdom
(K2CT3CA00004)
For Continental Europe
(K2CQ2CA00006)
For Australia and N.Z.
(K2CJ2DA00008)
1 x Remote Control
(N2QAYB000139)
2 x Remote control
batteries
Operations in these instructions are described mainly using
remote control, but you can perform the operations on the
main unit if the controls are the same.
Your unit may not look exactly the same as illustrated.
E
EB GN
RQTV0205-B.indd 1
RQTV0205-B.indd 1
SC-AK750
SA-AK750
SB-AK750
SB-WAK750
1 x FM indoor antenna
For Europe
(RSA0007-L)
For Australia and N.Z.
(RSA0006-L)
1 x AM loop antenna
(N1DAAAA00001)
Operating Instructions
CD Stereo System
Model No.
Table of contents
Caution for AC Mains Lead .....................4
Safety precautions ..................................4
Placement of speakers ............................5
Getting started .........................................6
Overview of controls ...............................8
Discs .........................................................9
Cassette tape - Play and record ..........12
FM/AM radio ...........................................13
Timer .......................................................14
Sound adjustment .................................15
External unit ...........................................15
Troubleshooting guide ..........................17
Maintenance ...........................................18
When moving the unit ...........................18
Specifi cations ........................................19
Before connecting, operating or adjusting this product,
please read these instructions completely.
Please keep this manual for future reference.
Note:
"EB" on the packaging indicates the United Kingdom.
SC-AK750
RQTV0205-1B
2/22/07 7:01:51 PM
2/22/07 7:01:51 PM
Advertisement
Table of Contents
Related Manuals for Panasonic SC-AK750
Summary of Contents for Panasonic SC-AK750
-
Page 1: Table Of Contents
Your unit may not look exactly the same as illustrated. EB GN RQTV0205-B.indd 1 RQTV0205-B.indd 1 SC-AK750 Table of contents SA-AK750 SB-AK750 SB-WAK750 Caution for AC Mains Lead ...4 Safety precautions ...4... - Page 2 (Back of product) RQT8043 RQTV0205-B.indd 2 RQTV0205-B.indd 2 Inside of product Tuotteen sisällä Produktets innside 2/22/07 7:01:56 PM 2/22/07 7:01:56 PM...
- Page 3 RQTV0205-B.indd 3 RQTV0205-B.indd 3 RQT8043 2/22/07 7:01:57 PM 2/22/07 7:01:57 PM...
-
Page 4: Caution For Ac Mains Lead
Caution for AC Mains Lead For your safety, please read the following text carefully. This appliance is supplied with a moulded three pin mains plug for your safety and convenience. A 5-ampere fuse is fi tted in this plug. Should the fuse need to be replaced please ensure that the replacement fuse has a rating of 5-ampere and that it is approved by ASTA or BSI to BS1362. -
Page 5: Handling Of The Disc Trays And Discs
Handling of the disc trays and discs Not doing the following will cause damage to the unit. Removing the mains plug • Press [y/I] to turn off the unit and remove the mains plug only after all the displays have disappeared. Tray caution •... -
Page 6: Getting Started
Getting started Making the connections Making the connections Connect the AC mains lead only after all other connections have been made. Connect the speaker cords. Connect the left (L) side in the same way Blue (–) Black (–) To household mains socket Connect the AC mains lead. - Page 7 Optional antenna connections Optional antenna connections Use outdoor antenna if radio reception is poor. Note: Disconnect the outdoor antenna when the unit is not in use. Do not use the outdoor antenna during a lightning storm. FM outdoor antenna Rear panel of this unit •...
-
Page 8: Overview Of Controls
Overview of controls Main unit Main unit Refer to the numbers in parentheses for page reference. Remote control signal sensor Disc tray open/close (5) Multiple discs change (9) Single disc change (10) AC supply indicator [AC IN] This indicator lights when the unit is connected to the AC mains supply. -
Page 9: Discs
Discs Basic play Basic play Press [0, OPEN/CLOSE] on the main unit to open the tray. The unit turns on, load a disc in the current tray with the label facing up. Press [0, OPEN/CLOSE] to close the tray. Press [6, CD] to start play. You can also press [DISC] and then [1] ~ [5] to select and play the other loaded discs. - Page 10 Discs (continued) Changing a single disc (SINGLE CHANGE) a single disc (SINGLE CHANGE) By main unit only While one disc is playing, you can change the discs in other trays. Press [0, SINGLE CHANGE]. Press [3, 1] ~ [3, 5] to select the desired tray. Change the disc.
- Page 11 Repeat play You can repeat program play or other selected play mode. Press [REPEAT]. “ ” is displayed. To cancel Press [REPEAT] again. ” is cleared. “ Note: You can use repeat mode with “Program play” (\ page 10) and “Play Mode function”...
-
Page 12: Cassette Tape - Play And Record
Cassette tape – Play and record The buttons described for “Cassette tape - Play and record” are mainly for the main unit unless indicated otherwise. TAPE Basic play Basic play Use normal position tapes. High position and metal position tapes can be played, but the unit will not be able to identify the characteristics of these tapes. -
Page 13: Fm/Am Radio
FM/AM radio TUNER / Manual tuning Manual tuning BAND Press [TUNER / BAND] to select “FM” or “AM”. Press [PLAY MODE] to select “MANUAL”. Press [4, / REW] or [¢, frequency of the required station. “ ” is displayed when a stereo FM broadcast is being received. -
Page 14: Timer
Timer Setting the clock Setting the clock This is a 24-hour clock. Press and hold [– CLOCK / TIMER] to select “CLOCK”. Each time you press the button: ˚ PLAY CLOCK Original display Within 8 seconds or so Press [4, / REW] or [¢, Press and hold [–... -
Page 15: Sound Adjustment
Sound adjustment Selecting sound effects Selecting sound effects Preset EQ Press [PRESET EQ] repeatedly to select your desired setting. HEAVY ➞ SOFT ➞ CLEAR ➞ ➞ FLAT (off) HALL Setting Effect HEAVY Adds punch to rock SOFT For background music CLEAR Clarifi... - Page 16 External unit (continued) Connecting and playing a USB mass Connecting and playing a USB mass storage class device storage class device The USB connectivity enables you to connect and play MP3 tracks from USB mass storage class. Typically, USB memory devices. (Bulk only transfer) Preparation Before connecting any USB mass storage device to the unit, ensure that the data stored therein has been backed up.
-
Page 17: Troubleshooting Guide
Troubleshooting guide Before requesting service, make the checks below. If you can’t fi x the system as described below, or if something not listed here occurs, refer to the enclosed directory to locate an Authorized Service Center convenient to you or contact your dealer. -
Page 18: Maintenance
Troubleshooting guide (continued) Disc trays Disc tray(s) cannot open. “CHGR ERR ” is displayed. Remote control Remote control doesn’t work. No response when [¶, REC] button is pressed. The USB drive or its contents cannot be read. Slow operation of the USB fl ash drive. -
Page 19: Specifi Cations
Specifi cations AMPLIFIER SECTION RMS output power THD 10%, both channels driven 1 kHz (Low channel) 10 kHz (High channel) 60 Hz (Subwoofer channel) Total output power FM/AM TUNER, TERMINALS SECTION Preset station Frequency Modulation (FM) Frequency range 87.50 to 108.00 MHz (50 kHz steps) Sensitivity S/N 26 dB Antenna terminal(s) - Page 20 Matsushita Electric Industrial Co., Ltd. Web Site: http://panasonic.net RQTV0205-B.indd 20 RQTV0205-B.indd 20 RQTV0205-1B L0207TK1027 2/22/07 7:03:01 PM 2/22/07 7:03:01 PM...
