Original BMW Accessories.
Installation Instructions.
Retrofit Reversing camera
BMW X5 (E70)
BMW X6 (E71)
Installation instructions valid only for vehicles with optional extra 508 (PDC) and
- optional extra 601 (TV function)
- optional extra 609 (navigation system Professional)
Retrofit kit No.
66 21 0 417 969
Retrofit kit Reversing camera
Installation time
The installation time of approx. 4.0 hours may vary depending on the vehicle's condition and equipment.
The vehicle must be updated to the latest I-level status by flashing before installing the retrofit. Differing program-
ming times may be necessary depending on the production age of the vehicle and on work previously performed
on the vehicle.
The installation time given does not include time needed for programming/encoding.
The total costs for the programming time should be taken into account when calculating retrofitting costs
(reimbursement through warranty is not permissible).
Important information
These installation instructions are primarily designed for use within the BMW dealership organisation and by
authorised BMW service companies.
In any event, the target group for these installation instructions is specialist personnel trained on BMW cars with
the appropriate specialist knowledge.
All work must be completed using the latest BMW repair manuals, circuit diagrams, servicing manuals and work
instructions, in a rational order, using the specified tools (special tools) and observing current health and safety
regulations.
In the event of installation or functional problems, limit troubleshooting to 0.5 hours for mechanical
jobs and 1.0 hours for electrical jobs.
To avoid unnecessary work and costs, send a corresponding enquiry via the Aftersales Assistance Portal (ASAP)
using the technical parts support application.
Please quote the following:
- Vehicle identification number
- Part number of the retrofit kit
- Exact description of the problem
- Work already carried out.
Instructions for the customer
The "Customer information" section at the end of the installation instructions should be printed out
and handed over to the customer.
Do not archive the hard copy of these installation instructions since daily updates are made by ASAP!
© BMW AG, Munich
01 29 0 418 006
10/2008
(Z/S)
1

Advertisement

Table of Contents
loading

Related Manuals for BMW 66 21 0 417 969

Summary of Contents for BMW 66 21 0 417 969

  • Page 1 These installation instructions are primarily designed for use within the BMW dealership organisation and by authorised BMW service companies. In any event, the target group for these installation instructions is specialist personnel trained on BMW cars with the appropriate specialist knowledge.
  • Page 2 Ensure that the cables/lines are not kinked or damaged as you install them in the car. Costs incurred as a result of incorrect installation will not be reimbursed by BMW AG. All pictures show LHD cars; proceed accordingly on RHD cars.

  • Page 3: Table Of Contents

    11. Customer information ............... . . 24 © BMW AG, Munich...

  • Page 4: Parts Overview

    Screw (2x) Miniature connector Minifuse 10A Cable tie (20x) Socket insert, 12-pin Socket housing, WS, 6-pin Socket housing, SW, 6-pin Cover, WS, 12-pin Cover, GN, 18-pin Socket insert, SW, 18-pin © BMW AG, Munich 01 29 0 418 006 10/2008 (Z/S)
  • Page 5 1. Parts overview 070 0743 Z AVM wiring loom AVM (not included in retrofit kit) SW 3-pin socket housing SW 4-pin socket housing © BMW AG, Munich 01 29 0 418 006 10/2008 (Z/S)

  • Page 6: Preparatory Work

    D-pillar trim, left 51 43 252 Video module, only with optional extra 601 65 50 011 Trim cover on rear apron 51 46 050 Navigation computer/CCC 65 90 511 © BMW AG, Munich 01 29 0 418 006 10/2008 (Z/S)

  • Page 7: Installation And Cabling Diagram For Vehicles With Optional Extra 609 And Without Optional Extra 696

    % - Legend Reversing camera wiring harness Reversing camera Navigation computer/CCC Only E70 vehicles Earth branch connector X151 Only E71 vehicles Negative battery terminal, X1369 Fuse holder X11012 K-CAN X300 © BMW AG, Munich 01 29 0 418 006 10/2008 (Z/S)

  • Page 8: Installation And Cabling Diagram For Vehicles With Optional Extra 609 And With Optional Extra 696

    Reversing camera wiring harness Reversing camera AVM wiring loom Navigation computer/CCC Only E70 vehicles Earth branch connector X151 Only E71 vehicles Negative battery terminal, X1369 Fuse holder X11012 K-CAN X300 © BMW AG, Munich 01 29 0 418 006 10/2008 (Z/S)

  • Page 9: Installation And Cabling Diagram For Vehicles With Optional Extra 601 (Tv Function)

    Installation and cabling diagram for vehicles with optional extra 601 (TV function) Legend Reversing camera wiring harness Reversing camera Navigation computer/CCC Only E70 vehicles Earth branch connector X151 Only E71 vehicles Negative battery terminal, X1369 Fuse holder X11012 K-CAN X300 © BMW AG, Munich 01 29 0 418 006 10/2008 (Z/S)

  • Page 10: Connections Diagram, Wiring Loom For Reversing Camera

    Only vehicles with optional extra 601 0.35 mm² At reversing camera B PIN 6 Socket contact Shield Only vehicles with optional extra 601 0.35 mm² At reversing camera B PIN 4 © BMW AG, Munich 01 29 0 418 006 10/2008 (Z/S)
  • Page 11 At PDC control unit, with miniature connector X300 0.35 mm² PIN 8 Wire end open K-CAN HIGH OR/GN At PDC control unit, with miniature connector X300 0.35 mm² PIN 2 © BMW AG, Munich 01 29 0 418 006 10/2008 (Z/S)

  • Page 12: Connections Diagram, Wiring Loom For Avm

    N38 Socket contact Kl. 30g RT/GR At navigation computer N38 X13812 2.5 mm² PIN 15 At navigation computer N38 X13812 Socket contact Kl. 31 2.5 mm² PIN 12 © BMW AG, Munich 01 29 0 418 006 10/2008 (Z/S)

  • Page 13: Installing Reversing Camera

    Screw down BR tap connection A5 to earth branch connector X151 at rear apron. Route tap connections A16-A18 along the vehicle wiring harness towards the fuse holder in the luggage compart- X151 ment. A16-A18 %$ - © BMW AG, Munich 01 29 0 418 006 10/2008 (Z/S)
  • Page 14 - A18, OR/GN, to OR/GN wire from Pin 2. X300 %' - Route tap connections A6 to A15 through rubber A6-A15 grommet (1) into tailgate, left-hand side. & - © BMW AG, Munich 01 29 0 418 006 10/2008 (Z/S)
  • Page 15 - A13, GN, at Pin 6. - A14, OR/GN, at Pin 1. A12-A15 - A15, RT/GN, at Pin 4. Plug socket housing I, WS and J, SW, into camera B. &! - © BMW AG, Munich 01 29 0 418 006 10/2008 (Z/S)
  • Page 16 Route wiring harness A forwards along the vehicle wiring harness. '! - Only for vehicles without optional extra 601 and without optional extra 696 Route wiring harness A to the navigation computer/CCC. &% - © BMW AG, Munich 01 29 0 418 006 10/2008 (Z/S)
  • Page 17 Route branch N1, (SW 18-pin socket housing) along vehicle wiring harness to AVM location and connect. N2-N7 Route branches N2 - N7 to radio compartment. Secure wiring loom N with cable ties G. 070 0737 Z © BMW AG, Munich 01 29 0 418 006 10/2008 (Z/S)
  • Page 18 Plug branches N6 and N7 into connector X13812 as follows: - Branch N6, RT/GR wire, at Pin 15. - Branch N7, BR wire, at PIN 12 X13812 070 0740 Z Connect branch N5 to socket housing Q. © BMW AG, Munich 01 29 0 418 006 10/2008 (Z/S)

  • Page 19: Finishing Off And Coding

    Engage reverse gear; picture must be displayed in on-board monitor Disengage reverse gear Reassemble vehicle in reverse order of removal Adjust visible area (calibration) of the camera as per ISTA 66 53 010. © BMW AG, Munich 01 29 0 418 006 10/2008 (Z/S)

  • Page 20: Circuit Diagram

    For vehicles with optional extra 609 and without optional extra 696 X13814 H*/K* 0,35 0,35 0,35 X300 OR/GN 0,35 0,35 X11012 A16* A18* A17* RT/GN 0,35 0,35 0,35 OR/GN 0,35 0,35 RT/GN X151 071 0220 Z © BMW AG, Munich 01 29 0 418 006 10/2008 (Z/S)
  • Page 21 For vehicles with optional extra 609 and with optional extra 696 X19595 X9331 X13812 X13814 RTGR RTGR 0,35 0,35 0,35 0,35 0,35 0,35 SCHIRM SCHIRM 0,75 0,75 RTGR X16845 070 0742 Z © BMW AG, Munich 01 29 0 418 006 10/2008 (Z/S)
  • Page 22 For vehicles with optional extra 601 X300 A 197 X11012 X18804 A16* L*/M* OR/GN 0,35 0,35 TR 0,35 A18* A17* RT/GN GN 0,35 GE/SW 0,35 OR/GN 0,35 0,35 RT/GN X151 071 0221 Z © BMW AG, Munich 01 29 0 418 006 10/2008 (Z/S)
  • Page 23 3-pin SW pin housing at socket housing P* All designations marked * only apply to these installation instructions or this circuit diagram. Cable colours Blue Orange Brown Yellow Black Green Transparent Grey White © BMW AG, Munich 01 29 0 418 006 10/2008 (Z/S)

  • Page 24: Customer Information

    Deactivation by the user during reversing camera image display on the CID (Central Information Display) by: - Activating iDrive (pop-up menu) - Pressing the PDC button. The reversing camera will transmit images again when reverse gear is engaged again. © BMW AG, Munich 01 29 0 418 006 10/2008 (Z/S)
