- Page 1 TU-PTA100E Receiver Operating Instructions English TQBC0200...
-
Page 2: Table Of Contents
Dear Panasonic Customer, Welcome to the Panasonic family of customers. We hope that you have many years of enjoyment from your new receiver. This is a very advanced receiver; however, the Quick Start Guide will allow you to use the receiver as quickly as possible. -
Page 3: Accessories
WARNINGS AND PRECAUTIONS Avoid exposing the Receiver to direct sunlight and other heat sources. To prevent damage which might result in fire or electrical shock hazard, do not expose the Receiver to rain or excessive moisture. ACCESSORIES Check that you have the accessories and items shown Operating Instruction book AC cable... -
Page 4: Quick Start Guide
QUICK START GUIDE Quick Start Guide Connections HD/VD cable (Supplied) (Cable with black plug) * The HD/VD cable has a white line marked on it for identification. Do not connect any other cables to the same signal connector by mistake. Plug in aerial and connect ancillary equipment Note: Additional equipment and cables shown are not supplied with this set. - Page 5 Note: Use the remote control unit for the Wide Plasma Display to make the setting. Set up Change Select COMPONENT/RGB IN Y/PB/PR Panasonic Auto (4:3) Just OSD Language English MENU Exit BAccess the COMPONENT/RGB IN BSelect the RGB. BPress the MENU button to exit.
-
Page 6: Operating The Receiver
QUICK START GUIDE Operating the receiver Land Deutschland Österreich France Italia España Nederland Danmark Sverige Norge Suomi Belgien Schweiz E.Eu OSD Sprache Deutsch Start ATP Suchlauf Select your country For Switzerland and Belgium, select the desired language Press the red button &... -
Page 7: Basic Controls
BASIC CONTROLS: FRONT PANEL AND REMOTE CONTROL Power On/OFF switch Power Indicator ( The Power Indicator will light. Power-OFF...Indicator not illuminated (The unit will still consume some power as long as the power cord is still inserted into the wall outlet.) Stand-by ...Red Power-ON...Green... -
Page 8: Using The On Screen Displays
USING THE ON SCREEN DISPLAYS This receiver has a comprehensive system of On Screen Display menus to access adjustments and options Menu Title Picture menu Contrast Options Brightness Colour Sharpness P-NR Selection bar Some selections, for example, Contrast, Brightness, Colour and Sharpness will allow you to increase or decrease their level. -
Page 9: Aspect Controls
The receiver will allow you to enjoy viewing the picture at its maximum size, including widescreen ‘cinema format’ pictures. Press the ASPECT button to move through the six aspect options: Panasonic Auto, 4:3, Zoom, S-Zoom, 16:9 and Just Panasonic Auto Some broadcasts are transmitted together with a wide screen identification signal (WSS). - Page 10 If, in Panasonic Auto mode, you experience problems with the screen display size when playing back widescreen format recordings from your VCR then it is possible that the tracking control of your VCR requires adjustment (your VCR instruction book will contain adjustment details).
-
Page 11: Still Control
STILL CONTROL STILL Control The STILL key allows you to freeze the picture at any time. -
Page 12: Picture Menu
PICTURE MENU Open the Picture menu Move to your choice Increase or decrease levels or set options Press the TV/AV button to exit the Picture menu Contrast The Contrast, Brightness, Colour and Brightness Sharpness levels can be adjusted to suit your own preferences. Colour Sharpness The Tint adjustment will only appear... -
Page 13: Sound Menu
SOUND MENU Open the Sound menu Move to your choice Increase or decrease levels or set options Press the TV/AV button to exit the Sound menu The Volume adjustment sets the Volume overall output volume. Note: At the time of shipment from the factory, the volume is set to the maximum level. -
Page 14: Setup Menu
SETUP MENU The Setup menu provides access to various advanced features and also to the Tuning menu Open the Setup menu Move to your choice Increase or decrease levels, set options or access further menus Press the TV/AV button to exit the Setup menu AV2 offers you a choice of signals to send to the AV2 SCART socket. -
Page 15: Tuning Menu - Overview
TUNING MENU - overview Open the Setup menu Move to Tuning menu Access Tuning menu Move to your choice Increase or decrease levels, set options or access further menus Press the TV/AV button to exit Accessing the Programme edit menu will allow stations to be moved, added, deleted, named or locked. -
Page 16: Tuning Menu - Programme Edit
TUNING MENU - PROGRAMME EDIT The Programme edit menu allows you to edit the programme position settings. Open the Setup menu Move to Tuning menu Access Tuning menu Move to Programme edit menu Access Programme edit menu Make required changes (see sections below) Press STR button to store changes If you have finished in the Programme... - Page 17 TUNING MENU - PROGRAMME EDIT To add a programme position Choose the programme position where the new programme is to be inserted. Press the Green button Press the Green button again to confirm. This blank programme can then be tuned, named or locked. Press STR to store If you have finished in the Programme edit menu, press the TV/AV button to...
- Page 18 TUNING MENU - PROGRAMME EDIT To tune a programme position Choose the programme position. Move the channel column Increase or decrease channel number or use the ‘C’ key for Direct Channel Access (see page 7). Press STR to store. If you have finished in the Programme edit menu, press the TV/AV button to exit.
- Page 19 TUNING MENU - PROGRAMME EDIT To lock a programme position to prevent access Choose the programme position. Move to the lock column. Choose between lock On or lock Off Press STR to store. If you have finished in the Programme edit menu, press the TV/AV button to exit.
-
Page 20: Tuning Menu - Auto Setup
TUNING MENU - AUTO SETUP The Auto setup menu will allow you to automatically retune the receiver to your local stations. It is useful if you move to a different region. Open the Setup menu Move to Tuning menu Access Tuning menu Move to Auto setup Access Auto setup Press to continue... -
Page 21: Tuning Menu - Manual Tuning
TUNING MENU - MANUAL TUNING Manual tuning of the programme positions is available either from the On Screen Display menu or from the front panel controls. Manual tuning menu Open the Setup menu Move to Tuning menu Access Tuning menu Move to Manual tuning Access Manual tuning Select the programme position to be... -
Page 22: Osd Language
OSD LANGUAGE When you first installed the receiver the On Screen Display language was set according to your choice of country. If you wish to use a different language then it can be chosen from the OSD language menu Open the setup menu Move to the OSD language menu Access the OSD language menu Move to your choice... -
Page 23: Av Select And Setup
AV SELECT AND SETUP The AV Select menu will allow you to choose which AV source to view. Press the TV/AV button Press the appropriate coloured remote control button (whilst the options remain on screen). The options will disappear. You may wish to make adjustments in the Setup or Sound menus. -
Page 24: Q-Link
B Whenever the Auto setup (ATP) function is used, tuning data will be downloaded to the VCR. Auto Power Functions With Panasonic Q-Link VCRs these additional features are available: B If you insert a tape in your VCR and press the Play button, the receiver will automatically switch on and select the AV2 input so you can view the tape. -
Page 25: Vcr/Dvd Operation
VCR/DVD OPERATION The Remote Control is capable of operating some functions of selected Panasonic VCRs and DVD (Digital Versatile Disc) equipment. Some VCR and DVD equipment have different functions, so to ensure compatibility please refer to the equipment’s instruction book or consult your dealer for details. -
Page 26: Teletext Operation
TELETEXT OPERATION B Teletext features may vary depending on the Broadcasting Companies and is only available if the channel selected is transmitting Teletext. B Pressing the Picture button whilst in Teletext mode will display the Brightness function with a white bar. Press the setting as required. - Page 27 TELETEXT OPERATION It is not possible to change the programme position when in News flash, Update or Sub Coded Page Access operation. Favourite Page (F.P.) Stores a favourite page in memory for instant recall. To store such a page, the receiver must be in LIST mode, and the programme position must be from 1 - 25.
-
Page 28: Audio/Video Connections
AUDIO/VIDEO CONNECTIONS Front AV3 4 pin S-Video, RCA Audio/Video and Headphone Sockets Output from Headphones socket 3.5 mm Stereo Plug STEREO HEADPHONES with 3.5 mm Plug Note: Additional equipment and cables shown are not supplied with this receiver. Scart and S-video socket information AV1 and AV4 Scart sockets Socket Earth CVBS out (video) -
Page 29: Rear Av1/Av2(S)/Av4(S) 21 Pin Scart
AUDIO/VIDEO CONNECTIONS Rear AV1/AV2(S)/AV4(S) 21 Pin Scart Input/Output from AV4 Scart Socket Scart cable S-VIDEO VCR SATELLITE RECEIVER S-VIDEO CAMCORDER Notes: Additional equipment and cables shown are not supplied with this receiver. Do not connect a computer with TTL output (5V) to this set. The AV2 21 pin terminal can also be used as an output to Audio/Video equipment;... -
Page 30: Trouble-Shooting
TROUBLE-SHOOTING Symptoms Picture Snowy Picture Multiple Images Interference Normal Picture No Picture No Colour Poor or Distorted Picture Normal Picture Sound Aerial location, direction or connection Noisy Sound Aerial location, direction or connection Normal Sound Electrical appliances Cars/Motorcycles Fluorescent lights Noisy Sound (Receiver or Wide Plasma Display) Volume level... -
Page 31: For Your Guidance
Before requesting service, please refer to the troubleshooting guide on previous page to determine the symptoms. To obtain service please contact your local Panasonic dealer quoting the model number and serial number (both are located at the rear of the receiver). - Page 32 Customer’s Record The model number and serial number of this product can be found on its rear cover. You should note this serial number in the space provided below and retain this book plus your purchase receipt as a permanent record of your purchase to aid in identification in the event of theft or loss, and for Warranty Service purposes.
