- Page 1 AVR 3700, AVR 370, AVR 370C, AVR 2700, AVR 270, AVR 270C Audio/Video Receiver Quick-Start Guide...
-
Page 2: Place Your Speakers
An owner’s manual containing complete information about operating all of your new AVR’s features is available at our Web site. Go to www.harmankardon.com and download the AVR 3700, AVR 370, AVR 370C, AVR 2700, AVR 270, AVR 270C Owner’s Manual. Place the AVR •... -
Page 3: Connect Your Speakers
If your TV has an HDMI connector: Use an HDMI cable (not included) to connect it to the AVR’s HDMI Out connector. (For the AVR 3700/AVR 370 you can use either HDMI Out connector.) You do not need to make any other connections to your TV from the AVR or from any of your video source components. -
Page 4: Connect Your Audio And Video Source Devices
D (blue) Composite Video 2/Analog Audio 2 Monitor Output Connector Connected Device HDMI Out 1 HDMI Out 2 (AVR 3700/AVR 370 only) Composite Video Monitor Out Record Output Connector Connected Device Analog Audio Rec Out Source Buttons and Assigned Connectors... - Page 5 Connections HDMI Devices Composite Video Devices If any of your source devices have HDMI connectors, using them will provide the best Use composite video connectors for video source devices that don’t have HDMI or possible video and audio performance quality. Since the HDMI cable carries both digital component video connectors.
- Page 6 Connections Analog Audio Devices Video Recorders Use the AVR’s analog audio connectors for source devices that don’t have HDMI or digital Connect an analog video recorder’s video input connector to the AVR’s Composite audio connectors. Monitor Out connector. You can record any composite video signal. To record the audio from the source device, connect the AVR’s Analog Rec Out connectors to the analog video AVR Analog recorder’s audio inputs.
-
Page 7: Connect The Radio Antennas
AVR Headphone Connector NOTE: To connect RS-232, multi-zone, remote IR and trigger equipment, please download the AVR 3700, AVR 370, AVR 2700, AVR 270 Owner’s Manual from www.harmankardon. com. Connect to AC Power Connect the AC power cord to the AVR’s AC Input connector and then to a working, non- switched AC power outlet. -
Page 8: Speaker Setup
Connections Assign Connectors to the AVR’s Source Buttons 4. Press the remote control’s AVR button. The AVR’s on-screen display (OSD) setup menu will appear on the TV. (Note: If you have used a composite video connection to your 1. Review the input connections you listed on the Source Buttons and Assigned TV, the OSD menus will not appear on your TV. -
Page 9: General Specifications
• For the AVR 2700/AVR 270, select “On” and press the OK button. 7. Press the remote’s Back/Exit button and repeat steps 3 – 6 for the remaining source • For the AVR 3700/AVR 370, select the HDMI Monitor Out connector you used for your buttons with connectors you want to re-assign. - Page 10 © 2012 HARMAN International Industries, Incorporated. All rights reserved. Harman Kardon is a trademark of HARMAN International Industries, Incorporated, registered in the United States and/or other coun- tries. EzSet/EQ is a trademark of HARMAN International Industries, incorporated. DLNA is a registered trademark of the Digital Living Network Alliance.
