- Page 2 INTRODUCTION Thank you for purchasing the Viper V760 gaming keyboard. This keyboard uses super quiet mechanical Kailh Brown switches for an undisruptive experience and each key can be individually customized to 16.8 million colors. The keyboard also features rollover anti-ghosting and 103 fully programmable macro keys for an optimal gaming experience that can be saved to up to 5 gaming profiles.
-
Page 3: Features & Technical Specifications
FEATURES & TECHNICAL • Game Mode PACKAGAGE CONTENTS • Onboard memory SPECIFICATIONS • Viper V760 gaming keyboard • 103 programmable macro keys • Detachable magnetic palm rest • 100% Kailh mechanical brown switches • 6 Multimedia control keys • Keycap remover •... -
Page 4: Hardware Installation
INSTALLATION HARDWARE INSTALLATION Connect the keyboard to two available USB ports. Wait 5-10 seconds for the keyboard to be recognized by the computer. SOFTWARE INSTALLATION Please download the keyboard software from the product page at http://www.patriotmemory.com to change light effects, create and manage macros, manage profiles, adjust latency, response and more. -
Page 5: Keyboard Shortcuts
KEYBOARD SHORTCUTS... -
Page 6: Multi-Media Keys
MULTI-MEDIA KEYS FN+1 FN+2 FN+3 PLAY/PAUSE PREVIOUS TRACK NEXT TRACK FN+4 FN+5 FN+6 MUTE VOLUME DOWN VOLUME UP... - Page 7 BACKLIGHT RECORDING MODES Record and Save custom key configurations Pressing any key in record mode will change the color of the key and pressing it again will cycle When Recording is complete, press FN+F12 through preset colors. to save your customized configuration. Pressing FN+F12 -key causes F1-F5 to Do this until keyboard is customized to preference.
- Page 8 RADAR/SPOTLIGHT/WAVE MODES Press FN+F6 -Continuously to alternate between modes SPOTLIGHT MODE RADAR MODE WAVES MODE Keys light up on both sides of the keyboard, Lighting travels along the edge of the keyboard Color spectrum moves from one end of the meet in the middle and then return covering a section of the keys at a time keyboard to the other...
-
Page 9: Ripple Mode
RIPPLE MODE RIPPLE MODE When pressing any key, the lighting will be spread in all directions; displaying a “ripple” effect FN+PgUp FN+PgDn Increases Speed of Ripple Mode Decreases Speed of Ripple Mode FN+ (-/+) Increases/Decreases Brightness... - Page 10 VORTEX/SIDEWINDER MODES Press FN+F8 -Continuously to alternate between modes VORTEX MODE SIDEWINDER MODE Entire keyboard lights up one key at a time from Lighting effect starts at the top and winds to side the top-left towards the center of the keyboard and to side until it hits the bottom row then becomes unlit in the reverse of the pattern FN+PgUp...
- Page 11 RAINDROP/REACTIVE MODES Press FN+F9 -Continuously to alternate between modes RAINDROP MODE REACTIVE MODE Keys are randomly lit resembling the pattern When pressing any key, the key will light up of rainfall and fade FN+PgUp FN+PgDn FN+PgUp FN+PgDn Decreases Fading Speed of Increases Speed of Vortex Mode Decreases Speed of Vortex Mode Increases Fading Speed of...
- Page 12 BREATHE BREATHE MODE Selected color brightens and then fades FN+PgUp FN+PgDn Increases Speed of Breathe Mode Decreases Speed of Breathe Mode FN+ (-/+) Increases/Decreases Brightness...
-
Page 13: Static Mode
STATIC/SPECTRUM Press FN+F11 Continuously to alternate between modes STATIC MODE SPECTRUM MODE All keys are illuminated with one specific color Keys cycles through colors of the rainbow FN+PgUp FN+PgDn Decreases Fading Speed of Increases Alternating Speed of Spectrum Mode Spectrum Mode FN+ (-/+) FN+ (-/+) Increases/Decreases Brightness... - Page 14 KEYBOARD SOFTWARE...
-
Page 15: Color Selection
COLOR SELECTION • Choose from seven preset colors • To change a preset color, double-click on a square and choose from Color window • Rainbow tile will cycle through all preset colors in all modes except Wave and Spectrum... -
Page 16: Light Settings
LIGHT SETTINGS • LIGHT BRIGHTNESS: Click and drag the knob from left to right to adjust the brightness of the keys • LIGHT SPEED: Animation of speed patterns can be adjusted from slow to fast with incremental levels • LIGHT DIRECTION: Choose from any direction in Wave mode for colors to be animated... - Page 17 MACRO MANAGEMENT • NEW: Creates a new Macro • DELETE: Deletes the currently selected Macro • RENAME: To rename Macro, double-click macro. • START RECORDING: Begins to record all keystrokes to selected macro • STOP RECORDING: Ceases to record all keystrokes to selected macro •...
- Page 18 • RECORD BEFORE: Insert a keystroke before the selected input • RECORD AFTER: Insert a keystroke before the selected input • INSERT MOUSE FUNCTION: Insert an emulated mouse click after the secleted input - Down: Emulates mouse button being pressed - Up: Emulates mouse button being released - Click: Emulates mouse button being pressed and released •...
- Page 19 • GAME MODE: Enables remapped keys to function according to user customization • WINDOWS KEY LOCK: Disables the Windows key located in the bottom left from being usable • RESPONSE TIME: Changing the response time will determine how long the system will take to react to a given input. The response time can be changed from 2ms to 20ms.
- Page 20 1. Visit www.patriotmemory.com and search “Viper V760” to find corresponding drivers and software to download and install. 2. If any technical issue occurs in the use of the keyboard, please Reset Settings in the software or use to factory reset the key- board’s onboard memory.
- Page 21 FCC and Legal: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 ofthe FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
