SERVICE MANUAL
ROOM AIR CONDITIONER
INDOOR UNIT
AH-129
AH-MP14
CONTENTS
SHARP CORPORATION
SHARP CORPORATION
1
SPLIT SYSTEM
OUTDOOR UNIT
AU-129
AU-MP14
Page
Advertisement
Table of Contents
Related Manuals for Sharp AU-MP14
Summary of Contents for Sharp AU-MP14
-
Page 1: Table Of Contents
SERVICE MANUAL SPLIT SYSTEM ROOM AIR CONDITIONER INDOOR UNIT OUTDOOR UNIT AH-129 AU-129 AH-MP14 AU-MP14 CONTENTS Page SPECIFICATIONS..............................2 EXTERNAL DIMENSIONS..........................4 WIRING DIAGRAMS............................5 ELECTRICAL PARTS............................6 MICROCOMPUTER CONTROL SYSTEM......................7 PRINTED WIRING DIAGRAM..........................8 FUNTIONS................................10 TROUBLESHOOTING............................14 REFRIGERATION CYCLE AND PERFORMANCE CURVES................16 DISASSEMBLING PROCEDURE........................17 REPLACEMENT PARTS LIST..........................25... -
Page 2: Specifications
CHAPTER 1. PRODUCT SPECIFICATION [1] SPECIFICATION 1. AH-129 / AU-129 INDOOR UNIT OUTDOOR UNIT ITEMS AH-129 AU-129 Cooling capacity 3.50 Moisture removal Liters/h – Electrical data Phase Single Rated frequency Rated voltage Rated current Rated input * 1090 Power factor 97 - 99 Compressor Type... - Page 3 2. AH-MP14 / AU-MP14 INDOOR UNIT OUTDOOR UNIT ITEMS AH-MP14 AU-MP14 Cooling capacity 3.50 Moisture removal Liters/h – Electrical data Phase Single Rated frequency Rated voltage Rated current Rated input * 1090 Power factor 97 - 99 Compressor Type Hermetically sealed rotary type...
-
Page 4: External Dimensions
[2] EXTERNAL DIMENSION 1. Indoor unit (AH-129 / AH-MP14) 2. Outdoor unit (AU-129 / AU-MP14) 37.5 167.5... -
Page 5: Wiring Diagrams
[3] WIRING DIAGRAM Indoor Unit (AH-129) Indoor Unit (AH-MP14) Outdoor (AU-129 / AU-MP14) -
Page 6: Electrical Parts
Transformer — Primary ; AC 220 / 240V 50Hz INDOOR — Secondary ; AC15.3V , 50Hz Fuse — 250V, 2.5A INDOOR 2. AH-MP14 / AU-MP14 REMARKS DESCRIPTION MODEL SITE Compressor RH207VXGT 220V, 50Hz, 1120W OUTDOOR Indoor fan motor CMOT-A448JBKZ 220 - 240V , 50Hz... -
Page 7: Microcomputer Control System
[2] MICRO-COMPUTER CONTROL SYSTEM 1. Electronic Control Diagram Indoor unit (AH-129 / AH-MP14) -
Page 8: Printed Wiring Diagram
2. PRINTED WIRING DIAGRAM 2.1 Indoor (AH-129) - Page 9 2.2 Indoor (AH-MP14)
-
Page 10: Funtions
CHAPTER 3. FUNCTIONS [1] FUNCTION 2.2. DRY TEMPERATURE CONTROL On the switch on, the compressor always starts to operate for 2 CHARACTERISTIC 1.1. COOL operation minutes with fan speed "DL". In the "COOL" mode, the thermostat circuit is controlled by five The microcomputer reads the room temperature 2 minutes after thermostat lines (C1 thru C5). - Page 11 TEST RUN OUTPUTS IN EACH OPERATION MODE If the "AUX" button on the unit is pressed for 5 seconds or more Mode Compres- Valve Coil during operation, cool test operation starts. The operation LED (red) Outdoor Indoor flickers during test run. Fan Motor Fan Motor Cooling...
- Page 12 [2] TEST MODE 1. AH-129 Keep pushing the "AUX." buttons and supply the power, the system will go to the test mode. In this mode, the output of operation is switched by pushing the ""AUX." button in the unit or the "OI" button in the remote controller. Normal outputs are shown in Table. STEP No.
- Page 13 [3] DIAGNOSIS PROCEDURE 1. AH-129 / AH-MP14 When indoor fan motor is out of order occurs, indoor fan motor and louver are all stopped and the operation LED(red) turns on or off synchronously with the timimg of the timer LED. When the thermistor for room temperature or pipe temperature is open or short state, the operation LED turns on or off synchrnoously with the timing of the timer LED by pushing continously for more than 5 seconds "AUX."...
-
