GE Profile JKP56AAAA Dimension Manual

TM
JKP56AAAA - GE Profile
Dimensions (in inches)
Locate
junction box
for 24"models
56" MIN. above
cutout floor
Locate
10
junction box
for 27"models
A
either 5" MIN.
below cutout
floor or 56"
MIN. above
cutout floor
D
Conduit
E
(49" long
JK950,
JKP56/45/27,
2" X 4" or
48-1/2" long
equiv. runners
Recommended
JRP24)
(cutout floor)
cutout location
from floor
Specification Revised 6/99
™ 27" Double Wall Oven
Allow 3/4"
for overlap
over all edges
of cutout
C
B
G
F
20" MIN.
door opening
allowance
Note: If a solid
bottom is used
instead of the
runners, a 6" x 10"
rectangle must be
cut out of the
Cut Opening
bottom for optimum
in Solid performance
and proper air
Bottom
circulation.
10
6
6
KW Rating
240V 6.8
208V 5.1
Breaker Size
30 Amps †
Cabinet
A – Cabinet Width Required
B – Minimum Cabinet Depth
C – Minimum Opening Width
D – Opening Height
E – Minimum Cutout Location from Floor
Oven
F – Overall Depth
G – Overall Height
H – Overall Width
† Note: Check local codes for required breaker size.
Installation Information: Before installing, consult installation instructions
[Pub. No. 31-10200] packed with product for current dimensional data.
Note: Cabinets installed adjacent to wall ovens must have an adhesion spec
of at least 194°
For answers to your Monogram, ®
GE Profile Performance Series, ™
GE Profile ™ or GE appliance questions, call
GE Answer Center ® service, 800.626.2000.
Listed by
Underwriters
Laboratories
R
JKP56
27" min
23-5/8"
25"
49-1/2" min.
13-1/4"
23-5/8"
51-1/8"
26-5/8"
