HVFM122ABL(USA HAC)
Wine Cooler
Service
Manual
HVFM122ABL
Features
●
●Optimized for Preservation of Wine Flavors.
●Temperature adjustable,
control .
mechanical
●Temperature range:A-3～A+3℃(A=7～15).
●Interior lights.
●wine rack.
Haier Group
Manual No.:HVFM122ABL(USA HAC)
Edition:20031120
1
PDF created with pdfFactory trial version
www.pdffactory.com
Downloaded from
www.Manualslib.com
manuals search engine
Advertisement
Table of Contents
Troubleshooting
Related Manuals for Haier HVFM122ABL
Summary of Contents for Haier HVFM122ABL
- Page 1 Manual HVFM122ABL Features ● ●Optimized for Preservation of Wine Flavors. ●Temperature adjustable, control . mechanical ●Temperature range:A-3～A+3℃(A=7～15). ●Interior lights. ●wine rack. Haier Group Manual No.:HVFM122ABL(USA HAC) Edition:20031120 PDF created with pdfFactory trial version www.pdffactory.com Downloaded from www.Manualslib.com manuals search engine...
-
Page 2: Table Of Contents
CONTENTS Contents 1. Contents…………………………………………………… ………….……. 1 2. Product Code illustration and Series Introduction…………………… . …2 3. Features ……………………………………………………………………...3 4. Specifications…………………………………………………………………4 …..6 5. Safety Precautions(including Warning and Cautions)…………… … 6. Net Dimension……………………………………………………..………..8 7. Installation and Accessory Parts…………………… ……………..…….…9 8. Parts and Functions………………………………… ………….….………11 9. -
Page 3: Product Code Illustration And Series Introduction
PRODUCT CODE ILLUMINNATION AND SERIES INTRODUCTION Product Code illustration and Series Introduction J C-□ G □ A B C D E A: The first letter of “wine” in Chinese spelling. B: Abbreviation of Cooler or Cellar. C: Capacity .( Unit: Liter ). D:G stands for “Freon free”. -
Page 4: Features
Features nitial Setup l Your wine cooler has temperature control knob on the top of the unit. There are 6 settings： 1 being the warmest and 7 being the coolest. You an set the temperature of your wine cooler at any setting you desire. The wine cooler will maintain a temperature range between 4℃... -
Page 5: Specifications
SPECIFICATIONS Specifications Wine cooler Model HVFM122ABL Commercial brand Haier Product description Wine cooler Type of Appliance (FS= freestanding BI= built-in) Energy efficiency class (N= + 18-32 °C T=+ 18-43 °C) Climate class Freezer compartment / Star rating (VDE / TÜV / IMQ / NF / ÖVE / DEMKO etc.) - Page 6 F= Flat / R= Rounded / S= Streamline Hinged (r =right l =left) / reversible) reversible Deco frame: panel thikness till: Compartments number / adjustable Lock Shelves: Number Number of bottles (total) Type (gr=grill/g=glass/p=plastic) Colour of shelves Adjustable Drawers: Number n°.
-
Page 7: Safety Precautions(Including Warning And Cautions)
Safety Precautions Read all of the instructions before using this appliance. When using this appliance ,always exercise basic safety precautions, including the following: 1. Use this appliance only for its intended purpose as described in this use and care guide. 2. - Page 8 9. Do not store foods in wine cooler as interior temperature may not be cool enough to prevent spoilage. PDF created with pdfFactory trial version www.pdffactory.com Downloaded from www.Manualslib.com manuals search engine...
-
Page 9: Net Dimension
Net Dimension Model HVFM122ABL Unit Dimersion(W*D*H) 595*640*1850 Dimersion 595*640*1170 (Opening door:135 PDF created with pdfFactory trial version www.pdffactory.com Downloaded from www.Manualslib.com manuals search engine... -
Page 10: Installation And Accessory Parts
Installation and Accessory Parts Unpacking Your Wine Cooler 1.Remove all packaging material, This includes the foam base and all adhesive tape holding the wine cooler accessories inside and outside ,compressor from shipping damage due to vibration and shock. 2.Inspect and remove any remains of packing ,tape or printed materials before powering on the wine cooler. - Page 11 Installation and Accessory Parts Electrical Requirement l Make sure there is a suitable power Outlet(115V)with proper grounding to power the wine cooler. l Avoid the use of three plug adapters or cutting off the third grounding in order to accommodate a two plug outlet ,This is a dangerous practice since it provides no effective grounding for the wine cooler and may result in shock hazard.
-
Page 12: Parts And Functions
Parts and Functions Model ● ● ● ● ● ● ● ● ● HVFM122ABL PDF created with pdfFactory trial version www.pdffactory.com Downloaded from www.Manualslib.com manuals search engine... -
Page 13: System Flow Chart
System Flow Chart Schematic Diagram of Refrigerating Principle Brief Description of Refrigerating Principle The refrigerating system of direct cooling single-system freezer belongs to the category of single-temperature and single-control refrigerating system with only one evaporator and is controlled by a single temperature control. PDF created with pdfFactory trial version www.pdffactory.com Downloaded from... -
Page 14: Function Schedule
Function Schedule Function Schedule Function Description Green lamp Work indicator light Adjust Thermostat knob Thermostat light Press the light switch The illustration of the function in the subject of “Features”. PDF created with pdfFactory trial version www.pdffactory.com Downloaded from www.Manualslib.com manuals search engine... -
Page 15: Circuit Diagram
Circuit Diagram PDF created with pdfFactory trial version www.pdffactory.com Downloaded from www.Manualslib.com manuals search engine... -
Page 16: Maintenance Service And Trouble Shooting
Maintenance Service Trouble Shooting Maintenance Service and Trouble Shooting Cleaning and Maintenance Warning: To avoid electric shock always unplug your wine cooler before cleaning, Lgnoring this warning may result in death or injury. Caution: Before using cleaning products, always read and follow manufacture’s instructions and warnings to avoid personal injury or product damage. -
Page 17: Trouble Shooting
MAINTENANCE SERVICE AND TROUBLE SHOOTING Maintenance Service and Trouble Shooting causes, Remove the power cord from AC outlet when a power outage occurs, When power has been restored ,replug power cord to AC outlet. Vacation and Moving Care l For ling vacations or absences ,unplug the wine cooler and clean the wine cooler and door gaskets according to “General cleaning “... - Page 18 MAINTENANCE SERVICE AND TROUBLE SHOOTING Maintenance Service and Trouble Shooting Wine cooler runs too frequently l This may be normal to maintain constant temperature during high temperature and humid days. l Doors may have been opened frequently or for an extended period of time . l Clean condenser coils, l Check gasket for proper seal.
-
Page 19: Exploded View
Exploded View PDF created with pdfFactory trial version www.pdffactory.com Downloaded from www.Manualslib.com manuals search engine... -
Page 20: List Of Parts
0.03% 0.06% 0075020160 Protect cover HVFM122ABL 0.01% 0.02% X 0072040090 Water box HVFM122ABL 0.01% 0.02% X 0074160001 Evaporator link tube HVFM122ABL 0.01% 0.02% X 0070201801 Soft water tube HVFM122ABL 0.01% 0.02% X 0074180002 Filer drier HVFM122ABL 0.01% 0.02% X 0074000027... -
Page 21: Exlpoded View
0074090534 Thermosta HVFM122ABL 0.50% 1.00% 0070801800 Lamp board HVFM122ABL 0.01% 0.02% X 0075120021 Daylight lamp HVFM122ABL 0.50% 1.00% 0075120028 Lamp cover HVFM122ABL 0.01% 0.02% X 0074010039 Evaporator HVFM122ABL 0.01% 0.02% X Cross-channel 0077010045 HVFM122ABL 0.01% 0.02% X self-tapping screw Evaporator... - Page 22 PDF created with pdfFactory trial version www.pdffactory.com Downloaded from www.Manualslib.com manuals search engine...
