Cooling Capacity :
24,000 - 60,000 BTU/h
Standard Features
• Two-Stage Copeland® UltraTech™ scroll compressor
• High-density foam compressor sound blanket
• ComfortNet™ Communications System compatible
• Expanded ComfortAlert™ diagnostics
• Set-up capable with two low-
voltage wires to outdoor unit
• Diagnostic indicator lights and
storage of 6 fault codes
• Color-coded terminal strip for
non-communicating set-up
• High- and low-pressure switches
• Factory-installed filter drier
• Coil and ambient temperature sensors
• Two-speed, quiet condenser fan motor
• AHRI Certified; ETL Listed
SS-DSXC16
Split System Air Conditioner
Cabinet Features
• Heavy-gauge galvanized-steel
cabinet with sound control top
• Baked-on powder paint finish
• Wire fan discharge grille
• Steel louver coil guard
• Top and side maintenance access
• Single-panel access to controls with space
provided for field-installed accessories
• When properly anchored, meets 2010
Florida Building Code unit integrity
requirements for hurricane-type winds
(Anchor bracket kits available.)
* Complete warranty details available from your local dealer or at www.
goodmanmfg.com. To receive the Lifetime Compressor Limited Warranty
(good for as long as you own your home), 10-Year Unit Replacement
Limited Warranty and 10-Year Parts Limited Warranty, online registration
must be completed within 60 days of installation. Online registration is not
required in California or Québec.
www.goodmanmfg.com
DSXC16
High-Efficiency
Up to 16 SEER
Contents
Nomenclature ......................................2
Product Specifications..........................3
Expanded Cooling Data ........................4
AHRI Ratings .......................................20
Wiring Diagram ..................................27
Dimensions .........................................28
Accessories .........................................28
5/15
Supersedes 11/14
Advertisement
Related Manuals for Goodman DSXC160241AA/B
Summary of Contents for Goodman DSXC160241AA/B
-
Page 1: Table Of Contents
DSXC16 High-Efficiency Cooling Capacity : 24,000 - 60,000 BTU/h Split System Air Conditioner Up to 16 SEER Contents Nomenclature ........2 Product Specifications......3 Expanded Cooling Data ......4 AHRI Ratings ........20 Wiring Diagram ........27 Dimensions .........28 Accessories .........28 Standard Features Cabinet Features •... -
Page 2: Nomenclature
Nomenclature 7,8,9 Brand Engineering * Goodman® B rand Minor R evision H igh F eature S et Engineering * Product C ategory Major R evision Split S ystem ... -
Page 3: Product Specifications
Product Specifications DSXC16 DSXC16 DSXC16 DSXC16 DSXC16 DSXC16 0241AA/B 0241AC 0361AA/B 0361AC 0481B* 0601B* Cooling Capacity Nominal Cooling (BTU/h) 24,000 24,000 36,000 36,000 48,000 60,000 Decibels 70.4/70.9 70.4/70.9 Compressor 10.3 11.7 16.7 15.3 21.2 28.8 52.0 58.0 82.0 83.0 104.0 152.9 Condenser Fan Motor Horsepower (RPM) -
Page 4: Expanded Cooling Data
Expanded Cooling Data — DSXC160241**/ CA*F3636C6C*+TXV/ MBVC1200** Low Stage www.goodmanmfg.com SS-DSXC16... - Page 5 Expanded Cooling Data — DSXC160241**/ CA*F3636C6C*+TXV/ MBVC1200** Low Stage (cont.) SS-DSXC16 www.goodmanmfg.com...
- Page 6 Expanded Cooling Data — DSXC160241**/ CA*F3636C6C*+TXV/ MBVC1200** High Stage www.goodmanmfg.com SS-DSXC16...
- Page 7 Expanded Cooling Data — DSXC160241**/ CA*F3636C6C*+TXV/ MBVC1200** High Stage (cont.) SS-DSXC16 www.goodmanmfg.com...
- Page 8 Expanded Cooling Data — DSXC160361** / CA*F3743*6A* +TXV / MBVC1600** Low Stage www.goodmanmfg.com SS-DSXC16...
- Page 9 Expanded Cooling Data — DSXC160361** / CA*F3743*6A* +TXV / MBVC1600** Low Stage (cont.) SS-DSXC16 www.goodmanmfg.com...
- Page 10 Expanded Cooling Data — DSXC160361** / CA*F3743*6A* +TXV / MBVC1600** High Stage www.goodmanmfg.com SS-DSXC16...
- Page 11 Expanded Cooling Data — DSXC160361** / CA*F3743*6A* +TXV / MBVC1600** High Stage (cont.) SS-DSXC16 www.goodmanmfg.com...
- Page 12 Expanded Cooling Data — DSXC160481B* / CA*F4860*6**+TXV/MBVC2000** Low stage www.goodmanmfg.com SS-DSXC16...
- Page 13 Expanded Cooling Data — DSXC160481B* / CA*F4860*6**+TXV/MBVC2000** Low stage (cont.) SS-DSXC16 www.goodmanmfg.com...
- Page 14 Expanded Cooling Data — DSXC160481B* / CA*F4860*6**+TXV/MBVC2000** High stage www.goodmanmfg.com SS-DSXC16...
- Page 15 Expanded Cooling Data — DSXC160481B* / CA*F4860*6**+TXV/MBVC2000** High stage (cont.) SS-DSXC16 www.goodmanmfg.com...
- Page 16 Expanded Cooling Data — DSXC160601B* / CA*F4961*6A*+TXV / MBVC2000**-1** Low Stage www.goodmanmfg.com SS-DSXC16...
- Page 17 Expanded Cooling Data — DSXC160601B*/CA*F4961*6A*+TXV / MBVC2000**-1** Low Stage (cont.) SS-DSXC16 www.goodmanmfg.com...
- Page 18 Expanded Cooling Data — DSXC160601B* / CA*F4961*6A*+TXV / MBVC2000**-1** High Stage www.goodmanmfg.com SS-DSXC16...
- Page 19 Expanded Cooling Data — DSXC160601B*/CA*F4961*6A*+TXV / MBVC2000**-1** High Stage (cont.) SS-DSXC16 www.goodmanmfg.com...
-
Page 20: Ahri Ratings
AHRI Ratings Indoor Units Cooling Ratings Outdoor AHRI # Unit Coils/Air Handlers Furnaces Total¹ Sens.¹ SEER² EER³ AVPTC30C14A* 23,000 16,800 16.0 12.5 5924460 CA*F3636*6D*+MBVC1200**-1A*+TXV 24,000 17,600 16.0 13.0 4392752 CA*F3636*6D*+TXV G*VC80604B*B* 24,000 17,600 16.0 13.0 5038827 CA*F3636*6D*+TXV A*VC80604B*B* 24,000 17,600 16.0 13.0 5039091... - Page 21 AHRI Ratings Indoor Units Cooling Ratings Outdoor AHRI # Unit Coils/Air Handlers Furnaces Total¹ Sens.¹ SEER² EER³ CHPF3636B6C*+TXV A*VC960603BNA* 24,000 17,600 16.0 13.0 7356249 CHPF3636B6C*+TXV A*VC960803BNA* 24,000 17,600 16.0 13.0 7356254 CHPF3636B6C*+TXV A*VM970603BNA* 24,000 17,600 16.0 13.0 7356320 CHPF3636B6C*+TXV A*VM970803BNA* 24,000 17,600 16.0...
- Page 22 AHRI Ratings Indoor Units Cooling Ratings Outdoor AHRI # Unit Coils/Air Handlers Furnaces Total¹ Sens.¹ SEER² EER³ CA*F3743*6D*+TXV A*VC960804CNA* 34,600 24,800 16.0 12.2 1,125 7356272 CA*F3743*6D*+TXV A*VC961205DNA* 34,200 24,600 15.5 12.2 1,115 7356282 CA*F3743*6D*+TXV A*VM970804CNA* 34,600 24,800 16.0 12.2 1,125 7356338 CA*F3743*6D*+TXV A*VM971205DNA*...
- Page 23 AHRI Ratings Indoor Units Cooling Ratings Outdoor AHRI # Unit Coils/Air Handlers Furnaces Total¹ Sens.¹ SEER² EER³ CHPF3743D6B*+TXV A*EC961205DNA* 34,600 24,800 15.5 12.2 1,250 7366126 CHPF4860D6D*+TXV G*VC80604B*B* 34,600 24,800 16.0 12.5 1,220 5038829 CHPF4860D6D*+TXV A*VC80604B*B* 34,600 24,800 16.0 12.5 1,220 5039095 CHPF4860D6D*+TXV A*VC80805C*B*...
- Page 24 AHRI Ratings Indoor Units Cooling Ratings Outdoor AHRI # Unit Coils/Air Handlers Furnaces Total¹ Sens.¹ SEER² EER³ CA*F4961*6D*+TXV ADVC81005C*B* 46,500 35,000 16.0 12.0 1,410 5038936 CA*F4961*6D*+TXV G*VC81005C*B* 46,500 35,000 16.0 12.0 1,370 5039012 CA*F4961*6D*+TXV G*VC80604B*B* 46,000 34,600 16.0 12.3 1,400 5039100 CA*F4961*6D*+TXV A*VC80604B*B*...
- Page 25 AHRI Ratings Indoor Units Cooling Ratings Outdoor AHRI # Unit Coils/Air Handlers Furnaces Total¹ Sens.¹ SEER² EER³ CHPF4860D6D*+TXV A*VC960804CNA* 46,000 34,600 15.5 12.0 1,400 7356291 CHPF4860D6D*+TXV A*VC961005CNA* 46,000 34,600 15.5 12.0 1,400 7356296 CHPF4860D6D*+TXV A*VC961205DNA* 47,000 35,200 15.5 12.0 1,450 7356301 CHPF4860D6D*+TXV A*VM970804CNA*...
- Page 26 • EEP - Order from Service Dept. Part No. B13707-38 or new Solid State Board B13707-35S. Part No. B13707-38 is not in- terchangeable with B13707-35S. The Goodman Gas Furnace contains the EEP cooling time delay www.goodmanmfg.com www.goodmanmfg.com...
-
Page 27: Wiring Diagram
Wiring Diagram SS-DSXC16 SS-DSXC16 www.goodmanmfg.com www.goodmanmfg.com... -
Page 28: Dimensions
Note: Maximum number of installed accessories at the same time is limited by the size of the unit’s control box. Goodman Manufacturing Company, L.P., reserves the right to discontinue, or change at any time, specifications or designs without notice or without incurring obligations. © 2015 Goodman Manufacturing Company, L.P. • Houston, Texas • Printed in the USA. www.goodmanmfg.com SS-DSXC16...
