SERVICE MANUAL
4 S ERVICE MANUAL
YD119
2007
XV-N650BEU,XV-N650BEY,XV-N650BEK,
XV-N650BER,XV-N652SEU,XV-N652SEY,
XV-N652SEZ,XV-N652SEK,XV-N652SER
COPYRIGHT © 2007 Victor Company of Japan, Limited
1
PRECAUTION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
2
SPECIFIC SERVICE INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-6
3
DISASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-7
4
ADJUSTMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-13
5
TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-14
DVD PLAYER
XV-N650BEU,XV-N650BEY,XV-N650BEK,XV-N650BER,
XV-N652SEU,XV-N652SEY,XV-N652SEZ,XV-N652SEK,XV-N652SER [D7P3]

TABLE OF CONTENTS

COPYRIGHT © 2007 Victor Company of Japan, Limited
EU -------- Western Europe
EY -------- Northern Europe
EZ --------- Eastern Europe
ER ---- Russian Federation
Only ver. ER
No.YD119
2007/4
