2 Button Remote Security System
with Anti Hi-Jack Feature
IMPORTANT ! In order to provide you and your vehicle with the highest level of
security, this system is equipped with a dual mode Anti Hi-Jack feature. The
selectable Anti Hi-Jack mode and the secured Anti Hi-Jack mode are described
in this manual. Having a thorough working knowledge of the operation of both
these safety features of your security system will afford you the highest level of
personal protection. We urge you to read this manual completely to take advan-
tage of all the features included in the APS-25HJ security system.
FEATURES :
Two 2 Button Three Channel Transmitters
Two Channel Code Learning Scan Deterrent Receiver
Negative Pulsed Door Lock Outputs
Selectable Door Lock/Unlock Output Duration
Selectable Ignition Controlled Lock On/Off
Selectable Ignition Controlled Unlock On/Off
Selectable Passive/Active Arming
Selectable Passive/Active Door Locks
Selectable Voltage Sensing On/Off
Selectable Anti Hi-Jack Mode On/Off
Selectable Hi-Jack Initiation Sequence 15/45 Seconds
Secured Mode Anti-Hi-Jack Feature
User Selectable Chirp Delete
7 Function LED With Memory
Intrusion Chirps With Memory
On Board Light Flash Relay
(+) & (-) Door Trigger Inputs
Additional Negative Trigger Input
Six Tone Multi-Tone Siren
Starter Inhibit Output W/Relay
Additional Ignition/Fuel Cut Output (Relay Required)
Single Stage Shock Sensor
OPTIONS :
Remote Trunk Release ( must have electronic trunk release )
Remote Keyless Entry ( must have power door locks )
Multiple Vehicle Capable
Remote Starter
Remote Power Window Roll Up
Remote Garage Door Interface
Model APS-25HJ
Owner's Manual
Page 1
Advertisement
Table of Contents
Related Manuals for Audiovox Prestige 128 -5264A
Summary of Contents for Audiovox Prestige 128 -5264A
- Page 1 2 Button Remote Security System with Anti Hi-Jack Feature IMPORTANT ! In order to provide you and your vehicle with the highest level of security, this system is equipped with a dual mode Anti Hi-Jack feature. The selectable Anti Hi-Jack mode and the secured Anti Hi-Jack mode are described in this manual.
-
Page 2: Arming The System - Active
ARMING THE SYSTEM - ACTIVE 1. Turn off the engine, exit the vehicle, and close all doors, hood lid, and trunk lid. 2. Press and release the ARM / DISARM button on the keychain transmitter. Red dash mounted L.E.D. begins to flash slowly. Parking Lights flash one time. -
Page 3: Disarming The System
This serves as a visual deterrent to the potential thief. The L.E.D. is a very low current bulb, and will not cause the vehicle’s battery to drain, even when left unattended for extended periods. Whenever the system is triggered, the vehicle’s parking lights will flash for the full 30 second alarm cycle, attracting visual attention to the vehicle. -
Page 4: Manually Overriding Your System
was made to a hood or trunk pin switch that was added to the system, or to a light activated entry point if the alarm was installed using the voltage sensing feature. If the L.E.D. is flashing three times...pause...three times...pause...etc., then an intrusion attempt was made through one of the vehicle’s doors. -
Page 5: Remote Panic Operation
1. Start with the valet switch in the off position, then turn the ignition key on then off. 2. Within 10 seconds, move the valet switch to on then off three times. 3. If the chirps were on before you started, then you will hear 2 chirps indicating they have been turned off. - Page 6 This initial flashing of the LED allows the operator, if Hi-Jack mode is inadvertently triggered, the time to disable the Hi-Jack mode before the siren sounds.This is ac- complished by pressing the hidden Anti Hi-Jack override button. Stage 2 For the next 30 seconds in 10 second intervals, the siren will emit a single chirp. The intent of the chirp signals is a warning that the next stage will begin the shut down sequence, first causing the engine to hesitate and then in stage 4 to stall.
- Page 7 1. Turn off the ignition switch. 2. Press the hidden Hi-Jack enable/override switch one time. The LED turns on for 5 seconds indicating that the secured mode has successfully be entered. 3. Exit the vehicle, close all doors, and arm your security system using the keychain trans- mitter.
- Page 8 Passive Arming Passive Locking Hardwire doors, hood, and trunk Valet Switch Override Anti Hi-Jack Feature On Hi-Jack Start Delay 15 Seconds Hi-Jack Start Delay 45 Seconds Audiovox Corp. 150 Marcus Blvd. APS-25HJ PASSIVE ARMING ARMED DISARMED VALET MODE INTRUSION ZONE 3...
- Page 9 Sistema de seguridad con control remoto de 2 botones y función antirrobo en presencia del conductor IMPORTANTE: A fin de proporcionarle a usted y su vehículo el mayor grado de seguri- dad, este sistema está equipado con una función antirrobo de doble modalidad: la moda- lidad antirrobo en presencia del conductor seleccionable y la modalidad antirrobo fija, las que se describen detalladamente en este manual.
- Page 10 ACTIVACIÓN DEL SISTEMA - MODO ACTIVO 1. Apague el motor, salga del vehículo y cierre todas las puertas y las tapas del capó y el baúl. 2. Oprima y suelte el botón de ARM / DISARM del transmisor de llavero una sola vez. El L.E.D.
- Page 11 visual para un posible ladrón. El indicador L.E.D. es una bombilla de muy poca corriente que no agotará la batería del vehículo, aun cuando se la deje encendida durante períodos prolongados. Cuando se dispara el sistema, las luces de estacionamiento del vehículo destellarán durante un ciclo completo de alarma de 30 segundos, lo que atraerá...
- Page 12 hubo algún intento de intrusión a través de alguna de las puertas del vehículo. Estos indicadores de advertencia de intrusión están almacenados en la memoria del siste- ma y solamente se borrarán cuando se encienda la llave de contacto. INTERRUPTOR VALET El interruptor valet le permite anular transitoriamente todas las funciones de la alarma, eliminando la necesidad de entregar el transmisor a los encargados de estacionar coches o los mecánicos de un garaje.
- Page 13 apague la llave de contacto. 2. A los 10 segundos, mueva el interruptor valet a las posiciones de encendido y apagado tres veces. 3. Si los chirridos estaban conectados antes de empezar, entonces oirá un chirrido que le indica que los está desconectando. Si los chirridos estaban desconectados antes de empezar, entonces oirá...
- Page 14 el ajuste de la hora de inicio que está indicado en la última hoja de este manual). El indica- dor L.E.D. comienza a destellar por 15 segundos. Este destello inicial del indicador L.E.C. le da tiempo al conductor, si se dispara por accidente la modalidad antirrobo, para desactivar la modalidad antirrobo antes de que suene la sirena.
- Page 15 MODALIDAD FIJA DE FUNCIONAMIENTO Esta modalidad fija de funcionamiento está disponible, independientemente de que la fun- ción antirrobo esté activada o no. La modalidad fija se usa en aquellos lugares en que el conductor del vehículo sea atacado al volver a su automóvil. Las playas de estacionamien- to de los centros comerciales, las calles oscuras, las entradas a garajes que estén ocultas son lugares típicos en que un ladrón puede ocultarse para esperar que el conductor vuelva a su vehículo.
- Page 16 Trabado pasivo Cableado de puertas, capó y baúl Captura manual del interruptor valet Función antirrobo encendida (“on”) Demora de arranque antirrobo 15 segundos Demora de arranque antirrobo 45 segundos Audiovox Corp. 150 Marcus Blvd. ACTIVACION PASIVA ACTIVADO DESACTIVADO MODO VALET...
