Technics EPC-U1200 Operating Instructions

Before connecting, operating or adjusting this product, please
read the instructions completely.
Please keep this manual for future reference.
E P
For Europe
Matsushita Electric
Industrial Co.,Ltd.
Web Site : http://
www.panasonic.co.jp/global/
2000 Matsushita Electric Industrial Co., Ltd.
Printed in Japan
Dear customer
Thank you for purchasing this product.
For optimum performance and safety, please read these instruc-
tions carefully.
(Only for U.S.A.)
User memo:
DATE OF PURCHASE
DEALER NAME
DEALER ADDRESS
TELEPHONE NUMBER
Supplied accessories
Please check and identify the supplied accessories.
(Only for U.S.A.)
Use numbers indicated in parentheses when ask-
ing for replacements parts.
To order accessories contact 1-800-332-5368
or web site (http://www.pasc.panasonic.com).
Head shell weight (RMJ0011) . . . . . . . . . . . . . . . . . . . . . . 1
Mounting screws (RHD26036) . . . . . . . . . . . . . . . . . . . . . . 2
Stylus cover (RMJ0010) . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Features
Designed for scratch play.
• Moving magnet (MM) type for high output and high quality
sound.
• Easily attached to Technics headshells.
Stereo Cartridge
Operating Instructions
EPC-U1200
Model No.
For U.S.A.
Panasonic Consumer Electronics
Company, Division of Panasonic
Corporation of North America
One Panasonic Way Secaucus,
New Jersey 07094
http://www.panasonic.com
Panasonic Puerto Rico, Inc.
Ave. 65 de Infantería, Km. 9.5
San Gabriel Industrial Park, Carolina,
Puerto Rico 00985
RQT5726-1E
M1200TK1055
A
Please Note
En
Treat the stylus with care.
The stylus is a delicate instrument for picking up sounds from
the grooves on records. The only surface it should touch is a
record.
• Do not move the tip of the stylus.
• Do not allow it to catch on anything.
• Do not allow the stylus to touch hard surfaces.
• Attach the stylus cover when you have finished play.
Remove dust from the record and stylus regularly.
Take the headshell off the tone arm and, using a soft-tipped
brush, carefully remove the dust with a brushing movement
toward the point of the stylus.
Wipe the headshell terminal occasionally.
Dust or fluff on the terminal can cause the connection to be
incomplete. Wipe it with a soft cloth and put the headshell back
on the tone arm.
SP records (78 r/min) cannot be played.
Use a cartridge designed for SP records.
Product service (Only for U.S.A.)
1. Damage requiring service—The unit should be serviced by
qualified service personnel if:
(a) The AC power supply cord or the plug has been damaged; or
(b) Objects or liquids have gotten into the unit; or
(c) The unit has been exposed to rain; or
(d) The unit does not operate normally or exhibits a marked change
in performance; or
(e) The unit has been dropped or the cabinet damaged.
2. Servicing—Do not attempt to service the unit beyond that described
in these operating instructions. Refer all other servicing to autho-
rized servicing personnel.
3. Replacement parts—When parts need replacing ensure the
servicer uses parts specified by the manufacturer or parts that have
the same characteristics as the original parts. Unauthorized sub-
stitutes may result in fire, electric shock, or other hazards.
4. Safety check—After repairs or service, ask the servicer to perform
safety checks to confirm that the unit is in proper working condition.
Product information
For product information or assistance with product operation:
In the U.S.A., contact 1-800-211-7262, or web site (http://
www.panasonic.com/consumersupport).
Specifications
Type
Stylus point
Output voltage
Frequency response
Channel separation
Channel balance
Compliance
Optimum stylus pressure
Recommended load resistance
Mass
Replacement stylus part no.
Specifications are subject to change without notice.
Mass and dimensions are approximate.
B
Headshell
terminal
Moving magnet stereo cartridge
0.6 mil (Conical diamond)
6 mV (1 kHz, 3.54 cm/s)
10 Hz – 20 kHz
20 dB (1 kHz)
1.5 dB (1 kHz)
4 10 -6 cm/dyne (100 Hz)
X
47 – 100 KΩ
5.3 g (0.19 oz.)
EPS-1200CS
2 g
