Audiovox ROSIBC Installation & Owner's Manual

Interior color camera

Download this manual

Page 2

Congratulations on the purchase of the ROSIBC. This camera is

designed to be mounted inside the vehicle to either view an infant

strapped into a car seat that is buckled in facing the back seat or view the

passengers. The camera can reverse the image by pushing the button on

camera. There are 3 different mounting configurations to choose from.

Page 3

Installation/Owners Manual

Interior Color Camera

FEATURES:

High Resolution, 1/3,CCD Color Camera

Adjustable Angle

Optical Control Infrared LED

Infrared LED for Night Vision

Mirror image selectable

If you want to adjust the camera to viewing area, please adjust the camera

up or down, left or right following the moving direction sign marked on

the camera shell.

Do not rotate the camera!

Model ROSIBC

Page 1 Page 2 Congratulations on the purchase of the ROSIBC. This camera is designed to be mounted inside the vehicle to either view an infant strapped into a car seat that is buckled in facing the back seat or view the passengers.
Page 2 Installation 1: View of the Suction cup page 4 Installation 1: Suction cup page 5 1. Locate and clean suitable mounting location on glass near baby seat side of vehicle. 2. Attach the camera suction cup to the selected mounting location. 3.
Page 3 Page 7 Installation 2: Headliner pins 1. Remove the suction cup by rotating counter clockwise. 2. Locate suitable mounting location on headliner of vehicle. 3. Insert the mounting pin along opposite sides of camera into the headliner. Push the mounting pins into the headlines until pin hooks are at mounting tab.
Page 4: Specifications
Page 10 Specifications: 1. Signal System: NTSC 2. Voltage: DC 12V 3. Current: 70mA / 140mA (LED on) 4. Image Sensor: 1/3 Super CCD Color Sensor NTSC: 510X492 picture elements 5. Horizontal Definition: 420 Lines 6. View Angle: 90 degrees 7.
