Philips PET800 Service Manual
Hide thumbs Also See for PET800:

Advertisement

Quick Links

DVD Portable Player
Service Manual

TABLE OF CONTENTS

Technical Specification................................................1
Safety Instructions.......................................................2
Instruction for Use.......................................................3
Mechanical Instructions............................................... 4
Troubleshooting & Service tips.....................................5
Overall block diagram.................................................. 6
Overall wiring diagram................................................ 7
Electrical diagram....................................................... 8
Component layout...................................................... 9
Service part list..........................................................10
Revision list...............................................................11
©Copyright 2005 Philips Consumer Electronics B.V. Eindhoven, The Netherlands
All rights reserved. No part of this publication may by reproduced, stored in a
retrieval system or transmitted, in any form or by any means, electronics,
mechanical, photocopying, or otherwise without the prior permission of Philips
Version 1.4
PET800
/00/05/55/93
Chapter
3141 785 30574

Advertisement

loading

Summary of Contents for Philips PET800

  • Page 1: Table Of Contents

    All rights reserved. No part of this publication may by reproduced, stored in a retrieval system or transmitted, in any form or by any means, electronics, mechanical, photocopying, or otherwise without the prior permission of Philips 3141 785 30574 Version 1.4...
  • Page 2: Technical Specification

    E.g. 050303 Current consumption Procedure on how to upgrade the software of the DVD Portable DC-IN SUPPLY (9.0V) Download the latest software from the Philips Battery Charging Current 1.2A typ. support site. BATT. SUPPLY (7.2V) Unzipped the files and then burn it onto a CD ROM Power Off then playback the CD ROM on the DVD Portable.
  • Page 3 2.0 SAFTETY INSTRUCTIONS WAARSCHUWING WARNING Alle IC’s en vele andere halfgeleiders zijn All ICs and many other semi-conductors are gevoelig voor electrostatische ontladingen susceptible to electrostatic discharges (ESD). (ESD). Careless handling during repair can reduce life Onzorgvuldig behandelen tijdens reparatie kan drastically.
  • Page 4 2.1 ESD PROTECTION When the power supply is being turned on, you may not remove this laser cautions label. If it removes, radiation of laser may be received. PREPARATION OF SERVICING Pickup Head consists of a laser diode that is very susceptible to external static electrocity. Although it operates properly after replacement, if it was subject to electrostatic discharge during replacement, its life might be shortened.
  • Page 5 SAFTY NOTICE SAFTY PRECAUTIONS LEAKAGE CURRENT CHECK Plug the AC line cord directly into a 120V AC outlet (do Measure the AC voltage across the 1500 resistor. not use an isolation transformer for this check). Use an The test must be conducted with the AC switch on and AC voltmeter, having 5000 per volt or more sensitivity.
  • Page 6: Instruction For Use

    3.0 INSTRUCTIONS FOR USE Front of player IR sensor POWER / CHG Power and charging indicator Grip Opens display and disc tray Left of player POWER ON / OFF Switches the player on / off POWER Right of player • • DC IN 9V PHONE 1 PHONE 2 AUDIO/VIDEO TV OUT...
  • Page 7 Disc tray MONITOR Selects display mode + / - Volume control SETUP Enters SETUP menu For previous ( ) or next ( chapters, tracks or titles OPEN PAUSE Opens disc tray Pause playback STOP Press twice to stop playback PLAY Starts / resumes playback TITLE Display TITLE page...
  • Page 8: Remote Control

    Remote control SETUP Enters SETUP menu On Screen Display on / off SUBTITLE LANGUAGE Subtitle language Language selector selector AUDIO ANGLE Audio language Selects DVD selector camera angle SCAN PLAY MODE Playback of the first 10 Selects play order seconds of each chapter options / index on the disc ZOOM...
  • Page 9 4.0 Mechnical instructions 1. Back View as Fig.1 5. Remove top cover as Fig.5 Remove screws to disassemble the base remove screws screws remove screws remove screws Fig.1 Fig.5 2. Soldered short pattern for laser diode as Fig.2 6. Disassemble the HV board as Fig.6 soldered Fig.2 Disassemble the DVD drive and main board as Fig.3,4...
  • Page 10: Troubleshooting & Service Tips

    1. Power on player and open DVD Door. 2. Press <Set Up> at Remote Control. In <Set Up Menu> select <Preferences> and press <OK>. 3. For PET800 - Press successively 2 1 2 2 2 5. . . 4. Display will show <Region Code 2> for Europe: 5.
  • Page 11 5.0 TROUBLESHOOTING & SERVICE TIPS 5.2 Identification Method on Sharp and Panasonic TFT LCD (For PET800) • Sharp panel - data cable jack is under the TFT and left side, the jack is 32pin • Panasonic panel - data cable jack is under the TFT and middle side, the jack is 30pin...
  • Page 12 5.0 TROUBLESHOOTING & SERVICE TIPS SYMPTOM: NO POWER, NO GREEN LED start Check if the power cable replace cable/ No defect, return set OK? adapter set to customer AC adapter Check if the replace connector power and play and switch unit button OK? replace MAIN go to other...
  • Page 13 5.0 TROUBLESHOOTING & SERVICE TIPS SYMPTOM: THE INITIAL SCREEN IS NOT DISPLAYED ON THE LCD Refer to the symptom NO start POWER, NO GREEN LED Replace broken Check if the Repair connector harness LED on the front lights up? Remove the LCD Open the top and Is the cover and plate of...
  • Page 14 5.0 TROUBLESHOOTING & SERVICE TIPS SYMPTOM: THE DVD DRIVE DOES NOT WORK Press the DISC cover switch at the center of the DVD player and turn on the power. Then check whether or not the optical pick- up lens of the DVD drive lights. CAUTION: start Visible laser radiation when open and interlock defeated.
  • Page 15 5.0 TROUBLESHOOTING & SERVICE TIPS SYMPTOM: THE DVD DRIVE DOES NOT OPERATE WITH BATTERY start Install a good battery does the LED lights up orange while the AC adapter is connected and does the DVD drive operate OK? NOTE: - For this check, use a battery which is not fully Replace battery charged (because the LED does not light when the battery is fully charged.)
  • Page 16 5.0 TROUBLESHOOTING & SERVICE TIPS SYMPTOM: NO SOUND COMES FROM THE HEADPHONES start Insert a good Customer  headphones and check if headphones the problem persist? defective Replace main board...
  • Page 17: Overall Block Diagram

    6.0 OVERALL BLOCK DIAGRAM DC 9V OSCILLATOR 8M FlashROM 64M SDRAM OZ960 TC4W53 74HCU04 27MHz MX29LV008TTC-70 NT56V6620C0T-75S 27MHz HIGH VOLTAGE ASS'Y UPD5100 TFT MONITOR RF AMP & SERVO & DVD PROCESSOR DV23 MPEG-2 DECODER & VIDEO ENCODER TFT POWER PU mechanism D3800 VIDEO OUT +3.3V +5V -14.5V +16V...
  • Page 18 7.0 OVERALL WIRING DAIGRAM SWITCH PCB CLK4 BATT+ LD/VCC XS001 SPEAKER BATTERY CD/DVD SW VCOMS ISEN VRCD VSEN VRDVD VCOMS LD/CD SPIO LD/DVD MODE2 LCDR MODE1 LCDG SPOI LCDB FCS- SPIO MODE1 TRK+ 3.3V TRK- 3.3V FCS+ 3.3V LIMIT 3.3V 3.3V TFT +5V TFT +5V...
  • Page 19 8.0 ELECRTICAL DIAGRAM MAIN BOARD CIRCUIT DIAGRAM (POWER CIRCUIT DIAGRAM) cation: REPLACE PUSE WITH SAME TYPE AND RATING L003 CDRH6D38-330MC #HV9V Littelfuse T3A/125V C001 C140 C141 C142 16V/47U 100n 100n 100n VD09 UDZS7E-174.7B N002 BA033 N003A L002 VD010 IR7304 CDRH6D38-330MC DV33 ISS355 F001...
  • Page 20 MAIN BOARD CIRCUIT DIAGRAM (TFT CIRCUIT DIAGRAM) UPD5100VDD UPD5100VDD R238 -14.5V CB21 CB17 CB16 C198 CB20 R199 C170 +16.5V 100n 100n 100n 100n 100n C197 C203 10U/16V C169 VD33 C168 C194 100n ISS355 100n 14.31318 ECJ3YF1C106Z CB15 C171 C193 C192 VD40 TF+5V 1R33...
  • Page 21 100P C117 R93 750K VD17 C228 STZ6.2N R120 C236 C234 +P5V C234 C234 C176 C519 C235 R115 VD19 WX10HB-2-20K 100U/6.3V 300P STZ6.2N R116 R64 560 AGND YUV0/CIN RR104 DVDA XS006 DVDA C138 DVDB DVDB VREF DV DC DACVDDB speaker DVDC DACVDDC DV DD KEYIN0...
  • Page 22 HIGH VOLTAGE BOARD CIRCUIT DIAGRAM C1 1 R1 1 1210 C1 0 UI8.5 SO T-23 R1 0 SO T-23...
  • Page 23: Component Layout

    9.0 COMPONENT LAYOUT PET800 HV POWER BOARD DIAGRAM...
  • Page 24 PET800 MAIN BOARD DIAGRAM...
  • Page 25: Service Part List

    10.0 SERVICE PARTS LIST Service 12NC Model # Accessory description Location Code Photos 994000001907PET800 Battery pack BATTERY 994000001898PET800/00 AC/DC adapter /00 ACADAPTOR 994000003524PET800/05 AC/DC adapter /05 ACADAPTOR 994000002896PET800/55 AC/DC adapter /55 ACADAPTOR 994000000732PET800/93 AC/DC adapter /93 ACADAPTOR 994000000724PET800 Remote control 994000001902PET800 Car cigarette adapter CARADAPTOR...
  • Page 26 10.0 SERVICE PARTS LIST 994000002899PET800 PET800 MAIN PCBA for Panasonic module 994000004213PET800 PET800 MAIN PCBA for Sharp module 994000002904PET800 IF PCB ASS'Y for Sharp module (Not applicable for Panasonic module) 994000002901PET800 PET800 HV PCBA for Panasonic module 994000004214PET800 PET800 HV PCBA for...
  • Page 27 10.0 SERVICE PARTS LIST 994000002335PET800 DISPLAY FRAME 994000002906PET800 MIDDLE CABINET 994000002907PET800 BOTTOM CABINET/00/05/55 994000002337PET800 BASE COVER 994000002989PET800 CONTROL KEY PAD 994000002911PET800 DOOR 994000002338PET800 DOOR SPRING 994000002341PET800 OPEN BUTTON SPRING430 996500039079PET800 ON/OFF SWITCH OFSWITCH 996500041639PET800 SWITCH SW1...
  • Page 28: Revision List

    11.0 REVISION LIST Version 1.0 (3141 785 30570) Initial release PET800/00/05/55/93 Version 1.1 (3141 785 30571) Chapter 10: Service parts list adapted with new parts and revised 12NC as listed below • Added photo on speaker (994000002908) • Added the new parts control key pad (994000002989) Version 1.2 (3141 785 30575)

This manual is also suitable for:

Pet800/00Pet800/05Pet800/55Pet800/93
