Plena Power Amplifier | Installation and User Instructions | Description
2.4 Controls, connectors and
indicators
2.4.1

Front panel

See figure 2.2 for an overview of the controls and
indicators.
1 Power button.
2 Output level meter (-18 db, 0 db).
3 Air inlet holes.
Note
Do not obstruct the airflow into the unit.
4 Headphone socket.
1
figure 2.2: Front panel
Bosch Security Systems | 2008-02 | PLE-1P120-US, PLE-1P240-US en
en | 11
2
B
3 4
