Craftsman 973.220490 Operator's Manual

Professional cordless hammer drill variable speed / reversible
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Operator's Manual
13 mm (1/2 in.), 24 VOLT
PROFESSIONAL CORDLESS HAMMER DRILL
Variable Speed / Reversible
Stock No.
22049
9
Model No.
973.220490
Save this manual for
future reference
WARNING:
To reduce the risk of
injury, the user must read and
understand the operator's manual
before using this product.
Customer Help Line: 1-877-369-8665
Sold by: Sears, Canada Inc., Toronto M5B 2B8
Visit the Craftsman web page: www.sears.com/craftsman
983000-263
4-03
®
• Safety
• Features
• Assembly
• Operation
• Maintenance
• Parts List

Advertisement

Table of Contents
loading

Related Manuals for Craftsman 973.220490

Summary of Contents for Craftsman 973.220490

  • Page 1 • Safety • Features Customer Help Line: 1-877-369-8665 • Assembly Sold by: Sears, Canada Inc., Toronto M5B 2B8 • Operation Visit the Craftsman web page: www.sears.com/craftsman • Maintenance • Parts List 983000-263 4-03...

  • Page 2: Table Of Contents

    Exploded View And Repair Parts List ..........................17 Parts Ordering / Service ..............................18 WARRANTY FULL TWO YEAR WARRANTY ON CRAFTSMAN TOOL If this Tool fails to operate within two years from the date of purchase, return it to the nearest Sears Canada Inc.

  • Page 3: General Safety Rules

    GENERAL SAFETY RULES Disconnect battery pack from tool or place the switch in Personal Safety the locked or off position before making any adjust- Stay alert, watch what you are doing and use ments, changing accessories, or storing the tool. Such common sense when operating a power tool.
  • Page 4 SPECIFIC SAFETY RULES AND/OR SYMBOLS Important Rules for Battery Tools Make sure cord is located so that it will not be stepped on, tripped over, or otherwise subjected to Battery tools do not have to be plugged into an damage or stress. Following this rule will reduce the electrical outlet;...
  • Page 5 SYMBOLS Important: Some of the following symbols may be used on your tool. Please study them and learn their meaning. Proper interpretation of these symbols will allow you to operate the tool better and safer. SYMBOL NAME DESIGNATION/EXPLANATION Volts Voltage Amperes Current Hertz...

  • Page 6: Features

    FEATURES PRODUCT SPECIFICATIONS: Chuck 13 mm (1/2 in.) Keyless Motor DC Motor 24 Volts Gear Train Two Speed Switch Variable Speed No Load Speed 0-400 RPM (Low) 0-1400 RPM (High) Hammer Speed 0-6,400 BPM (Low) 0-22,400 BPM (High) Clutch 24 Positions Maximum Torque 600 in.lb.
  • Page 7 FEATURES TWO SPEED LEVEL SCREWDRIVER BITS GEAR TRAIN (HI-LO) AUXILIARY HANDLE KEYLESS CHUCK YELLOW LIGHT "ON" AND STORAGE RED LIGHT FLASHING AREA INDICATES DEFECTIVE BATTERY PACK DIRECTION OF ROTATION SELECTOR (FORWARD/REVERSE) TORQUE SWITCH ADJUSTMENT TRIGGER RING BATTERY PACK RED LIGHT "ON" CHARGER INDICATES FAST CHARGING MODE...

  • Page 8: Assembly

    ASSEMBLY INSTALLING BITS AUXILIARY HANDLE See Figure 4. See Figure 3. Lock the switch trigger by placing the direction of An auxiliary handle is packed with your hammer drill for rotation selector in center position. See Figure 11. ease of operation and to help prevent loss of control. The handle can be rotated 360°.
  • Page 9 ASSEMBLY TO ATTACH BATTERY PACK TO DRILL TO REMOVE BATTERY PACK FROM DRILL See Figure 7. See Figure 6. Lock the switch trigger by placing the direction of Note: Battery pack is shipped in a low charge condition. rotation selector in center position. See Figure 11. Therefore, it must be charged prior to use.

  • Page 10: Operation

    OPERATION WARNING: If battery pack is deeply discharged, red light should If any parts are missing, do not operate become steady after voltage has increased, normally your hammer drill until the missing parts are replaced. within 60 minutes. Failure to do so could result in possible serious personal injury.
  • Page 11 OPERATION SWITCH LOCK SWITCH See Figure 11. See Figure 9. The switch trigger can be locked in the OFF position. This To turn your drill ON, depress the switch trigger. To turn it feature can be used to prevent the possibility of accidental OFF, release the switch trigger.
  • Page 12 OPERATION KEYLESS CHUCK ADJUSTING RING TO DECREASE See Figure 12. TORQUE A keyless chuck has been provided with your drill to allow for easy installation and removal of bits. As the name implies, you can hand tighten or release drill bits in the chuck jaws.
  • Page 13 OPERATION DRILLING APPLICATIONS See Figure 16. You may use the hammer drill for the purposes listed below: Hammer drilling in concrete, brick, or other masonry. END VIEW LEVEL Drilling in wood. Drilling in ceramics, plastics, fiberglass, and laminates. Drilling in both soft and hard metals. Driving screws with screwdriver bits, using driving accessories.
  • Page 14 OPERATION ADJUSTING DRILLING MODE ADJUSTING THE DEPTH GAUGE ROD See Figure 18. See Figure 17. Follow these steps to adjust the depth gauge rod. To adjust for type of drilling, slide adjustment button on top of motor housing hammer mode or drilling mode. For your Lock the trigger switch by placing the rotation selector convenience a hammer symbol and drill bit symbol have in the center position.
  • Page 15 OPERATION CHUCK REMOVAL Insert hex key wrench in chuck and tighten chuck jaws securely. Tap sharply with a mallet in a counter- See Figures 19, 20, and 21. clockwise direction. This will loosen chuck on the The chuck must be removed in order to use some spindle.

  • Page 16: Maintenance

    When servicing use only identical temperature, the quicker they lose their charge. If you Craftsman replacement parts. Use of any other parts store your tool for long periods of time without using it, may create a hazard or cause product damage.

  • Page 17: Exploded View And Repair Parts List

    CRAFTSMAN 13 mm (1/2 in.), 24 VOLTS PROFESSIONAL CORDLESS DRILL-DRIVER MODEL NO. 973.220490 The model number will be found on a plate attached to the motor housing. Always mention the model number in all correspondence regarding your CRAFTSMAN PROFESSIONAL CORDLESS DRILL-DRIVER or when ordering repair parts.

  • Page 18: Parts Ordering / Service

    Operator’s Manual STOCK NO. 22049 MODEL NO. 973.220490 Sears service is available at or through your Sears Retail Store or Catalogue Sales Office. How to order repair parts When ordering repair parts always give: SERVICE AND REPAIR PARTS 1. The Part Number CALL 1-800-665-4455 * 2.
